DODGE RAM 2001 Service Repair Manual

8W-35 ALL WHEEL ANTILOCK BRAKES
Component Page
Brake Lamp Switch.................. 8W-35-4
Brake Pressure Switch................ 8W-35-4
Controller Antilock Brake.......... 8W-35-2, 3, 4
Engine Control Module................ 8W-35-4
Fuse 3 (JB)......................... 8W-35-2
Fuse 11 (PDC)....................... 8W-35-2
G100.............................. 8W-35-4
G101.............................. 8W-35-3
G107.............................. 8W-35-3
G200.............................. 8W-35-4
Instrument Cluster................... 8W-35-3Component Page
Joint Connector No. 1................. 8W-35-4
Joint Connector No. 3................. 8W-35-3
Joint Connector No. 4................. 8W-35-4
Joint Connector No. 7................. 8W-35-3
Junction Block...................... 8W-35-2
Left Front Wheel Speed Sensor......... 8W-35-2
Power Distribution Center............. 8W-35-2
Powertrain Control Module............. 8W-35-4
Rear Wheel Speed Sensor.............. 8W-35-2
Right Front Wheel Speed Sensor........ 8W-35-2
BR/BE8W-35 ALL WHEEL ANTILOCK BRAKES 8W - 35 - 1

8W-39 VEHICLE THEFT SECURITY SYSTEM
Component Page
Central Timer Module C1.............. 8W-39-4
Central Timer Module C2.......... 8W-39-2, 3, 4
Clockspring......................... 8W-39-3
Daytime Running Lamp Module......... 8W-39-2
Driver Cylinder Lock Switch............ 8W-39-4
Driver Door Ajar Switch............... 8W-39-4
Fuse G (PDC)....................... 8W-39-2
Fuse H (PDC)....................... 8W-39-3
G100.............................. 8W-39-3
G102.............................. 8W-39-2
G300.............................. 8W-39-4
Headlamp Beam Select Switch.......... 8W-39-2
High Note Horn..................... 8W-39-3
Horn Relay......................... 8W-39-3Component Page
Horn Switch........................ 8W-39-3
Joint Connector No. 1............... 8W-39-2, 3
Joint Connector No. 3................. 8W-39-3
Joint Connector No. 6................. 8W-39-3
Joint Connector No. 8................. 8W-39-4
Left Outboard Headlamp.............. 8W-39-2
Low Note Horn...................... 8W-39-3
Overhead Console.................... 8W-39-4
Passenger Cylinder Lock Switch......... 8W-39-4
Passenger Door Ajar Switch............ 8W-39-4
Power Distribution Center........... 8W-39-2, 3
Right Outboard Headlamp............. 8W-39-2
Security Relay....................... 8W-39-2
BR/BE8W-39 VEHICLE THEFT SECURITY SYSTEM 8W - 39 - 1
