DODGE RAM 2002 Service Repair Manual

8W-31 TRANSMISSION CONTROL SYSTEM
Component Page
Controller Antilock Brake.............. 8W-31-5
Fuse I (PDC)........................ 8W-31-2
G100.............................. 8W-31-5
G107.............................. 8W-31-5
G200.............................. 8W-31-4
Generator.......................... 8W-31-2
Instrument Cluster................... 8W-31-5Component Page
Leak Detection Pump................. 8W-31-2
Output Speed Sensor................. 8W-31-4
Overdrive Switch.................... 8W-31-4
Power Distribution Center............. 8W-31-2
Powertrain Control Module......... 8W-31-2, 3, 4
Transmission Control Relay.......... 8W-31-2, 3
Transmission Solenoid Assembly....... 8W-31-2, 3
BR/BE8W-31 TRANSMISSION CONTROL SYSTEM 8W - 31 - 1

8W-33 VEHICLE SPEED CONTROL
Component Page
Brake Lamp Switch...................8w-33-2
Clockspring.........................8w-33-3
Engine Control Module................8w-33-4
G100..............................8w-33-2
Joint Connector No. 1...............8w-33-3, 4Component Page
Left Speed Control Switch..............8w-33-3
Powertrain Control Module...........8w-33-2, 4
Right Speed Control Switch.............8w-33-3
Speed Control Servo..................8w-33-2
BR/BE8W-33 VEHICLE SPEED CONTROL 8W - 33 - 1
