DODGE SPRINTER 2007 2.G Owners Manual
Manufacturer: DODGE, Model Year: 2007, Model line: SPRINTER, Model: DODGE SPRINTER 2007 2.GPages: 393, PDF Size: 7.61 MB
Page 1 of 393
2007
Page 2 of 393
Thank you for choosing the new
Sprinter.
Before your first journey, please familiarize
yourself with your vehicle and how it oper-
ates, as well as its driving, control and con-
venience functions.
Before you drive off, read these Operating
Instructions. This will help you get the
most out of your vehicle and avoid endan-
gering yourself and others.
Since the scope of delivery is based on the
sales order, your vehicle’s equipment may
differ from some descriptions and illustra-
tions. Items of optional equipment are also
described in these Operating Instructions,
should you require a description of the way
they work.
Country-specific vehicle equipment, lim-
ited availability of items of special equip-
ment or different product labeling is
possible in some countries.DaimlerChrysler Vans LLC reserves the
right to introduce changes in design,
equipment and technical features. You
cannot, therefore, base any claims on the
data, illustrations or descriptions con-
tained in these Operating Instructions.
Your nearest authorized Sprinter Dealer
will be happy to assist you further if you
have any other questions.
The Operating Instructions, brief instruc-
tions, Sprinter Service Booklet, Owner’s
Warranty Information Book and equip-
ment-related supplementary operating in-
structions are considered part of the
vehicle. For this reason, you should always
keep them in the vehicle and pass them on
to the new owner if you sell the vehicle.
The technical documentation team at
DaimlerChrysler Vans LLC wishes you safe
and pleasant driving.Symbols
Trademarks
ESP
® is a registered trademark of
DaimlerChrysler. * Optional equipment
G
Warning
H
Environmental note
!
Caution
i
Tip
\1Action required
\1Sequence of actions (several
\1)
\2 \2Continuation symbol
\2 \2Continuation symbol for warnings
\2 page
Page reference
Display
Display in the multifunction display
Page 3 of 393
Contents
Introduction. . . . . . . . . . . . . . . 3
1
At a glance . . . . . . . . . . . . . . . 112
Safety . . . . . . . . . . . . . . . . . . . 231
Controls in detail
.
.
. . . . . .
.
514
Operation . . . . . . . . . . . . . . . 1735
Practical hints . . . . . . . . . . . 2496
*Technical data . . . . . . . . . . 351
Index . . . . . . . . . . . . . . . . . . . . . . . . . 377
Page 4 of 393
3 Introduction
\3 Environmental protection
In this manual, whenever you see instruc-
tions to discard materials, you should first
attempt to reclaim and recycle them. To
preserve our environment, follow appropri-
ate environmental rules and regulations
when disposing of materials.
Environmental note
H
DaimlerChrysler’s declared policy is one of
comprehensive environmental protection.
The objectives are for the natural resources
which form the basis of our existence on this
planet to be used sparingly and in a manner
which takes the requirements of both nature
and humanity into account.
You too can contribute to environmental
protection by operating your vehicle in an
environmentally-responsible manner.
Fuel consumption and engine, transmission,
brake and tire wear depend on the two fol-
lowing factors:
\4Operating conditions of your vehicle
\4Your personal driving style
You can influence both factors.
Observe the following notes:
Operating conditions
\4Avoid driving short distances as this in-
creases fuel consumption.
\4Make sure that the tire pressures are al-
ways correct.
\4Do not carry any unnecessary weight
in / on the vehicle.
\4Keep an eye on the vehicle’s fuel con-
sumption.
\4Remove roof racks once you no longer
need them.
\4A regularly serviced vehicle will contrib-
ute to environmental protection. You
should therefore adhere to the specified
service intervals.
\4Always have maintenance work carried
out at an authorized Sprinter Dealer.
Personal driving style
\4Do not depress the accelerator pedal
when starting the engine.
\4Do not warm up the engine when the ve-
hicle is stationary.
\4Adopt an anticipatory style of driving
and keep a sufficient distance from oth-
er vehicles.
\4Avoid frequent, sudden acceleration.
\4Switch off the engine in stationary traf-
fic.
Environmental concerns and recom-
mendations
Page 5 of 393
4 IntroductionOperating safety
Operating safetyWarning
G
Engine exhaust, some of its constituents,
and certain vehicle components contain or
emit chemicals known to the State of Cali-
fornia to cause cancer and birth defects or
other reproductive harm.
In addition, certain fluids contained in vehi-
cles, and certain products of component
wear, contain chemicals known to the State
of California to cause cancer and birth de-
fects or other reproductive harm.
Warning
G
Work carried out incorrectly on electronic
equipment and its software could cause the
equipment to stop working. The electronic
systems are networked with each other via
interfaces. Tampering with the electronic
systems may also cause malfunctions in
systems that have not been modified. These
malfunctions, however, can jeopardize the
operating safety of your vehicle and there-
fore put your own safety at considerable
risk.
Other work carried out incorrectly or modifi-
cations to the vehicle could also jeopardize
operating safety.
Some safety systems only function while the
engine is running. Therefore, you should not
switch off the engine while driving.
Warning
G
Always have maintenance work carried out
at an authorized Sprinter Dealer which has
the necessary specialist knowledge and
tools to carry out the work required. The
manufacturer recommends that you use an
authorized Sprinter Dealer for this purpose.
In particular, work relevant to safety or on
safety-related systems must be carried out
at an authorized Sprinter Dealer.
Page 6 of 393
5 Introduction
Operating safety
The manufacturer warrants to the original
and each subsequent owner of a
Mercedes-Benz heavy-duty on highway
diesel engine that:
(1) the engine was designed, built and
equipped so as to conform at the time
of sale with the applicable regulations
adopted by the Federal Environmental
Protection Agency, and
(2) the emission control system of such
engine is free from defects in materials
and workmanship which would cause it
not to conform with those regulations
for a period of use of five years or
100000 miles or 3000 hours of engine
operation, whichever occurs first.
The Owner’s Warranty Information Book
contains detailed information about the
warranties covering your Sprinter.The manufacturer may instruct its autho-
rized Sprinter Dealer to carry out technical
inspections on certain vehicles to improve
their quality or safety.
If you did not purchase your vehicle from
an authorized dealership and your vehicle
has not yet been inspected at an autho-
rized Sprinter Dealer, there is a possibility
that your vehicle has not been registered in
your name with the manufacturer. The
manufacturer will only be able to inform
you about vehicle inspections if the manu-
facturer is in possession of your registra-
tion data.
It is advisable to have your vehicle regis-
tered at an authorized Sprinter Dealer.
Inform the manufacturer as soon as possi-
ble if your address has changed or there
has been a change of vehicle owner.
Warning
G
A heavy impact to the underbody, tires or
wheels, for example when bottoming out on
rough terrain or driving over an obstacle at
high speed, could damage your vehicle. This
also applies to vehicles equipped with un-
derbody protection.
In this case, have your vehicle checked at an
authorized Sprinter Dealer which has the
necessary specialist knowledge and tools to
carry out the work required. The manufac-
turer recommends that you use an autho-
rized Sprinter Dealer for this purpose.
In particular, work relevant to safety or on
safety-related systems must be carried out
at an authorized Sprinter Dealer.
Service and warranty information
Registering your vehicle
Page 7 of 393
6 IntroductionOperating safetyDo not allow the electronically stored total
distance covered by your vehicle to be
modified as a result of tampering with the
electronics system.
This type of modification or failing to in-
form the buyer when selling the vehicle
could constitute an offense punishable by
law, depending on the country concerned.
Having the engine power output of your
vehicle increased by tampering with the
electronic engine management system will
invalidate the vehicle’s general operating
permit and insurance coverage, as well as
your warranty and warranty entitlement.
Modifications to the output of the engine
must be reported to the insurance provider
and require the vehicle to be recertified.
The tires, chassis, brake and cooling sys-
tems must be adapted to the increased en-
gine power output.Tampering with the electronic engine man-
agement system modifies emission values
and it will not be possible to guarantee the
operating safety of the engine in every
case. Increases in performance may lead
to malfunctions and consequential dam-
age to other assemblies.
If you sell the vehicle, failing to inform the
buyer of the modified engine power output
could constitute an offense punishable by
law, depending on the country concerned.
The manufacturer recommends the use of
genuine Sprinter parts and conversion
parts as well as accessories that have
been expressly approved for your vehicle
model (\2page 352).
These parts have been subjected to spe-
cial tests in order to determine their safety,
reliability and suitability.Body builder guideline
If you intend on making any alterations to
the vehicle, we strongly recommend that
you select one of the following options in
order to obtain all necessary information:
\4Contact the authorized Sprinter Dealer
nearest you to obtain a copy of the
Sprinter Body Builder Guideline.
\4Call DaimlerChrysler Vans LLC at tele-
phone (800) 992-1997 to request a
copy of the Sprinter Body Builder
Guideline (there may be a charge).
\4Write to the following address and or-
der the Sprinter Body Builder Guideline
(there may be a charge).
DaimlerChrysler Vans LLC
P.O. Box 21-8004
Auburn Hills, MI 48321-8004
United States of AmericaDigital speedometer and total
distance recorderModifying the engine power output
Vehicle alterations
Page 8 of 393
7 Introduction
Operating safety
Body builders and dealers who make any
modifications which may affect the final
certification of the engine, vehicle or
equipment assume the sole responsibility
for the vehicle, including labeling and doc-
umentation, affected by their modifica-
tions.
It is their responsibility to certify that the
altered vehicle conforms to all applicable
standards and regulations affected by the
vehicle alteration or continues to comply
with the motor vehicle safety standards
and emissions regulations.
They are responsible for ensuring that
modifications or equipment installation
does not affect the safety of the vehicle.The manufacturer is not responsible for
any final certification or claims regarding
product liability, or warranty claims, which
result from any component, assembly, or
system being altered, or which cause non-
compliance with any of the emission con-
trol standards or motor vehicle safety stan-
dards, or which would otherwise cause the
vehicle to be or become defective or un-
safe.
The manufacturer does not assume the re-
sponsibility as the final stage manufacturer
or the consequential product liability.Observe the following information when
using your vehicle:
\4The safety notes in this manual
\4The “Technical data” section in this
manual
\4Traffic rules and regulations
\4Motor vehicle laws and safety stan-
dardsWarning
G
Any modifications or alterations of the
Sprinter vehicle not in compliance with the
Sprinter Body Builder Guideline and the
Sprinter Operator’s Manual may seriously
inhibit its roadworthiness and safety and
may lead to an accident resulting in serious
personal injury or death.
Consult the Sprinter Body Builder Guideline
and the Sprinter Operator’s Manual prior to
initiating any alterations or modifications.
Correct useWarning
G
Be sure to read the Operating Instructions.
Otherwise, you may not be aware of certain
risks and could injure yourself or others.
Page 9 of 393
8 IntroductionOperating safety
If you should experience a problem with
your vehicle, particularly one that you be-
lieve may affect its safe operation, we urge
you to immediately contact an authorized
Sprinter Dealer to have the problem diag-
nosed and corrected if required.
If the matter is not handled to your satis-
faction, please discuss the problem with
the Sprinter Dealer management, or if nec-
essary contact us at the following address.In the USA:
DaimlerChrysler Motors Corporation Cus-
tomer Center
P.O. Box 21-8004
Auburn Hills, MI 48321-8001
United States of America
Telephone: 800-992-1997
In Canada:
DaimlerChrysler Canada, Inc. Customer
Center
P.O. Box 1621
Windsor, Ontario N9A 4H6
Telephone: (800) 465-2001
Warning
G
Various warning labels are affixed to your
vehicle. These warning labels are intended
to make you and others aware of various
risks. You should not remove any of these
warning labels unless explicitly instructed to
do so by information on the label itself. Re-
moval of any of these labels may cause you
and others to be unaware of certain risks
which may result in an accident and/or per-
sonal injury.
Problems with your vehicle
Page 10 of 393
9 Introduction
REPORTING SAFETY DEFECTS
\3 REPORTING SAFETY DEFECTS
In the 50 United States and Washington D.C.: If you believe that your vehicle has a defect, which could cause a crash or cause injury
or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying the man-
ufacturer.
If the NHTSA receives similar complaints, it may open an investigation, and if it finds that a safety defect exists in a group of vehicles,
it may order a recall and remedy campaign. However, NHTSA cannot become involved in individual problems between you, your dealer,
and the manufacturer.
To contact NHTSA, you may either call the Auto Safety Hotline toll free at 1–888–327–4236 (TTY: 1-800-424-9153),
or go to http://www.safercar.gov; or write to: Administrator, NHTSA, 400 Seventh Street, SW., Washington DC 20590. You can also
obtain other information about motor vehicle safety from http://www.safercar.gov.
http://www.NHTSA.gov.
In Canada:
If you believe that your vehicle has a safety defect, you should contact the Customer Service Department immediately.
Canadian customers who wish to report a safety defect to the Canadian government should write to
Transport Canada, Motor Vehicle Defect Investigations and Recalls, 2780 Sheffield Road, Ottawa, Ontario K1B 3V9.
