FIAT DOBLO COMBI 2018 Owner handbook (in English)

Fuel consumption (according to the current European Directive - litres/100 km)
VERSIONS CONSUMPTION
1.4 16V Euro 5 / Euro 6 Start&Stop Urban Extra-urban Combined
Cargo short wheelbase 9.2 5.7 7.0
Cargo short wheelbase, increased payload - Cargo long
wheelbase9.7 5.9 7.3
Combi 5-seater - Doblò 5/7-seater 9.3 5.9 7.2
Cargo,short wheelbase, High roof / Cargo, short
wheelbase, increased payload, high roof9.4 5.9 7.2
Doblò 5-seater, high roof 9.5 6.1 7.4
Flatbed, short wheelbase / long wheelbase, low roof 9.8 6.5 7.7
.
VERSIONS CONSUMPTION
1.4 16V Euro 5 / Euro 6 NO Start&Stop Urban Extra-urban Combined
Cargo, short wheelbase - Cargo, short wheelbase,
increased payload - Cargo, long wheelbase9.9 5.8 7.3
Combi 5-seater, short wheelbase / Combi 5-seater, long
wheelbase / Doblò 5/7-seater10.0 5.9 7.4
Cargo, short wheelbase, high roof - Cargo, short
wheelbase, high roof, increased payload10.2 5.9 7.5
Doblò 5/7-seater, high roof 10.3 6.1 7.6
Flatbed, short wheelbase / long wheelbase, low roof 10.5 6.5 8.0
199

.
VERSIONS CONSUMPTION
1.4 Euro 4 Urban Extra-urban Combined
Cargo short wheelbase 9.8 5.7 7.2
Cargo short wheelbase, increased payload - Cargo long
wheelbase10.3 5.7 7.4
Combi 5-seater - Doblò 5/7-seater 9.7 5.9 7.3
Cargo, short wheelbase, high roof 10.3 5.6 7.3
Doblò 5-seater, high roof 9.9 6.1 7.5
.
VERSIONS CONSUMPTION
1.4 T-JET Euro 5 / Euro 6 Urban Extra-urban Combined
Cargo, short wheelbase - Cargo, long wheelbase 9.5 5.9 7.2
Cargo, short wheelbase, high roof 9.5 6.4 7.5
Cargo, long wheelbase, high roof 9.7 6.5 7.7
Combi 5 seats 9.5 5.9 7.2
Combi 5-seater, long wheelbase 9.7 6.1 7.4
Doblò 5/7-seater 9.5 5.9 7.2
.
VERSIONS CONSUMPTION
1.3 MultiJet 90 HP Euro 5 / Euro 5+ Start&Stop Urban Extra-urban Combined
Cargo short wheelbase / Cargo short wheelbase,
increased payload5.9 4.2 4.8
Cargo long wheelbase 6 4.3 4.9
Combi 5 seats 6 4.3 4.9
Flatbed, short wheelbase / long wheelbase, low roof 6.3 4.7 5.4
.
200
TECHNICAL DATA

VERSIONS CONSUMPTION
1.3 MultiJet 90 HP Euro 5 / Euro 5+ Start&Stop Eco
PackUrban Extra-urban Combined
Cargo short wheelbase / Cargo short wheelbase,
increased payload5.2 3.9 4.4
Cargo, long wheelbase, increased payload 5.3 4.0 4.5
Combi, short wheelbase / long wheelbase 5.3 4.0 4.5
Flatbed, short wheelbase / long wheelbase, low roof 5.8 4.5 5.0
.
VERSIONS CONSUMPTION
1.3 MultiJet 90 HP Euro 5 / Euro 5+ NO Start&Stop
with DPFUrban Extra-urban Combined
Cargo, short wheelbase - Cargo, short wheelbase,
increased payload - Cargo, long wheelbase6.5 4.2 5.0
Combi 5-seater, short wheelbase / long wheelbase 6.6 4.3 5.1
Flatbed, short wheelbase / long wheelbase, low roof 7.1 4.8 5.6
.
VERSIONS CONSUMPTION
1.3 Multijet 80 HP/95 HP Euro 6 Start&Stop Eco
PackUrban Extra-urban Combined
Cargo short wheelbase / Cargo short wheelbase,
increased payload5.4 4.1 4.6
Cargo, long wheelbase / Cargo, long wheelbase (700 kg) 5.5 4.2 4.7
Combi, short wheelbase / Combi, short wheelbase,
increased payload5.5 4.2 4.7
Long wheelbase Combi 5.5 4.2 4.7
Truck, long wheelbase 5.7 4.3 4.8
Flatbed, short wheelbase / long wheelbase, low roof 5.7 4.3 4.8
.
201

VERSIONS CONSUMPTION
1.3 Multijet 80 HP/95 HP Euro 6 NO Start&Stop Urban Extra-urban Combined
Cargo short wheelbase 6.5 4.2 5.0
Cargo short wheelbase, Increased payload 6.5 4.2 5.0
Cargo, long wheelbase / Cargo, long wheelbase (700 kg) 6.6 4.3 5.1
Combi, short wheelbase - Combi, short wheelbase,
increased payload - Cargo, long wheelbase6.6 4.3 5.1
Truck, long wheelbase 6.8 4.4 5.3
Flatbed, short wheelbase / long wheelbase, low roof 6.8 4.4 5.3
.
VERSIONS CONSUMPTION
1.3 Multijet Euro 4 Urban Extra-urban Combined
Cargo short wheelbase / Cargo short wheelbase,
increased payload6.4 4.5 5.2
Cargo long wheelbase 6.6 4.5 5.3
Combi 5 seats 6.6 4.5 5.3
Flatbed, short wheelbase / long wheelbase, low roof 6.6 4.6 5.3
.
VERSIONS CONSUMPTION
1.3 Multijet Euro 4 Start&Stop with DPF Urban Extra-urban Combined
Doblò 5/7-seater 6 4.3 4.9
202
TECHNICAL DATA

.
VERSIONS CONSUMPTION
1.3 MultiJet 75 HP Euro 5+ DPF Start&Stop Urban Extra-urban Combined
Flatbed, short wheelbase / long wheelbase 6.3 4.6 5.2
Cargo short wheelbase / Cargo short wheelbase,
increased payload5.9 4.2 4.8
Cargo long wheelbase, increased payload / Combi
5-seater6 4.3 4.9
.
VERSIONS CONSUMPTION
1.3 MultiJet 75 HP Euro 5+ DPF NO Start&Stop Urban Extra-urban Combined
Flatbed, short wheelbase / long wheelbase 6.9 4.6 5.4
Cargo short wheelbase / Cargo Short wheelbase,
Increased payload / Cargo Long wheelbase6.5 4.2 5.0
Combi 5-seater / Cargo long wheelbase / Increased
payload6.6 4.3 5.1
.
VERSIONS CONSUMPTION
1.6 MultiJet 105 HP Euro 5 / Euro 5+ Start&Stop Urban Extra-urban Combined
Cargo short wheelbase 6.1 4.6 5.2
Cargo short wheelbase, increased payload / Cargo long
wheelbase6.2 4.6 5.2
Combi 5-seater, short wheelbase 6.1 4.7 5.2
Combi 5-seater, long wheelbase 6.3 4.8 5.4
Doblò 5/7-seater 6.1 4.7 5.2
Cargo, short wheelbase, high roof - Cargo, short
wheelbase, high roof, increased payload6.3 5.1 5.5
Cargo, long wheelbase, high roof 6.4 5.3 5.7
Doblò 5-seater, high roof 6.4 5.3 5.7
203

VERSIONS CONSUMPTION
1.6 MultiJet 105 HP Euro 5 / Euro 5+ Start&Stop Urban Extra-urban Combined
Doblò 5-seater, long wheelbase 6.1 4.7 5.2
Flatbed, short wheelbase / long wheelbase, low roof 6.8 6.2 6.4
.
VERSIONS CONSUMPTION
1.6 MultiJet 105 HP Euro 5 / Euro 5+ Start&Stop Eco
PackUrban Extra-urban Combined
Cargo short wheelbase 5.4 4.3 4.7
Cargo, short wheelbase / Cargo, short wheelbase,
increased payload5.5 4.3 4.7
Combi short wheelbase 5.4 4.4 4.8
Combi Long wheelbase 5.5 4.6 4.9
Combi Panorama, short wheelbase / long wheelbase -
Doblò, short wheelbase / long wheelbase5.4 4.4 4.8
Cargo / Cargo increased payload, short wheelbase, high
roof5.8 4.7 5.1
Cargo, long wheelbase, high roof 5.7 4.9 5.2
Doblò, short wheelbase, high roof 5.8 4.8 5.2
Flatbed, short wheelbase / long wheelbase, low roof 6.1 5.8 5.9
.
VERSIONS CONSUMPTION
1.6 MultiJet 105 HP Euro 5 / Euro 5+ NO Start&Stop Urban Extra-urban Combined
Cargo short wheelbase 6.7 4.7 5.4
Cargo short wheelbase, increased payload / Cargo long
wheelbase6.8 4.7 5.5
Combi 5-seater, short wheelbase 6.8 4.7 5.5
Combi 5-seater, long wheelbase 6.9 4.9 5.6
204
TECHNICAL DATA

VERSIONS CONSUMPTION
1.6 MultiJet 105 HP Euro 5 / Euro 5+ NO Start&Stop Urban Extra-urban Combined
Doblò 5/7-seater 6.8 4.7 5.5
Cargo, long wheelbase, high roof 7.1 5.4 6.0
Cargo, short wheelbase, high roof / Cargo, short
wheelbase, high roof, increased payload7.1 5.1 5.8
Doblò 5-seater, high roof 7.1 5.4 6.0
Doblò 5-seater, long wheelbase 6.8 4.7 5.5
Flatbed, short wheelbase / long wheelbase, low roof 7.5 6.3 6.7
.
VERSIONS CONSUMPTION
1.6 MultiJet 90 HP Euro 5 / Euro 5+ NO Start&Stop Urban Extra-urban Combined
Doblò 5/7-seater 6.8 4.7 5.5
Doblò 5-seater, high roof 7.1 5.3 6.0
.
VERSIONS CONSUMPTION
1.6 MultiJet 90 HP Euro 5 / Euro 5+ Start&Stop Urban Extra-urban Combined
Doblò 5/7-seater 6.1 4.7 5.2
Doblò 5-seater, high roof 6.3 5.2 5.6
.
VERSIONS CONSUMPTION
1.6 Multijet Euro 5+ TREKKING Urban Extra-urban Combined
Doblò 5-seater Short Wheelbase Low Roof - No
Start&Stop7.1 5.1 5.8
Doblò 7-seater Short Wheelbase Low Roof - Start&Stop 6.3 5.1 5.5
Doblò 5-seater Short Wheelbase Low Roof - Eco Pack 5.8 4.7 5.1
205

VERSIONS CONSUMPTION
1.6 Multijet Euro 5+ TREKKING Urban Extra-urban Combined
Doblò 5-seater Short Wheelbase Low Roof - No
Start&Stop7.1 5.1 5.8
Doblò 7-seater Short Wheelbase Low Roof - Start&Stop 6.3 5.1 5.5
Doblò 5-seater Short Wheelbase Low Roof - Eco Pack 5.8 4.7 5.1
Combi 5-seater Short Wheelbase Low Roof - No
Start&Stop7.1 5.1 5.8
Combi 5-seater Short Wheelbase Low Roof - Start&Stop 6.3 5.1 5.5
Combi 5-seater Short Wheelbase Low Roof - Eco Pack 5.8 4.7 5.1
Combi 5-seater Short Wheelbase Low Roof - No
Start&Stop - Reinforced suspension7.1 5.1 5.8
Combi 5-seater Short Wheelbase Low Roof - Start&Stop
- Reinforced suspension6.3 5.1 5.5
Combi 5-seater Short Wheelbase Low Roof - Eco Pack -
Reinforced suspension5.8 4.7 5.1
.
VERSIONS CONSUMPTION
1.6 Multijet 90 HP with COMFORT-MATIC transmission Urban Extra-urban Combined
Cargo short wheelbase 5.5 4.6 4.9
Cargo short wheelbase High roof / Cargo
short wheelbase increased payload high
roofF.C.
(*)14705.6 5.2 5.3
F.C.
(*)15905.7 5.4 5.5
Cargo short wheelbase, increased payload / long wheelbase 5.6 4.7 5.0
Combi Short Wheelbase 5.6 4.8 5.0
Combi Long Wheelbase 5.7 4.8 5.1
(*) F.C.: flywheel class
The fuel consumption figures in the table refer to the AUTO-ECO logic..
206
TECHNICAL DATA

VERSIONS CONSUMPTION
1.6 Multijet 90 HP NO Start&Stop with COMFORT-
MATIC transmissionUrban Extra-urban Combined
Cargo short wheelbase 6.3 4.7 5.3
Cargo short wheelbase high roof / cargo
short wheelbase increased payload high
roofF.C.
(*)14706.5 5.2 5.7
F.C.
(*)15906.6 5.5 5.9
Cargo short wheelbase, increased payload / long wheelbase 6.4 4.8 5.4
Combi Short Wheelbase / Long Wheelbase 6.4 4.8 5.4
(*) F.C.: flywheel class
The fuel consumption figures in the table refer to the AUTO-ECO logic..
VERSIONS CONSUMPTION
Versions with DUALOGIC
™transmission Urban Extra-urban Combined
1.6 MultiJet 90 HP
5.6 / 5.9(*)4.7 / 5.3(*)5.0 / 5.5(*)
1.6 Multijet 90 HP NO Start&Stop
6.4 / 6.7(*)4.8 / 5.5(*)5.4 / 5.9(*)
(*) High roof versions
The fuel consumption figures in the table refer to the AUTO-ECO logic..
VERSIONS CONSUMPTION
1.6 Multijet 95 HP/105 HP/120 HP Euro 6 NO
Start&StopUrban Extra-urban Combined
Doblò 5/7 seater, short wheelbase / low roof 6.5 4.4 5.2
Doblò 5 seater, long wheelbase / low roof / reinforced
suspension6.8 4.7 5.5
Doblò 5 seater, short wheelbase / low roof / reinforced
Suspension6.9 5.1 5.8
Doblò 5 seater (120 HP), long wheelbase / high roof /
reinforced suspension6.9 5.1 5.8
207

VERSIONS CONSUMPTION
1.6 Multijet 95 HP/105 HP/120 HP Euro 6 NO
Start&StopUrban Extra-urban Combined
Cargo, short wheelbase, low roof 6.3 4.4 5.1
Cargo, short wheelbase, high roof, increased payload 6.5 4.4 5.2
Cargo, short wheelbase, high roof / Cargo, short
wheelbase, high roof, increased payload6.5 4.4 5.2
Cargo, long wheelbase, low roof / Cargo, long
wheelbase, low roof (700 kg)6.5 4.4 5.2
Cargo, long wheelbase, high roof 6.7 5.1 5.7
Combi, short wheelbase, low roof / Combi, short
wheelbase, low roof, increased payload6.4 4.5 5.2
Combi, long wheelbase, low roof 6.5 4.6 5.3
Combi, long wheelbase, high roof 6.7 5.1 5.7
Truck, long wheelbase, low roof 6.7 5.1 5.7
Flatbed, short wheelbase / long wheelbase, low roof 6.7 5.1 5.7
Flatbed, short wheelbase / long wheelbase, low roof —
Increased payload6.8 5.2 5.8
.
VERSIONS CONSUMPTION
1.6 Multijet 95 HP/105 HP/120 HP Euro 6 Start&Stop
Eco PackUrban Extra-urban Combined
Doblò 5/7 seater, short wheelbase, low roof 5.4 4.3 4.7
Doblò 5 seater, long wheelbase, low roof, reinforced
suspension5.6 4.5 4.9
Doblò 5 seater, short wheelbase, low roof, reinforced
suspension6.0 4.9 5.3
Doblò 5 seater (120 HP), long wheelbase, high roof,
reinforced suspension6.0 4.9 5.3
208
