FIAT DOBLO COMBI 2018 Owner handbook (in English)

VERSION GVW ENGINE A B C D
PLATFORM
TYPE1.4 1000 500 0 100
1.3 Multijet 1000 500 0 100
1.3 Multijet Euro 6 1000 500 0 100
1.6 Multijet 1300 500 0 100
1.6 Multijet Euro 6 1300 500 0 100
2.0 Multijet 1300 500 0 100
M1= people carrier
NOTE For vehicles with tow hook: the vertical static load on the tow hook must be within the maximum permitted weight
declared for the vehicle.
189

REFUELLING
1.4 1.4 T-JET1.4 T-JET Natural
PowerRecommended fuels and original
lubricants
Fuel tank: 60 litres 60 litres 22 litres
Unleaded petrol not less than 95 RON
(EN 228 specification)
including a reserve of: 8–10 litres 8–10 litres 5.5 litres
Methane cylinder
capacity (1.4 T-JET
Natural Power):Long
wheelbase
versions
--16.15 kg (approx.)
Methane
(*)Short
wheelbase
versions22.1 kg (approx.)
Engine cooling system: 5 litres 5.8 litres 5.8 litresMixture of demineralised water and
50% PARAFLU
UP(**)
Engine sump: 2.35 litres/2kg 2.1kg
- SELENIA K P.E.
Engine sump and filter: 2.7 litres / 2.3 kg 2.45 kg
Engine sump (1.4 T-JET Natural
Power):- - 2.1 litres
SELENIA MULTIPOWER GAS 5W-40
Engine sump and filter (1.4 T-JET
Natural Power):- - 2.45 litres
(*) The amount of methane depends on the outside temperature, the supply pressure, the quality of the gas and the type of refuelling system. Overall cylinder
volume approximately 95 litres (short wheelbase versions) and 130 litres (long wheelbase versions).
(**) When the vehicle is used in particularly harsh weather conditions, we recommend using a 60-40 mixture of PARAFLU
UPand demineralised water.
190
TECHNICAL DATA

1.4 1.4 T-JET1.4 T-JET Natural
PowerRecommended fuels and original
lubricants
Gearbox casing/differential: 1.76 litres / 1.5 kg 1.5 kg -TUTELA TRANSMISSION
GEARFORCE
Transmission/differential casing
(1.4 T-JET Natural Power):- - 1.5 kg TUTELA TRANSMISSION TECHNYX
Hydraulic brake circuit with ABS
anti-lock device:0.450 kg 0.450 kg 0.450 kg TUTELA TOP 4/S
Hydraulic power steering: 0.900 kg 0.900 kg 0.900 kg- TUTELA TRANSMISSION GI/E
Windscreen/rear window washer
fluid reservoir:2.2
(***)/6(****)
litres
2.2(***)/6(****)
litres6.0 litres(°)Mixture of water and PETRONAS
DURANCE SC35
(***) For Doblò versions without headlamp washers.
(****) For Doblò/Doblò Combi/Doblò Cargo versions with headlamp washers.
(°) DOBLÒ ACTIVE versions: 2.2 litres
IMPORTANT Note that when using a fuel like methane, the range is extremely variable because in addition to the vehicle
maintenance and driving conditions it also depends on the temperature of the gas in the cylinder. The methane actually heats
up during the refuelling and cools down whilst driving, undergoing variations in pressure that reduce the quantity that can
be used. It should also be pointed out that whilst the vehicle is being run in (up to around 3000 km) the fuel consumption may
be higher than the figures given.
191

1.3 Multijet 1.6 Multijet 2.0 MultijetRecommended fuels and
original lubricants
Fuel tank: 60 litres 60 litres 60 litres
Diesel for motor vehicles (EN590
Specification)
including a reserve of: 8–10 litres 8–10 litres 8–10 litres
Engine cooling system: 5.2 litres 6.7 litres 6.7 litresMixture of distilled water and
PARAFLU
UPliquid at 50%(***)
Engine sump: 3 litres / 2.5 kg 4.5 litres / 3.6 kg 4.5 litres / 3.6 kgSELENIA WR P.E. (Euro 5
versions) / SELENIA WR
FORWARD (Euro 6 versions) Engine sump and filter: 3.2 litres / 2.7 kg 4.9 litres / 3.9 kg 4.9 litres / 3.9 kg
Gearbox casing/differential: 2 litres / 1.7 kg 2 litres / 1.7 kg 2 litres / 1.7 kgTUTELA TRANSMISSION
GEARFORCE
COMFORT-MATIC and
DUALOGIC™transmission
actuation hydraulic system (1.6
Multijet 90 HP versions)— 0.7 litres / 0.59 kg —TUTELA CS SPEED Special oil
with “ATF DEXRON III” type
additive
Hydraulic brake circuit with ABS: 0.450 kg 0.450 kg 0.450 kg TUTELA TOP 4/S
Hydraulic power steering: 0.900 kg 0.900 kg 0.900 kg TUTELA TRANSMISSION GI/E
Windscreen/headlight washer
reservoir:2.2
(*)/6(**)litres2.2(*)/6(**)litres2.2(*)/6(**)litresMixture of water and
PETRONAS DURANCE SC35
(***) When the vehicle is used in particularly harsh weather conditions, we recommend using a 60-40 mixture of PARAFLUUPand demineralised water.
(*) For Doblò versions without headlamp washers.
(**) For Doblò/Doblò Combi/Doblò Cargo versions with headlamp washers.
192
TECHNICAL DATA

FLUIDS AND LUBRICANTS
Your vehicle is equipped with an engine oil that has been thoroughly developed and tested in order to meet the
requirements of the Service Schedule. Constant use of the prescribed lubricants guarantees the fuel consumption
and emission specifications. Lubricant quality is crucial for engine operation and duration.
RECOMMENDED PRODUCTS AND THEIR SPECIFICATIONS
Use Features SpecificationOriginal fluids and
lubricantsReplacement interval
Lubricants for petrol
enginesSAE 5W-40
ACEA C3 / API SN9.55535-S2SELENIA K P.E.
Contractual Technical
Reference N° F603.C07According to Scheduled
Servicing Plan
Lubricants for Euro 5
diesel engines
46)
SAE 5W-30
ACEA C29.55535-S1SELENIA WR P.E.
Contractual Technical
Reference N° F510.D07According to Scheduled
Servicing Plan
Lubricants for Euro 6
diesel engines
46)
SAE 0W-30
ACEA C29.55535–DS1SELENIA WR
FORWARD
Contractual Technical
Reference N° F842.F13According to Scheduled
Servicing Plan
Lubricants for petrol/
methane engines
46)
SAE 5W-40
ACEA C3FIAT 9.55535-T2SELENIA MULTIPOWER
GAS 5W-40
Contractual Technical
Reference N° F922.E09According to annual
maintenance and
inspection plan
If lubricants conforming to the specific request are not available, products that meet the indicated specifications can be used to
top up; in this case optimal performance of the engine is not guaranteed.
193
WARNING
46)The use of products with different specifications than those indicated above could cause damage to the engine not covered by the
warranty.

Use Features SpecificationOriginal fluids and
lubricantsApplications
Lubricants and greases
for drive transmissionSAE 75W API GL4 grade
synthetic lubricant.9.55550-MZ6 or
MS.90030–M1TUTELA
TRANSMISSION
GEARFORCE
Contractual Technical
Reference N° F002.F10Manual gearbox and
differential
SAE 75W- 85 grade
synthetic lubricant.9.55550-MX3TUTELA
TRANSMISSION
TECHNYX
Contractual Technical
Reference N° F010.B05Mechanical transmissions
and differentials (1.4 T-JET
Natural Power versions)
Specific fluid for ratio
selector electrohydraulic
actuators.FIAT 9.55550-SA1TUTELA CS SPEED
Contractual Technical
Reference No. F005.F98COMFORT-MATIC and
DUALOGIC™electrically
controlled electrohydraulic
actuator
Molybdenum disulphide
grease, for use at high
temperatures.9.55580 — GRASS IITUTELA ALL STAR
Contractual Technical
Reference N° F702.G07Wheel side constant
velocity joints
Grease for constant
velocity joints with low
friction coefficient.9.55580 — GRASS IITUTELA STAR 700
Contractual Technical
Reference N° F701.C07Differential side constant
velocity joints
Lubricant for power
steering
Exceeds "ATF DEXRON
III" specifications9.55550-AG2.TUTELA
TRANSMISSION GI/E
Contractual Technical
Reference N° F001.C94Hydraulic power steering
Brake fluidSynthetic fluid for brake
and clutch systems
Exceeds specifications:
FMVSS n° 116 DOT 4,
ISO 4925, SAE J 1704,9.55597 or MS.90039.TUTELA TOP 4/S
Contractual Technical
Reference N° F005.F15Hydraulic brakes and
clutch controls
194
TECHNICAL DATA

Use Features SpecificationOriginal fluids and
lubricantsApplications
Protective agent for
radiatorsRed protective with
antifreeze action, based
on inhibited monoethyl
glycol with organic
formula. Exceeds CUNA
NC 956-16, ASTM D
3306 specifications.9.55523 or MS.90032PARAFLUUP(*)
Contractual Technical
Reference N° F101.M01Cooling circuits. Use rate
50% up to -35°C. Mixture
with different formulation
products not allowed.
Diesel fuel additiveAdditive for diesel
antifreeze, protecting
diesel engines.-PETRONAS DURANCE
DIESEL ART
Contractual Technical
Reference N° F601.C06To be mixed with diesel
(25 cc per 10 litres)
Windscreen washer fluidMixture of alcohol and
surfactants CUNA NC
956-II.9.55522 or MS.90043PETRONAS DURANCE
SC 35
Contractual Technical
Reference N° F001.D16To be used diluted or
undiluted in windscreen
washer/wiper systems
(*)When the vehicle is used in particularly harsh weather conditions, we recommend using a mixture of 60%PARAFLUUPand 40% demineralised water.
195

PERFORMANCE
Top permitted speed after initial vehicle use in km/h.
1.4 1.4 T-JET 1.4 T-JET Natural Power 1.3 Multijet 1.6 Multijet
161172 (low roof)
172(*)
158 (Euro 5) 164
156 (Euro 4) 158 (90 HP low roof)
167 (high roof)148 (undersized
75 HP)153 (90 HP high roof)
(*) Running on petrol or methane alike
1.6 MultiJet 120 HP Euro 6 1.6 MultiJet 95 HP Euro 6 2.0 Multijet
176 (Eco Pack) 164 (Eco Pack)
179 172 160
171 (high roof Eco Pack) 159 (high roof Eco Pack)
167 (high roof) 155 (high roof)
172 (Eco Pack Trekking version) 160 (Eco Pack Trekking version)
168 (Eco Pack Trekking version) 156 (Eco Pack Trekking version)
1.6 MultiJet 105 HP 1.3 Multijet Euro 6 95 HP 1.3 Multijet Euro 6 80 HP
170 (Eco Pack) 161 (Eco Pack) 148 (Eco Pack)
166 159 146
165 (High roof Eco Pack) - -
161 (High roof) - -
196
TECHNICAL DATA

1.6 Multijet 90 HP with COMFORT-MATIC transmission 1.6 Multijet 90 HP with DUALOGIC™transmission
158 (Cargo 2/3-seater - Combi 5-seater) 158 (Doblò 5/7-seater)
153 (High roof) 153 (High roof)
141 (Truck) 141 (Truck)
197

FUEL
CONSUMPTION
The fuel consumption figures given in
the tables below are determined on the
basis of the type-approval tests laid
down by specific European Directives.
These consumption values refer to
basic vehicles without optionals.
The following procedures are used to
measure the fuel consumption:
urban cycle: begins with cold
starting, followed by driving simulating
the use of the vehicle in town;
extra-urban cycle: driving that
simulates using the vehicle out of town
with frequent acceleration in all gears;
the speed varies from 0 to 120 km/h;
combined consumption: calculated
with a weighting of approximately
37% of the urban cycle and 63% of the
extra-urban cycle.
IMPORTANT The type of route, traffic
situations, weather conditions, driving
style, general conditions of the vehicle,
trim level/equipment/accessories,
climate control system, vehicle load,
roof rack, other situations that affect
aerodynamics or air drag may lead to
different fuel consumption levels than
those measured.
198
