FIAT DOBLO COMBI 2018 Owner handbook (in English)

VERSIONS CONSUMPTION
1.6 Multijet 95 HP/105 HP/120 HP Euro 6 Start&Stop
Eco PackUrban Extra-urban Combined
Cargo, short wheelbase, low roof 5.3 4.1 4.5
Cargo, short wheelbase, high roof, increased payload 5.3 4.2 4.6
Cargo, short wheelbase, high roof / Cargo, short
wheelbase, high roof, increased payload5.3 4.2 4.6
Cargo, long wheelbase, low roof / Cargo, long
wheelbase, low roof (700 kg)5.3 4.2 4.6
Cargo, long wheelbase, high roof 5.6 4.7 5.0
Combi, short wheelbase, low roof / Combi, short
wheelbase, low roof, increased payload5.2 4.3 4.6
Combi, long wheelbase, low roof 5.3 4.4 4.7
Combi, long wheelbase, high roof 5.6 4.7 5.0
Truck, long wheelbase, low roof 5.6 4.7 5.0
Flatbed, short wheelbase / long wheelbase, low roof 5.6 4.7 5.0
.
VERSIONS CONSUMPTION
1.6 Multijet Euro 6 TREKKING Urban Extra-urban Combined
Doblò 5-seater Short Wheelbase Low Roof - No
Start&Stop6.8 4.7 5.5
Doblò 5-seater Short Wheelbase Low Roof - Eco Pack 5.7 4.6 5.0
Doblò 7-seater Short Wheelbase Low Roof - No
Start&Stop6.8 4.7 5.5
Doblò 7-seater Short Wheelbase Low Roof - Eco Pack 5.7 4.6 5.0
.
209

VERSIONS CONSUMPTION
1.6 Multijet Euro 4 Urban Extra-urban Combined
Cargo short wheelbase 6.6 4.7 5.4
Cargo, increased payload, short wheelbase, long
wheelbase6.7 4.7 5.4
Cargo,short wheelbase, high roof / Cargo, short
wheelbase, increased payload, high roof6.8 5.1 5.7
.
VERSIONS CONSUMPTION
1.6 Multijet Euro 4 Start&Stop with DPF Urban Extra-urban Combined
Doblò 5/7-seater 6.1 4.7 5.2
Doblò 5-seater, high roof 6.4 5.3 5.7
.
VERSIONS CONSUMPTION
2.0 Multijet Euro 5 / Euro 5+ Urban Extra-urban Combined
Cargo short wheelbase / long wheelbase 6.5 5.1 5.6
Combi 5-seater / Doblò 5/7-seater 6.7 5.1 5.7
Cargo,short wheelbase, high roof / Cargo, short
wheelbase, increased payload, high roof6.7 5.2 5.8
Doblò 5-seater, high roof 6.8 5.5 6.0
Combi, long wheelbase, high roof 7.2 5.5 6.1
Cargo, long wheelbase, high roof 6.8 5.5 6.0
Doblò 5-seater, long wheelbase 6.1 4.7 5.2
210
TECHNICAL DATA

.
VERSIONS CONSUMPTION
2.0 Multijet Euro 5+ TREKKING Urban Extra-urban Combined
Combi 5-seater Short Wheelbase Low Roof - No
Start&Stop7.3 5.2 6.0
Combi 5-seater Short Wheelbase Low Roof - No
Start&Stop - Reinforced suspension7.3 5.2 6.0
.
VERSIONS CONSUMPTION
2.0 MultiJet 135 HP Euro 5 / Euro 5+ NO Start&Stop Urban Extra-urban Combined
Cargo short wheelbase / Cargo short wheelbase,
increased payload / Cargo long wheelbase7.2 5.1 5.9
Combi 5-seater, short wheelbase / Combi 5-seater, long
wheelbase / Doblò 5/7-seater7.3 5.1 5.9
Cargo, short wheelbase, high roof, increased payload /
Cargo short wheelbase, high roof7.8 5.5 6.3
Cargo, short wheelbase, high roof / increased payload /
Doblò 5-seater, high roof7.4 5.5 6.2
Combi 5-seater, long wheelbase, high roof 7.8 5.5 6.3
Cargo, long wheelbase, high roof 7.4 5.5 6.2
Doblò 5-seater, long wheelbase 7.3 5.1 5.9
Flatbed, short wheelbase / long wheelbase, low roof 7.8 6.6 7.0
.
NOTE The consumption values of the Natural Power versions when running on methane are indicated in m3/100 km.
211

VERSIONS CONSUMPTION
1.4 T-JET Natural Power Urban Extra-urban Combined
Doblò 5-seater (M1) - Short wheelbase - Long wheelbase
9.7(*) / 9.9 (**)6.1(*)/ 6.1(**)7.4(*)/ 7.5(**)
Cargo, short wheelbase, high roof
9.7(*)/10(**)6.5(*)/ 6.4(**)7.7(*)/ 7.7(**)
Combi long wheelbase
9.7(*)/10(**)6.3(*)/ 6.2(**)7.6(*)/ 7.6(**)
(*) Running on petrol
(**) Methane fuel supply (m3/100 km)
212
TECHNICAL DATA

CO2EMISSIONS
These are measured by analysing the exhaust gases emitted under testing, and are correlated to the consumption values
through the carbon balance of the emissions. The CO
2emission figures in the table below refer to combined fuel consumption.
CO
2emissions (according to the European Directive in force g/km)
1.4 16V Euro 5 / Euro 6 Start&Stop Combined
Cargo short wheelbase163
Cargo short wheelbase, increased payload - Cargo long wheelbase 168
Combi 5-seater - Doblò 5/7-seater 166
Cargo,short wheelbase, High roof / Cargo, short wheelbase,
increased payload, high roof167
Doblò 5-seater, high roof171
Flatbed, short wheelbase / long wheelbase, low roof 179
213

1.4 16V Euro 5 / Euro 6 NO Start&Stop Combined
Cargo Short Wheelbase169
Cargo, short wheelbase, increased payload / Cargo, long wheelbase /
Combi 5-seater, short wheelbase / Combi 5-seater, long wheelbase172
Doblò 5/7-seater / Cargo, short wheelbase, high roof 173
Cargo, short wheelbase, high roof, increased payload / Doblò 5/7-
seater, high roof177
Flatbed, short wheelbase / long wheelbase, low roof 185
1.4 Euro 4 Combined
Cargo short wheelbase169
Cargo short wheelbase, increased payload / Cargo long wheelbase 174
Combi 5-seater - Doblò 5/7-seater 172
Cargo, short wheelbase, high roof 173
Doblò 5-seater, high roof177
1.4 T-JET Euro 5 / Euro 6 Combined
Cargo short wheelbase / Cargo long wheelbase 169
Cargo, short wheelbase, high roof 175
Cargo, long wheelbase, high roof 179
Combi 5 seats169
Combi 5-seater, long wheelbase 173
Doblò 5/7-seater169
214
TECHNICAL DATA

1.3 MultiJet 90 HP Euro 5 / Euro 5+ Start&Stop Combined
Cargo short wheelbase / Cargo short wheelbase, increased payload 126
Cargo long wheelbase / Combi 5-seater 129
Flatbed, short wheelbase / long wheelbase, low roof 142
1.3 MultiJet 90 HP Euro 5 / Euro 5+ Start&Stop Eco Pack Combined
Cargo, short wheelbase / Cargo, increased payload, short wheelbase 115
Cargo increased payload, long wheelbase / Combi, short wheelbase /
long wheelbase118
Flatbed, short wheelbase / long wheelbase, low roof 131
1.3 MultiJet 90 HP Euro 5 / Euro 5+ NO Start&Stop with DPF Combined
Cargo Short wheelbase / Cargo Short wheelbase, Increased payload
/ Cargo Long wheelbase133
Combi 5-seater, short wheelbase / Combi 5-seater, long wheelbase 136
Flatbed, short wheelbase / long wheelbase, low roof 149
1.3 Multijet 80 HP/95 HP Euro 6 Start&Stop Eco Pack Combined
Cargo short wheelbase / Cargo short wheelbase, increased payload 120
Cargo, long wheelbase / Cargo, long wheelbase (700 kg) 123
Combi, short wheelbase / Combi, short wheelbase, increased
payload / Combi, long wheelbase123
Truck, long wheelbase127
Flatbed, short wheelbase / long wheelbase, low roof 127
215

1.3 Multijet 80 HP/95 HP Euro 6 NO Start&Stop Combined
Cargo short wheelbase / Cargo short wheelbase, increased payload 133
Cargo, long wheelbase / Cargo, long wheelbase (700 kg) 136
Combi, short wheelbase / Combi, short wheelbase, increased
payload / Combi, long wheelbase136
Truck, long wheelbase140
Flatbed, short wheelbase / long wheelbase, low roof 140
1.3 Multijet Euro 4 Combined
Cargo short wheelbase / Cargo short wheelbase, increased payload 136
Cargo long wheelbase139
Combi 5 seats139
Flatbed, short wheelbase / long wheelbase, low roof 141
1.3 Multijet Euro 4 Start&Stop with DPF Combined
Doblò 5/7-seater129
1.3 MultiJet 75 HP Euro 5+ DPF Start&Stop Combined
Flatbed, short wheelbase / long wheelbase 137
Cargo short wheelbase / Cargo short wheelbase, increased payload 126
Cargo long wheelbase, increased payload / Combi 5-seater 129
1.3 MultiJet 75 HP Euro 5+ DPF NO Start&Stop Combined
Flatbed, short wheelbase / long wheelbase 144
Cargo Short wheelbase / Cargo Short wheelbase, Increased payload
/ Cargo Long wheelbase133
216
TECHNICAL DATA

1.3 MultiJet 75 HP Euro 5+ DPF NO Start&Stop Combined
Combi 5-seater / Cargo long wheelbase / Increased payload 136
1.6 MultiJet 105 HP Euro 5 / Euro 5+ Start&Stop Combined
Cargo short wheelbase136
Cargo short wheelbase, increased payload Cargo long wheelbase 137
Combi 5-seater, short wheelbase 138
Combi 5-seater, long wheelbase 141
Doblò 5/7-seater138
Cargo,short wheelbase, high roof / Cargo, short wheelbase,
increased payload, high roof146
Doblò 5-seater, high roof150
Doblò 5-seater, long wheelbase 138
Flatbed, short wheelbase / long wheelbase, low roof 170
1.6 MultiJet 105 HP Euro 5 / Euro 5+ Start&Stop Eco Pack Combined
Cargo short wheelbase124
Cargo, increased payload, short wheelbase / long wheelbase 125
Combi short wheelbase126
Combi long wheelbase129
Combi Panorama, short wheelbase / long wheelbase - Doblò, short
wheelbase / long wheelbase126
Cargo / Cargo increased payload, short wheelbase, high roof 134
Doblò, short wheelbase, high roof 136
Flatbed, short wheelbase / long wheelbase, low roof 155
217

1.6 MultiJet 105 HP Euro 5 / Euro 5+ NO Start&Stop Combined
Cargo short wheelbase143
Cargo Short wheelbase, Increased payload 144
Cargo, long wheelbase / Combi 5-seater, short wheelbase 145
Combi 5-seater, long wheelbase 148
Doblò 5/7-seater145
Cargo, long wheelbase, high roof 158
Cargo, short wheelbase, high roof 154
Cargo, short wheelbase, high roof / increased payload / Doblò
5-seater, high roof158
Doblò 5-seater, long wheelbase 145
Flatbed, short wheelbase / long wheelbase, low roof 178
1.6 MultiJet 90 HP Euro 5 / Euro 5+ NO Start&Stop Combined
Doblò 5/7-seater145
Doblò 5-seater, high roof158
1.6 Multijet Euro 5+ TREKKING Combined
Doblò 5-seater Short Wheelbase Low Roof - No Start&Stop 154
Doblò 7-seater Short Wheelbase Low Roof - Start&Stop 146
Doblò 5-seater Short Wheelbase Low Roof - Eco Pack 134
Doblò 5-seater Short Wheelbase Low Roof - No Start&Stop 154
Doblò 7-seater Short Wheelbase Low Roof - Start&Stop 146
Doblò 5-seater Short Wheelbase Low Roof - Eco Pack 134
Combi 5-seater Short Wheelbase Low Roof - No Start&Stop 154
218
