FIAT DUCATO BASE CAMPER 2017 Owner handbook (in English)

2.3 130 Multijet 2 with Adblue
VersionF.C.(*)Consumption
Urban Extra-urban Combined
Light 2040 6.9 5.4 6.0
Light 2150 7.0 5.5 6.1
Maxi 2150 7.2 5.5 6.1
Light 2270 7.2 5.7 6.3
Maxi 2270 7.6 5.8 6.5
(*) Flywheel class
249

2.3 150 Multijet 2 / 180 Multijet 2 Power
VersionF.C.(*)Consumption
Urban Extra-urban Combined
Light 1700 6.3 5.4 5.7
Maxi 1700 6.4 5.4 5.8
Tempo Libero 1700 6.4 5.4 5.8
Light 1810 6.5 5.5 5.9
Maxi 1810 6.7 5.5 5.9
Tempo Libero 1810 6.7 5.5 5.9
Light 1930 6.9 5.6 6.1
Maxi 1930 7.0 5.7 6.2
Tempo Libero 1930 7.0 5.7 6.2
Light 2040 7.1 5.8 6.3
Maxi 2040 7.3 5.8 6.4
Tempo Libero 2040 7.3 5.8 6.4
Light 2150 7.4 5.9 6.5
Maxi 2150 7.7 5.9 6.6
Tempo Libero 2150 7.7 5.9 6.6
Light
-
Maxi
-
Tempo Libero2270 (I) 7.8 6.0 6.7
2270 (II) 7.9 6.0 6.7
2270 (III) 7.9 6.0 6.7
(*) Flywheel class
250
TECHNICAL DATA

3.0 140 Natural Power
Consumption according to the current European directive
VersionF.C.(*)Methane (m3x100 km)
Methane (kg/100 km)(**)
Urban Extra-urban Combined Urban Extra-urban Combined
Light –
16.3 11.2 13.1 10.6 7.3 8.6 Maxi –
Tempo Libero –
(*) Flywheel class
(**) Consumption in kg x 100 km according to molecular weight calculation
251

CO2EMISSIONS
The CO2emission figures in the table below refer to combined fuel consumption.
These emission values refer to basic vehicles without optionals.
CO
2emissions (according to the European Directive in force g/100 km)
2.0 115 Multijet 2
Version
F.C.(*)CO2emissions
Combined
Light / Tempo libero 1700 147
Light / Tempo libero 1810 152
Light / Tempo libero 1930 152
Light / Tempo libero 2040 162
Light / Tempo libero 2150 167
(*) Flywheel class
252
TECHNICAL DATA

2.3 150 ECOJET
VersionF.C.(*)CO2emissions
Combined
Light 1700 141
Maxi 1700 143
Tempo Libero 1700 143
Light 1810 146
Maxi 1810 148
Tempo Libero 1810 148
Light 1930 151
Maxi 1930 153
Tempo Libero 1930 153
Light 2040 156
Maxi 2040 158
Tempo Libero 2040 158
Light 2150 161
Maxi 2150 163
Tempo Libero 2150 163
Light
-
Maxi
-
Tempo Libero2270 (I) 166
2270 (II) 168
2270 (III) 168
Light M1 2040 144
Light M1 2150 147
(*) Flywheel class
253

VersionF.C.(*)CO2emissions
Combined
Maxi M1 2150 148
Light M1 2270 (I) 152
Maxi M1 2270 (I) 153
(*) Flywheel class
254
TECHNICAL DATA

2.3 130 Multijet 2
VersionF.C.(*)CO2emissions
Combined
Light 1700 151
Maxi 1700 153
Tempo Libero 1700 153
Light 1810 156
Maxi 1810 158
Tempo Libero 1810 158
Light 1930 161
Maxi 1930 163
Tempo Libero 1930 163
Light 2040 166
Maxi 2040 168
Tempo Libero 2040 168
Light 2150 171
Maxi 2150 173
Tempo Libero 2150 173
Light
-
Maxi
-
Tempo Libero2270 (I) 177
2270 (II) 178
2270 (III) 178
(*) Flywheel class
255

2.3 130 Multijet 2 with Adblue
VersionF.C.(*)CO2emissions
Combined
Light 2040 156
Light 2150 159
Maxi 2150 162
Light 2270 164
Maxi 2270 170
(*) Flywheel class
256
TECHNICAL DATA

2.3 150 Multijet 2 / 180 Multijet 2 Power
VersionF.C.(*)CO2emissions
Combined
Light 1700 150
Maxi 1700 152
Tempo Libero 1700 152
Light 1810 155
Maxi 1810 157
Tempo Libero 1810 157
Light 1930 160
Maxi 1930 162
Tempo Libero 1930 162
Light 2040 165
Maxi 2040 167
Tempo Libero 2040 167
Light 2150 170
Maxi 2150 172
Tempo Libero 2150 172
Light
-
Maxi
-
Tempo Libero2270 (I) 175
2270 (II) 177
2270 (III) 177
(*) Flywheel class
257

3.0 140 Natural Power
VersionF.C.(*)CO2emissions
Combined
Light
– 234 Maxi
Tempo Libero
(*) Flywheel class
258
