FIAT MULTIPLA 2006 1.G Service Manual

40
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
DIMMER
This function is used to adjust (increase/decrease) the brightness of the instrument panel and of the display.
Standard display
Back to standard displayAfter 10s without actions Adjust brightness
Turn ignition
key to MAR
IMPORTANT The display will be dimmed when the external
lights are switched on. This function will not be available in the
event of a failure to the dimmer and the display will be on at maxi-
mum brightness.
â
ãâ
ã
Q
Switch side/
taillights on

41
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SEATS
FRONT SEATS
Moving the seat backwards or forwards (where provided)
Lift the lever (A) (on seat internal side) and push the seat forwards or
backwards: in the driving position the arms should rest on the rim of the
steering wheel.
Driver’s seat lumbar adjustment (where provided)
This gives better support to your back. To adjust, turn the knob (C).
Adjustment and lowering of seat back
Lift the lever (B) and adjust the slope of the seat back.
F0E0629m
Only make adjustments when the car is stationary.WARNING
Once you have released the lever, check that the seat is firmly locked in the
runners by trying to move it back and forth. Failure to lock the seat in place could
result in the seat moving suddenly and the driver losing control of the car.WARNING

42
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
The same lever can be used to lower it, on the rear of the centre seat
back there is a rigid surface that acts as an armrest and table with glass
holders.
Use the same lever to return the seat back to its original position.
When lowering the centre seat back make sure that the seat is pushed
back as far as it will go and that the head restraint is lowered.
Driver’s seat electrical height adjustment (where provided)
This can only be adjusted with the ignition key at MAR.
Use button (A) to adjust the seat height.
REAR SEATS
Adjustment and lowering of seat back
Lift the lever (B) and adjust the slope of the seat back. To lower use the
same lever.
The back of the centre rear seat back has a rigid surface that can be used
as a table with glass holders.
F0E0012m
F0E0013m

43
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
Centre sliding seat (where provided)
Lift the lever (A) and push the seat forwards or backwards. After
releasing the lever, make sure the seat is correctly locked on the runners.
Moving the seats
To increase the boot load capacity the seats have two positions (three
for the centre seat).
To move the seats forward from the standard position, use the special
anchorages on the floor.
To set the centre seat in the most forward position (maximum load
position), bring the centre front seat fully forward and tip the seatback
over.
At this point, refit the rear seat, positioning the seat back as shown in the
figure in its most forward position.
The central seat can be moved backwards by 100 mm.
A - all forward position
B - standard position
C - all backward position
F0E0016m
F0E0232m
F0E0015m

44
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
HEAD RESTRAINTS
FRONT SEATS
To improve passenger safety, the height of the head restraints can be
adjusted. They will automatically lock in the position required.
To raise grip it at the base and pull upwards.
To lower press it downwards from above, keeping button (A) pressed.
When you release the button, check the restraints are firmly locked in
place.
REAR SEATS (where provided)
Only the rear seat head restraints can be removed.
To remove the head restraints:
1 - lift to the first notch
2 - press the two buttons (A) and (B) and remove the head restraints.
The special head restraint configuration interferes intentionally with the
rear passenger back correct positioning in order to oblige the passenger
to raise the head restraint for its proper use.
Remember that head restraints should be adjusted to support your head and not
your neck. Only if they are in this position will they be able to provide effective
protection in the event of a rear-end shunt.WARNING
F0E0231m

45
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
STEERING WHEEL
It can be adjusted vertically.
1) Move lever (A) to position 1.
2) Adjust the steering wheel position.
3) Return the lever to position 2 to lock the wheel in place again.
F0E0018m
All adjustments must be made when the car is stationary.WARNING

46
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
REARVIEW MIRRORS
DRIVING MIRROR
This mirror is adjustable. Move lever (A) to shift the mirror to the
following positions:
1) standard position;
2) anti-dazzle position.
The mirror is also fitted with a safety device that releases the mirror in
the event of a collision.
DOOR MIRRORS
These are divided into two sections.
A - upper mirror that can be adjusted from inside the car;
B - lower mirror that cannot be adjusted.
The fixed part of the left-hand mirror is panoramic, to cover any blind
spots on the left side of the car.
F0E0020m
F0E0021m
F0E0019m

47
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
When driving the mirrors shall always be in position (1).
As the door mirrors are curved, they may slightly alter the perception of distance. The fixed part of the right-hand mirror reflects the
rear right wheel when parking.
This can only be adjusted with the ignition key at MAR.
Use switch (C) to select the mirror (left, neutral, right)
for adjustment.
Press any of the four directions on switch (D) located
on the ceiling light.
Switch (E) electrically controls the movement of the
folding mirrors from position 1 to position 2.
Electrically folding mirrors have a demisting device that
comes on automatically when rear window heating is
turned on.The mirrors can tilt in both directions in the event of a
collision.
To reset the mirror in the correct position, first set it
in the fully closed position by keeping the control
pressed until the mirror stops, then open it.
If the mirror is moved out of its position manually, it is
possible to set it back to the correct position
manually, although it is preferable to move it
electrically. If the mirror is moved out of its position
electrically, it is COMPULSORY to set it back
electrically to its correct position.
If the open mirror makes it difficult to pass through
narrow gaps, fold it from position 1 to position 2.

48
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
HEATING AND CLIMATE CONTROL SYSTEM
F0E0045m
1 Windscreen defrosting/demisting vents - 2 Front side window defrosting/demisting vents - 3 Upper vent to send
air over the heads of the front seat passengers - 4 Directional and adjustable outlets - 5 Vents sending air to feet of
front seat passengers - 6 Directional and adjustable centre vents.

49
SAFETY
DEVICES
CORRECT USE
OF THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICAL
SPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
DIRECTIONAL AND ADJUSTABLE OUTLETS
Use the directional control to adjust the air flow (A). Outlets can be
directed by rotation.
DIRECTIONAL AND ADJUSTABLE VENTS
A - Control for air flow adjustment.
B - Controls to direct the air flow.
F0E0046m
F0E0047m
