Page 21 of 26
20
RADIO
iPOD®CONNECTION
(for versions/markets, where provided)
iPod
®connection
The iPod
®must be connected to the
port B-fig. 7 placed under the radio, close
to the USB port. Lift up the cover to gain
access to the port.
To prevent damage to the
radio system, do not con-
nect to iPod
®port devices
other than audio devices.
Reading lists/Select tracks
Available lists are Artist, Genre and
Playlist (as defined in the iPod
®).
Selection and Navigation are described
in previous phases, from 1 to 5.
Selection of classification and tracks lists
is as described for the USB reader.
WIP Bluetooth ®MODE - Bluetooth®TELEPHONE
Bluetooth®technology allows wireless
communication without any electrical con-
nections (wireless) between your mobile
phone and the hands-free set on the ve-
hicle.
The Bluetooth
®services offered de-
pend on your phone provider, your
SIM card and compatibility between
the devices used; check the available
services in your mobile phone user
handbook and with your service
provider.First mobile phone connection
In order to make the initial connection
between a mobile phone and the hands-
free system, the Bluetooth
®function on the
phone must be activated according to the
instructions (consult the phone instruction
manual). When the function is active, the
icon appears on the display and the tele-
phone researches for Bluetooth
®acces-
sories near the phone.
Press the MENU(O) button to activate
the Bluetooth
®function, then use the ÷
/˜buttons to select, in order:
– Bluetooth telephony - Audio
– Bluetooth configuration.
– Perform a Bluetooth search
“Search in progress..” is shown on the dis-
play followed by the list of the first 4 recog-
nised telephones.
Use the ÷/˜buttons to select the
telephone to connect to in the list and
confirm with OK(N).
WARNINGIt is possible to connect to
only one telephone at a time.
For safety reasons, the Blue-
tooth®connection procedure
between the mobile phone and the
hands-free system must be carried out
only with the vehicle parked and the
ignition key turned to M.
WARNING
603_97_184 SCUDO RADIO GB 1E:Radio Scudo G9 EN 1-07-2009 15:18 Pagina 20
Page 22 of 26
21
RADIO
A keyboard appears on the display
through which you have to dial a code of
at least 4 letters. Confirm the code with
the OK(N) button.
Now, a message of connection accep-
tance will appear on the selected tele-
phone. Dial the previous radio code to
accept and confirm.
If the operation fails, repeat it: the num-
ber of tests is unlimited.
If the operation is successfully completed,
“Connection Telephone_Name Succeeded”
appears on the radio display.
WARNINGSThe authorised auto-
matic connection is activated only after
having configured the telephone. The
phone book and the list of calls are ac-
cessible after timed synchronisation. De-
pending on mobile telephone compatibil-
ity, the “TELEPHONE” menu allows you
to access the “Phone book” function (in
the case of total compatibility only) and
the “List of calls” and “Connection set-
tings” functions.
WARNINGThe initial connection may
also be done by the mobile phone.Receiving a call
A phone called is indicated by an acoustic
warning and a message on the multi-func-
tion display.
Use the ˜or ÷(L) button to se-
lect SI mode on the radio display and con-
firm with OK(N).
The phone call can also be accepted by
holding down(5) button at the end of ra-
dio controls lever on the steering-wheel
for at least two seconds.
Making a call
Press the MENU(Obutton, then
through the ˜/÷buttons select in
sequence:
– Bluetooth telephony - Audio
– Manage the phone call
– Call
– List of calls
or
– Contact list
Use the ˜/÷buttons to select the
number to call in the list and then press
OK(N). Bluetooth
®AUDIO STREAMING
MODE
(for versions/markets, where provided)
This mode allows wireless broadcasting
of music files stored on the mobile phone
through the radio device.
To use this mode, the telephone must
manage the right Bluetooth
® profiles
(A2DP/AVRCP profiles).
The telephone number must
be dialled on the mobile
phone when the vehicle is completely
stationary.
WARNING
Hold down the (5) button at the end of
the radio controls lever on the steering-
wheel for at least two seconds to show
the contact list of the mobile telephone di-
rectly on the radio display.
Use the mobile phone keypad to dial
a telephone number.
603_97_184 SCUDO RADIO GB 1E:Radio Scudo G9 EN 1-07-2009 15:18 Pagina 21
Page 23 of 26
22
RADIO
Mobile phone connection
Make the initial connection to the mo-
bile phone following the instructions
shown in the paragraph “WIP Blue-
toothth
® MODE – Bluetooth®TELE-
PHONE” or, in case of one or more con-
nected mobile phones, press the button
MENU (O) and select the telephone to
connect.
During the initial connection, the audio
system connects automatically.
Streaming mode activation.
Repeatedly press the button SOURCE
(C) and select Streaming mode.
WARNINGSIn some cases, track
reading must be activated with the key-
pad.
Selecting tracks
If the telephone supports the function,
it is possible to select tracks through the
controls on the radio front or through the
controls on the steering-wheel. Contex-
tual information can be shown on the
display
603_97_184 SCUDO RADIO GB 1E:Radio Scudo G9 EN 1-07-2009 15:18 Pagina 22
Page 24 of 26
NOTES
603_97_184 SCUDO RADIO GB 1E:Radio Scudo G9 EN 1-07-2009 15:18 Pagina 23
Page 25 of 26
Fiat Group Automobiles S. p. A. – Customer Services – Technical Services
Service Engineering Largo Senatore G. Agnelli, 5 – 10040 Volvera – Torino (Italia)
Print no. 603.97.184 – 06/2009 – 1 Edition
