REMOVAL AND INSTALLATION
Shock Absorber
Removal
WARNING: All vehicles are equipped with gas pressurized shock absorbers which will
extend unassisted. Do not apply heat or flame to the shock absorbers during removal or
component servicing. Failure to follow these instructions can result in personal injury.
CAUTION: Suspension fasteners are critical parts because they affect performance of vital
components and systems and their failure can result in major service expense. A new part with
the same part number or an equivalent part must be installed, if installation is necessary. Do
not use a part of lesser quality or substitute design. Torque values must be used as specified
during reassembly to ensure proper retention of these parts.
1. Raise the vehicle on a hoist. For additional information, refer to Section 100 - 02 .
2. Remove the wheel and tire assembly. For additional information, refer to Section 204 - 04 .
3. Remove the front brake disc. For additional information, refer to Section 206 - 03 .
4. Remove the bolt and the ABS sensor.
5. Unclip the ABS sensor wire from the bracket.
6. Remove the nut and the ABS sensor wire bracket.
SECTION 204-
01: Front Suspension 2003 Mustang Workshop Manual Klj . 1 ba
52003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

REMOVAL AND INSTALLATION
Spring
Removal
CAUTION: Suspension fasteners are critical parts because they affect performance of vital
components and systems and their failure can result in major service expense. A new part with
the same part number or an equivalent part must be installed, if installation is necessary. Do
not use a part of lesser quality or substitute design. Torque values must be used as specified
during reassembly to ensure proper retention of these parts.
1. Mark the front shock absorber (18124) relative to the protective sleeve with the vehicle in a static, level ground position (curb height).
2. Raise the vehicle on a hoist. For additional information, refer to Section 100 - 02 .
3. Remove the wheel and tire assembly. For additional information, refer to Section 204 - 04 .
4. Remove the cotter pin and nut. Discard the cotter pin.
SECTION 204-
01: Front Suspension 2003 Mustang Workshop Manual Special Tool(s)
Tie-
Rod End Remover
211- 001 (TOOL- 3290-D) or
Equivalent Coil Spring Compressor
204-
D001 (D78P-5310- A) or
Equivalent Klj . 1 ba
82003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

SPECIFICATIONS
SECTION 204-
02: Rear Suspension 2003 Mustang Workshop Manual Torque Specifications
Description Nm lb-
ft lb-
in Mustang
Rear shock absorber (upper attachment) 40 30 —
Rear shock absorber (lower attachment) 80 59 —
Shock absorber clevis bracket-to-
axle nut 108 80 —
Upper arm-
to-frame bolt 97 72 —
Upper arm-
to-axle bolt 111 82 —
Lower arm-
to-body attachment bolt 150 111 —
Lower arm-
to-axle bolt 150 111 —
Stabilizer bar-
to-lower arm bolt 55 41 —
Parking brake cable bracket 55 41 —
Axle damper front bolt 90 66 —
Axle damper rear nut 90 66 —
Axle damper bracket-
to-frame bolt 80 59 —
Pinion bumper mount-
to-body bolts 14 10 —
Bracket assembly-
to-differential housing bolt 48 35 —
Wheel nuts 129 95 —
Cobra
Subframe-to-
body bolts 103 76 —
Subframe-to-
rear bracket bolts 103 76 —
Subframe rear bracket-
to-body bolts 80 59 —
Shock absorber-
to-lower arm and bushing bolts 133 98 —
Shock absorber-
to-body nuts 40 30 —
Upper arm and bushing-
to-subframe nuts 90 66 —
Upper arm and bushing-
to-knuckle nut 90 66 —
Lower arm and bushing-
to-subframe bolts 250 184 —
Lower arm and bushing-
to-knuckle nut 115 85 —
Toe link-
to-subframe nut 48 35 —
Toe link-
to-knuckle nut 48 35 —
Stabilizer bar bracket bolt 55 41 —
Stabilizer bar link nuts 48 35 —
Rear axle differential rear insulator-
to-axle housing bolts 103 76 —
Rear brake disc dust shield-
to-knuckle bolts 10 — 89
Brake line-
to-rear brake caliper bolt 40 30 —
Parking brake cable bracket-
to-lower arm and bushing bolt 15 11 —
ABS sensor bolt 23 17 — Klj . 1 ba
22003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

DESCRIPTION AND OPERATION
Rear Suspension
WARNING: All vehicles are equipped with gas pressurized shock absorbers which will
extend unassisted. Do not apply heat or flame to the shock absorbers during removal or
component servicing. Failure to follow these instructions can result in personal injury.
CAUTION: Suspension fasteners are critical parts because they affect performance of vital
components and systems and their failure can result in major service expense. A new part with
the same part number must be installed if installation becomes necessary. If substitution is
necessary, the part must be of the same finish and property class. Torque values must be used
as specified during reassembly to make sure of correct retention of these parts.
The rear suspension consists of the following components:
zrear spring (4460)
z rear shock absorber (18125)
z rear upper suspension arm and bushings (5500)
„common LH and RH
z rear lower suspension arm and bushings (5A649)
„common LH and RH
z rear stabilizer bar (5A772) (4.6 2V- equipped models only)
z axle drive line vibration dampers (4.6 2V- equipped models only)
Rear Suspension SECTION 204-
02: Rear Suspension 2003 Mustang Workshop Manual Klj . 1 ba
22003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

Removal
CAUTION: Suspension fasteners are critical parts because they affect performance of vital
components and systems and their failure can result in major service expense. A new part with
the same part number must be installed if installation becomes necessary. If substitution is
necessary, the part must be of the same finish and property class. Torque values must be used
as specified during reassembly to make sure of correct retention of these parts.
1. Remove the rear wheel knuckle (5A968/5A969). For additional information, refer to Wheel Knuckle — Cobra in this section.
2. Remove the bolts and the dust shield. Discard the bolts.
3. Position the knuckle in a vise.
4. NOTE: There are two methods for removing the rear hub (1109) from the rear wheel bearing
(1A049). Both methods are shown.
Method one. Using the special tools, remove the hub. Step Plate Adapter Set
205-
DS011 (D80L-630- A) or
Equivalent Klj . 2 ba
62003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

REMOVAL AND INSTALLATION
Wheel Studs
Removal
CAUTION: Suspension fasteners are critical parts because they affect performance of vital
components and systems and their failure can result in major service expense. A new part with
the same part number must be installed if installation becomes necessary. If substitution is
necessary, the part must be of the same finish and property class. Torque values must be used
as specified during reassembly to make sure of correct retention of these parts.
1. Raise the vehicle on a hoist. For additional information, refer to Section 100 - 02 .
2. Remove the wheel and tire assembly. For additional information, refer to Section 204 - 04 .
3. Remove the rear brake disc. For additional information, refer to Section 206 - 04 .
4. Using the special tool, remove and discard the wheel stud.
Installation CAUTION: Do not use air tools to install the wheel stud. The serrations in the hub flange
can be stripped.
1. Install the wheel stud. 1. Position a new wheel stud in the hub flange making sure the serrations on the stud line up with the serrations in the flange.
2. Position washers and a reversed wheel nut on the wheel stud.
3. Tighten the wheel nut until the wheel stud seats on the back of the hub flange.
SECTION 204-
02: Rear Suspension 2003 Mustang Workshop Manual Special Tool(s)
C-
Frame and Clamp Assembly
211- 023 (T74P-3044- A1) Klj . 1 ba
22003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

REMOVAL AND INSTALLATION
Upper Arm
Removal
CAUTION: Suspension fasteners are critical parts because they affect performance of vital
components and systems and their failure can result in major service expense. A new part with
the same part number must be installed if installation becomes necessary. If substitution is
necessary, the part must be of the same finish and property class. Torque values must be used
as specified during reassembly to make sure of correct retention of these parts.
1. Mark the rear shock absorber (18125) relative to the protective sleeve with the vehicle in a static, level ground position (curb height).
2. Raise the vehicle on a hoist. For additional information, refer to Section 100 - 02 .
3. Support the differential housing with a jack stand.
4. Disconnect the upper arm and bushing (5500) from the axle. 1. Remove and discard the nut and bolt.
2. Disconnect the arm and bushing from the axle.
5. Remove the upper arm and bushing from the mounting bracket. 1. Remove and discard the nut and bolt.
2. Remove the arm and bushing.
SECTION 204-
02: Rear Suspension 2003 Mustang Workshop Manual Klj . 1 ba
42003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

REMOVAL AND INSTALLATION
Upper Arm —
Cobra
Removal
CAUTION: Suspension fasteners are critical parts because they affect performance of vital
components and systems and their failure can result in major service expense. A new part with
the same part number must be installed if installation becomes necessary. If substitution is
necessary, the part must be of the same finish and property class. Torque values must be used
as specified during reassembly to make sure of correct retention of these parts.
1. Mark the rear shock absorber (18125) relative to the protective sleeve with the vehicle in a static, level ground position (curb height).
2. Raise the vehicle on a hoist. For additional information, refer to Section 100 - 02 .
3. Remove both wheel and tire assemblies. For additional information, refer to Section 204 - 04 .
4. Remove the rear brake disc. For additional information, refer to Section 206 - 04 .
5. Remove the rear springs (5560). For additional information, refer to Spring — Cobra in this
section.
6. Raise the subframe into position and remove the front bolts.
7. Lower the subframe from the vehicle.
8. Mark the cam bolt position relative to the upper suspension arm and bushing (5500).
SECTION 204-
02: Rear Suspension 2003 Mustang Workshop Manual Klj . 1 ba
52003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

REMOVAL AND INSTALLATION
Lower Arm
Removal
CAUTION: Suspension fasteners are critical parts because they affect performance of vital
components and systems and their failure can result in major service expense. A new part with
the same part number must be installed if installation becomes necessary. If substitution is
necessary, the part must be of the same finish and property class. Torque values must be used
as specified during reassembly to make sure of correct retention of these parts.
1. Mark the rear shock absorber (18125) relative to the protective sleeve with the vehicle in a static, level ground position (curb height).
2. Remove the muffler assembly(ies). For additional information, refer to Section 309 - 00 .
3. Remove the rear spring (5560). For additional information, refer to Spring — Coil in this section.
4. Remove the lower suspension arm and bushing (5A649) from the body attachment. 1. Remove and discard the bolt and nut.
2. Remove the lower arm.
Installation 1. Install the lower suspension arm and bushing to the body attachment. 1. Position the lower arm. 2. Install a new bolt and a new nut. Do not tighten at this time. SECTION 204-
02: Rear Suspension 2003 Mustang Workshop Manual Klj . 1 ba
22003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

REMOVAL AND INSTALLATION
Stabilizer Bar
Removal
CAUTION: Suspension fasteners are critical parts because they affect performance of vital
components and systems and their failure can result in major service expense. A new part with
the same part number must be installed if installation becomes necessary. If substitution is
necessary, the part must be of the same finish and property class. Torque values must be used
as specified during reassembly to make sure of correct retention of these parts.
1. Raise the vehicle. For additional information, refer to Section 100 - 02 .
2. Disconnect the anti- lock brake sensor wires from the brackets.
3. Remove the parking brake cable brackets. 1. Remove and discard the bolts.
2. Remove the parking brake cable brackets.
4. Remove the bolts and the stabilizer bar (5A772). Discard the bolts.
SECTION 204-
02: Rear Suspension 2003 Mustang Workshop Manual Klj . 1 ba
32003 Mustang Workshop Manual
17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...
