Youshouldhavereceivedakey
number tag with your keys. You will
need this key number if you ever
have to get a lost key replaced. Use
only Honda-approved key blanks.These keys contain electronic
circuits that are activated by the
immobilizer system. They will not
work to start the engine if the
circuits are damaged.
Protect the keys f rom direct
sunlight, high temperature, and
high humidity.
Donotdropthekeysorsetheavy
objects on them.
Keep the keys away f rom liquids.
If they get wet, dry them
immediately with a sof t cloth.
The valet key does not contain a
battery. Do not try to take it apart.
The master key fits all the locks on
your vehicle. The valet key works
only in the ignition and the driver’s
door lock. You can keep the glove
boxlockedwhenyouleaveyour
vehicle and the valet key at a parking
f acility.
Keys and Locks
77
KEY
NUMBER
TAG
VALET
KEY
(Gray)
MASTER KEY
WITH REMOTE
TRANSMITTER

Inst rument s and Cont rols

2012 Crosstour

If the system repeatedly does not
recognize the coding of your key,
contact your dealer.
If you lose your key and you cannot
start the engine, contact your dealer.
When you turn the ignition switch to
the ON (II) position, the immobilizer
system indicator should come on
brief ly, then go of f . If the indicator
starts to blink, it means the system
does not recognize the coding of the
key. Turn the ignition switch to the
LOCK (0) position, remove the key,
reinsert it, and turn the ignition
switch to the ON (II) position again.
The system may not recognize your
key’s coding if another immobilizer
key or other metal object (i.e. key
chain) is near the ignition switch
when you insert the key. The immobilizer system protects
your vehicle f rom thef t. If an
improperly coded key (or other
device) is used, the engine’s f uel
system is disabled.
Do not attempt to alter this system
or add other devices to it. Electrical
problems could result that may make
your vehicle inoperable.As required by the FCC:
This device complies with Part 15 of theFCC rules. Operation is subject to thef ollowing two conditions: (1) This devicemay not cause harmf ul interf erence, and(2) this device must accept anyinterf erence received, includinginterf erence that may cause undesiredoperation.
Changes or modif ications not expresslyapproved by the party responsible f orcompliance could void the user’sauthority to operate the equipment.
This device complies with IndustryCanada Standard RSS-210.Operation is subject to the f ollowing twoconditions: (1) this device may not causeinterf erence, and (2) this device mustaccept any interf erence that may causeundesired operation of the device.
Immobilizer System
78
Always take the ignition key with you
whenever you leave the vehicle alone.

Inst rument s and Cont rols

2012 Crosstour

µ
µ
µ
µ You will hear a reminder beeper if
you leave the key in the ignition
switch in the LOCK (0) or the
ACCESSORY (I) position and open
the driver’s door. Remove the key to
turn of f the beeper.
If the f ront wheels are turned, the
anti-theft lock may make it difficult
to turn the key. Firmly turn the
steering wheel to the lef t or right as
you turn the key.
Use this position
only to start the engine. The switch
returns to the ON (II) position when
you let go of the key. This is the normal key
position when driving. Several of the
indicators on the instrument panel
come on as a test when you turn the
ignition switch f rom the
ACCESSORY (I) to the ON (II)
position. You can
operate the audio system and the
accessory power sockets in this
position.
You can insert or
remove the key only in this position.
To turn the key, the shift lever must
be in Park, and you must push the
key in slightly. TheshiftlevermustbeinPark
bef ore you can remove the key f rom
the ignition switch.
The ignition switch has f our
positions: LOCK (0), ACCESSORY
(I), ON (II), and START (III). ST A RT (III) ON (II) A CCESSORY (I)
LOCK (0)
Ignition Switch
79

Inst rument s and Cont rols

2012 Crosstour

When the door is unlocked, you can
seetheredindicatoronthelocktab
above the inner door handle.
To lock all doors and the tailgate,
push the f ront of the master door
lock switch on either f ront door, pull
the lock tab rearward on the driver’s
door, or use the key on the outside
lock on the driver’s door.
Pushing the rear of either master
door lock switch will unlock all doors
and the tailgate. Pushing f orward the
lock tab on the driver’s door unlocks
only that door.
All doors and the tailgate can be
locked f rom the outside by using the
key in the driver’s door lock. To
unlock only the driver’s door, insert
the key, turn the key, and release it.
The remaining doors and the tailgateunlock when you turn the key a
second time within a f ew seconds.
Youcanopenorclosethewindows
and the moonroof by using the key
in the driver’s door (see page ).
To lock any passenger’s door when
getting out of the vehicle, pull the
lock tab rearward and close the door.
To lock the driver’s door, remove the
key f rom the ignition switch, pull the
locktabrearwardorpushthefront
of the master switch, then close the
door.
Locking and unlocking the driver’s
door will also lock and unlock the
f uel f ill door (see page ).
The lock tab on each passenger’s
door locks and unlocks that door. 108
283
Door L ocks
80
POWER DOOR LOCK MASTER SWITCH
RED INDICATORLock
Unlock
Lock
Unlock LOCK TAB

Inst rument s and Cont rols

2012 Crosstour

The auto door locking f eature has
three possible settings:The auto door locking is
deactivated all the time.
When you customize the setting,
make sure your vehicle is parked
saf ely, the engine is of f , and the
parking brake is applied. Make all
settings bef ore you start driving.
With any door and the tailgate open
and the key in the ignition, locking
with the master door lock switch is
disabled. The lock tab on the driver’s
door is not disabled if the driver’s
door is closed. Pulling the driver’s
lock tab rearward will lock all doors
and the tailgate. If you try to lock an
open driver’s door by pulling the lock
tab rearward, the lock tab on the
driver’s door pops out and unlocks
the driver’s door.
Your vehicle has customizable
settings f or the doors and tailgate to
automatically lock and unlock. There
are default settings for each of these
f eatures. You can turn of f or change
the settings for these features as
described on the f ollowing pages. The doors and tailgate lock
whenever you move the shif t lever
out of the Park (P) position.
The doors and tailgate lock when
the vehicle speed reaches 10 mph
(15 km/h).
This is the def ault setting.
CONT INUED
L ockout Prevent ionA uto Door L ocking
A uto Door L ocking/Unlocking
Door L ocks
81
NOTE: When customizing a setting,
use the appropriate remote transmitter
(Driver 1 or Driver 2).
T o customize, remove the master key
with the remote transmitter, and press
the UNLOCK button once.

Inst rument s and Cont rols

2012 Crosstour

Turn the ignition switch to the ON
(II) position, and open the driver’s
door.Pushandholdthefrontof the
master door lock switch on the
driver’s door until you hear a click
(af ter about 5 seconds).
Turn the ignition switch to the ON
(II) position, and make sure to
close the driver’s door.
Make sure the shif t lever is in the
Park (P) position. Release the switch, and within 20
seconds, turn the ignition switch
to the LOCK (0) position.
Make sure the shif t lever is in the
Park (P) position.
1.
2.
1.
2. 3.
4.
Locks all doors and tailgate when the
shif t lever is moved out of the Park (P)position.
To program the Park Lock mode:
To turn of f the
Auto

Door Lock modes:
Door L ocks
82

Inst rument s and Cont rols

2012 Crosstour

Pushandholdthefrontof the
master door lock switch on the
driver’s door. You will hear a click.
Keep holding the switch until you
hear another click (after about 5
seconds).
Release the switch, and within 20
seconds, turn the ignition switch
to the LOCK (0) position.Turn the ignition switch to the ON
(II) position, and make sure to
close the driver’s door. Make sure the shif t lever is in the
Park (P) position.Push and hold the brake pedal,
and move the shif t lever out of the
Park (P) position.
Pushandholdthefrontof the
master door lock switch on the
driver’s door. You will hear a click.
Keep holding the switch until you
hear another click (after about 5
seconds).
Release the switch, and within 20
seconds, turn the ignition switch
to the ACCESSORY (I) position.
Move the shift lever to the Park
(P) position.
Turn the ignition switch to the
LOCK (0) position.
1.
2. 3.
4.
5.
6.
3.
4.
Locks all doors and tailgate when the
vehicle’s speed reaches about 10 mph(15 km/h).
T o program t he Drive L ock mode:
Door L ocks
83

Inst rument s and Cont rols

2012 Crosstour

The auto door unlocking f eature
has f ive possible settings:Turn the ignition switch to the ON
(II) position, and open the driver’s
door.Pushandholdtherearof the
master door lock switch on the
driver’s door. You will hear a click,
and after about 5 seconds, you will
hear another click.
Make sure the shif t lever is in the
Park (P) position.
The auto door unlocking is
deactivated all the time.
The driver’s door unlocks when
you move the shif t lever to the
Park (P) position with the brake
pedal depressed.
This is the def ault setting.
All doors and tailgate unlock when
you move the shif t lever to the
Park (P) position with the brake
pedal depressed.
The driver’s door unlocks
whenever you turn the ignition
switch to the ACCESSORY (I)
position.
All doors and tailgate unlock
whenever you turn the ignition
switch to the ACCESSORY (I)
position. Release the switch, and within 20
seconds, turn the ignition switch
to the LOCK (0) position.
1.
2. 3.
4.
A uto Door Unlocking
To turn of f the
Auto Door Unlock modes:
Door L ocks
84

Inst rument s and Cont rols

2012 Crosstour

Pushandholdtherearof the
master door lock switch on the
driver’s door. You will hear a click.
Continue to hold the switch:Until you hear another click
(af ter about 5 seconds) to
activate
Turn the ignition switch to the ON
(II) position, and make sure to
close the driver’s door.
Make sure the shif t lever is in the
Park (P) position.
Turn the ignition switch to the ON
(II) position, and make sure to
close the driver’s door. Make sure the shif t lever is in the
Park (P) position.
Or, until you hear two more
clicks (af ter about 10 seconds)
to activate
.
Release the switch, and within 20
seconds, turn the ignition switch
to the LOCK (0) position.
1.
2. 1.
2.
3.
4.
driver’s door unlock
feature.
Unlocks the driver’s door or all doors
and tailgate when the shif t lever ismoved to Park (P) position with thebrake pedal depressed. Unlocks the driver’s door or all doors
and tailgate when the ignition switch ismoved out of the ON (II) position.
all doors and tailgate
unlock f eature
CONT INUED
To program the Park Unlock mode: To program the Ignition
Door L ocks
85

Inst rument s and Cont rols
Switch Unlock mode:

2012 Crosstour

Turn the ignition switch to the
LOCK (0) position.
Until you hear another click
(af ter about 5 seconds) to
activate
Pushandholdtherearof the
master door lock switch on the
driver’s door. You will hear a click.
Continue to hold the switch: Even if your vehicle’s battery is
removed or goes dead, the system
keeps the auto door lock/unlock
setting which you selected.
Push and hold the brake pedal,
then move the shift lever out of
the Park (P) position.
Or, until you hear two more
clicks (af ter about 10 seconds)
to activate
.
Release the switch, and within 20
seconds, turn the ignition switch
to the ACCESSORY (I) position.
Move the shift lever to the Park
(P) position.
4. 5.
6.
3.
driver’s door unlock
feature.
all doors and tailgate
unlock f eature
Door L ocks
86

Inst rument s and Cont rols

2012 Crosstour
