CONTROLS AND EQUIPMENT1- 65
JB580B2-A CARE OF DISC Proper Handling Handle your disc as shown. Do not drop the disc. Hold the disc so you will not leave fingerprints onthe surface. If the surface is scratched, it maycause the pickup to skip signal tracks. Do notaffix tape, paper, or gummed labels on the disc.Do not write on the disc. Damaged Disc Do not attempt to play damaged, warped or cracked discs. It could severely damage theplayback mechanism. Storage When not in use, place your discs in their indi- vidual case and store them in a cool place awayfrom the sun, heat, and dust.
Do not grip or pull out the disc with your handwhile the disc is being pulled into the unit by theSelf Loading mechanism. Keep Your Discs Clean
SR040B1-F Care of Cassette Tapes Proper care of your cassette tapes will extend the tape life and increase your listening enjoy-ment. Always protect your tapes and cassettecases from direct sunlight, severe cold and dustyconditions. When not in use, cassettes shouldalways be stored in the protective cassette casein which they were originally supplied. When thevehicle is very hot or cold, allow the interiortemperature to become more comfortable beforelistening to your cassettes.
o Never leave a cassette inserted in the player
when not being played. This could damage the tape player unit and the cassette tape.
o We strongly recommend against the use of tapes longer than C-60 (60 minutes total).Tapes such as C-120 or C-180 are very thinand do not perform as well in the automotiveenvironment.
Fingerprints, dust, or soil on the surface couldcause the pickup to skip signal tracks. Wipe thesurface clean with a clean soft cloth. If the sur-face is heavily soiled, dampen a clean soft clothin a solution of mild neutral detergent to wipe itclean.
B850A01L
B850A02L
B860A01L

CONTROLS AND EQUIPMENT
1- 66
o Be sure that the cassette label is not loose or
peeling off or tape ejection may be difficult.
o Never touch or soil the actual audio tape surfaces.
o Keep all magnetized objects, such as electric motors, speakers or transformers away from your cassette tapes and tape player unit.
o Store cassettes in a cool, dry place with the open side facing down to prevent dust fromsetting in the cassette body.
o Avoid repeated fast reverse usage to replay one given tune or tape section. This cancause poor tape winding to occur, and even-tually cause excessive internal drag and pooraudio quality in the cassette. If this occurs, itcan sometimes be corrected by fast windingthe tape from end to end several times. If thisdoes not correct the problem, do not continueto use the tape in your vehicle.
HGK062-D
o The playback head, capstan and pinch rollerswill develop a coating of tape residue that can result in deterioration of sound quality, suchas a wavering sound. They should be cleanedmonthly using a commercially available headcleaning tape or special solution availablefrom audio specialty shops. Follow thesupplier's directions carefully and never oilany part of the tape player unit.
o Always be sure that the tape is tightly wound on its reel before inserting in the player.Rotate a pencil in the drive sprockets to windup any slack.
Head
Cotton applicatorSSAR042B
NOTE: Look at a tape before you insert it.If the tape is loose, tighten it by turning one ofthe hubs with a pencil or your finger.If the label is peeling off, do not put it in theplayer. It may cause the tape jam in the drivemechanism when you try to eject it.Do not leave tape sitting where they are ex-posed to hot warm or, high humidity, such ason top of the dashboard or in the player.If a tape is exposed to excessively hot or cold,let it reach a moderate temperature beforeputting it in the player.
B860A04A

CONTROLS AND EQUIPMENT1- 67
B870A01A-GAT ANTENNA Fixed Rod Antenna Your car uses a fixed rod antenna to receive both AM and FM broadcast signals.This antenna is a removable type. To remove theantenna, turn the antenna counterclockwise. Toinstall the antenna, turn the antenna clockwise. CAUTION: Be sure to remove the antenna before wash-ing the car in an automatic car wash or theantenna may be damaged.
B870A01F

DRIVING YOUR HYUNDAI 2- 1
SC000A1-E
2. DRIVING YOUR HYUNDAI
2
C010A01O-EAT
WARNING: ENGINE EXHAUST CAN BE DANGEROUS!
Engine exhaust gases are potentially lethal. If at any time engine exhaust gas is detected within the passenger compartment, move the vehicle to an open area and open all windows. o Never inhale exhaust gas. Exhaust gases contain Carbon Monoxide which is colourless and odourless. Carbon Monoxide is poisonous and can cause unconsciousness and death by asphyxiation. o Exhaust System Maintenance. Ensure that the exhaust system is maintained in good condition and is free from excessive corrosion and damage which may result in leakage. If the vehicle is driven over an object which strikes the exhaust system, ensure that the exhaustsystem is inspected at the first available opportunity to ensure that no leakage exists. o Confined Areas. Do not run the engine in confined spaces, allowing the engine to idle in a garage, even when the doors are open is dangerous practice. Only start the engine immediately prior to moving the vehicle out of the garage. o Prolonged Idling. If it is necessary to allow the vehicle to idle for prolonged periods, ensure that the heating system air intake control is set to the "Fresh" position, the blower is set to high speed operation and that the vehicle is standing in an open area. o Load Carrying. If it is necessary to carry long objects which do not permit the hatchback door to be fully closed, the side windows must remain closed and the heating air intake control set to the "Fresh" position with the blower running at the highest speedsetting. To ensure correct operation of the heater system, the air intake grilles at the base of the windscreen must not be obstructed by snow leaves etc..

DRIVING YOUR HYUNDAI
2- 2 SC030A1-E
BEFORE STARTING THE ENGINE
Before you start the engine, you should always:
1. Look around the vehicle to be sure there are no flat tires, puddles of oil or water or other indications of possible trouble.
2. After entering the car, check to be sure the parking brake is engaged.
3. Check that all windows, and lights are clean.
4. Check that the interior and exterior mirrors are clean and in position.
5. Check your seat, seatback and head re- straint to be sure they are in their properpositions.
6. Close all the doors.
7. Fasten your seat belt and be sure that all other occupants have fastened theirs.
8. Turn off all lights and accessories that are not needed.
9. When you turn the ignition switch to "ON' check that all appropriate warning lights are operating and that you have sufficient fuel.
10.Check the operation of warning lights and all bulbs when key is in the "ON" position. o To start the engine, insert the ignition key
and turn it to the "START" position. Releaseit as soon as the engine starts. Do not holdthe key in the "START" position for more that15 seconds.
NOTE: For safety, the engine will not start if the shift lever is not in "P" or "N" Position (AutoT/A).
SC040A1-F
COMBINATION IGNITION SWITCH AND STEERING LOCK To Start the Engine
o If your Hyundai is equipped with a manual
transaxle, place the shift lever in neutral and depress the clutch pedal fully.
o If your Hyundai has an automatic transaxle, place the shift lever in "P" (park). SC050A2-E
KEY POSITIONS WARNING:
The engine must never be turned off and the key removed from the ignition key cylinderwhilst the vehicle is in motion since thesteering lock will operate and control of thevehicle will be lost. "START"
The engine is started in this position. It willcrank until you release the key. NOTE: Do not hold the key in the "START" position for more than 15 seconds.
"ON" When the key is at the "ON" position, the ignition and all accessories are available for use. If theengine is not running, the key should not be leftat this position since the battery will becomedischarged and damage to the ignition systemmay also result. For information regarding en-gine starting, refer to "STARTING THE EN-GINE". "ACC" When the ignition key is at the "ACC" position, the radio and other accessories may be used. "LOCK" The ignition key may only be inserted or removed at this position.
C040A01E
LOCK
ACC
ON
START

DRIVING YOUR HYUNDAI 2- 3
SB050B1-E
STEERING WHEEL LOCK
When the key is removed, the steering column
lock will be activated and will engage when the steering wheel is turned to the appropriate po-sition. It is not necessary to turn the wheel untillocked each time the key is removed since inthe event of any unauthorized attempt at re-moval, the lock will become effective as soonas the steering wheel is turned. To unlock thesteering, insert the key and turn to the "ACC"position. If the steering is locked, it may benecessary to rock the steering wheel slightly tofacilitate turning the key. Under no circum-stances should the key be forced since break-age of the key will occur. SC060A1-E
STARTING THE ENGINE
C050A01E
SC090D1-F
To Remove the Ignition Key
1. Turn the ignition key to the "ACC" position.
2. Simultaneously push and turn the ignition key counterclockwise from the "ACC" posi-tion to the "LOCK" position.
3. The key can be removed in the "LOCK" position.C070C01E
LOCK ACC
ON
START LOCK
ON
START
1. Ensure that the transaxle is in neutral and that the clutch pedal is held depressed (manual transaxle) or the transaxle selectoris at the "P" position (automatic transaxlevehicle).
2. Turn the ignition key to and hold at the "Start" position until the engine starts. Whenthe engine has started, release the key.

DRIVING YOUR HYUNDAI
2- 4 SC060B1-E FUEL ECONOMY
The following suggestions are made to assist in
achieving the greatest degree of fuel economy.
o Maintaining a constant check on fuel con- sumption will enable the most economical use pattern and driving style to be adopted.
o Avoid using the vehicle for very short jour- neys if possible, particularly when a coldstart is involved.
o Ensure that tyre pressures are maintained at the correct level.
o Use only the recommended grade of fuel.
o Avoid carrying unnecessary weight, and if a roof rack is in use, remove it as soon as possible after use.
o Anticipate the road and conditions ahead to enable adjustments in speed to be madesmoothly. Avoid heavy acceleration and sharpbraking.
o Avoid cruising at unnecessary high speeds.
o Always ensure that the periodic maintenance services are performed by a Hyundai dealer
at the time and/or mileage intervals speci-fied.
o Use the air conditioning only when neces- sary.
NOTE: Do not operate the starter for more than 15
seconds continuously or continue to oper- ate the starter after the engine has started toavoid damaging the starter motor. If theengine makes a false start, allow it and thestarter motor to come to rest before at-tempting to start the engine again. Neverattempt to start the engine with the transaxlein gear. Do not depress the accelerator pedalwhilst starting the engine. Allow the engineto idle for 20 seconds or so before drivingthe vehicle.
CAUTION: Do not leave the vehicle unattended whilst
idling. Never allow the vehicle to idle or warm up in a confined space (ie garage)longer than is necessary to move the vehi-cle into an open area. C070A01GK-EAT MANUAL TRANSAXLE The five speed fully synchronized transaxle is controlled by a floor mounted shift lever uponwhich the shift pattern is indicated. It is importantthat when changing gear, the clutch pedal is fullydepressed to avoid transaxle damage.
HGK242
Mis-shift preventiontab
HGK181
A Type B Type
B Type

DRIVING YOUR HYUNDAI 2- 5
1-2 2-3 3-44-5 5-6
When shifting into reverse gear, pull the miss-
shift prevention tab and shift into reverse gear position. (B Type : 6 speed type) CAUTION:
o Do not attempt to engage reverse gear when the car is in motion.
o To avoid damaging the selector mecha- nism, do not use the gear shift lever as a hand rest. Release the lever immediatelythe shift is completed.
o To avoid premature clutch wear, do not use the clutch pedal as a foot rest, and donot hold the vehicle on a gradient usingthe clutch.
o Ensure that the engine is not over-revved by upshifting before the tachometer needleenters the red zone.
o Do not coast with the shift lever at the neutral position.
o When descending long gradients, make use of the engine braking to assist thefootbrake to avoid brake fade or over-heating.
o When slippery conditions are encountered, increased caution should be exercisedwhen gear changing, braking or ac-celerating. Abrupt changes in speed maycause a loss of traction or control of thevehicle. NOTE:
o During cold weather, shifting may be dif- ficult until the transaxle lubricant haswarmed up. This is normal and not harm-ful to the transaxle.
o If you 've come to a complete stop and it's hard to shift into 1 st
or R(Reverse),
put the shift lever in N(Neutral) positionand let up on the clutch. Press the clutchpedal back down, and then shift into 1 st
or R(Reverse) gear position.
o Do not use the shift lever as a handrest during driving, as this can result in pre-mature wear of the transaxle shift forks.
SC090B1-F
Using the Clutch The clutch should be pressed all the way to the
floor before shifting, then released slowly. Donot rest your foot on the clutch pedal whiledriving.
This can cause unnecessary wear. Do not partially engage the clutch to hold the
car on an incline. This causes unnecessary wear.
Use the parking brake to hold the car on an
incline. Do not operate the clutch pedal rapidlyand repeatedly. C070E02GK-AAT
RECOMMENDED SHIFT POINTS
The shift points as shown below are recom-
mended for optimum fuel economy and perfor-mance.
1-2 2-33-4 4-5
Shift
from-to Recommended
15 mph (20 km/h) 25 mph (40 km/h) 35 mph (55 km/h) 45 mph (75 km/h)
Shift
from-to Recommended
10 mph (15 km/h) 20 mph (35 km/h)30 mph (50 km/h) 45 mph (70 km/h) 60 mph (95 km/h)
A Type (5 speed) B Type (6 speed)

DRIVING YOUR HYUNDAI
2- 6 The first few shifts on a new vehicle, or if the battery has been disconnected, may besomewhat abrupt. This is a normal condi-tion, and the shifting sequence will adjustafter shifts are cycled a few times by theT.C.M (Transaxle Control Module). CAUTION: Never shift into "R" or "P" position while the vehicle is moving. The indicator lights in the instrument cluster indicate the selector lever position when theignition is switched "ON". During "D" or sportsmode operation, the gear currently in use dis-plays in the numeral indicator.
C090A02L-D
C090B01A-AAT
The function of each position is as follows:
o P (Park): Use to hold the vehicle in place when parked or while starting the engine. Whenever parking thecar, apply the parking brake and shift the selec-tor lever to the "P" (Park) position. CAUTION: Never place the selector lever in the "P"(Park) position unless the vehicle is fullystopped. Failure to observe this caution willcause severe damage to the transaxle. C090C01A-AAT
o R(Reverse): Use for backing up the vehicle. Bring the car to a complete stop before shifting the selectorlever to "R" position. C090D02O-AAT
o N (Neutral): In the "N" position, the transaxle is in neutral, which means that no gears are engaged. Theengine can be started with the shift lever in "N"position, although this is not recommended ex-cept if the engine stalls while the car is moving.
HGK174-D
C090A04Y-GAT
AUTOMATIC TRANSAXLE
The highly efficient Hyundai automatic transaxle
has four forwards speeds and one reverse speed. The individual speeds are selected au-tomatically, depending on the position of thespeed selector lever. The selector lever has 2gates; the main gate and the manual gate.
NOTE: For information on manual gate operation,
refer to "Sports Mode".
In the main gate, the selector lever has 4
positions, and is equipped with a button to avoid inadvertent wrong selection.
NOTE: Depress the brake pedal and push the
button when shifting.
Push the button when shifting. The selector lever can be shifted freely.

DRIVING YOUR HYUNDAI 2- 7
C090F02GK-GAT
Sports Mode
HGK175-D
Whether the vehicle is stationary or in motion, sports mode is selected by pushing the selectorlever from the "D" position into the manual gate.To return to "D" range operation, push theselector lever back into the main gate. In sports mode, moving the selector lever back- wards and forwards can make rapid gearshiftssimple. In contrast to a manual transaxle, thesports mode allows gearshifts with the accel-erator pedal depressed. UP (+) : Push the lever forward once to shift up
one gear.DOWN (-) : Pull the lever backwards once to
shift down one gear.
C090E01O-AAT
o D(Drive):
Use for normal driving. The transaxle will auto-
matically shift through a four gear sequence.
C090H01L-GAT
NOTE:
o For smooth and safe operation, depress the brake pedal when shifting from "Neu- tral" position or "Park" position to a for-ward or reverse gear.
o The ignition key must be in the "ON" position and the brake pedal fully de-pressed in order to move the shift leverfrom the "P" (Park) position to any of theother positions.
o It is always possible to shift from "R", "N", "D" position to "P" position. Thevehicle must be fully stopped to avoidtransaxle damage.
CAUTION:
o In sports mode, the driver must execute shifts in accordance with prevailing roadconditions, taking care to keep the en-gine speed below the red zone.
o For engine protection, upward shifts are made automatically when the engine rpmreaches the red zone.
o By rapidly moving the selector lever back- wards (-) twice it is possible to skip onegear by using the sports mode. Sincesudden engine braking and/or rapid ac-celeration can cause a loss of traction,however, downshifts must be made care-fully in accordance with the vehicle'sspeed.
NOTE:
o In sports mode, only the four forward gears can be selected. To reverse or parkthe vehicle, move the selector lever tothe "R" or "P" position as required.
o In sports mode, downward shifts are made automatically when the vehicleslows down. When the vehicle stops, 1stgear is automatically selected.
o To maintain the required levels of vehicle performance and safety, the system maynot execute certain gearshifts when theselector lever is operated. o Before driving away from a stop on a
slippery road, push the selector leverforward into the +(UP) position. Thiscauses the transaxle to shift into 2ndgear which is better for smooth drivingaway on a slippery road. Push the selec-tor lever to the -(DOWN) side to shiftback to 1st gear.
