Hyundai Coupe 2003 Owner's Manual

DRIVING YOUR HYUNDAI
2- 8 when you are driving down a long hill, slow down and shift to a lower gear. When you dothis, engine braking will help slow the car.
o Slow down before shifting to a lower gear. Otherwise, the lower gear may not be en-gaged.
o Always use the parking brake. Do not de- pend on placing the transaxle in "P" to keepthe car from moving.
o Exercise extreme caution when driving on a slippery surface. Be especially careful whenbraking, accelerating or shifting gears. On aslippery surface, an abrupt change in vehi-cle speed can cause the drive wheels tolose traction and the vehicle to go out ofcontrol.
WARNING:
o Avoid high cornering speeds.
o Do not make quick steering wheel move- ments, such as sharp lane changes or fast, sharp turns.
o Always wear your seat belts. In a collision crash, un unbelted personis significantly more likely to die than aperson wearing a seatbelt.
o The risk of rollover is greatly increased if you lose control of your vehicle at high-way speeds.
o Loss of control often occurs if two or more wheels drop off the roadway andthe driver oversteers to reenter the road-way. o In the event your vehicle leaves the road-
way, do not steer sharply. Instead, slowdown before pulling back into the travellanes.
o Never exceed posted speed limits. SC140A1-E EFFECTIVE BRAKING Braking system performance and friction mate- rial life are greatly affected by the driving styleadopted. The following suggestions are made toassist in achieving the best results from thebraking system.
o Anticipate the road and conditions ahead in order that heavy braking may be avoided.
o When descending long gradients, use the engine to assist in retarding the vehicle to minimize the possibility of brake fade occur-ring.
o When trailer towing, ensure that the trailer brakes function correctly and use enginebraking to assist the vehicle braking system.
o Use only genuine Hyundai replacement brake pads and shoes to ensure consistentfriction characteristics and wear rates.
o After driving through deep water (e.g. fording), the brakes may become wet andperformance reduced. Always check brakeefficiency after emerging from the water anddry the brakes by lightly depressing thebrake pedal several times whilst driving slow-ly.
C090I01L-GAT
CAUTION:
o Shift into "R" and "P" position only when the vehicle has completely stopped.
o Do not accelerate the engine in reverse or any of the forward positions with the brakes applied.
o Always apply the footbrake when shift- ing from "P" or "N", to "R", "D"position.
o Do not use the "P" (Park) position in place of the parking brake. Always setthe parking brake, shift the transaxle into"P" (Park) position and turn off the igni-tion when you leave the vehicle, evenmomentarily. Never leave the vehicleunattended while the engine is running.
o Check the automatic transaxle fluid level regularly, and add fluid as necessary.
C090N02O-AAT
Good Driving Practices
o Never move the gear selector lever from "P" or "N" to any other position with the acceler- ator pedal depressed.
o Never move the gear selector lever into "P" when the vehicle is in motion.
o Be sure the car is completely stopped be- fore you attempt to shift into "R".
o Never take the car out of gear and coast down a hill. This may be extremely hazard-ous. Always leave the car in gear whenmoving.
o Do not "ride" the brakes. This can cause them to overheat and malfunction. Instead,

DRIVING YOUR HYUNDAI 2- 9
o Apply the parking brake only when the vehi-
cle is at rest.
o Since the power assistance provided by the brake servo is derived from the engine, coasting with the engine turned off or towingof the vehicle with the engine turned off willresult in greatly increased pedal pressuresbeing required to stop the vehicle.
o Do not hold the vehicle on the upgrade with the accelerator pedal. This can cause thetransaxle to overheat. Always use the brakepedal or parking brake.
SC140B1-E
ANTI-LOCK BRAKE SYSTEM (Not all models)
The Anti-Lock Brake System (ABS) is designed
to prevent wheel lock-up during sudden braking or on hazardous road surfaces. The ABS con-trol module monitors the wheel speed and con-trols the pressure applied to each brake. Thus,in emergency situations or on slick roads, ABSwill increase vehicle control during braking.
NOTE: During ABS operation, a slight pulsation
may be felt in the brake pedal when the brakes are applied. Also, a noise may beheard in the engine compartment while brak-ing. These conditions are normal and indi-cate that the anti-lock brake system is func-tioning properly. WARNING: ABS will not prevent accidents due to im-
proper or dangerous driving manoeuvres. Even though vehicle control is improvedduring emergency braking, always maintaina safe distance between you and objectsahead. Vehicle speeds should always bereduced during extreme road conditions.
The braking distance for cars equipped with
an anti-lock braking system may be longerthan for those without it in the followingroad conditions.
o Rough, gravel or snow-covered roads.
o With tire chains installed.
o On roads where the road surface is pit- ted or has different surface height.
These roads should be driven at reduced
speeds. The safety features of an ABS equipped vehicle should not be tested byhigh speed driving or cornering. This couldendanger the safety of yourself or others. C300A03Y-EAT
TRACTION CONTROL SYSTEM (TCS) (Not all models)
HGK156A-D
On slippery road surfaces, the traction control system (TCS) limits the drive wheels from spin-ning excessively, thus helping the car to accel-erate. It also provides sufficient driving forceand steering performance as the car turns ataccelerated speeds.
SLIP Control Limits the drive wheels from spinning exces-sively during starting or while making accelerat-ed turns on slippery roads to avoid losing thedriving force of the front wheels.
Driving hints TCS does not actively apply brakes. Be sure todecelerate the car sufficiently before enteringcurves.

DRIVING YOUR HYUNDAI
2- 10 C310D01O-AAT
Indicators and Warning The indicators should illuminate when the igni-
tion key is turned to ON or START but should go out after three seconds.
If the indicators do not illuminate, or the TCS or
TCS-OFF indicator does not go out after 3seconds, have it checked by an authorizeddealer.
Should there be any unusual conditions in the
device while driving, TCS-OFF indicator illumi-nates as a warning.
If TCS-OFF indicator illuminates, pull your car
to a safe place and stop the engine. Then, start the engine again to check if the
TCS-OFF indicator goes out.
If the indicator remains lit even after the engine
has been started, have your car checked by anauthorized Hyundai dealer. effect of brake control and indicates noth-ing unusual.
3) When the engine starts, a click is heard from the engine compartment; however,this is only the sound of traction controlbeing checked.
4) When moving out of the mud or fresh snow, pressing the accelerator pedal maynot cause the engine speed to increasedue to TCS operation. NOTE:
1) When the TCS-OFF indicator illuminates,
traction control is automatically deacti- vated for safety.
2) This warning function is not provided when the driver selects the TCS-OFFmode.
SC150A1-F DRIVING FOR ECONOMY You can save fuel and get more miles from your car if you follow these suggestions:
o Drive smoothly. Accelerate at a moderate rate. Don't make "jack-rabbit" starts or full- throttle shifts and maintain a steady cruisingspeed. Don't race between stoplights. Try toadjust your speed to that of the other trafficso you don't have to change speeds unnec-essarily. Avoid heavy traffic whenever possible. Al- ways maintain a safe distance from othervehicles so you can avoid unnecessary brak-ing. This also reduces brake wear.
o Drive at a moderate speed. The faster you drive, the more fuel your car uses. Driving ata moderate speed, especially on the high-way, is one of the most effective ways toreduce fuel consumption.
o Don't "ride" the brake or clutch pedal. This can increase fuel consumption and alsoincrease wear on these components. In ad-dition, driving with your foot resting on thebrake pedal may cause the brakes to over-
C310B01O-AAT
TCS ON/OFF Mode When the TCS is running, the TCS indicator
light in the instrument cluster will blink. If you turn the system off by pressing the TCS
switch, the TCS-OFF indicator light will comeon and stay on. In the TCS-OFF mode, theSLIP control will be deactivated. Adjust youdriving accordingly. To turn the system backon, press the switch again. The TCS-OFF indi-cator light should go off.
NOTE:
1) The TCS mode will automatically be turned ON after the engine is turned offand restarted.
2) When the traction control system is op- erating properly, you can feel a slightpulsation in the vehicle. This is only the
CAUTION: When the TCS indicator blinks, SLIP control
has been activated. It also means that the road is slippery or your car is acceleratingexcessively. In this situation, gently releasefoot pressure from the accelerator pedaland maintain moderate speed.
WARNING: Traction control is only a driving aid; all
normal precautions for driving in inclement weather and on slippery road surfacesshould be observed.

DRIVING YOUR HYUNDAI 2- 11
heat, which reduces their effectiveness and may lead to more serious consequences.
o Take care of your tires. Keep them inflated to the recommended pressure. Incorrect infla-tion, either too much or too little, results inunnecessary tire wear. Check the tire pres-sures at least once a month.
o Be sure that the wheels are aligned cor- rectly. Improper alignment can result fromhitting curbs or driving too fast over irregularsurfaces. Poor alignment causes faster tirewear and may also result in other problemsas well as greater fuel consumption.
o Keep your car in good condition. For better fuel economy and reduced maintenancecosts, maintain your car in accordance withthe maintenance schedule in Section 5. Ifyou drive your car in severe conditions,more frequent maintenance is required (seeSection 5 for details).
o Keep your car clean. For maximum service, your car should be kept clean and free ofcorrosive materials. It is especially impor-tant that mud, dirt, ice, etc. not be allowed toaccumulate on the underside of the car. Thisextra weight can result in increased fuelconsumption and also contribute to corro-sion.
o Travel lightly. Don't carry unnecessary weight in your car. Weight is an enemy of good fueleconomy.
o Don't let the engine idle longer than neces- sary. If you are waiting (and not in traffic),turn off your engine and restart only whenyou're ready to go. o Remember, your car does not require ex-
tended warm-up. As soon as the engine isrunning smoothly, you can drive away. Invery cold weather, however, give your en-gine a slightly longer warm-up period.
o Don't "lug" or "over-rev" the engine. Lugging is driving too slowly in too high a gearresulting in the engine bucking. If this hap-pens to you, shift to a lower gear. Over-revving is racing the engine beyond its safe limit. This can be avoided by shifting atthe recommended speeds.
o Use your air conditioning sparingly. The air conditioning system is operated by the en-gine power so your fuel economy is reducedwhen you use it.
SC160A1-F
SMOOTH CORNERING
Avoid braking or gear changing in corners,
especially when roads are wet. Ideally, cornersshould always be taken under gentle accelera-tion. If you follow these suggestions, tire wearwill be held to a minimum.
SC170A1-E
WINTER MOTORING The onset of winter conditions subject motor
vehicles to greater operating demands. There-fore, the following suggestions will assist inmaintaining peak performance and reliabilityduring these periods: ZC170B1-E
Electrical System
Winter conditions impose severe demands uponvehicle electrical systems, particularly the charg-ing circuit. The battery condition and perfor-mance along with the alternator performanceand drive belt condition should be checked priorto the onset of winter. ZC170C1-E
Anti-freeze/Corrosion inhibitor The cooling system must always contain an Ethylene-Glycol based anti-freeze solution. Thesystem is filled during manufacture with solu-tion of the correct strength which should bechecked before the onset of winter and adjust- ed or changed as required. NOTE: The anti-freeze solution contains a corro- sion inhibitor to prevent degradation of thealuminum castings contained within theengine. Therefore, never, drain the systemand refill with water only. In addition, anti-freeze solution must ALWAYS be used in vehicles fitted with air conditioning,to prevent the heater matrix from freezing andsubsequently bursting with the refrigeration sys-tem in use.

DRIVING YOUR HYUNDAI
2- 12 WARNING:
It is not recommended that the vehicle be used for towing until the first 1000 miles ofRunning In has been completed. All Hyundaicoupe models are suited to towing trailersand caravans up to the limits indicated onpage 2-14. Coupe models fitted with auto-matic transaxle have a transaxle oil coolerand further transaxle cooling should not berequired.
SC200A1-E
TRAILER AND CARAVAN TOWING
Nose weightSSA2200B
Total trailer weight
o When driving in extreme conditions, the
windscreen wiper blades may fail to clear the screen properly due to the formation ofice upon the blade edge. It will therefore benecessary to periodically remove such iceto restore their efficiency.
o If the power operated door mirrors become frozen, attempts to adjust these may dam-age the mechanism.
o The formation of snow or ice built up inside the wheel arches may interfere with the roadwheels or steering mechanism. In such in-stances, unusual noises or an increase insteering effort may result. Therefore, ensurethat the wheel arches are checked periodi-cally and any accumulated snow or iceremoved.
o It is advisable to carry emergency equip- ment including, torch, shovel, tow rope, blan-kets etc., if a journey is to be undertaken intoareas of severe road conditions.
ZC170D1-E
Door Locks
Should the door lock mechanism become fro-
zen, a proprietary lock de-icer should be used.Alternatively, warming the door key may thawthe door lock. However, the key should behandled carefully to avoid burning the fingers.
Never attempt to thaw a frozen door lock using
hot water, since the water will eventually freezeand compound the problem.
NOTE:The proper temperature for using the immo-
bilizer key is from -40°F (-40°C) to 176°F(80°C). If you heat the immobilizer key over176°F (80°C) to open the frozen lock, it maycause damage to the transponder in its head. SC170E1-E Windscreen Washers and Wipers
The windscreen washer bottle should be filled
with a solution of water and a proprietary winter screen wash additive. The windscreen wipersshould not be used if the blades are frozen tothe windscreen or if they are covered withsnow, before this is removed.
NOTE: Never allow undiluted screen washer fluid
additive to spill upon the paintwork or use engine coolant anti-freeze since damage tothe paintwork may result.

DRIVING YOUR HYUNDAI 2- 13
C190E01GK-EAT
TOWING ATTACHMENTS
It is strongly recommended that only an Hyundai
Approved towing attachment is used to ensure that the loads placed upon the body structureare correctly distributed. The use of a nonapproved attachment will result in the invalida-tion of the vehicle warranty. Hyundai towingattachments are designed and constructed toensure maximum towing performance and easeof fitment. A range of accessories includingelectrical kits and mirrors are available throughthe Hyundai dealer network.
It is of the utmost importance that those areas
of the vehicle which are subjected to greaterstress during towing are maintained in accor-dance with the recommendations given at theend of this book. In addition, the daily operatingchecks relating to engine oil, transaxle oil andtyres must be performed at each refuelling toensure maximum reliability and safety.
The use of a proprietary stabiliser will assist in
achieving an inherently stable outfit but whilstthe use of such equipment will improve thecharacteristics of a balanced outfit, it will notcompensate for a badly loaded and thereforeunstable outfit.
The tyres and braking equipment fitted to the
trailer or caravan must be maintained in accor-dance with the recommendations of the manu-facturer. Special attention should be paid totyres which deteriorate through time and expo- sure rather than as a result of the distancestowed. The inside walls of the tyres should beinspected along with the outside walls for crack-ing and damage. The trailer wheel nut torquemust be checked on a regular basis, preferablybefore each towing session.
The trailer towbar hitch and the safety catch
mechanism must be maintained in good work-ing order. The trailer break away cable or cableshould be inspected for damage and should beattached to the vehicle towing attachment eachand every time the trailer is hitched to thevehicle.
Whilst towing, the performance of the vehicle
will be reduced in terms of acceleration, brakingand handling due to the increased loads placedupon the vehicle. The driver should anticipatethe change in characteristics and adjust thedriving style in keeping with these changes.Care should be exercised when cornering andbraking to prevent the outfit becoming uncon-trollable by reducing cornering speeds and al-lowing increased braking distances.
The driver should exercise care to ensure that
when pulling away from rest particularly onuphill gradients the clutch unit is not subjectedto excessive slippage which will reduce theuseful life of this component. Use of the "Over-drive Off" "2" and "L" positions when drivingvehicles with automatic transaxle will assistwith braking performance when long down hill gradients are encountered. Improved accelera-tion performance will be available by selecting"Overdrive Off","2", or "1" depending upon roadspeed if it is found that the transaxle unit makesan undesirable upshift whilst hill climbing orovertaking. The transaxle unit should be oper-ated in "D" with the Overdrive "On" undernormal circumstances to enhance fuel economyand reduce noise and engine wear.
SSA2200DGross Axle Weight
Gross Vehicle Weight
CAUTION: The use of a badly loaded or overloaded trailer may result in instability. This following specifications are recom- mended when towing a trailer. The loadedtrailer weight or the Gross Train Weightmust not exceed the values in the chartbelow.

DRIVING YOUR HYUNDAI
2- 14
Coupling point
HGK260
View from below the vehicle YC200E1-E Trailer or Vehicle Towing Tips
1. Before towing, check towbar hitch and safe-
ty cable connections as well as proper oper- ation of the trailer running lights, brake lights,and turn signals.
2. Always drive your vehicle at a moderate speed (Less than 60mph).
3. Trailer towing requires more fuel than nor- mal conditions.
4. To maintain engine braking efficiency, do not tow a trailer with the transaxle engagedin an overdrive gear.
5. Always secure items in the trailer to prevent load shift while driving.
6. Check the condition and air pressure of all tires on the trailer and your car. Low tirepressure can seriously affect the handling.Also check the spare tire.
7. The vehicle/trailer combination is more af- fected by crosswind and buffeting. When being passed by a large vehicle, keep a constant speed and steer straight ahead.If there is too much wind buffeting, slowdown to get out of the other vehicle's airturbulence.
8. When parking your car and trailer, especial- ly on a hill, be sure to follow all the normalprecautions. Turn your front wheel into thecurb, set the parking brake firmly, and putthe transaxle in 1st or Reverse (manual) orPark (automatic). In addition, place wheelchocks at each of the trailer's tires.
o The maximum permissible static vertical
load on the coupling device :
o The maximum permissible overhang of the coupling point : 38.98 in.(990 mm)
1.6 L
2.0/2.7 L 110(50) 132(60)
Lbs.(kg)
NOTE:
o The total gross vehicle weight with trailer must not exceed the Gross Vehicle Weight Rating (GVWR) shown on the vehicleidentification plate (see page 8-1). Thetotal gross vehicle weight is the com-bined weight of the vehicle, driver, allpassengers and their luggage, cargo,hitch, trailer nose weight and other op-tional equipment.
o The front or rear axle weight must not exceed the Gross Axle Weight Rating(GAWR) shown on the vehicle identifica-tion plate (see page 8-1). it is possiblethat your towing package does not ex-ceed the GVWR but exceeds the GAWR.Improper trailer loading and/or too muchluggage in the boot can overload the rearaxle. Redistribute the load and check theaxle weight again. Maximum
Towable Weight
Trailer
1,212(550)
2,645(1,200) 3,086(1,400)
Lbs.(kg)
With Brake Type1.6 L
2.0/2.7 L
Without Brake Type

DRIVING YOUR HYUNDAI 2- 15
9. If the trailer has electric brakes, start your
vehicle and trailer moving, and then apply the trailer brake controller by hand to besure the brakes are working. This lets youcheck your electrical connection at the sametime.
10. During your trip, check occasionally to be sure that the load is secure, and that thelights and any trailer brakes are still working.
11. Avoid jerky starts, sudden acceleration or sudden stops.
12. Avoid sharp turns and rapid lane changes.
13. Avoid holding the brake pedal down too long or too frequently. This could cause the brakes to overheat, resulting in reduced brakingefficiency.
14. When going down a hill, shift into a lower gear and use the engine braking effect. When ascending a long grade, downshift the transaxle to a lower gear and reduce speedto reduce chances of engine overloadingand/or overheating.
15. If you have to stop while going uphill, do not hold the vehicle in place by pressing on theaccelerator. This can cause the automatictransaxle to overheat. Use the parking brakeor footbrake. NOTE: When towing check transaxle fluid more
frequently.
CAUTION:If overheating should occur when towing,
(temperature gauge reads near red zone), taking the following action may reduce oreliminate the problem.
1. Turn off the air conditioner.
2. Reduce highway speed.
3. Select a lower gear when going uphill.
4. While in stop and go traffic, place the gear selection in park or neutral and idle the engine at a higher speed.

3-1
IN CASE OF EMERGENCY
the transaxle selector is at the "P" or"N" position.
2. Check the battery terminals and connections to ensure that these are clean and also tight.
3. If the ignition warning lamps dim when the engine is cranked and the battery terminalshave been checked, a discharged battery isindicated.
4. Do not attempt to push or tow start the ve- hicle, refer to "Jump Starting" for informationregarding engine starting when the battery isdischarged.
SD000A1-E
3. IN CASE OF EMER-
GENCY
SD020A1-E IF THE ENGINE WILL NOT STARTSeek assistance from the nearest Hyundai dealer with regard to the method of ignition and fuelsystem diagnosis. WARNING: If the engine refuses to start, no attemptshould be made to push or tow start thevehicle. Vehicles with automatic transaxle orfuel injection will not be able to be started inthis manner since no drive is transmittedthrough the automatic transaxle whilst theengine is not running, and in the case of fuelinjected derivatives, the fuel pump will notoperate under tow start conditions. In addi-tion, if the vehicle is equipped with an ex-haust catalyst, damage to the catalyst mayresult if the vehicle is tow started. SD020B1-E IF THE ENGINE CANNOT BE CRANKED
1. If the vehicle is fitted with manual transaxle, ensure that the clutch pedal is depressedwhilst cranking the engine. If the vehicle isfitted with automatic transaxle, ensure that D010C01A-AAT If Engine Turns Over Normally but Does Not Start
1. Check fuel Level.
2. With the key in the off position, check all
connectors at ignition coils and spark plugs.Reconnect any that may be disconnected orloose.
3. Check the fuel line in the engine room.
4. If engine still refuses to start, call a Hyundai dealer or seek other qualified assistance.
D010D01A-AAT If Engine Stalls While Driving
1. Reduce your speed gradually, keeping a straight line. Move cautionsly off the road to a safe place.
2. Turn on your emergency flashers.
3. Try to start the engine again. If your vehicle will not start, contact a Hyundai dealer orseek other qualified assistance. SD030A1-E JUMP STARTING
3
HGK184
Battery
DOHC
HGK184A
V6
Battery
CAUTION: Personal injury and damage to the vehicle may occur if jump starting is not performedcorrectly. If any doubt exists as to how thisoperation should be performed, seek assis-tance from qualified personnel.

IN CASE OF EMERGENCY
3-2 4. Check to see if the water pump drive belt is
missing. If it is not missing, check to see that it is tight. If the drive belt seems to be satisfac-tory, check for coolant leaking from the radia-tor, hoses or under the car. (If the air condi-tioning had been in use, it is normal for coldwater to be draining from it).
WARNING:Whilst the engine is running, keep hands andclothing away from moving parts such as thefan and drive belts to prevent injury.
5. If the water pump drive belt is broken or coolant is leaking out, stop the engine imme- diately and call the nearest Hyundai dealerfor assistance.
WARNING:Do not remove the radiator cap when theengine is hot since steam and boiling watermay be ejected from the radiator resulting inburns or scalding.
6. If the cause of the overheating cannot be found, wait until the engine temperature has returned to normal. Then, if coolant has beenlost, carefully remove the radiator cap andadd water to bring the fluid level in the reser-voir up to the base of the radiator fill opening.Fill the coolant expansion tank to the halfwaymark.
WARNING:Motor vehicle batteries contain sulphuric acidand emit hydrogen gas. Protective clothingshould be worn and care exercised to preventthe acid from coming into contact with skin orclothing and the vehicle. Naked lights shouldnot be permitted in the vicinity of the battery.Care should be exercised to prevent sparksoccurring during connection. If acid acciden-tally comes into contact with skin or eyes, theaffected area should immediately be flushedwith copious amounts of water and medicalassistance sought.
1. Ensure that the booster battery is 12 volt type.
If the booster battery is installed in another vehicle, ensure that the two vehicles are nottouching.
2. Turn off all unnecessary electrical equipment in both vehicles.
3. Ensure that the engine of the vehicle provid- ing the jump start is running prior to connec-tion of the jump cables.
4. Connect the red jump cable to the positive (+) terminal of the booster battery and the otherend to the positive (+) terminal of the dis-charged battery.
5. Attach the black jump cable to the negative (-) terminal of the booster battery, and theother end to a ground point within the enginecompartment of the vehicle with the flat bat-tery. Do not connect to the negative batteryterminal of the flat battery since sparks maybe generated with the subsequent risk ofexplosion. 6. Raise the booster vehicle engine speed to
2,000 r.p.m. and start the engine of the vehi-cle with the flat battery.
7. Remove jump cables in the reverse order of installation (black cable first).
CAUTION:If the jump cable is incorrectly installed, dam-age to the vehicle electrical system may oc-cur, in particular the electronic componentssuch as the Fuel Injection system computerand the Automatic Transaxle computer. Thebattery must never be disconnected whilstthe engine is running. SD040A1-E IF THE ENGINE OVERHEATSIf the temperature gauge indicates overheating:
1. Pull off the road and stop as soon as it is safe to do so.
2. Place the gear selector lever in "P" (auto- matic), or neutral (manual transaxle) and set the parking brake. If the air conditioning is on,turn it off.
3. If coolant is running out under the car or steam is coming out from under the bonnetstop the engine. Do not open the bonnet untilthe coolant has stopped running or the steam-ing has stopped. If there is no visible loss ofcoolant and no steam, leave the engine run-ning and check to be sure the engine coolingfan is operating.If the fan is not running, turn the engine off.
