FEATURES OF YOUR HYUNDAI
67FRONT DOOR EDGE WARN- ING LIGHT
B620A01S-AAT A red light comes on when the front door is opened. The purpose of thislight is to assist when you get in or out and also to warn passing vehicles.
B620A01GK
HOOD RELEASE
B570A01GK-GAT
1. Pull the release knob to unlatch the hood. 2. Press the secondary latch lever up
and lift the hood.
3. Raise the hood by hand. When closing the hood, slowly close the hood and make sure it locks into place.
Hood Release Lever
HGK2019 HGK2020

1FEATURES OF YOUR HYUNDAI
68
!
B560A02A-AAT The fuel-filler lid may be opened from inside the vehicle by pulling up on thefuel-filler lid opener located on the front floor area on the left side of the car. NOTE: If the fuel-filler lid will not open because ice has formed around it, tap lightly or push on the lid tobreak the ice and release the lid. Do not pry on the lid. If necessary, spray around the lid with an ap-proved de-icer fluid (do not use radiator anti-freeze) or move the vehicle to a warm place and allowthe ice to melt.REMOTE FUEL-FILLER LID RELEASE
WARNING:
o Gasoline vapors are dangerous. Before refueling, always stop the engine and never allow sparks oropen flames near the filler area. If you need to replace the filler cap, use a genuine Hyundai replace-ment part. If you open the fuel filler cap during high ambient tempera-tures, a slight "pressure sound" may be heard. This is normal and not a cause for concern.Whenever you open the fuel filler cap, turn it slowly.
HGK2017
HGK2018Q
!WARNING:
o Always double check to be sure that the hood is firmly latched before driving away. If it is notlatched, the hood could open while the vehicle is being driven, causing a total loss of visibility,which might result in an acci- dent.
o Do not move the vehicle with the hood in the raised position, asvision is obstructed and the hood could fall or be damaged.

1
FEATURES OF YOUR HYUNDAI
69
o Automotive fuels are flammable/
explosive materials. When refu- eling, please note the following guidelines carefully.
o Before touching the fuel nozzle or fuel filler cap, have one's handsin contact with metal parts awayfrom the filler neck to discharge static electricity.
o Do not get back in the vehicle
while refueling. Do not operateanything that can produce static electricity. Static electricity dis-charge can ignite fuel vapors re- sulting in explosion.
o When using a portable fuel con-
tainer be sure to place the con-tainer on the ground while refu- eling. Static electricity dischargefrom the container can ignite fuel vapors causing a fire. While start- ing refueling contact should bemaintained until the filling is com- plete. o Do not use cellular phones
around a gas station. The elec- tric current or electronic interfer-ence from cellular phones can ignite fuel vapors causing a fire.
o When refueling always shut the
engine off. Sparks by electricalequipment of the engine can ig- nite fuel vapors causing a fire.After refueling, check to make sure the fuel filler cap is securely closed, and then start the en-gine.
o Do not smoke or try to light ciga-
rettes around a gas station. Au-tomotive fuels are flammable.
TAIL GATE
B540A01F-AAT Remote Tail Gate Release To open the tail gate without using the key, pull up the lid release lever lo- cated on the driver's door panel.To close, lower the tail gate, then press down on it until it locks. To be sure the tail gate is securely fastened,always try to pull it up again. HGK2012

1FEATURES OF YOUR HYUNDAI
70
B540D01GK-GAT When you close the tail gate
B540D01GK
HGK227
!WARNING:
The tail gate should always be kept completely closed while the vehicle is in motion. If it is left open or ajar,poisonous exhaust gases may en- ter the car resulting in serious ill- ness or death to the occupants. Seeadditional warnings concerning exhaust gases on page 2-2. B540C01F-AAT To Unlock Using the Key To open the tail gate, insert the key and turn it clockwise to unlock. The tail gate compartment light illuminateswhen the tail gate is opened.
B540C02GK

1
FEATURES OF YOUR HYUNDAI
71SUN VISOR
!WARNING:
Do not close an open tail gate (rear hatch) while a person(s) is sittingupright on the rear seat. The tail gate or tail gate glass may contact the head of a person sitting uprighton the rear seat. Closing the tail gate onto a person's head may cause serious injuries, includingdeath. B580A02A-AAT Your Hyundai is equipped with sun visors to give the driver and front pas-senger either frontal or sideward shade. To reduce glare or to shut out direct rays of the sun, turn the sun visordown. A vanity mirror is provided on the back of the sun visor for the front passenger.Vanity mirror
HGK2119
!
NOTE: The Supplemental Restraint Sys- tem (SRS) label containing useful information can be found on thefront of each sun visor.WARNING:
Do not place the sun visor in such a manner that it obscures visibility of the roadway, traffic or other ob-jects.

1FEATURES OF YOUR HYUNDAI
72LUGGAGE NET
B540D02HP-DAT (If Installed) Type A
Some objects can be kept in the net of the luggage compartment. Use the luggage net on the floor or atthe back of the luggage compartment to prevent objects from sliding. HGK2126
Type B
HGK2050
HORN
!
STEERING WHEEL TILT LEVER
B600A01HP-AAT (If installed) To adjust the steering wheel:
1. Pull the lever toward you and hold it
to unlock.
2. Raise or lower the steering wheel to
the desired position.
3. After adjustment, release the lever.
WARNING:
Do not attempt to adjust the steer- ing wheel while driving as this mayresult in loss of control of the ve- hicle and serious injury or death. B610A01S-GAT Press the pad on the steering wheel to sound the horn.
HGK2049
Working Zone

1
FEATURES OF YOUR HYUNDAI
73CRUISE CONTROL
!
!
CAUTION:
To prevent damage to the goods or the vehicle, care should be taken when carrying fragile or bulky ob- jects in the luggage compartment.
WARNING:
Avoid eye injury. DO NOT over-stretch. ALWAYS keep face and body out of recoil path. DO NOT use when strap has visible signs ofwear or damage. B660A01S-GAT (If Installed) The cruise control system provides automatic speed control for your com- fort when driving on freeways, tollroads,or other noncongested highways. This is designed to function above approxi- mately 40 km/h (25 mph).
Main switch
B660A01GK
B660B01GK-GAT To Set the Cruise Speed
1. Push in the cruise control mainswitch on the end of the barrel. The "CRUISE" indicator light in the in-strument cluster will be illuminated. This turns the system on.
2. Accelerate to the desired cruising speed above 40 km/h (25 mph).
3. Push the control switch downward
to "SET (COAST)" and release it. The "SET" indicator light in the in- strument cluster will illuminate.
4. Remove your foot from the accel- erator pedal and the desired speedwill automatically be maintained. B660B01GK

1FEATURES OF YOUR HYUNDAI
74
o Decrease the vehicle speed to lessthan 40 km/h (25 mph).
o Release the main switch. B660D01E-GAT To Resume the Preset Speed The vehicle will automatically resume the speed set prior to cancellation when you push the control switch upward to"RESUME (ACCEL)" position and re- lease it, providing the vehicle speed is above 40 km/h (25 mph).
B660D01GK
!
5. To increase speed, depress the accelerator pedal enough for the vehicle to exceed the preset speed. When you remove your foot from the accelerator pedal, the vehiclewill return to the speed you have set.
WARNING:
To avoid accidental cruise controlengagement, keep the cruise con- trol main switch off when not using the cruise control. B660C01GK-GAT To Cancel the Cruise Speed To disengage the cruise control sys- tem, pull the control switch toward the steering wheel to "CANCEL" position.Additionally, the following actions will disengage the system :
o Depress the brake pedal.
o Depress the clutch pedal (Manual
transaxle).
o Shift the selector lever to "N" posi- tion (Automatic transaxle).
o Decrease the vehicle speed lower than the memorized speed by 15km/h (9 mph). B660C01GK

1
FEATURES OF YOUR HYUNDAI
75
B660E01E-AAT To Reset at a Faster Speed
1. Push the control switch upward to
"RESUME (ACCEL)" position and hold it.
2. Accelerate to desired speed and
release the control switch. Whilethe control switch is held, the ve- hicle will gradually gain speed. B660F01GK-AAT To Reset at a Slower Speed
1. Push the control switch downward
to "SET (COAST)" and hold it. The "SET" indicator light in the instru-ment cluster will illuminate. The ve- hicle will decelerate.
2. When the desired speed is obtained, release the control switch. The"SET" indicator light in the instru- ment cluster will turn off. While thecontrol switch is pushed, the vehicle speed will gradually decrease. B660B01GK
!WARNING:
o Keep the main switch off when not using the cruise control.
o Use the cruise control system only when traveling on open high- ways in good weather.
o Do not use the cruise control when it may not be safe to keepthe car at a constant speed, for instance, driving in heavy or vary-ing traffic, or on slippery (rainy, icy or snow-covered) or winding roads or over 6% up-hill or down-hill roads.
o Pay particular attention to the
driving conditions whenever us-ing the cruise control system.
o During cruise-control driving
with a manual transaxle vehicle,do not shift into neutral without depressing the clutch pedal, or the engine will be overrevved. Ifthis happens, depress the clutch pedal or release the main switch.

1FEATURES OF YOUR HYUNDAI
76
SEEK (UP / ) Switch Press the SEEK UP ( ) switch 1 sec. or more.
1. RADIO mode When the SEEK UP ( ) switch is pressed, the unit will automatically tune to the next higher frequency.
2. TAPE mode Pressing the SEEK UP ( ) switch will play the beginning of the next music segment.
3. CD (compact disc)/CDC(compact disc changer) mode
Press the SEEK UP ( ) switch once to skip forward to the beginning of the next track.
VOL ( / ) Switch
o Press the VOL ( ) button to in- crease volume.
o Press the VOL ( ) button to de- cease volume.AUDIO REMOTE CONTROL SWITCH
o With the cruise control engaged,
when the brake pedal is applied, it is normal to hear the cruise control system deactivate. This is an indication of normal systemoperation.
o During normal cruise control
operation, when the"SET(COAST)" is activated or reactivated after applying the brakes, the cruise control willenergize after approximately 3 seconds. This delay is normal. B610A01GK-GAT (If installed) The steering wheel audio remote con- trol switch is installed to promote safe driving. POWER ON/OFF Switch Press the POWER ON/OFF switch to select Radio, Tape, CD (compact disc) and CDC (compact disc changer). Press the POWER ON/OFF switch once again to cancel Radio, Tape, CD (compact disc) and CDC (compactdisc changer).B610A01GK
