FEATURES OF YOUR HYUNDAI
57
3. Distance to Empty
o This mode indicates the estimated
distance to empty from the current fuel in the fuel tank and distance toempty symbol.
o When refueling with more than 8
liters, the trip computer will recog-nize refueling.
o For an accurate distance to empty,
drive more than 500 m.
o When the distance to empty is less than 50 km, the symbol will alwayscome on and the distance to emptydigits will indicate "----" with flash until more fuel is added. NOTE:
o The distance to empty can differ
from the actual tripmeter ac- cording to driving conditions.
o The distance to empty can vary according to the driving condi-tions, driving pattern or vehiclespeed.
Distance to empty
Odometer
Distance to empty symbol
HXDFL230B HXDFL1026
o Pressing the trip computer switch
for more than 1 second, when thetripmeter is being displayed, clears the tripmeter to zero.
o The meter's working range is from
0 to 999.9 kms.
2. Average Fuel Consumption
o This mode calculates the average fuel consumption from the total fuel used and the distance since the last average consumption reset.
o The total fuel used is calculated from the fuel consumption input.
o For an accurate calculation, drive
more than 500 m.
o The meter's working range is from 0.0 to 99.9 L/100 km. Average fuel consumption
HXDFL230C Distance to empty FLASHING
Distance to empty symbol
Odometer
Odometer

1FEATURES OF YOUR HYUNDAI
58MULTI-FUNCTION LIGHT SWITCH
B340C03E-AAT Headlight Switch To operate the headlights, turn the barrel on the end of the multi-function switch. The first position turns on the parking lights, sidelights, tail lights andinstrument panel lights. The second position turns on the headlights. NOTE: The ignition must be in the "ON" position to turn on the headlights. Parking Light Auto Off If you do not turn the parking lights "OFF" after driving, the parking light will automatically shut "OFF" when thedriver's door is opened.
B340A01A-AAT COMBINATION TURN SIGNAL, HEADLIGHT AND HIGH-BEAMSWITCHTurn Signal Operation Pulling down on the lever causes the turn signals on the left side of the car to blink. Pushing upwards on the levercauses the turn signals on the right side of the car to blink. As the turn is completed, the lever will automaticallyreturn to the center position and turn off the turn signals at the same time. If either turn signal indicator light blinksmore rapidly than usual, goes on but does not blink, or does not go on at all, there is a malfunction in the system.Check for a burned-out fuse or bulb or see your Hyundai dealer.
B340B01A-AAT Lane Change Signal To indicate a lane change, move the lever up or down to a point where it begins flashing.The lever will automatically return to the center position when released.
HXDFL352
HXDFL360

1
FEATURES OF YOUR HYUNDAI
59
B340E01A-AAT Headlight Flasher To flash the headlights, pull the switch lever toward you, then release it. The headlights can be flashed even thoughthe headlight switch is in the "OFF" position. HXDFL351
To turn them "ON" again you must simply turn the ignition key to the "ON"position. B340F01A-GAT Daytime Running Lights (If installed) Your Hyundai is equipped with day- time running lights. The daytime run- ning lights are used to improve visibil- ity for oncoming traffic. Your vehicledaytime running lights are designed to remain on continuously when the en- gine is operating even though the head-light switch is in the "OFF" position. However, the daytime running lights will be off while the parking brake isapplied.
B340D01A-AAT High-beam Switch To turn on the headlight high beams, push the lever forward (away from you). The high beam indicator light will come on at the same time. For lowbeams, pull the lever back toward you.
B340G01LZ-GAT Auto Light (If installed)
HXDFL361
To operate the automatic light feature, turn the barrel on the end of the multi- function switch. If you set the multi-function switch to "AUTO", the tail lights and headlights will be turned automatically on or off according toexternal illumination conditions. NOTE: Switch on car light manually in foggy, cloudy and rainy conditions.

1FEATURES OF YOUR HYUNDAI
60WINDSHIELD WIPER AND WASHER SWITCH
B350A01L-AAT The windshield wiper switch has three positions:
1. Intermittent wiper operation
2. Low-speed operation
3. High-speed operation NOTE: To prevent damage to the wiper system, do not attempt to wipe away heavy accumulations of snow or ice. Accumulated snow and iceshould be removed manually. If there is only a light layer of snow or ice, operate the heater in the defrost mode to melt the snow or ice beforeusing the wiper. B350C01S-AAT Adjustable Intermittent Wiper Operation To use the intermittent wiper feature, place the wiper switch in the "INT"position. With the switch in this posi- tion, the interval between wipes can be varied from approximately 2 to 10 sec-onds by turning the interval adjuster barrel.
B360B01L-GAT Front Fog Light Switch (If installed) To turn on the front fog lights, place the switch in the "ON" position. They willcome on when the headlight switch is in the first or second position.
HXDFL359
HXDFL353
HXDFL354
1
2
3

1
FEATURES OF YOUR HYUNDAI
61
B350B01A-AAT Windshield Washer Operation To use the windshield washer, pull the wiper/washer lever toward the steer- ing wheel. When the washer lever isoperated, the wipers automatically make two passes across the wind- shield. The washer continues to oper-ate until the lever is released. NOTE:
o Do not operate the washer more
than 15 seconds at a time or when the fluid reservoir is empty.
o In icy or freezing weather, be
sure the wiper blades are notfrozen to the glass prior to oper- ating the wipers. B390A01E-AAT Rear Window Wiper And Washer (If installed)
1. : The rear window wiper starts
to operate three times after the washer fluid sprays onto therear window.
2.OFF3.INT: The interval between wipes op-erates every 5 seconds inter- mittently.
4.ON : The rear window wiper starts
to operate continuously.
5. : The washer fluid will be sprayed
onto the rear window and the wiper operates while the rear window wiper barrel is placed in this position.
HXDFL355
HXDFL357
o In areas where water freezes inwinter, use windshield washer antifreeze.
Mist Wiper Operation If a single wipe is desired to clear mist, push the windshield wiper and washer control lever upwards. HXDFL356-EU

1FEATURES OF YOUR HYUNDAI
62
B360A01Y-GAT (If installed) To turn on the rear fog lights, push the switch. They will come on when the headlight switch is in the second posi-tion and the key is in the "ON" position. B360A02EB345G01E-GAT (If installed)
B345H01E
Do not operate the washer continu- ously for more than 15 seconds orwhen the fluid reservoir is empty; this could damage the system. Do not op- erate the wiper when the window isdry; this can result in scratching as well as premature wiper blade wear. For the reason stated above,do notoperate the washer when the washer fluid reservoir is empty.
B345G01E
REAR FOG LIGHT SWITCH HEADLIGHT WASHER
SWITCH

1
FEATURES OF YOUR HYUNDAI
63REAR WINDOW DEFROSTER SWITCH
B380A02A-AAT The rear window defroster and heated outside rearview mirrors are turned onby pushing in the switch. To turn the defroster off, push the switch a second time. The rear window defroster auto-matically turns itself off after about 15 minutes. To restart the defroster cycle, push in the switch again after it hasturned itself off. B380B01E
The headlight washer switch can beoperated with the ignition switch at the"ON" position and the light switch at
the "ON" position. Push the button and the washer fluid will be sprayed on tothe headlights for about 0.7 second. NOTE: Check the headlight washers peri- odically to confirm that the washerfluid is being sprayed properly onto the headlight lenses.
NOTE: The ignition must be in the "ON" position for the rear window defroster to operate.
!
CAUTION:
Do not clean the inner side of the rear window glass with an abrasive type of glass cleaner or use a scraper to remove foreign deposits from theinner surface of the glass as this may cause damage to the defroster ele- ments.

1FEATURES OF YOUR HYUNDAI
64TICKET HOLDER
B590A01E-AAT For your convenience, it may be used for holding a tollgate ticket. HXDFL240
B400A01E-AAT There are three control buttons for the digital clock. Their functions are: HOUR
-Push "H" to advance the hour
indicated.
MIN -Push "M" to advance the
minute indicated.
RESET - Push "R" to reset minutes to
":00" to facilitate resetting the clock to the correct time. When this is done:
Pressing "R" between 10 : 30 and 11 :29 changes the readout to 11 : 00.Pressing "R" between 11 : 30 and 12 : 29 changes the readout to 12 : 00. Push the "R" buttion for 5 seconds to display a 12- or 24-hour clock (If in- stalled).
HAZARD WARNING SYSTEM
B370A01A-AAT The hazard warning system should be used whenever you find it necessaryto stop the car in a hazardous location. When you must make such an emer- gency stop, always pull off the road asfar as possible. The hazard warning lights are turned on by pushing in the hazard switch.This causes all turn signal lights to blink. The hazard warning lights will operate even though the key is not inthe ignition. To turn the hazard warning lights off, push the switch a second time. HXDFL371
DIGITAL CLOCK
HXDFL400-1

1
FEATURES OF YOUR HYUNDAI
65INSTRUMENT PANEL LIGHT CONTROL (RHEOSTAT)
B410A01A-AAT (If installed) The instrument panel lights can be made brighter or dimmer by turning the instrument panel light control knob. B420A02A-AAT For the cigarette lighter to work, the key must be in the "ACC" position or the "ON" position.To use the cigarette lighter, push it all the way into its socket. When the element has heated, the lighter willpop out to the "ready" position. Do not hold the cigarette lighter pressed in. This can damage the heating ele-ment and create a fire hazard. If it is necessary to replace the ciga- rette lighter, use only a genuine Hyundaireplacement or its approved equiva- lent.
B410A01E
HXDFL420
CIGARETTE LIGHTER
CAUTION:
Do not use electric accessories or equipment other than the Hyundai genuine parts in the socket.
!

1FEATURES OF YOUR HYUNDAI
66POWER OUTLETASHTRAY
B430A01B-AAT Front Ashtray
The front ashtray may be opened by pushing and releasing the ashtray lid. To remove the ashtray to empty orclean it, lift the metal ash receptacle upward and pull it out. The ashtray light will only illuminate when the exter-nal lights are on (If installed).
!
B500D08O-AAT
These supply 12V electric power to operate electric accessories or equip-ment only when the key is in the "ON" or "ACC" position. CAUTION:
o Use the power outlet only when the engine is running and removethe plug from the power outlet after using the electric device.Using when the engine stops or keeping the electric device with plugged in for many hours maycause the battery to discharge.
o Do not use the power outlet to
connect electric accessories orequipment that are not designed to operate on 12 volts.
o Some electronic devices can cause electronic interference whenplugged into the power outlet. These devices may cause exces-sive audio noise and malfunctions in other electronic systems or de- vices in your vehicle. HXDFL440
HXDFL421
