Hyundai Ioniq Electric 2017 Quick Reference Guide
Manufacturer: HYUNDAI, Model Year: 2017, Model line: Ioniq Electric, Model: Hyundai Ioniq Electric 2017Pages: 26, PDF Size: 9.24 MB
Page 21 of 26

Quick Reference Guide I 39
38 I Quick Reference Guide
IONIQ ELECTRIC HYUNDAI
1 On-Board Charger (OBC)External device (low speed) to charge the high voltage battery2 InverterTransforms direct current into alternate current to supply power to
the motor, and transforms alternate current into direct current to
charge the high voltage battery.3 Low Voltage DC-DC Converter (LDC)Transforms power from the high voltage battery to low voltage (12V)
to supply power to the vehicle (DC-DC).4 MotorUses electrical energy stored inside the high voltage battery to drive
the vehicle (functions like an engine in a standard vehicle)5 Reduction GearDelivers rotational force of the motor to the tires at appropriate
speeds and torque.6 High voltage battery (lithium-ion polymer)Stores and supplies power necessary for the electric vehicle to
operate(12V auxiliary battery provides power to the vehicle features
such as lights and wipers).
ELECTRIC VEHICLE COMPONENTS
DRIVING
LOW TIRE PRESSURE INDICATORIlluminates if one or more of your tire is significantly under-inflated.TPMS MALFUNCTION INDICATORBlinks for approximately one minute, then remains illuminated when
there is a malfunction with the TPMS. Inspect all Tires and adjust the
Tire pressure to specification. If the lamp remains illuminated, we
recommend the vehicle be checked by an authorized HYUNDAI dealer.LOW TIRE PRESSURE / TIRE PRESSURE MONITOR /
TPMS MALFUNCTION DISPLAY(LCD DISPLAY)Tire pressures will display after driving a short distance. If a tire
pressure drops lower than predetermined specification, the Low Tire
Pressure Indicator
will illuminate and the LCD display will indicate
Tire(s) requiring air. Recommended tire pressure is located on the
placard that can be found on the driver’s side door pillar.Low Tire Pressure /
Tire Pressure Monitor /
TPMS Malfunction Display
(shown on the cluster LCD display) Low Tire Pressure Indicator /
TPMS Malfunction Indicator
TIRE PRESSURE MONITORING SYSTEM (TPMS)
1
On-Board Charger
(OBC)
EPCU
(2 Inverter +
3 LDC)
4
Motor
5
Reduction
Gear
6
High voltage battery
Page 22 of 26

Quick Reference Guide I 41
40 I Quick Reference Guide
IONIQ ELECTRIC HYUNDAI
DRIVING
AUTOMATIC WITH PUSH BUTTON DRIVE SELECTORREGENERATIVE BRAKE LEVEL CONTROL PADDLES
ELECTRONIC PARKING BRAKE (EPB)VIRTUAL ENGINE SOUND SYSTEM (VESS)
Select gear positions by pressing
the shift button. The gear position is
displayed in the instrument cluster.
For your safety, always depress the
brake pedal while shifting to another
gear.
The paddle shifter is used to adjust
the regenerative braking rate from 0
to 3 during decelerating or braking.
• Left side( ): Increases
regenerative braking and
deceleration.
• Right side( ): Decreases
regenerative braking and
deceleration.
The paddle shifter does not operate.
• When the two paddle shifters are
pulled at the same time.
• When the Cruise Control system
or Advanced Cruise Control
system is activated.The Virtual Engine Sound System (VESS) generates engine sound for
pedestrians to hear vehicle sound because there is no sound while the
Electric Vehicle (EV) is operating.
• If the vehicle is moving at low speed, the VESS will operate.
• When the gear is shifted to R (Reverse), an additional warning
sound will be heard.
Applying
Stop the vehicle
then pull up the
EPB switch
Releasing
Press the EPB
switch while
depressing the
brake pedal.
Automatic releasing
• When shifted to P:
Depress the brake pedal and shift
out of P to R or D.
• When shifted to N:
Depress the brake pedal and shift
out of N to R or D.
NOTE:
If necessary, emergency braking is possible by pulling up and
holding the EPB switch.
Page 23 of 26

Quick Reference Guide I 43
42 I Quick Reference Guide
IONIQ ELECTRIC HYUNDAI
DRIVING
To cancel the AUTO HOLD operation, press the AUTO HOLD switch again.When the vehicle reaches a stop,
Auto Hold keeps the vehicle stopped
even when the brake pedal is released.
The brakes are released automatically
when the accelerator pedal is depressed.
1.
Press the AUTO HOLD switch.
WHITE
2.
Stop the vehicle by depressing the brake pedal.
The brake will remain engaged even if the brake
pedal is released.
GREEN
3.
The AUTO HOLD will be released, when the
accelerator pedal is depressed with the gear in
D or N.
WHITE
ESC automatically selects the ON
position when the engine is started.To turn off Traction ControlPress the ESC OFF button shortly.To turn off Traction & Stability
ControlPress the ESC OFF button for more
than 3 seconds.The ESC system is an electronic
system designed to help the driver
maintain vehicle control under
adverse conditions.
ELECTRONIC STABILITY CONTROL (ESC)
AUTO HOLD
Page 24 of 26

Quick Reference Guide I 45
44 I Quick Reference Guide
IONIQ ELECTRIC HYUNDAI LANE DEPARTURE WARNING SYSTEM (LDWS)
The Lane Departure Warning System
detects the lane on the road and
warns the driver if the vehicle leaves
the lane. The system operates when
the vehicle speed is over 40 mph.
• To turn on the LDWS, press the
LDWS switch.
• To turn off the LDWS, press the
switch again.
2
The BSD (Blind Spot Detection)
system uses a radar sensor to alert
the driver while driving.
It monitors the rear area of the vehicle
and provides information to the driver.1 Blind Spot Detection2 Lane Change Assist3 Rear Cross Traffic Alert
The system will activate if vehicle speed exceeds 20 mph.• To turn on the BSD, press the BSD
button (indicator illuminated).
• To turn off the BSD, press the BSD
button again.
When the vehicle is in R (Reverse), the system provides an alert if a
vehicle is approaching from the sides.Rear Cross Traffic AlertBLIND SPOT DETECTION SYSTEM (BSD)
3
1
DRIVING
DRIVE MODE INTEGRATED CONTROL SYSTEM
You can select the drive mode
according to your preference or the
road condition.
The system initializes to the NORMAL
mode (except ECO mode)
after the vehicle is restarted.
Each time you press the button, the
drive mode is changed as follows :
Eco mode system helps to improve fuel efficiency. When the ECO
mode system is activated, the vehicle acceleration, gear shift points
and air conditioning perfomance will be reduced to conserve the fuel
consumption.
ECO modeNormal mode provides regular daily driving performance with some
fuel efficiency.NORMAL modeSport mode provides a sporty feel and may have heavier steering
effort. In Sport mode, the fuel efficiency may decrease. SPORT mode
NORMAL
ECO
SPORT
Normal mode is not displayed on
the instrument cluster.
Page 25 of 26

Quick Reference Guide I 47
46 I Quick Reference Guide
IONIQ ELECTRIC HYUNDAI
DRIVING
AUTONOMOUS EMERGENCY BRAKING (AEB)
The Autonomous Emergency Braking (AEB)
system is designed to detect and monitor the
vehicle ahead or detect a pedestrian in the
roadway through radar signals and camera
recognition to warn the driver that a collision is
imminent, and if necessary, apply emergency
braking.
To activate the system,
Select “User Settings
Driving Assist
Autonomous Emergency Braking”
The system deactivates, when the system
setting is cancelled.
1 To turn on/off the cruise control.2 To resume or increase the cruise
control speed.3 To set or decrease the cruise
control speed.4 To cancel the cruise control. The Cruise Control system allows you to
program the vehicle to maintain a
constant speed without depressing the
accelerator pedal.
If your vehicle is equipped with Advanced Smart Cruise Control and you
wish to eliminate the vehicle distance function, you can change cruise control
setting to a standard setting. Press the Cruise Control button on the steering
wheel to turn on the Cruise Control. Then press and hold the vehicle distance
button for more than 2 seconds to toggle between the Smart Cruise Control
(SCC) and Cruise Control (CC) mode. Please refer to your Owner’s Manual for
more information.
CRUISE CONTROL / SMART CRUISE CONTROL
Setting Vehicle Distance (Smart
Cruise Control only)This system allows you to program
the vehicle to maintain constant
speed and distance without
depressing the accelerator or brake
pedal.
The vehicle to vehicle distance
1 will
automatically activate when you set
the cruise speed
2.
Each time the vehicle distance set
button is pressed, the vehicle to
vehicle distance changes as
following:
2
1
Distance 2 Distance 3 Distance 4
(Longest)
Distance 1(Shortest)
2341
Page 26 of 26

48 I Quick Reference Guide
HYUNDAI
DRIVINGDRIVING
The following tips may help benefit you to maximizing fuel economy and
experience Electric vehicle driving.
Set headlight switch to AUTO or OFF
when not in use. This will help preserve
vehicle battery charge.
Use the DRIVER ONLY button with no
front passenger. This will help reduce
energy consumption.
Try to drive in an eco-friendly manner
and maintain ECO Mode indicator to
illuminate as much as possible. Common practice:
• Check tire pressure
• Roll windows up when driving
• Properly maintain your vehicle
• Turn A/C off
Driving suggestions to improve fuel economy:• Drive smoothly.
• Accelerate at moderate speed.
• Try to maintain your speed with traffic to prevent unnecessary
speed adjustments.
• Always maintain a safe driving distance from the vehicle in
front of you so you can avoid unnecessary braking.
+
IONIQ CUSTOMER DELIVERY CHECKLIST CUSTOMER NAME DEALERSHIP NAME SALES CONSULTANT DATE VIN ☐
SET TIRE PRESSURE LF
RF
RR
LR
☐
VERIFY VEHICLE IS CLEAN, IN GOOD CONDITION,
FREE OF CHIPS AND SCRATCHES · CLEAN WINDSHIELD
AND BACK WINDOW
☐ ENSURE FLOOR MATS ARE SNAPPED INTO PLACEBEFORE DELIVERY Sales Consultant Date Sales Manager Date
Customer Date
Email
ELECTRIC VEHICLE
