Hyundai Santa Fe 2009 Owner's Manual - RHD (UK, Australia)

1FEATURES OF YOUR HYUNDAI
120
!
B750B02Y-DAT Using a mobile phone or a two- way radio When a mobile phone is used inside the vehicle, noise may be produced fromthe audio equipment. This does not mean that something is wrong with the audio equipment. In such a case, usethe mobile phone at a place as far as possible from the audio equipment.
CAUTION:
When using a communication sys-tem such a mobile phone or a radio inside the vehicle, a separate exter-nal antenna must be fitted. When a mobile phone or a radio set is used with an internal antenna alone, itmay interfere with the vehicle's elec- trical system and adversely affect safe operation of the vehicle.
WARNING:
Don't use a mobile phone when you are driving, you must stop at a safe place to use a mobile phone.
!
B750A04L B750A05L
o Station Swapping - As an FM signal weakens, another more powerful sig- nal near the same frequency may begin to play. This is because your radio is designed to lock onto the clearest signal. If this occurs, selectanother station with a stronger sig- nal.
o Multi-Path Cancellation - Radio sig- nals being received from several di-rections can cause distortion or flut- tering. This can be caused by adirect and reflected signal from the same station, or by signals from two stations with close frequencies. Ifthis occurs, select another station until the condition has passed.
o Fading - As your car moves away
from the radio station, the signal willweaken and sound will begin to fade. When this occurs, we suggest that you select another stronger station.
o Flutter/Static - Weak FM signals or large obstructions between the trans-mitter and your radio can disturb the signal causing static or flutteringnoises to occur. Reducing the treble level may lessen this effect until the disturbance clears.
CM-aust-1a.p65 5/21/2008, 2:12 PM
120

1
FEATURES OF YOUR HYUNDAI
121CARE OF DISCS
Damaged Disc Do not attempt to play damaged, warped or cracked discs. These could severelydamage the playback mechanism. Storage When not in use, place your discs in their individual cases and store them in a cool place away from the sun, heat,and dust. Do not grip or pull out the disc with your hand while the disc is being pulled intothe unit by the self loading mechanism.
B850A02F-DAT Proper Handling Handle your disc as shown. Do not drop the disc. Hold the disc so you will notleave fingerprints on the surface. If the surface is scratched, it may cause the pickup to skip signal tracks. Do notaffix tape, paper, or gummed labels on the disc. Do not write on the disc.
B850A02LB850A01L
Fingerprints, dust, or foreign material on the surface of a disc could cause the pickup to skip signal tracks. Wipe the surface clean with a clean soft cloth.If the surface is heavily soiled, dampen a clean soft cloth in a solution of mild neutral detergent to wipe it clean.
Keep Your Discs Clean
CM-aust-1a.p65
5/21/2008, 2:12 PM
121

1FEATURES OF YOUR HYUNDAI
122
1. Power ON/OFF&Volume ControlButton
2. FM Selection Button 3. AM Selection Button 4. Automatic Channel Selection Button
5.Preset Button6. AST(AUTO STORE Button) 7. SETUP Button 8. Manual Channel Selector & Sound Quality ControlAUDIO SYSTEM
RADIO, SET UP, VOLUME, AUDIO CONTROL (IF INSTALLED)
■ PA710
■ PA760
CM-aust-1b.p65 5/19/2008, 6:33 PM
122

1
FEATURES OF YOUR HYUNDAI
123
1
FEATURES OF YOUR HYUNDAI
123
1
FEATURES OF YOUR HYUNDAI
123
1
FEATURES OF YOUR HYUNDAI
123
1
FEATURES OF YOUR HYUNDAI
123
1. Power ON/OFF&Volume Con- trol Button
Turns on/off the set when the IGNI- TION SWITH is on ACC or ON. If the button is turned to the right, it increasesthe volume and left,decreases the vol- ume. 2. FM Selection Button Turns to FM mode and toggles FM1and FM2 when the button is pressed each time. 3. AM Selection Button Pressing the [AM] button selects the AM band. AM Mode is displayed on the LCD.
4. Automatic Channel Selection
Button
o When the [SEEK
] button is
pressed, it increases the band fre- quency to automatically select chan-nel. Stops at the previous frequency if no channel is found.
o When the [TRACK
] button is
press- ed, it reduces the band fre- quency to automatically select chan- nel. Stops at the previous frequencyif no channel is found. 5. Preset Button Push [1]~[6] buttons less than 0.8 second to play the channel saved in each button. Push Preset button for 0.8second or longer to save current chan- nel to the respective button with a beep. 6. ST(AUTO STORE Button) When the button is pressed, it auto- matically selects and saves channelswith high reception rate to PRESET buttons [1]~[6] and plays the channel saved in PRESET1. If no channel issaved after AST, it will play the previ- ous channel.
7. SETUP Button Press this button to turn to the TEXT SCROLL adjustment mode. If no ac- tion is taken for 5 seconds after press- ing the button, it will return to the playmode. (After entering SETUPmode, PUSH functions of the TUNE button to adjust TEXT SCROLL.)
8. Manual Channel Selector &
Sound Quality Control
Turn this control while listening to a radio channel to manually adjust fre- quency. Turn clockwise to increase fre-quency and counterclockwise to reduce frequency. Pressing the button changes the BASS,MIDDLE, TREBLE, FADER and BAL- ANCE TUNE mode. The mode selected is shown on the display. After selectingeach mode, rotate the Audio control knob clockwise or counterclockwise. BASS Control To increase the BASS, rotate the knob clockwise, while to decrease the BASS,rotate the knob counterclockwise. MIDDLE Control To increase the MIDDLE, rotate the knob clockwise, while to decrease theMIDDLE, rotate the knob counterclock- wise.
CM-aust-1b.p65 5/19/2008, 6:33 PM
123

1FEATURES OF YOUR HYUNDAI
124
TREBLE Control To increase the TREBLE, rotate theknob clockwise, while to decrease the TREBLE, rotate the knob counterclock-wise. FADER Control Turn the control knob clockwise to emphasize rear speaker sound(front speaker sound will be attenuated). Whenthe control knob is turned counterclock- wise, front speaker sound will be emphasized(rear speaker sound will beattenuated). BALANCE Control Rotate the knob clockwise to empha- size right speaker sound(left speaker soundwill be attenuated). When the control knob is turned counter clockwise, left speaker sound will be emphasized(right speaker sound will be attenuated). 9. TA Selection Button In FM, CD, AUX mode, turns on/off the reception of TA channels of RDS. 10. PTY(FLDR) Button
o Moves [FOLDER
] Button when
searching PTY in RDS Broadcasting Program Type selection.
o Moves [PTY
] button when search-
ing PTY in RDS Broadcasting Pro- gram Type selection.
CM-aust-1b.p65 5/19/2008, 6:33 PM
124

1
FEATURES OF YOUR HYUNDAI
125
1
FEATURES OF YOUR HYUNDAI
125
1
FEATURES OF YOUR HYUNDAI
125
1
FEATURES OF YOUR HYUNDAI
125
1
FEATURES OF YOUR HYUNDAI
125
1. CD Loading Slot 2. CD Eject Button 3. INFO Button 4. Automatic Track Selection Button5. RANDOM Play Button 6. REPEAT Button 7. CD Selection Button (PA710) CD/AUX Selection Button (PA760)
8. CD Indicator (CDP only)9. Folder Moving Button10. Search/ENTER Button 11. SCAN Play Button 12. AUX Selection Button (PA710)
DISC Selection Button (PA760)
13. CD LOAD Button
CDP, AUX (IF INSTALLED) ■
PA710
■ PA760
CM-aust-1b.p65 5/19/2008, 6:33 PM
125

1FEATURES OF YOUR HYUNDAI
126
1. CD Loading Slot Please face printed side upward and gently push in. When the ignition switch is on ACC or ON and power is off, poweris automatically turned on if the CD is loaded. This CDP supports only 12cm CD. If VCD, Data CD are loaded, "Read-ing Error" message will appear and CD will be ejected. 2. CD Eject Button Push
button for less than 0.8 sec-
onds to eject the CD during CD play- back. This button is enabled when igni-tion switch is off. ALL EJECT(CDC Only) Press this button for more than 0.8 seconds to eject all discs inside the deck in respective order. 3. INFO Button Displays the information of the current CD TRACK(FILE) as below when the button is pressed each time.
o CDDA : DISC TITLE ➟DISC
ARTIST ➟ TRACK TITLE ➟TRACK
ARTIST ➟ TOTAL TRACK... o MP3/WMA : FILE NAME
➟TITLE ➟
ARTIST ➟ALBUME ➟FOLDER
NAME ➟ TOTAL FILE... (not dis-
played if the information is not avail- able on the DISC.)
4. Automatic Track Selection Button
o Push [TRACK
] button for less
than 0.8 second to play from the
beginning of current song.
o Push [TRACK
] button for less
than 0.8 second and press again within 1 seconds to play the previous song.
o Push [TRACK
] button for 0.8 or
longer to initiate reverse direction high speed sound search of current song.
o Push [SEEK
] button for less than
0.8 second to play the next song.
o Push [SEEK
] button for 0.8 or
longer to initiate high speed sound search of current song. 5. RANDOM Play Button Press this button for less than 0.8 second to activate ‘RDM’ mode and more than 0.8 seconds to activate ‘ALLRDM’ mode.
o RDM : Only files/tracks in a folder/
disc are played back in a random sequence.
o ALL RDM(MP3/WMA Only) : All files
in a disc are played back in therandom sequence.
6. REPEAT Button Press this button for less than 0.8 second to activate ‘RPT’ mode and more than 0.8 seconds to activate ‘FLD RPT’ mode.
o RPT : Only a track(file) is repeatedly played back.
o FLD RPT(MP3/WMA Only) : Only
files in a folder are repeatedly played back.
CM-aust-1b.p65 5/19/2008, 6:33 PM
126

1
FEATURES OF YOUR HYUNDAI
127
1
FEATURES OF YOUR HYUNDAI
127
1
FEATURES OF YOUR HYUNDAI
127
1
FEATURES OF YOUR HYUNDAI
127
1
FEATURES OF YOUR HYUNDAI
127
7. CD or CD/AUX Selection But- ton
CD Selection Button If the CD is loaded, turns to CD mode. If no CD, it displays "NO Disc" for 3seconds and returns to th previous mode. CD/AUX Selection Button If the auxiliary device is connected, it switches to the AUX mode from theother mode to play the sound from the auxiliary player. If the CD is loaded, turns to CD mode, and if a device isconnected to AUX then it toggles. CD ➟AUX ➟CD... when the button is
pressed each time.(It will not turn to AUX if the auxiliary device is not con- nected) If no CD and auxiliary device is not connected, it displays "NO Media"for 3 seconds and returns to the previ- ous mode. 8. CD Indicator(CDP Only) When car ignition switch is ACC or ON and if the CD is loaded, this indicator is lighted. If the CD is ejected the light is turned off. 9. Folder Moving Button
o Moves [FOLDER
] button child
folder of the current folder and dis- plays the first song in the folder.Press TUNE/ ENTER knob to move to the folder displayed. It will play the first song in the folder.
o Moves [CAT
], [PTY ],
[FOLDER
] button parent folder
and displays the first song in the folder. Press TUNE/ENTER knob to move to the folder displayed.
10. Search/ENTER Button Turn this button clockwise to display the songs next to the currently played song. Turn the button counterclock-wise to display the songs before the currently played song. Press the button to skip and play the selected song. 11. SCAN Play Button Plays first 10 seconds of each song in the DISC. To cancel the mode, pressthe button once again. 12. AUX or DISC Selection But-
ton
AUX selection button If the auxiliary device is connected, it turns to AUX mode from the other modeto play the sound from the auxiliary player. If no auxiliary device is con- nected, it displays "NO Media" for 3seconds and returns to the previous mode. DISC selection button
o [DISC
] Change Button Changes
disc to the previous disc.
o [DISC
] Change Button Changes
disc to the next disc.
13. CD LOAD Button Push [LOAD] button to load CDs to available CDC deck (from 1~6). Push [LOAD] button for more than 2 seconds to load into all available decks.The last CD will play. 10 seconds idle status will disable loading process.
CM-aust-1b.p65 5/19/2008, 6:33 PM
127

1FEATURES OF YOUR HYUNDAI
128
!
Caution in using USB
device
o To use the external USB device, make sure the device is not mounted when starting up the ve- hicle and mount the device after starting up.
o If you start the vehicle when the USB device is mounted, it maydamage the USB device. (USB isnot ESA)
o If the vehicle is started up or turned
off while the external USB deviceis connected, the external USB device may not work.
o It may not play inauthentic MP3 or WMA files.
1) It can only play MP3 files with
the compression rate between 8Kbps~320Kbps.
2) It can only play WMA music
files with the compression ratebetween 8Kbps~320Kbps.
o Take cautions for static electricity
when mounting or dismountingthe external USB device.
o Encoded MP3 PLAYER is not rec-
ognizable.o Depending on the condition of the external USB device, the connected external USB device can be unrec-ognizable.
o When the formatted byte/sector
setting of External USB devices isnot either 512BYTE or 2048BYTE, then the device will not be recog- nized.
o Only the USB device formatted to FAT 12/16/32.
o USB device without USB IF au-
thentication may not be recogniz- able.
o Make sure the USB connection terminal does not come in contact with human body or any object.
o If you repeat mounting or dis- mounting USB device in a shortperiod of time, it may break thedevice.
o You might hear strange noise when
mounting or dismounting a USBdevice. o If you dismount the external USB
device during playback in USBmode, the external USB device can be damaged or malfunction. Therefore, mount the external USBdevice when the engine is turned off or in another mode.
o Depending on the type and capac-
ity of the external USB device orthe type of the files stored in the device, there is a difference in thetime taken for recognition of the device, but this is not a trouble Please wait for a moment.
o Do not use the USB device for other purposes than playing mu-sic files.
o Use of USB accessories such as the recharger or heater using USBI/F may lower the performance orcause trouble.
o If you use devices such as the USB
hub you purchased separately, thevehicle’s audio system may not recognize the USB device. Con- nect the USB device directly to themultimedia terminal of the vehicle.
CM-aust-1b.p65 5/19/2008, 6:33 PM
128

1
FEATURES OF YOUR HYUNDAI
129
1
FEATURES OF YOUR HYUNDAI
129
1
FEATURES OF YOUR HYUNDAI
129
1
FEATURES OF YOUR HYUNDAI
129
1
FEATURES OF YOUR HYUNDAI
129
o If USB device is divided by logical drives, only the music files on the highest-priority drive are recog- nized by car audio.
o Devices such as MP3 Player/ Cel- lular phone/Digital camera thoseare not recognizable by standardUSB I/F can be unrecognizable.
o USB devices other than standard-
ized goods (METAL COVER TYPE USB) can be unrecognizable.
o USB flash memory reader (such
as CF, SD, microSD, etc.) or exter-nal-HDD type devices can be un- recognizable.
o Music files protected by DRM (DIGI- TAL RIGHTS MANAGEMENT) arenot recognizalbe.
o The data in the USB memory may lost while using this AUDIO, It isrecommeded to back up impor- tant data on a personal.
o Please avoid using USB memoryproducts which can be used as key chains or cellular phone ac-cessories as they could cause damage to the USB jack. Please make certain only to use plug typeconnector products as shown be- low.
CM-aust-1b.p65 5/19/2008, 6:33 PM
