AUDIO ANTENNA
Revision: 2004 November 2004 FX35/FX45
Wiring Diagram — M/ANT —AKS007WF
TKWM0569E

AUDIO ANTENNA
AV-51
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2004 November 2004 FX35/FX45
Terminals and Reference Value for Audio UnitAKS007WW
Antenna Amp. InspectionAKS007WX
1. CHECK ANTENNA FEEDER
Check with visual observation if antenna feeder between audio unit and antenna amp. has disconnection or
malfunction on the mounting part (engagement, looseness of shield earth, etc.).
OK or NG
OK >> GO TO 2
NG >> Replace antenna feeder.
2. CHECK ANTENNA SIGNAL
1. Turn the ignition switch ACC.
2. Check voltage between audio unit harness connector M58 ter-
minal 5 (R/W) and ground.
OK or NG
OK >> INSPECTION END (System is OK)
NG >> Replace audio unit.
Terminal
(wire color)
ItemSignal
input/
outputCondition
Reference valueExample of symp-
tom
+–Ignition
switchOperation
5 (R/
W)GroundAntenna sig-
nalOutput ACC – Approx. 12VReceiving status of
radio broadcast
becomes bad.
10
(LG/R)GroundACC power
supplyInput ACC – Battery voltageSystem does not
work properly
5 – Ground : Approx. 12V
SKIA6854E

AV-52
AUDIO ANTENNA
Revision: 2004 November 2004 FX35/FX45
Location of AntennaAKS005TX
Window Antenna RepairAKS005TY
CHECK ELEMENT
1. Attach probe circuit tester (ohm setting) to antenna terminal on
each side.
SKIA5819E
SEL250I

AUDIO ANTENNA
AV-53
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2004 November 2004 FX35/FX45

When measuring continuity, wrap tin foil around the top of
probe. Then, press the foil against the wire with your finger.
2. If an element is broken, no continuity will exist.
3. To locate a break, move probe along element. Tester needle will
swing abruptly when probe passes the broken point.
SEL122R
SEL252I
SEL253I

AV-54
AUDIO ANTENNA
Revision: 2004 November 2004 FX35/FX45
Removal and Installation of Roof AntennaAKS005TZ
REMOVAL
1. Remove head lining. Refer to EI-42, "HEADLINING" .
2. Remove nut and remove rod and antenna base.
3. Remove instrument panel. Refer to IP-10, "
INSTRUMENT
PANEL ASSEMBLY" .
4. Disassembly antenna feeder (upper) and antenna feeder
(lower).
5. Disengaged the clips (7) to separate antenna feeder (upper)
from vehicle.
6. Pull off antenna feeder (lower) from audio unit.
7. Disengaged the clips (5) to separate antenna feeder (lower)
from vehicle.
INSTALLATION
Install in the reverse order of removal.
PKIA2463E
SKIA5821E

INTEGRATED DISPLAY SYSTEM
AV-55
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2004 November 2004 FX35/FX45
INTEGRATED DISPLAY SYSTEMPFP:28090
System DescriptionAKS00BO5
A/C AND AV SWITCH SYSTEM
Refer to Owner′s Manual for A/C and AV switch operating instructions.
Using the A/C and AV switch at the center of the instrument panel, the controls of the following systems are
centralized:

Integrated display system (Drive computer, setting screen, etc.)

Auto A/C system

Audio system
PRECAUTION OF LCD MONITOR

In order to use LED for backlight of a display, by in car temperature, brightness may change. In low tem-
perature, the refreshing rate of the picture also becomes low because of the low response of the LCD
monitor. When passenger room becomes warm, however, the LCD recovers the normal display.

Backlight sometimes flickers or darkens according to the total consumption hours and the number of times
switched ON and OFF. In this case, display unit should be replaced. (Exchange only of backlight is impos-
sible.)
POWER SUPPLY AND GROUND
Power is supplied at all times

through 15A fuse (No. 32, located in fuse and fusible link box)

to display unit terminal 1, and

to A/C and AV switch terminal 1.
When ignition switch is in ACC or ON position, power is supplied

through 10A fuse [No. 6, located in fuse block (J/B)]

to display unit terminal 2, and

to A/C and AV switch terminal 2.
When ignition switch is in ON or START position, power is supplied

through 10A fuse [No. 12, located in fuse block (J/B)]

to display unit terminal 3.
Ground is supplied

to display unit terminals 6 and 15, and

to A/C and AV switch terminal 5

through body grounds M35, M45 and M85.

AV-56
INTEGRATED DISPLAY SYSTEM
Revision: 2004 November 2004 FX35/FX45
DRIVE COMPUTER
Refer to Owner′s Manual for drive computer operating instructions.
TRIP Switch
When “TRIP” switch is pressed, display TRIP screen. As TRIP infor-
mation, it indicates journey time (TIME), trip odometer (DIST), aver-
age vehicle speed (AVG).
Pressing “TRIP” switch once cycles display from TRIP 1→TRIP
2→Display OFF→TRIP 1.
“TIME”

Journey time indication is performed by reset or battery connec-
tion.

When pushing “TRIP RESET” or “TRIP” switch more than
approximately 1.5 seconds, journey time will be reset.

If journey time is reset, journey distance and average speed will
be reset at the same time.
“DIST”

Trip odometer indication is performed by vehicle speed signal.

When pushing “TRIP RESET” or “TRIP” switch more than approximately 1.5 seconds, driving distance will
be reset.

If trip odometer is reset, journey time and average speed will be reset at the same time.
“AVG”

Average speed indication is performed by running distance and running time.

Indication will be renewed every 30 seconds.

When pushing “TRIP RESET” or “TRIP” switch more than approximately 1.5 seconds, average speed will
be reset.

After reset operation, the displays shows “ ” for 30 seconds.
FUEL ECON Switch
When “FUEL ECON” switch is pressed, display FUEL ECON screen.
As FUEL ECON information, it indicates average fuel consumption
(AVG), distance to empty (DTE).
Pressing “FUEL ECON” switch once cycles display from FUEL
ECON→Display OFF→FUEL ECON.
“AVG” (Average Fuel Consumption)

Average fuel consumption indication is performed by fuel con-
sumption signal and vehicle speed signal after system is reset.

Indication will be renewed every 30 seconds.

When pushing “TRIP RESET” or “FUEL ECON” switch more
than approximately 1.5 seconds, average fuel economy will be
reset.

After reset operation, the display shows “ . ” until the vehicle is driven 1,600 ft (500 m.) or 30 seconds
has passed.
“DTE” (Distance to Empty)

Distance to empty receives via CAN communication and indicates values calculated by meter.

Display range is maximum 999 miles (maximum 999 km).

If low-fuel WARNING is received from meter via CAN communication, distance to empty indication will be
“”.

Indication will be renewed every 30 seconds.
SKIA5916E
SKIA5917E

INTEGRATED DISPLAY SYSTEM
AV-57
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2004 November 2004 FX35/FX45
MAINT Switch (Maintenance Switch)

When “MAINT” switch is pressed, display vehicle information screen. As vehicle information, it indicates
engine oil, tire rotation and tire pressure.

Pressing “MAINT” switch once cycles display from engine oil→tire rotation→(tire pressure)Note →display
OFF→engine oil.
NOTE:
For models with low tire pressure warning system.
Engine Oil and Tire Rotation

Operating the joystick left/right, replace distance can be set.

When journey distance is the same as replace distance, alert is
displayed. (SERVICE ALERT setting is ON.)

Selected replace distance is 0 - 7,500 miles (0 - 12,000 km) in
increments of 500 mile (800 km).

Press and hold “TRIP RESET or MAINT” switch for 1.5 seconds
or longer, reset present journey distance.

During driving, cannot change settings.
Tire Pressure

Tire pressure signal is received from low tire pressure warning
control unit via CAN communication.

Tire pressure is displayed.

When FLAT TIRE signal is received from low tire pressure warn-
ing control unit, “FLAT TIRE” is displayed.
E/M SWITCH
When “E/M” (English/Metric) switch is pressed, change the unit as followings.
SKIA5918E
SKIA5919E
UnitUS Mile, °F, M P G
Metric km, °C, l/100km

AV-58
INTEGRATED DISPLAY SYSTEM
Revision: 2004 November 2004 FX35/FX45
SETTING SCREEN

Setting of electric status can be changed by A/C and AV switch. The signal is sent to BCM through display
unit to change vehicle electric system setting.

Display unit is communicating with driver seat control unit.

Pressing “SETTING” switch once cycles display from DISPLAY→LANGUAGE→BEEP SET→SERVICE
ALERT→PERSONALIZED SETTINGS MENU→DISPLAY OFF→DISPLAY.

Using the joystick, setting of each item will become possible.
Adjustable Vehicle Status
NOTE:
Setting in factory shipment is ON.
Setting itemsSetting varia-
tionsInitial
settingOperation
DISPLAY ON/OFF ON It switches displayed/Non-displayed of the screen.
LANGUAGEENGLISH/
FRANCAIS– It switches displayed language.
BEEP SET ON/OFF ONIt selects beep sound ON/OFF during switch operation. How-
ever, even if beep is set OFF, beep for NO OPERATION and
for screen interception are not reset.
SERVICE ALERT ON/OFF OFFIt switches displayed/Non-displayed of alert indication.

When the setting is ON, if engine oil or tire rotation will be
replace distance, alert is displayed.

When the setting is OFF, alert is not displayed.
PERSONALIZED
SETTING MENUSLIDE BACK DR
SEAT ON EXITON/OFF
ON
NoteThe driver’s seat automatically moves back and returns to
the original position for exceptional ease of exit and entry.
(Models with automatic drive positioner.)
LIFT STEERING
WHEEL ON EXITON/OFF
ON
NoteThe steering column automatically tilts up and returns to the
original position for exceptional ease of entry and exit. (Mod-
els with automatic drive positioner.)
REMOTE UNLOCK
DOOR LOGICDR-1ST/ALL DR-1STThis key can switch the unlock doors of the 1st unlocking
operation as follows:

Only the driver side door⇔All the doors
HORN CHIRP WITH
REMOTEON/OFF ONThis key changes the horn chirp mode occurring when press-
ing the LOCK button on the keyfob.
LAMPS FLASH
WITH REMOTEALL/LOCK/
UNLOCK/OFFALLThis key changes the hazard indicator flash mode occurring
when pressing the LOCK or UNLOCK button on the keyfob.
AUTO RE-LOCK
TIME5m/1m/OFF 1mThe length of auto door re-lock time can be set. Select the
“Auto Re-Lock timer” key, then move the joystick to adjust the
time.
AUTO HEADLAMP
SENSITIVITYLEVEL 1/2/3/4LEVEL
2Automatic light illumination can be set as desired. Select the
“Auto Headlamp Sensitivity” key, then move the joystick to
the left (lower) or right (higher).
AUTO HEADLAMP
OFF DELAYOFF/30/45/60/
90/120/150/
180 SEC45 SECThis key can control how long it takes the automatic turn off
timer to extinguish the headlamps in “AUTO” position. Select
the “Auto Headlamp Off Delay” key, then move the joystick to
the left or right to adjust the timer.
SPEED SENSING
WIPER INTERVALON/OFF ONThis key turns on and off the driving speed dependent inter-
mittent wiper function.
CONFIRM RESET
SETTINGSYES/NO NOWhen this key is selected and turned on using the “ENTER”
button, all settings mode by PERSONALIZED SETTINGS will
return to the initial conditions.

INTEGRATED DISPLAY SYSTEM
AV-59
C
D
E
F
G
H
I
J
L
MA
B
AV
Revision: 2004 November 2004 FX35/FX45
D/N SCREEN

Turning on “DAY/NIGHT” switch, DAY MODE or NIGHT MODE
is indicated for present mode.

If press “DAY/NIGHT” again when display adjustment lumi-
nance, change DAY-NIGHT(NIGHT-DAY) mode (screen of
adjustment luminance).
As follows:

Press “PREV” or not operate for 10sec. when displayed screen
of adjustment luminance, back to default screen (same mode).

Can adjust luminance by “DISP” switch. Light can be adjusted by pressing “+” (bright) or “–” (dark).

Adjustment range is a 12 stage (MIN to MAX) and default set value is 10 (DAY) and 4 (NIGHT).
WARNING INDICATIONS
When BCM receives warning signal from some control units or sensors, then combination meter warning lamp
is illuminated.
Then BCM sends warning signal to display unit warning indications on the screen.
AV COMMUNICATION LINE
Display unit is controlled by the following unit with AV communication line.

A/C and AV switch
NOW Change display
DAY DAY→NIGHT→DAY→·····
NIGHT NIGHT→DAY→NIGHT→·····
SKIA5920E
Warning indicatorsWarning lamps in
instrument panelWarning detection and cancel conditions Cases of malfunction
DOOR OPEN DoorDetection
conditionVehicle is running [approx. 3.5 km/h (2 MPH) or
faster] and door ajar of any of the doors is detected.
Door is open
Cancel
conditionVehicle is stopped and all the doors close.
