POSITIVE CRANKCASE VENTILATION
DescriptionINFOID:0000000001326507
SYSTEM DESCRIPTION
This system returns blow-by gas to the intake manifold.
The positive crankcase ventilation (PCV) valve is pr
ovided to conductcrankcase blow-by gas to the intake
manifold.
During partial throttle operation of the engine, the intake manifoldsucks the blow-by gas through the PCV
valve.
Normally, the capacity of the valv e is sufficient to handle any blow-b yand a small amount of ventilating air.
The ventilating air is then drawn from the air inlet tubes into thecrankcase. In this process the air passes
through the hose connecting airinlet tubes to rocker cover.
Under full-throttle condition, the manifold vacuum is insu fficient todraw the blow-by flow through the valve. The
flow goes through the hose connectionin the reverse direction.
On vehicles with an excessively high blow-by, the valve does not
meetthe requirement. This is because some of the flow will go
through the hoseconnection to the air inlet tubes under all condi-
tions.
Component InspectionINFOID:0000000001326508
PCV (POSITIVE CRANKCASE VENTILATION) VALVE
PBIB0062E
PBIB1588E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ON BOARD DIAGNOSTIC (OBD) SYSTEMEC-637
< SERVICE INFORMATION > [VK45DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
*6: Models with ICC.
*7: SRT code will not be set if the self-diagnostic result is NG.
*8: When the ECM is in the mode of displaying SRT status, MIL may flash. For the details, refer to "How to Display SRT Status".
DTC AND 1ST TRIP DTC
The 1st trip DTC (whose number is the same as the DT
C number) is displayed for the latest self-diagnostic
result obtained. If the ECM memory was cleared previous ly, and the 1st trip DTC did not reoccur, the 1st trip
DTC will not be displayed.
If a malfunction is detected during the 1st trip, the 1st trip DTC is stored in the ECM memory. The MIL will not
light up (two trip detection logic). If the same malfunc tion is not detected in the 2nd trip (meeting the required
driving pattern), the 1st trip DTC is cleared from the ECM memory. If the same malfunction is detected in the
2nd trip, both the 1st trip DTC and DTC are stored in t he ECM memory and the MIL lights up. In other words,
the DTC is stored in the ECM memory and the MIL light s up when the same malfunction occurs in two consec-
utive trips. If a 1st trip DTC is stored and a non-diagnostic operation is performed between the 1st and 2nd
trips, only the 1st trip DTC will continue to be stored. Fo r malfunctions that blink or light up the MIL during the
1st trip, the DTC and 1st trip DTC are stored in the ECM memory.
Procedures for clearing the DTC and the 1st trip DT C from the ECM memory are described in "HOW TO
ERASE EMISSION-RELATED DIAGNOSTIC INFORMATION".
For malfunctions in which 1st trip DTCs are displa yed, refer to "EMISSION-RELATED DIAGNOSTIC INFOR-
MATION ITEMS". These items are required by legal r egulations to continuously monitor the system/compo-
nent. In addition, the items monitored non-cont inuously are also displayed on CONSULT-III.
1st trip DTC is specified in Service $07 of SAE J1979. 1st trip DTC detection occurs without lighting up the MIL
and therefore does not warn the driver of a malfunction. However, 1st trip DTC detection will not prevent the
vehicle from being tested, for example during Inspection/Maintenance (I/M) tests.
When a 1st trip DTC is detected, check, print out or write down and erase (1st trip) DTC and Freeze Frame
data as specified in Work Flow procedure Step 2, refer to EC-666, "
Trouble Diagnosis Introduction". Then per-
form DTC Confirmation Procedure or Overall Function Che ck to try to duplicate the malfunction. If the mal-
function is duplicated, the item requires repair.
How to Read DTC and 1st Trip DTC
DTC and 1st trip DTC can be read by the following methods.
With CONSULT-III
With GST
CONSULT-III or GST (Generic Scan Tool ) Examples: P0340, P0850, P1148, etc.
These DTCs are prescribed by SAE J2012.
(CONSULT-III also displays the malfunctioning component or system.)
No Tools
The number of blinks of the MIL in the Diagnostic Test Mode II (Self-Diagnostic Results) indicates the DTC.
Example: 0340, 0850, 1148, etc.
These DTCs are controlled by NISSAN.
 1st trip DTC No. is the same as DTC No.
 Output of a DTC indicates a malfunc tion. However, GST or the Diagnostic Test Mode II do not indi-
cate whether the malfunction is stil l occurring or has occurred in the past and has returned to nor-
mal. CONSULT-III can identify malfunction status as shown below. Therefore, using CONSULT-III (if
available) is recommended.
A sample of CONSULT-III display for DTC and 1st trip DT C is shown below. DTC or 1st trip DTC of a malfunc-
tion is displayed in SELF-DIAGNOSTIC RESULTS m ode of CONSULT-III. Time data indicates how many
times the vehicle was driven after the last detection of a DTC.
If the DTC is being detected currently, the time data will be [0].
If a 1st trip DTC is stored in the ECM, the time data will be [1t].
FREEZE FRAME DATA AND 1ST TRIP FREEZE FRAME DATA
The ECM records the driving conditions such as fuel system status, calculated load value, engine coolant tem-
perature, short term fuel trim, long term fuel trim, engi ne speed, vehicle speed, absolute throttle position, base
fuel schedule and intake air temperature at the moment a malfunction is detected.
Data which are stored in the ECM memory, along with the 1st trip DTC, are called 1st trip freeze frame data.
The data, stored together with the DTC data, are ca lled freeze frame data and displayed on CONSULT-III or
GST. The 1st trip freeze frame data can only be displa yed on the CONSULT-III screen, not on the GST. For
details, see EC-695, "
CONSULT-III Function (ENGINE)".
Only one set of freeze frame data (either 1st trip freez e frame data or freeze frame data) can be stored in the
ECM. 1st trip freeze frame data is stored in the ECM me mory along with the 1st trip DTC. There is no priority
for 1st trip freeze frame data and it is updated each time a different 1st trip DTC is detected. However, once
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

TROUBLE DIAGNOSISEC-671
< SERVICE INFORMATION > [VK45DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Fail-Safe ChartINFOID:0000000001326525
When the DTC listed below is detected, the EC
M enters fail-safe mode and the MIL lights up.
Priority Detected items (DTC)
1  U1000 U1001 CAN communication line  U1010 CAN communication
 P0101 P0102 P0103 Mass air flow sensor
 P0112 P0113 P0127 Intake air temperature sensor
 P0117 P0118 P0125 Engine coolant temperature sensor
 P0122 P0123 P0222 P0223 P1225 P1226 P2135 Throttle position sensor
 P0128 Thermostat function
 P0181 P0182 P0183 Fuel tank temperature sensor
 P0327 P0328 P0332 P0333 Knock sensor
 P0335 Crankshaft position sensor (POS)
 P0340 Camshaft posi tion sensor (PHASE)
 P0460 P0461 P0462 P0463 Fuel level sensor
 P0500 Vehicle speed sensor
 P0605 ECM
 P0643 Sensor power supply
 P0700 TCM
 P0705 Park/neutral position (PNP) switch
 P0850 Park/neutral position (PNP) switch
 P1610 - P1615 NATS
 P2122 P2123 P2127 P2128 P2138 Accelerator pedal position sensor
2  P0031 P0032 P0051 P0052 Air fuel ratio (A/F) sensor 1 heater  P0037 P0038 P0057 P0058 Heated oxygen sensor 2 heater
 P0075 P0081 Intake valve timing control solenoid valve
 P0130 P0131 P0132 P0133 P0150 P0151 P0152 P0153 P2A00 P2A03 Air fuel ratio (A/F) sensor 1
 P0137 P0138 P0139 P0157 P0158 P0159 Heated oxygen sensor 2
 P0441 EVAP control system purge flow monitoring
 P0443 P0444 P0445 EVAP canister purge volume control solenoid valve
 P0447 P0448 EVAP canister vent control valve
 P0451 P0452 P0453 EVAP control system pressure sensor
 P0550 Power steering pressure sensor
 P0603 ECM power supply
 P0710 P0717 P0720 P0731 P0732 P0733 P0734 P0735 P0740 P0744 P0745 P1730 P1752 P1757 P1762 P1767
P1772 P1774 A/T related sensors, solenoid valves and switches
 P1140 P1145 Intake valve timing control position sensor
 P1217 Engine over temperature (OVERHEAT)
 P1805 Brake switch
 P2100 P2103 Throttle control motor relay
 P2101 Electric throttle control function
 P2118 Throttle control motor
3  P0011 P0021 Intake valve timing control  P0171 P0172 P0174 P0175 Fuel injection system function
 P0300 - P0308 Misfire
 P0420 P0430 Three way catalyst function
 P0442 P0456 EVAP co ntrol system (SMALL LEAK, VERY SMALL LEAK)
 P0455 EVAP control system (GROSS LEAK)
 P0506 P0507 Idle speed control system
 P1148 P1168 Closed loop control
 P1211 TCS control unit
 P1212 TCS communication line
 P1421 Cold start control
 P1564 ICC steering switch / ASCD steering switch
 P1568 ICC command value
 P1572 ICC brake switch / ASCD brake switch
 P1574 ICC vehicle speed sensor / ASCD vehicle speed sensor
 P1715 Turbine revolution sensor
 P1800 VIAS control solenoid valve
 P2119 Electric throttle control actuator
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

EC-674
< SERVICE INFORMATION >[VK45DE]
TROUBLE DIAGNOSIS
1 - 6: The numbers refer to the order of inspection.
(continued on next page)
SYSTEM — ENGINE MECHANICAL & OTHER
Vehicle speed signal circuit 2 3 3 3
EC-992
Power steering pressure sensor circuit 2 3 3EC-998
ECM 22333333333EC-1003,
EC-1007
Intake valve timing control solenoid valve cir-
cuit 32 13223 3
EC-754
PNP switch circuit 3 3 3 3 3 EC-1014
Refrigerant pressure sensor circuit 2 3 3 4EC-1177
Electrical load signal circuit 3EC-1147
Air conditioner circuit 223333333 3 2AT C - 3 2
VIAS control solenoid valve circuit 1EC-1080
ABS actuator and electric unit (control unit) 4EC-1028
SYMPTOM
Reference
page
HARD/NO START/RESTART (EXCP. HA)
ENGINE STALL
HESITATION/SURGING/FLAT SPOT
SPARK KNOCK/DETONATION
LACK OF POWER/POOR ACCELERATION
HIGH IDLE/LOW IDLE
ROUGH IDLE/HUNTING
IDLING VIBRATION
SLOW/NO RETURN TO IDLE
OVERHEATS/WATER TEMPERATURE HIGH
EXCESSIVE FUEL CONSUMPTION
EXCESSIVE OIL CONSUMPTION
BATTERY DEAD (UNDER CHARGE)
Warranty symptom code AA AB AC AD AE AF AG AH AJ AK AL AM HA
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

TROUBLE DIAGNOSISEC-675
< SERVICE INFORMATION > [VK45DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
SYMPTOM
Reference
page
HARD/NO START/RESTART (EXCP. HA)
ENGINE STALL
HESITATION/SURGING/FLAT SPOT
SPARK KNOCK/DETONATION
LACK OF POWER/POOR ACCELERATION
HIGH IDLE/LOW IDLE
ROUGH IDLE/HUNTING
IDLING VIBRATION
SLOW/NO RETURN TO IDLE
OVERHEATS/WATER TEMPERATURE HIGH
EXCESSIVE FUEL CONSUMPTION
EXCESSIVE OIL CONSUMPTION
BATTERY DEAD (UNDER CHARGE)
Warranty symptom code AA AB AC AD AE AF AG AH AJ AK AL AM HA
Fuel Fuel tank 5
5 FL-10
Fuel piping 5 5 5 5 5 5
EM-190
Va p o r l o c k —
Valve deposit 5 555 55 5 —
Poor fuel (Heavy weight gasoline,
Low octane) —
Air Air duct
55555 5 EM-173
Air cleaner
EM-173
Air leakage from air duct
(Mass air flow sensor — electric
throttle control actuator)
5555 EM-173
Electric throttle control actuator
EM-175
Air leakage from intake manifold/
Collector/GasketEM-175
Cranking Battery
111111
11
SC-4
Generator circuit
SC-19
Starter circuit 3SC-8
Signal plate 6EM-241
PNP switch 4AT- 1 0 2
Engine Cylinder head
55555 55 5 EM-226
Cylinder head gasket 4 3
Cylinder block
66666 66 6 4
EM-241
Piston
Piston ring
Connecting rod
Bearing
Crankshaft
Va l v e
mecha-
nism Timing chain
55555 55 5 EM-199
Camshaft
EM-211
Intake valve timing controlEM-199
Intake valve
3EM-199
Exhaust valve
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

TROUBLE DIAGNOSISEC-677
< SERVICE INFORMATION > [VK45DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
Engine Control Com
ponent Parts LocationINFOID:0000000001326527
1. IPDM E/R 2. ICC brake hold relay
(ICC models only)3. Refrigerant pressure sensor
4. Intake valve timing control position sensor (Bank 2) 5. Intake valve timing control solenoid
valve (Bank 2) 6. Electric throttle control actuator
7. Cooling fan motor 8. Intake valve timing control solenoid valve (Bank 1)9. Intake valve timing control position
sensor (Bank 1)
10. Camshaft position sensor (PHASE) 11. Mass air flow sensor
(with intake air temperature sensor) 12. Ignition coil (with power transistor)
and spark plug (Bank 1)
13. Vacuum tank 14. VIAS control solenoid valve 15. Engine coolant temperature sensor
16. Fuel injector (Bank 1) 17. Power valve actuator 18. Knock sensor (Bank 1)
19. Knock sensor (Bank 2) 20. Fuel injector (Bank 2) 21. EVAP canister purge volume control solenoid valve
22. EVAP service port 23. Ignition coil (with power transistor) and spark plug (Bank 2)
PBIB3224E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

EC-678
< SERVICE INFORMATION >[VK45DE]
TROUBLE DIAGNOSIS
: Vehicle front
1. Mass air flow sensor (with intake air temperature sensor) 2. Camshaft position sensor (PHASE) 3. Engine coolant temperature sensor
4. Engine coolant temperature sensor sub-harness connector 5. Knock sensor (Bank 1) 6. Knock sensor (Bank 2)
7. Refrigerant pressure sensor
PBIB3225E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

TROUBLE DIAGNOSISEC-679
< SERVICE INFORMATION > [VK45DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
: Vehicle front
1. Intake valve timing control position sensor (Bank 2) 2. Intake valve timing control solenoid
valve (Bank 2) 3. Intake valve timing control solenoid
valve (Bank 1)
4. Intake valve timing control position sensor (Bank 1) 5. Electric throttle control actuator 6. Condenser
7. Ignition coil (with power transistor) (Bank 2) 8. Ignition coil (with power transistor)
(Bank 1)
PBIB3226E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

EC-684
< SERVICE INFORMATION >[VK45DE]
TROUBLE DIAGNOSIS
Vacuum Hose Drawing
INFOID:0000000001326528
Refer to EC-609, "Schematic" for Vacuum Control System.
: Vehicle front : To EVAP canister purge volume control solenoid valve
1. Intake manifold collector 2. Vacuum tank 3. VIAS control solenoid valve
4. Power valve actuator
NOTE:
Do not use soapy water or any type of solvent while installing vacuum hoses or purge hoses.
PBIB3222E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

EC-688
< SERVICE INFORMATION >[VK45DE]
TROUBLE DIAGNOSIS
5L/BThrottle control motor
(Open) [Ignition switch: ON]
 Engine stopped
 Selector lever: D
 Accelerator pedal: Fully depressed 0 - 14V
6R Heated oxygen sensor 2
heater (Bank 1) [Engine is running]
 Engine speed: Below 3,600 rpm after the fol-
lowing conditions are met
- Engine: After warming up
- Keeping the engine speed between 3,500
and 4,000 rpm for 1 minute and at idle for 1
minute under no load 0 - 1.0V
[Ignition switch: ON]
 Engine stopped
[Engine is running]
 Engine speed: Above 3,600 rpm BATTERY VOLTAGE
(11 - 14V)
10 OR Intake valve timing control
solenoid valve (Bank 1) [Engine is running]

Warm-up condition
 Idle speed BATTERY VOLTAGE
(11 - 14V)
[Engine is running]
 Warm-up condition
 Engine speed: 2,000rpm 7 - 12V
11 B R Intake valve timing control
solenoid valve (Bank 2) [Engine is running]

Warm-up condition
 Idle speed BATTERY VOLTAGE
(11 - 14V)
[Engine is running]
 Warm-up condition
 Engine speed: 2,000rpm 7 - 12V
12 R/G Power steering pressure
sensor [Engine is running]
 Steering wheel: Being turned
0.5 - 4.5V
[Engine is running]
 Steering wheel: Not being turned 0.4 - 0.8V
TER-
MI-
NAL NO. WIRE
COLOR ITEM CONDITION DATA (DC Voltage)
PBIB1105E
PBIB1790E
PBIB1790E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
