INFINITI FX35 2008 Service Manual

BCM (BODY CONTROL MODULE)BCS-11
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
BCS
N
O P
CONSULT-III Function (BCM)INFOID:0000000001328611
CONSULT-III can display each diagnostic item using the diagnostic test mode shown following.
TKWM4453E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

BCS-12
< SERVICE INFORMATION >
BCM (BODY CONTROL MODULE)
ITEMS OF EACH PART
BCM can perform the following functions for each system.
NOTE:
CONSULT-III displays systems equipped in the vehicle.
×:Applicable
NOTE:
 *1: Vehicle with remote keyless entry system display this item.
 *2: Vehicle with Intelligent Key system display this item.
 *3: This item is displayed, but does not function.
WORK SUPPORT
Display Item List
BCM Diagnostic test item Check item, diagnostic test mode Content
Inspection by part WORK SUPPORT Changes setting of each function.
SELF-DIAG RESULTS BCM performs self-diagnosis of CAN communication.
DATA MONITOR Displays the input data of BCM in real time.
CAN DIAG SUPPORT MNTR
The transmit/receive diagnosis result of CAN communication can be
read.
ACTIVE TEST Gives a drive signal to a load to check the operation.
ECU PART NUMBER ECM part number can be read.
CONFIGURATION (Not be used)
System and item CONSULT-III display Diagnostic test mode (Inspection by part)
WORK SUPPORT DATA MONITOR ACTIVE TEST
BCM BCM ×
Power door lock system DOOR LOCK ×××
Rear window defogger REAR DEFOGGER ××
Warning chime BUZZER ××
Room lamp timer INT LAMP ×××
Remote keyless entry system*
1MULTI REMOTE ENT ×××
Headlamp HEAD LAMP ×××
Wiper WIPER ×××
Turn signal lamp
Hazard lamp FLASHER
××
Blower fan switch signal
A/C switch signal AIR CONDITONER
×
Intelligent Key system*
2INTELLIGENT KEY ×
Combination switch COMB SW ×
NVIS IMMU ××
Room lamp battery saver BATTERY SAVER ×× ×
Trunk lid TRUNK*
3××
Vehicle security system THEFT ALM ×××
Retained power control RETAINED PWR ×××
Oil pressure swit ch SIGNAL BUFFER ××
Low tire pressure warning system AIR PRESSURE MONITOR ×××
Panic system PANIC ALARM ×
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

BCM (BODY CONTROL MODULE)BCS-13
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
BCS
N
O P
SELF-DIAG RESULTS
U1000 CAN Communication CircuitINFOID:0000000001606767
1.PERFORM SELF DIAGNOSTIC
1. Turn ignition switch ON and wait for 2 seconds or more.
2. Check “Self Diagnostic Result” of BCM.
Is
“CAN COMM CIRCUIT” displayed?
YES >> Refer to LAN-14, "Trouble Diagnosis Flow Chart".
NO >> Refer to GI-25, "
How to Perform Efficient Diagnosis for an Electrical Incident".
Removal and Installation of BCMINFOID:0000000001328613
REMOVAL
1. Remove the dash side finisher (LH). Refer to EI-38.
2. Disconnect BCM connector.
3. Remove bracket mounting screws (3) to remove BCM and fuse block with bracket.
Item Description
RESET SETTING VALUE Return a value set with WORK SUPPORT of each system to a default value in factory shipment.
DTC DTC Detection Condition Possible cause
U1000: CAN COMM CIRCUIT When BCM cannot communicate CAN com-
munication signal continuously for 2 sec-
onds or more. Any item (or items) of the following listed below is
malfunctioning in CAN communication system.
Transmission
 Receiving (ECM)
 Receiving (IPDM E/R)
 Receiving (METER/M&A)
 Receiving (I-KEY)
SKIA4964E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

BCS-14
< SERVICE INFORMATION >
BCM (BODY CONTROL MODULE)
4. Raise the pawl of fuse block and remove bracket from fuse blockto remove BCM.
INSTALLATION
Installation is the reverse order of removal.
NOTE:
When replacing BCM perform initialization of NATS s ystem and registration of all NATS ignition key IDs.
SKIA4965E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

BL-1
BODY
C
DE
F
G H
J
K L
M
SECTION BL
A
B
BL
N
O P
CONTENTS
BODY, LOCK & SECURITY SYSTEM
SERVICE INFORMATION .. ..........................4
DTC INDEX ..................................................... .....4
INTELLGENT KEY UNIT U1000 ...............................4
INTELLGENT KEY UNIT B2013-B2014 ............. ......4
ECM P1610-P1615 ...................................................4
PRECAUTIONS ...................................................5
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
5
Precaution Necessary for Steering Wheel Rota-
tion After Battery Disconnect .....................................
5
Precaution for Work ..................................................5
PREPARATION ...................................................6
Special Service Tool ........................................... ......6
Commercial Service Tool ..........................................6
SQUEAK AND RATTLE TROUBLE DIAGNO-
SIS .......................................................................
7
Work Flow ........................................................... ......7
Generic Squeak and Rattle Troubleshooting ............9
Diagnostic Worksheet .............................................11
HOOD .................................................................13
Fitting Adjustment ............................................... ....13
Removal and Installation of Hood Assembly ...........14
Removal and Installation of Hood Lock Control ......15
Hood Lock Control Inspection ............................. ....16
RADIATOR CORE SUPPORT ...........................18
Removal and Installation ..................................... ....18
FRONT FENDER ................................................20
Removal and Installation ..................................... ....20
POWER DOOR LOCK SYSTEM ........................21
Component Parts and Harness Connector Loca-
tion ...................................................................... ....
21
System Description .................................................22
CAN Communication System Description ...............23
CAN Communication Unit .................................... ....23
Schematic/With Intelligent Key ................................24
Wiring Diagram - D/LOCK -/With Intelligent Key .....25
Schematic/Without Intellig ent Key ...........................30
Wiring Diagram - D/LOCK -/Without Intelligent
Key ...................................................................... ....
31
Terminal and Reference Value for BCM ..................35
Terminal and Reference Value for Intelligent Key
Unit (With Intelligent Key System) ...........................
35
Work Flow ................................................................36
CONSULT-III Function (BCM) .................................36
Trouble Diagnosis Chart by Symptom .....................37
Check BCM Power Supply and Ground Circuit .......37
Check Door Switch ..................................................38
Check Key Switch ....................................................42
Check Door Lock and Unlock Switch ......................43
Check Door Lock Actuator (Driver Side) .................45
Check Door Lock Actuator (Passenger Side and
Rear LH/RH) ............................................................
45
Check Fuel Lid Lock Actuator ..................................46
Check Front Door Key Cylinder Switch (Lock) ........47
Check Front Door Key Cylinder Switch (Unlock) .....47
Check Select Unlock Relay Circuit ..........................48
REMOTE KEYLESS ENTRY SYSTEM .............50
Component Parts and Harness Connector Loca-
tion ...........................................................................
50
System Description ..................................................50
CAN Communication System Description ...............53
CAN Communication Unit ........................................53
Schematic ................................................................54
Wiring Diagram - KEYLES - ....................................55
Terminal and Reference Value for BCM ..................58
Terminal and Reference Value for IPDM E/R ..........59
CONSULT-III Function (BCM) .................................60
Work Flow ................................................................62
Trouble Diagnosis Chart by Symptom .....................62
Check Key Fob Battery and Function ......................63
Check ACC Switch ..................................................64
Check Door Switch ..................................................65
Check Key Switch ....................................................68
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

BL-2
Check Remote Keyless Entry Receiver ..................69
Check IPDM E/R Operation ....................................71
Check Hazard Warning Lamp Function ..................72
Check Horn Function ..............................................72
Check Headlamp Function .....................................72
Check Map Lamp and Ignition Keyhole Illumina-
tion Function ...........................................................
72
ID Code Entry Procedure .......................................73
Removal and Installation of Remote keyless Entry
receiver ................................................................ ...
75
Key Fob Battery Replacement ................................75
INTELLIGENT KEY SYSTEM ............................76
Component Parts and Harness Connector Loca-
tion ....................................................................... ...
76
System Description .................................................78
CAN Communication System Description ..............83
CAN Communication Unit .......................................84
Schematic ...............................................................84
Wiring Diagram - I/KEY - ........................ ................86
Terminal and Reference Value for INTELLIGENT
KEY UNIT ........... ................................. ...................
99
Terminal and Reference Value for Steering Lock
unit ....................................................................... ..
101
Terminal and Reference Value for BCM ................101
Terminal and Reference Value for IPDM E/R ........102
Diagnosis Procedure .............................................103
CONSULT-III Functions (INTELLIGENT KEY) ......103
CONSULT-III Application Item ............................. ..104
List of Operation Related Parts .............................105
Trouble Diagnosis Symptom Chart ........................106
Check CAN Communication System Inspection ....111
Check Intelligent Key Unit Power Supply and
Ground Circuit ..................................................... ..
111
Check Key Switch (Intelligent Key Unit Input) .......112
Check Key Switch (BCM Input) ........................... ..113
Check Ignition Knob Switch ...................................114
Check Door Switch ................................................115
Check Unlock Sensor ............................................117
Check Door Request Switch ..................................119
Check Intelligent Key Warning Buzzer ..................120
Check Outside Key Antenna ............................... ..121
Check Inside Key Antenna ....................................123
Check Steering Lock Unit ......................................124
Check Stop Lamp Switch ......................................126
Check Park Position Switch ...................................126
Check Select Unlock Relay ...................................128
Check Hazard Function .........................................128
Check Horn Function .............................................129
Check Headlamp Function ....................................129
Check IPDM E/R Operation ...................................129
Removal and Installation of Intelligent Key Unit ....130
Intelligent Key Battery Re placement .....................130
DOOR .............................................................. .131
Fitting Adjustment ................................................ ..131
Removal and Installation of Front Door .................132
Removal and Installation of Rear Door ..................133
Removal and Installation of Door Weatherstrip .....134
FRONT DOOR LOCK .......................................135
Removal and Installation ...................................... .135
REAR DOOR LOCK .........................................138
Removal and Installation ...................................... .138
BACK DOOR .................................................. ..141
Fitting Adjustment ................................................ .141
Back Door Assembly .............................................141
Removal and Installation of Back Door Striker .....142
Removal and Installation of Back Door Stay .........143
Removal and Installation of Dave Tail Male & Fe-
male ..................................................................... .
144
Removal and Installation of Back Door Weather-
strip .......................................................................
144
BACK DOOR LOCK ASSEMBLY ....................146
Removal and Installation of Back Door Lock &
Closure Assembly ................................................ .
146
Removal and Installation of Back Door Opener
Switch ...................................................................
146
Disassembly and Assembly ..................................147
BACK DOOR AUTO CLOSURE SYSTEM ......148
Component Parts and Harness Connector Loca-
tion ....................................................................... .
148
System Description ...............................................148
Wiring Diagram - B/CLOS - ...................................150
Terminal and Reference Value for Back Door Clo-
sure Control Unit ...................................................
152
Work Flow .............................................................153
Preliminary Check .................................................153
Trouble Diagnosis Chart by Symptom ..................153
Check Back Door Closure Control Unit Power
Supply and Ground Circuit ....................................
153
Check Half-Latch Switch .......................................154
Check Close Switch ..............................................155
Check Open Switch ..............................................156
Check Back Door Opener Switch (With Intelligent
Key) ...................................................................... .
157
Check Back Door Opener Switch (Without Intelli-
gent Key) ...............................................................
159
Check Unlock Sensor (Without Intelligent Key) ....160
Check Closure Motor ........................................... .161
Removal and Installation of Back Door Closer
Control Unit ...........................................................
162
VEHICLE SECURITY (THEFT WARNING)
SYSTEM ...........................................................
163
Component Parts and Harness Connector Loca-
tion ....................................................................... .
163
System Description ...............................................164
CAN Communication System Description ............166
CAN Communication Unit .....................................166
Schematic .............................................................167
Wiring Diagram - VEHSEC - .................................168
Terminal and Reference Value for BCM ...............173
Terminal and Reference Value for IPDM E/R .......174
CONSULT-III Function ..........................................174
Trouble Diagnosis .................................................176
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

BL-3
C
DE
F
G H
J
K L
M A
B
BL
N
O P
Preliminary Check ...............................................
..
177
Trouble Diagnosis Symptom Chart .......................177
Diagnosis Procedure 1 ..........................................178
Diagnosis Procedure 2 ..........................................182
Diagnosis Procedure 3 ..........................................183
Diagnosis Procedure 4 ..........................................183
Diagnosis Procedure 5 ..........................................183
Diagnosis Procedure 6 ..........................................184
IVIS (INFINITI VEHICLE IMMOBILIZER SYS-
TEM-NATS) ......................................................
185
Component Parts and Harness Connector Loca-
tion ...................................................................... ..
185
System Description ...............................................185
System Composition .............................................186
ECM Re-Communicating Function ........................187
Wiring Diagram - NATS - ......................................188
Terminal and Reference Value for Steering Lock
Unit/with Intelligent Key System ............................
191
Terminal and Reference Value for Intelligent Key
Unit/with Intelligent Key System ............................
191
Terminal and Reference Value for BCM ............. ..192
CONSULT-III Function ..........................................192
Diagnosis Procedure .............................................194
Trouble Diagnosis Symptom Chart ...................... ..195
Security Indicator Inspection .................................195
Diagnosis Procedure 1 ..........................................195
Diagnosis Procedure 2 ..........................................197
Diagnosis Procedure 3 ..........................................197
Diagnosis Procedure 4 ..........................................197
Diagnosis Procedure 5 ..........................................198
Diagnosis Procedure 6 ..........................................200
Removal and Installation NATS Antenna Amp ......201
INTEGRATED HOMELINK TRANSMITTER ..202
Wiring Diagram - TRNSCV - ..................................202
Trouble Diagnosis ..................................................202
BODY REPAIR ................................................204
Body Exterior Paint Color ......................................204
Body Component Parts .........................................205
Corrosion Protection ..............................................208
Body Sealing .........................................................211
Body Construction .................................................215
Body Alignment .....................................................215
Handling Precaution for Plastics ............................225
Precaution in Repairing High Strength Steel .........228
Replacement Operation .........................................230
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

BL-4
< SERVICE INFORMATION >
DTC INDEX
SERVICE INFORMATION
DTC INDEX
INTELLGENT KEY UNIT U1000INFOID:0000000001529387
INTELLGENT KEY UNIT B2013-B2014INFOID:0000000001529388
ECM P1610-P1615INFOID:0000000001529389
CONSULT display Descr iption Reference page
U1000: CAN COMM CIRCUIT M alfunction is detected in CA N communication.
BCS-13, "
U1000 CAN
Communication Circuit"
CONSULT display Descr iption Reference page
B2013: STRG COMM 1 .Malfunction is detected in communication of Intelligent
Key unit and steering lock unit BL-124, "
Check Steering
Lock Unit"
B2014: STRG COMM 2
Malfunction is detected in communication of Intelligent Key
unit and steering lock unit. BL-124, "Check Steering
Lock Unit"
CONSULT display Descr
iption Reference page
P1610: LOCK MODE When the starting operation is carried out 5 or more times
consecutively under the following conditions, IVIS(NATS)
will shift the mode to prevent the engine start.
• unregistered ignition key is used (without intelligent key
system)
 BCM or ECM malfunctioning BL-198, "
Diagnosis Proce-
dure 5"
P1611: ID DISCORD, IMM-ECM
The result of ID verification between BCM and ECM is NG.
System initialization is required. BL-197, "Diagnosis Proce-
dure 4"
P1612: CHAIN OF ECM-IMMU Communication impossible between ECM and BCM.
BL-197, "Diagnosis Proce-
dure 2"
P1613: ECM INT CIRC-IMMUThe malfunction of ECM internal circuit to BCM communi-
cation line is detected. BL-195, "Diagnosis Proce-
dure 1"
P1614: CHAIN OF IMMU-KEY BCM cannot receive the key ID signal.
BL-200, "Diagnosis Proce-
dure 6"
P1615: DIFFERENCE OF KEY
BCM can receive the key ID signal but the result of ID ver-
ification between key ID and BCM is NG. BL-197, "Diagnosis Proce-
dure 3"
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

PRECAUTIONSBL-5
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
BL
N
O P
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000001612892
The Supplemental Restraint System such as “A IR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severi ty of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the “SUPPLEMENTAL RESTRAINT SYS-
TEM” and “SEAT BELTS” of this Service Manual.
WARNING:
• To avoid rendering the SRS inoper ative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
 Improper maintenance, including in correct removal and installation of the SRS, can lead to personal
injury caused by unintentional act ivation of the system. For removal of Spiral Cable and Air Bag
Module, see the “SUPPLEMEN TAL RESTRAINT SYSTEM”.
 Do not use electrical test equipm ent on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identi fied by yellow and/or orange harnesses or har-
ness connectors.
Precaution Necessary for Steering Wh eel Rotation After Battery Disconnect
INFOID:0000000001612889
NOTE:
 This Procedure is applied only to models with Intell igent Key system and NVIS/IVIS (NISSAN/INFINITI
VEHICLE IMMOBILIZER SYSTEM - NATS).
 Remove and install all control units after disconnecti ng both battery cables with the ignition knob in the
″ LOCK ″ position.
 Always use CONSULT-III to perform self-diagnosis as a part of each function inspection after finishing work.
If DTC is detected, perform trouble diagnosis according to self-diagnostic results.
For models equipped with the Intelligent Key system and NVIS/IVIS, an electrically controlled steering lock
mechanism is adopted on the key cylinder.
For this reason, if the battery is disconnected or if the battery is discharged, the steering wheel will lock and
steering wheel rotation will become impossible.
If steering wheel rotation is required when battery pow er is interrupted, follow the procedure below before
starting the repair operation.
OPERATION PROCEDURE
1. Connect both battery cables. NOTE:
Supply power using jumper cables if battery is discharged.
2. Use the Intelligent Key or mechanical key to turn the ignition switch to the ″ACC ″ position. At this time, the
steering lock will be released.
3. Disconnect both battery cables. The steering lock will remain released and the steering wheel can be
rotated.
4. Perform the necessary repair operation.
5. When the repair work is completed, return the ignition switch to the ″LOCK ″ position before connecting
the battery cables. (At this time, the steering lock mechanism will engage.)
6. Perform a self-diagnosis check of all control units using CONSULT-III.
Precaution for WorkINFOID:0000000001327777
 After removing and installing the opening/closing parts, be sure to carry out fitting adjustments to check their
operation.
 Check the lubrication level, damage, and wear of each part. If necessary, grease or replace it.
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

BL-6
< SERVICE INFORMATION >
PREPARATION
PREPARATION
Special Service ToolINFOID:0000000001327778
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Commercial Service ToolINFOID:0000000001327779
Tool number
(Kent-Moore No.)
Tool name Description
(J-39570)
Chassis ear Locating the noise
(J-43980)
NISSAN Squeak and Rat-
tle Kit Repairing the cause of the noise
SIIA0993E
SIIA0994E
Tool name Description
Engine ear Locating the noise
Power tool Loosening bolts and nuts
SIIA0995E
PIIB1407E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
