INFINITI G COUPE 2013 Owner's Manual

8-26Maintenance and do-it-yourself
SDI2034
PASSENGER COMPARTMENTGUID-B150D9E0-F345-4BB5-BF72-57CEBE3509C0
CAUTION
Never use a fuse of a higher or lower
amperage rating than that specified on the
fuse box cover. This could damage the
electrical system or cause a fire.
If any electrical equipment does not
operate, check for an open fuse.
1. Be sure the ignition switch is pushed tothe OFF or LOCK position and the
headlight switch is turned to OFF. 2. Open the fuse box lid.
3. Remove the fuse with the fuse puller
*A.
4. If the fuse is open, replace it with a new fuse.
5. If a new fuse also opens, have the electrical system checked and repaired
by an INFINITI retailer. Spare fuses are
stored in the fuse box.
SDI2704
Extended storage switch (if
equipped)
GUID-686D0C65-BB54-46EA-AAE5-01212C2311DD

CAUTION
Be careful not to allow children to swallow
the battery and removed parts.
SDI1834
Replace the battery as follows:
1. Release the lock knob at the back of theIntelligent Key and remove the mechan-
ical key.
2. Insert a flat-blade screwdriver
*Awrapped with a cloth into the slit*Bof the corner and twist it to separate
the upper part from the lower part.
Maintenance and do-it-yourself8-27
INTELLIGENT KEY BATTERY REPLACEMENT

8-28Maintenance and do-it-yourself
SDI2042
3. Replace the battery with a new one.Recommended battery: CR2032 or
equivalent.
.Do not touch the internal circuit andelectric terminals as it could cause a
malfunction.
.Hold the battery by the edges.
Holding the battery across the con-
tact points will seriously deplete the
storage capacity.
.Make sure that the + side faces thebottom of the case.
4. Align the tips of the upper and lower parts, and then push them together
until it is securely closed. 5. Push the buttons two or three times to
check its operation.
See an INFINITI retailer if you need any
assistance for replacement.
FCC Notice:
For USA:
This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any interfer-
ence received, including interference that
may cause undesired operation.
NOTE:
Changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s authority
to operate the equipment.
For Canada:
This device complies with RSS-210 of
Industry Canada. Operation is subject to
the following two conditions: (1) this
device may not cause interference, and
(2) this device must accept any interfer-
ence, including interference that may
cause undesired operation of the device.

GUID-CC43F1E0-CD84-4C89-AE76-E3BF74F58A31
JVM0099X
SEDANGUID-DC499FCB-C993-49FE-B186-4299E70AF763

8-30Maintenance and do-it-yourself
SDI2702
COUPEGUID-0388FA1F-19E7-4691-88ED-9037CE2CE37C

WARNING
HIGH VOLTAGE
When xenon headlights are on, they pro-
duce a high voltage. To prevent an electric
shock, never attempt to modify or disas-
semble. Always have your xenon headlights
replaced at an INFINITI retailer. For addi-
tional information, see “Headlight and turn
signal switch” (P.2-34).
Use the same number and wattage shown
in the following chart as originally in-
stalled.
If replacement is required, see an INFINITI
retailer.
Fog may temporarily form inside the lens of
the exterior lights in the rain or in a car
wash. A temperature difference between
the inside and the outside of the lens
causes the fog. This is not a malfunction. If
large drops of water collect inside the lens,
contact an INFINITI retailer.
EXTERIOR AND INTERIOR LIGHTSGUID-BDE3C310-75C1-4F4D-9E48-5E09104465DA

8-32Maintenance and do-it-yourself
CoupeGUID-6BE0C122-8A5E-4B16-9AFC-881BF27CAAA6

SDI1679
SDI2508
Map light
SDI2031
Rear personal light (Sedan only)
SDI2032
Vanity mirror light (Type A)
SDI1839
Vanity mirror light (Type B)
Maintenance and do-it-yourself8-33

8-34Maintenance and do-it-yourself
GUID-9503AF79-9CA5-400E-9F06-81B6757D713C
WARNING
.Improperly inflated tires can fail
suddenly and cause an accident.
.The Gross Vehicle Weight rating
(GVWR) is located on the F.M.V.S.
S./C.M.V.S.S. label. The vehicle
weight capacity is indicated on
the Tire and Loading Information
label. Do not load your vehicle
beyond this capacity. Overloading
your vehicle may result in reduced
tire life, unsafe operating condi-
tions due to premature tire failure,
or unfavorable handling character-
istics and could also lead to a
serious accident. Loading beyond
the specified capacity may also
result in failure of other vehicle
components.
.Before taking a long trip, or
whenever you heavily load your
vehicle, use a tire pressure gauge
to ensure that the tire pressures
WHEELS AND TIRES
