BRC-28
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2006 January2006 M35/M45
E, S SIDE G-SENSORTransverse G detected by side G
sensorVehicle stopped
Approx. 0 m/s
2
Vehicle turning rightNegative value
(m/s2 )
Vehicle turning leftPositive value
(m/s
2 )
E, S STR ANGLE SIGSteering angle detected by steering
angle sensorStraight-ahead Approx. 0
Steering wheel turned –720 to 720
E, S PRESS SENSORBrake fluid pressure detected by
pressure sensorWith ignition switch turned
ON and brake pedal
releasedApprox. 0 bar
With ignition switch turned
ON and brake pedal
depressed–40 to 300 bar
E, S ENGINE RPM With engine runningWith engine stopped 0 rpm
Engine runningAlmost in accor-
dance with tachom-
eter display
E, S FLUID LEV SW Brake fluid level switchWhen brake fluid level
switch ONON
When brake fluid level
switch OFF OFF
E, S PARK BRAKE SW Parking brake switchParking brake switch is
activeON
Parking brake switch is
inactiveOFF
M, SFR RH IN SOL
FR RH OUT SOL
FR LH IN SOL
FR LH OUT SOL
RR RH IN SOL
RR RH OUT SOL
RR LH IN SOL
RR LH OUT SOLOperation status of all solenoid
valve Actuator (solenoid valve) is
active (“ACTIVE TEST”
with CONSULT-II) or actua-
tor relay is inactive (in fail-
safe mode)ON
When the actuator (sole-
noid valve) is not active
and actuator relay is active
(ignition switch ON)OFF
M, S MOTOR RELAY Motor and motor relay operationWhen the motor relay and
motor are operatingON
When the motor relay and
motor are not operatingOFF
M, SACTUATOR RLY
(Note 3)Actuator relay operationWhen the actuator relay is
operatingON
When the actuator relay is
not operatingOFF
M, S ABS WARN LAMPABS warning lamp
(Note 4)When ABS warning lamp is
ONON
When ABS warning lamp is
OFFOFF
M, S OFF LAMPVDC OFF indicator lamp
(Note 4)When VDC OFF indicator
lamp is ONON
When VDC OFF indicator
lamp is OFFOFF E: ECU INPUT SIGNALS M: MAIN SIGNALS S: SELECTION FROM MENU
SELECT
MONITOR
ITEM Monitor item Display contentData monitor
ConditionReference value in
normal operation

TROUBLE DIAGNOSIS
BRC-29
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2006 January2006 M35/M45
M, S SLIP LAMPSLIP indicator lamp
(Note 4)When SLIP indicator lamp
is ONON
When SLIP indicator lamp
is OFFOFF
S4WD FAIL REQ
(Note 2)AWD control unit fail-safe signal When AWD control unit is
fail-safe mode ON
When AWD control unit is
normalOFF
S SNOW MODE SW Snow mode switchWhen snow mode switch is
ONON
When snow mode switch is
OFFOFF
S BST OPER SIG Not applied but displayed — OFF
S M-MODE SIG Manual mode activatedWhen the manual mode is
activeON
When the manual mode is
inactiveOFF
S EBD SIGNAL EBD operationEBD is active ON
EBD is inactive OFF
S ABS SIGNAL ABS operationABS is active ON
ABS is inactive OFF
S TCS SIGNAL TCS operationTCS is active ON
TCS is inactive OFF
S VDC SIGNAL VDC operationVDC is active ON
VDC is inactive OFF
S EBD FAIL SIG EBD fail-safe signalIn EBD fail-safe ON
EBD is normal OFF
S ABS FAIL SIG ABS fail-safe signalIn ABS fail-safe ON
ABS is normal OFF
S TCS FAIL SIG TCS fail-safe signalIn TCS fail-safe ON
TCS is normal OFF
S VDC FAIL SIG VDC fail-safe signalIn VDC fail-safe ON
VDC is normal OFF
S CRANKING SIG Crank operationCrank is active ON
Crank is inactive OFF
SUSV
HSV
(FL-RR, FR-RL)
(Note 3)VDC switch-over valveWhen actuator (switch-
over valve) is active
(“ACTIVE TEST” with
CONSULT-II) or actuator
relay is inactive (when in
fail-safe mode)ON
When actuator (switch-
over valve) is not active
and actuator relay is active
(ignition switch ON)OFF E: ECU INPUT SIGNALS M: MAIN SIGNALS S: SELECTION FROM MENU
SELECT
MONITOR
ITEM Monitor item Display contentData monitor
ConditionReference value in
normal operation

BRC-30
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2006 January2006 M35/M45
Note 1: Confirm tire pressure is normal.
Note 2: Only AWD model.
Note 3: A brief moment of ON/OFF condition occurs every 20 seconds after ignition switch turned ON. This is not malfunction because it
is an operation for checking.
Note 4: On and off timing for warning lamp and indicator lanp.Refer to BRC-33, "
ON and OFF Timing for Warning Lamp and Indicator
Lamp" .
Active TestNFS000QI
CAUTION:
Do not perform active test while driving vehicle.
Make sure to completely bleed air from brake system.
The active test cannot be performed with the ABS warning lamp, VDC indicator lamp, SLIP indica-
tor lamp and brake warning lamp are on.
ABS warning lamp, VDC OFF indicator lamp, SLIP indicator lamp and brake warning lamp are on
during active test.
Erase memory of ICC system after implementing active test. Refer to ACS-34, "Self-Diagnostic
Function" .
OPERATION PROCEDURE
1. Touch “START (NISSAN BASED VHCL)”, “ABS”, “ACTIVE TEST” in order on the CONSULT-II screen.
CAUTION:
When “START (NISSAN BASED VHCL)” is touched immediately after starting engine or turning on
ignition switch, “ABS” might not be displayed in the "SELECT SYSTEM" screen. In this case,
repeat the operation from step 1.
2. Touch “SELECT TEST ITEM” is displayed.
3. Touch necessary test item.
4. While “MAIN SIGNALS” indication is inverted, touch “START”.
5. “ACTIVE TEST” screen will be displayed so perform the following test.
SV/R OUTPUT
(Note 3)Solenoid valve relay activatedWhen the solenoid valve
relay is active (When igni-
tion switch OFF)ON
When the solenoid valve
relay is not active (in the
fail-safe mode)OFF
S M/R OUTPUTActuator motor and motor relay acti-
vatedWhen the actuator motor
and motor relay are active
(
ACTIVE TEST” with
CONSULT-II)ON
When the actuator motor
and motor relay are inac-
tiveOFF E: ECU INPUT SIGNALS M: MAIN SIGNALS S: SELECTION FROM MENU
SELECT
MONITOR
ITEM Monitor item Display contentData monitor
ConditionReference value in
normal operation
SFIA0591E

TROUBLE DIAGNOSIS
BRC-31
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2006 January2006 M35/M45
NOTE:
When active test is performed while depressing the pedal, the pedal depression amount will change.
This is normal. (Only solenoid valve and ABS motor)
“TEST IS STOPPED” is displayed 10 seconds after operation start.
After “TEST IS STOPPED” is displayed, to perform test again, touch “BACK” and repeat step 3.
TEST ITEMS
Solenoid Valve
NOTE:
The example shown is for front right wheel. The procedure for the other wheels is the same as given below.
When performing an active test of the ABS function, select the
"MAIN SIGNALS" for each test item.In addition, when perform-
ing an active test of the VDC/TCS function, select the item menu
for each test item.
For ABS solenoid valve, touch “UP”, “KEEP”, and “DOWN” on
the display screen. For ABS solenoid valve (ACT), touch “UP”,
“ACT UP”, “ACT KEEP” and confirm that solenoid valves (IN,
OUT, USV, HSV) operate as shown in the table below.
*: ON for 1 to 2 seconds after the touch, and then OFF
Note: A brief moment of ON/OFF condition occurs every 20 seconds after ignition switch turned ON. This is not malfunction because it is
an operation for checking.
ABS Motor
Touch “ON” and “OFF” on screen. Make sure motor relay and actua-
tor relay operates as shown in table below.
Note: A brief moment of ON/OFF condition occurs every 20 seconds after ignition
switch turned ON. This is not malfunction because it is an operation for checking.
SFIA0678E
Operation
(Note)ABS solenoid valve ABS solenoid valve (ACT)
UP KEEP DOWN UP ACT UP ACT KEEP
FR RH IN SOL OFF ON ON OFF OFF OFF
FR RH OUT SOL OFF OFF ON* OFF OFF OFF
USV [FR-RL] OFF OFF OFF OFF ON ON
HSV [FR-RL] OFF OFF OFF OFF ON* OFF
Operation ON OFF
MOTOR RELAY ON OFF
ACTUATOR RLY
(Note)ON ON
SFIA0593E

BRC-38
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2006 January2006 M35/M45
3. Turn ignition switch OFF and check continuity between ABS
actuator and electric unit (control unit) harness connector E30
terminal 1, 4 and ground.
OK or NG
OK >>Check battery for terminal looseness, low voltage, etc. If any malfunction is found, repair mal-
functioning parts.
Perform the self-diagnosis, and make sure that the result shows NO DTC IS DETECTED.
NG >>
Repair or replace malfunctioning components.
Perform the self-diagnosis, and make sure that the result shows NO DTC IS DETECTED.
Inspection 5: ABS Motor and Motor Relay CircuitNFS000QP
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
Is above displayed on the self-diagnosis display?
YES >> GO TO 2.
NO >> INSPECTION END
2. CHECK CONNECTOR
1. Turn ignition switch OFF and disconnect ABS actuator and electric unit (control unit) connector E30,
check terminal for deformation, disconnection, looseness, and so on. If any malfunction is found, repair or
replace terminal.
2. Reconnect connector and perform self-diagnosis.
OK or NG
OK >> INSPECTION END
NG >> GO TO 3.
SFIA3033E
ABS actuator and electric unit (control unit) Ground Continuity
1, 4 — Yes
Self-diagnosis results
PUMP MOTOR

TROUBLE DIAGNOSIS
BRC-39
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2006 January2006 M35/M45
3. CHECK ABS MOTOR AND MOTOR RELAY POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF and disconnect ABS actuator and electric unit (control unit) connector E30.
2. Check voltage between the ABS actuator and electric unit (con-
trol unit) harness connector E30 terminal 2 and ground.
OK or NG
OK >> GO TO 4.
NG >>
Repair or replace malfunctioning components.
Perform the self-diagnosis, and make sure that the result shows NO DTC IS DETECTED.
4. CHECK ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT) GROUND CIRCUIT
Check continuity between ABS actuator and electric unit (control
unit) harness connector E30 terminal 1, 4 and ground.
OK or NG
OK >>Replace ABS actuator and electric unit (control unit).
Perform the self-diagnosis, and make sure that the result shows NO DTC IS DETECTED.
NG >>
Repair or replace malfunctioning components.
Perform the self-diagnosis, and make sure that the result shows NO DTC IS DETECTED.
SFIA3034E
ABS actuator and electric unit (control unit) Ground Voltage
2 — Battery voltage (Approx. 12 V)
SFIA3033E
ABS actuator and electric unit (control unit) Ground Continuity
1, 4 — Yes

BRC-40
[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Revision: 2006 January2006 M35/M45
Inspection 6: Solenoid, VDC Change-Over Valve and Actuator Relay CircuitNFS000QQ
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
Is above displayed on the self-diagnosis display?
YES >> GO TO 2.
NO >> INSPECTION END
2. CHECK CONNECTOR
1. Turn ignition switch OFF and disconnect ABS actuator and electric unit (control unit) connector E30,
check terminal for deformation, disconnection, looseness, and so on. If any malfunction is found, repair or
replace terminal.
2. Reconnect connector and perform self-diagnosis.
OK or NG
OK >> INSPECTION END
NG >> GO TO 3.
3. CHECK SOLENOID, VDC CHANGE-OVER VALVE AND ACTUATOR RELAY POWER SUPPLY CIR-
CUIT
1. Turn ignition switch OFF and disconnect ABS actuator and electric unit (control unit) connector E30.
2. Check voltage between ABS actuator and electric unit (control
unit) harness connector E30 terminal 3 and ground.
Self-diagnosis results
FR RH IN ABS SOL
FR RH OUT ABS SOL
FR LH IN ABS SOL
FR LH OUT ABS SOL
RR RH IN ABS SOL
RR RH OUT ABS SOL
RR LH IN ABS SOL
RR LH OUT ABS SOL
USV LINE [FL-RR]
USV LINE [FR-RL]
HSV LINE [FL-RR]
HSV LINE [FR-RL]
MAIN RELAY
SFIA3035E
ABS actuator and electric unit (control unit) Ground Voltage
3 — Battery voltage (Approx. 12 V)

TROUBLE DIAGNOSIS
BRC-41
[VDC/TCS/ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
Revision: 2006 January2006 M35/M45
OK or NG
OK >> GO TO 4.
NG >>
Repair or replace malfunctioning components.
Perform the self-diagnosis, and make sure that the result shows NO DTC IS DETECTED.
4. CHECK SOLENOID, VDC CHANGE-OVER VALVE, ACTUATOR RELAY GROUND CIRCUIT
Check continuity between ABS actuator and electric unit (control
unit) harness connector E30 terminal 1, 4 and ground.
OK or NG
OK >>Replace ABS actuator and electric unit (control unit).
Perform the self-diagnosis, and make sure that the result shows NO DTC IS DETECTED.
NG >>
Repair or replace malfunctioning components.
Perform the self-diagnosis, and make sure that the result shows NO DTC IS DETECTED.
Inspection 7: Pressure Sensor CircuitNFS000QR
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
Is above displayed on the self-diagnosis display?
YES >>Replace ABS actuator and electric unit (control unit).
Perform the self-diagnosis, and make sure that the result shows NO DTC IS DETECTED.
NO >> INSPECTION END
Inspection 8: Steering Angle Sensor CircuitNFS000QS
INSPECTION PROCEDURE
1. CHECK SELF-DIAGNOSIS RESULTS
Check self-diagnosis results.
Is above displayed on the self-diagnosis display?
YES >> GO TO 2.
NO >> INSPECTION END
SFIA3033E
ABS actuator and electric unit (control unit) Ground Continuity
1, 4 — Yes
Self-diagnosis results
PRESS SEN CIRCUIT
Self-diagnosis results
ST ANG SEN CIRCUIT

EC-6Revision: 2006 January2006 M35/M45 On Board Diagnosis Logic ....................................533
DTC Confirmation Procedure ...............................533
Diagnostic Procedure ...........................................534
Removal and Installation ......................................534
DTC P1226 TP SENSOR ........................................535
Component Description ........................................535
On Board Diagnosis Logic ....................................535
DTC Confirmation Procedure ...............................535
Diagnostic Procedure ...........................................536
Removal and Installation ......................................536
DTC P1550 BATTERY CURRENT SENSOR ..........537
Component Description ........................................537
CONSULT-II Reference Value in Data Monitor Mode
.537
On Board Diagnosis Logic ....................................537
DTC Confirmation Procedure ...............................538
Wiring Diagram .....................................................539
Diagnostic Procedure ...........................................540
Component Inspection ..........................................542
D T C P 1 5 5 1 , P 1 5 5 2 B A T T E R Y C U R R E N T S E N S O R .543
Component Description ........................................543
CONSULT-II Reference Value in Data Monitor Mode
.543
On Board Diagnosis Logic ....................................543
DTC Confirmation Procedure ...............................544
Wiring Diagram .....................................................545
Diagnostic Procedure ...........................................546
Component Inspection ..........................................548
DTC P1553 BATTERY CURRENT SENSOR ..........549
Component Description ........................................549
CONSULT-II Reference Value in Data Monitor Mode
.549
On Board Diagnosis Logic ....................................549
DTC Confirmation Procedure ...............................550
Wiring Diagram .....................................................551
Diagnostic Procedure ...........................................552
Component Inspection ..........................................554
DTC P1554 BATTERY CURRENT SENSOR ..........555
Component Description ........................................555
CONSULT-II Reference Value in Data Monitor Mode
.555
On Board Diagnosis Logic ....................................555
Overall Function Check ........................................556
Wiring Diagram .....................................................557
Diagnostic Procedure ...........................................558
Component Inspection ..........................................560
DTC P1564 ICC STEERING SWITCH ....................561
Component Description ........................................561
CONSULT-II Reference Value in Data Monitor Mode
.561
On Board Diagnosis Logic ....................................561
DTC Confirmation Procedure ...............................562
Wiring Diagram ................................................
.....563
Diagnostic Procedure ...........................................564
Component Inspection ..........................................567
DTC P1564 ASCD STEERING SWITCH ................568
Component Description ........................................568
CONSULT-II Reference Value in Data Monitor Mode
.568On Board Diagnosis Logic ....................................568
DTC Confirmation Procedure ................................569
Wiring Diagram .....................................................570
Diagnostic Procedure ............................................571
Component Inspection ..........................................574
DTC P1568 ICC FUNCTION ...................................575
On Board Diagnosis Logic ....................................575
DTC Confirmation Procedure ................................575
Diagnostic Procedure ............................................575
DTC P1572 ICC BRAKE SWITCH ..........................576
Component Description ........................................576
CONSULT-II Reference Value in Data Monitor Mode
.576
On Board Diagnosis Logic ....................................576
DTC Confirmation Procedure ................................577
Wiring Diagram .....................................................578
Diagnostic Procedure ............................................579
Component Inspection ..........................................584
DTC P1572 ASCD BRAKE SWITCH ......................585
Component Description ........................................585
CONSULT-II Reference Value in Data Monitor Mode
.585
On Board Diagnosis Logic ....................................585
DTC Confirmation Procedure ................................586
Wiring Diagram .....................................................587
Diagnostic Procedure ............................................588
Component Inspection ..........................................592
DTC P1574 ICC VEHICLE SPEED SENSOR .........593
Component Description ........................................593
On Board Diagnosis Logic ....................................593
DTC Confirmation Procedure ................................593
Diagnostic Procedure ............................................594
DTC P1574 ASCD VEHICLE SPEED SENSOR .....595
Component Description ........................................595
On Board Diagnosis Logic ....................................595
DTC Confirmation Procedure ................................595
Diagnostic Procedure ............................................596
DTC P1715 INPUT SPEED SENSOR (TURBINE
REVOLUTION SENSOR) ........................................597
Description ............................................................597
CONSULT-II Reference Value in Data Monitor Mode
.597
On Board Diagnosis Logic ....................................597
Diagnostic Procedure ..........................................
..597
DTC P1805 BRAKE SWITCH .................................598
Component Description ........................................598
CONSULT-II Reference Value in Data Monitor Mode
.598
On Board Diagnosis Logic ....................................598
DTC Confirmation Procedure ................................599
Wiring Diagram .....................................................600
Diagnostic Procedure ............................................601
Component Inspection ..........................................606
DTC P2100, P2103 THROTTLE CONTROL MOTOR
RELAY .....................................................................607
Component Description ........................................607
CONSULT-II Reference Value in Data Monitor Mode
.607
On Board Diagnosis Logic ....................................607

EC-14Revision: 2006 January2006 M35/M45 Wiring Diagram ....................................................1325
Diagnostic Procedure ..........................................1326
Component Inspection .........................................1327
Removal and Installation .....................................1328
DTC P1805 BRAKE SWITCH ................................1329
Component Description .......................................1329
CONSULT-II Reference Value in Data Monitor Mode
1329
On Board Diagnosis Logic ...................................1329
DTC Confirmation Procedure ..............................1330
Wiring Diagram ....................................................1331
Diagnostic Procedure ..........................................1332
Component Inspection .........................................1337
DTC P2100, P2103 THROTTLE CONTROL MOTOR
RELAY ....................................................................1338
Component Description .......................................1338
CONSULT-II Reference Value in Data Monitor Mode
1338
On Board Diagnosis Logic ...................................1338
DTC Confirmation Procedure ..............................1338
Wiring Diagram ....................................................1340
Diagnostic Procedure ..........................................1341
DTC P2101 ELECTRIC THROTTLE CONTROL
FUNCTION .............................................................1344
Description ...........................................................1344
On Board Diagnosis Logic ...................................1344
DTC Confirmation Procedure ..............................1344
Wiring Diagram ....................................................1345
Diagnostic Procedure ..........................................1346
Component Inspection .........................................1350
Removal and Installation .....................................1350
DTC P2118 THROTTLE CONTROL MOTOR ........1351
Component Description .......................................1351
On Board Diagnosis Logic ...................................1351
DTC Confirmation Procedure ..............................1351
Wiring Diagram ....................................................1352
Diagnostic Procedure ..........................................1353
Component Inspection .........................................1354
Removal and Installation .....................................1355
DTC P2119 ELECTRIC THROTTLE CONTROL
ACTUATOR ............................................................1356
Component Description .......................................1356
On Board Diagnosis Logic ...................................1356
DTC Confirmation Procedure ..............................1356
Diagnostic Procedure ..........................................1357
DTC P2122, P2123 APP SENSOR ........................1358
Component Description .......................................1358
CONSULT-II Reference Value in Data Monitor Mode
1358
On Board Diagnosis Logic ...................................1358
DTC Confirmation Procedure ..............................1359
Wiring Diagram ....................................................1360
Diagnostic Procedure ..........................................1361
Component Inspection .........................................1363
Removal and Installation .....................................1364
DTC P2127, P2128 APP SENSOR ........................1365
Component Description .......................................1365
CONSULT-II Reference Value in Data Monitor Mode
1365On Board Diagnosis Logic ...................................1365
DTC Confirmation Procedure ...............................1366
Wiring Diagram ....................................................1367
Diagnostic Procedure ........................................... 1368
Component Inspection .........................................1371
Removal and Installation ......................................1371
DTC P2135 TP SENSOR .......................................1372
Component Description .......................................1372
CONSULT-II Reference Value in Data Monitor Mode
1372
On Board Diagnosis Logic ...................................1372
DTC Confirmation Procedure ...............................1373
Wiring Diagram ....................................................1374
Diagnostic Procedure ........................................... 1375
Component Inspection .........................................1378
Removal and Installation ......................................1378
DTC P2138 APP SENSOR .....................................1379
Component Description .......................................1379
CONSULT-II Reference Value in Data Monitor Mode
1379
On Board Diagnosis Logic ...................................1379
DTC Confirmation Procedure ...............................1380
Wiring Diagram ....................................................1381
Diagnostic Procedure ........................................... 1382
Component Inspection .........................................1386
Removal and Installation ......................................1386
DTC P2A00, P2A03 A/F SENSOR 1 ......................1387
Component Description .......................................1387
CONSULT-II Reference Value in Data Monitor Mode
1387
On Board Diagnosis Logic ...................................1387
DTC Confirmation Procedure ...............................1387
Wiring Diagram ....................................................1389
Diagnostic Procedure ........................................... 1392
Removal and Installation ......................................1397
VARIABLE INDUCTION AIR CONTROL SYSTEM
(VIAS) .....................................................................1398
Description ...........................................................1398
CONSULT-II Reference Value in Data Monitor Mode
1399
Wiring Diagram ....................................................1400
Diagnostic Procedure ...........................................
1402
Component Inspection .........................................1405
Removal and Installation ......................................1406
IGNITION SIGNAL .................................................1407
Component Description .......................................1407
Wiring Diagram ....................................................1408
Diagnostic Procedure ........................................... 1413
Component Inspection .........................................1417
Removal and Installation ......................................1419
FUEL INJECTOR ....................................................1420
Component Description .......................................1420
CONSULT-II Reference Value in Data Monitor Mode
1420
Wiring Diagram ....................................................1421
Diagnostic Procedure ........................................... 1422
Component Inspection .........................................1426
Removal and Installation ......................................1426
