Gear position supposed by TCM 1 2 3 4
In case of gear position with no malfunctions 1 2 3 4
In case of gear position with shift solenoid valve B stuck closed 1 2 2 1*
*: P0744 is detected.
Diagnostic trouble code Malfunction is detected when ... Check item (Possible cause)
: A/T TCC S/V FNCTN
A/T cannot perform lock-up even if elec-
trical circuit is good.ILine pressure solenoid valve
ITorque converter clutch solenoid valve
IEach clutch
IHydraulic control circuit
: P0744
SAT014K
SAT971J
DIAGNOSTIC TROUBLE CODE (DTC) CONFIRMATION
PROCEDURE
NBAT0054S01CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If ªDIAGNOSTIC TROUBLE CODE CONFIRMATION PROCE-
DUREº has been previously conducted, always turn ignition
switch ªOFFº and wait at least 5 seconds before conducting
the next test.
After the repair, perform the following procedure to confirm the
malfunction is eliminated.
With CONSULT-II
1) Start engine and select ªDATA MONITORº mode for ªA/Tº with
CONSULT-II.
2) Make sure that output voltage of A/T fluid temperature sensor
is within the range below.
FLUID TEMP SEN: 0.4 - 1.5V
If out of range, drive the vehicle to decrease the voltage (warm
up the fluid) or stop engine to increase the voltage (cool down
the fluid).
3) Select ªTCC S/V FNCTN P0744º of ªDTC WORK SUPPORTº
mode for ªA/Tº with CONSULT-II and touch ªSTARTº.
SAT021J
4) Accelerate vehicle to more than 67 to 100 km/h (42 to 62 MPH)
and maintain the following condition continuously until ªTEST-
INGº has turned to ªCOMPLETEDº. (It will take approximately
30 seconds after ªTESTINGº shows.)
THROTTLE POSI: 1.0/8 - 2.0/8 (at all times during step 4)
Selector lever: D position (OD ªONº)
TCC S/V DUTY: More than 94%
VHCL/S SE´A/T: Constant speed of more than 67 to 100
km/h (42 to 62 MPH)
ICheck that ªGEARº shows ª4º.
IFor shift schedule, refer to SDS, AT-356.
DTC P0744 IMPROPER LOCK-UP OPERATION
Description (Cont'd)
AT-154
Page 164 of 2395

7 CHECK CONTROL VALVE
1. Disassemble control valve assembly. Refer to AT-301.
2. Check line pressure circuit valves for sticking.
IPressure regulator valve
IPilot valve
IPressure modifier valve
SAT367H
OK or NG
OK©GO TO 8.
NG©Repair control valve.
8 CHECK SHIFT UP (D3TO D4)
Does A/T shift from D3to D4at the specified speed?
YesorNo
Ye s©GO TO 9.
No©Check control valve again. Repair or replace control valve assembly.
9 CHECK DTC
Perform Diagnostic Trouble Code (DTC) confirmation procedure, AT-154.
OK or NG
OK©INSPECTION END
NG©IGO TO 10.
IAnd check for proper lock-up.
10 CHECK LOCK-UP CONDITION
During ªCruise test þ Part 1º, AT-71.
Does A/T perform lock-up at the specified speed?
YesorNo
Ye s©Perform ªCruise test þ Part 1º again and return to the start point of this flow chart.
No©GO TO 11.
11 CHECK TORQUE CONVERTER CLUTCH SOLENOID VALVE
1. Remove control valve assembly. Refer to AT-273.
2. Check torque converter clutch solenoid valve operation.
Refer to AT-161.
OK or NG
OK©GO TO 12.
NG©Replace solenoid valve assembly.
GI
MA
EM
LC
EC
FE
TF
PD
AX
SU
BR
ST
RS
BT
HA
SC
EL
IDX
DTC P0744 IMPROPER LOCK-UP OPERATION
Diagnostic Procedure (Cont'd)
AT-159
Page 165 of 2395

12 CHECK CONTROL VALVE
1. Disassemble control valve assembly. Refer to AT-301.
2. Check control valves for sticking.
ITorque converter clutch control valve
ITorque converter clutch relief valve
SAT367H
OK or NG
OK©GO TO 13.
NG©Repair control valve
13 CHECK LOCK-UP CONDITION
Does A/T perform lock-up at the specified speed?
YesorNo
Ye s©GO TO 14.
No©Check control valve again. Repair or replace control valve assembly.
14 CHECK DTC
Perform Diagnostic Trouble Code (DTC) confirmation procedure, AT-154.
OK or NG
OK©INSPECTION END
NG©Perform ªCruise test Ð Part 1º again and return to the start point of this flow chart.
DTC P0744 IMPROPER LOCK-UP OPERATION
Diagnostic Procedure (Cont'd)
AT-160
Page 173 of 2395

SAT341H
DescriptionNBAT0060Shift solenoid valves A and B are turned ªONº or ªOFFº by the TCM
in response to signals sent from the PNP switch, vehicle speed and
throttle position sensors. Gears will then be shifted to the optimum
position.
Gear position1234
Shift solenoid valve A ON (Closed) OFF (Open) OFF (Open) ON (Closed)
Shift solenoid valve B ON (Closed) ON (Closed) OFF (Open) OFF (Open)
TCM TERMINALS AND REFERENCE VALUENBAT0060S02Remarks: Specification data are reference values.
Terminal
No.Wire color Item ConditionJudgement
standard
(Approx.)
11 L/WShift solenoid
valve A
When shift solenoid valve A operates.
(When driving in ªD
1ºorªD4º.)Battery volt-
age
When shift solenoid valve A does not operate.
(When driving in ªD
2ºorªD3º.)0V
ON BOARD DIAGNOSIS LOGICNBAT0060S03
Diagnostic trouble code Malfunction is detected when ... Check item (Possible cause)
: SFT SOL A/CIRC TCM detects an improper voltage drop
when it tires to operate the solenoid
valve.IHarness or connectors
(The solenoid circuit is open or shorted.)
IShift solenoid valve A
: P0750
SAT014K
SAT020K
DIAGNOSTIC TROUBLE CODE (DTC) CONFIRMATION
PROCEDURE
NBAT0060S01CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If ªDIAGNOSTIC TROUBLE CODE CONFIRMATION PROCE-
DUREº has been previously conducted, always turn ignition
switch ªOFFº and wait at least 5 seconds before conducting
the next test.
After the repair, perform the following procedure to confirm the
malfunction is eliminated.
With CONSULT-II
1) Turn ignition switch ªONº and select ªDATA MONITORº mode
for ªENGINEº with CONSULT-II.
2) Start engine.
3) Drive vehicle in ªDº position and allow the transmission to shift
ª1º,ª2º (ªGEARº).
With GST
Follow the procedure ªWith CONSULT-IIº.
DTC P0750 SHIFT SOLENOID VALVE A
Description
AT-168
Page 177 of 2395

SAT341H
DescriptionNBAT0063Shift solenoid valves A and B are turned ªONº or ªOFFº by the TCM
in response to signals sent from the PNP switch, vehicle speed and
throttle position sensors. Gears will then be shifted to the optimum
position.
Gear position1234
Shift solenoid valve A ON (Closed) OFF (Open) OFF (Open) ON (Closed)
Shift solenoid valve B ON (Closed) ON (Closed) OFF (Open) OFF (Open)
TCM TERMINALS AND REFERENCE VALUENBAT0063S02Remarks: Specification data are reference values.
Terminal
No.Wire color Item ConditionJudgement
standard
(Approx.)
12 L/RShift solenoid
valve B
When shift solenoid valve B operates.
(When driving in ªD
1ºorªD2º.)Battery volt-
age
When shift solenoid valve B does not operate.
(When driving in ªD
3ºorªD4º.)0V
ON BOARD DIAGNOSIS LOGICNBAT0063S03
Diagnostic trouble code Malfunction is detected when ... Check item (Possible cause)
: SFT SOL B/CIRC TCM detects an improper voltage drop
when it tires to operate the solenoid
valve.IHarness or connectors
(The solenoid circuit is open or shorted.)
IShift solenoid valve B
: P0755
SAT014K
SAT020K
DIAGNOSTIC TROUBLE CODE (DTC) CONFIRMATION
PROCEDURE
NBAT0063S01CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If ªDIAGNOSTIC TROUBLE CODE CONFIRMATION PROCE-
DUREº has been previously conducted, always turn ignition
switch ªOFFº and wait at least 5 seconds before conducting
the next test.
After the repair, perform the following procedure to confirm the
malfunction is eliminated.
With CONSULT-II
1) Turn ignition switch ªONº and select ªDATA MONITORº mode
for ªENGINEº with CONSULT-II.
2) Drive vehicle in ªDº position and allow the transmission to shift
1,2,3 (ªGEARº).
With GST
Follow the procedure ªWith CONSULT-IIº.
DTC P0755 SHIFT SOLENOID VALVE B
Description
AT-172
Page 182 of 2395

ON BOARD DIAGNOSIS LOGICNBAT0066S04
Diagnostic trouble code Malfunction is detected when ... Check item (Possible cause)
: TP SEN/CIRC A/T
TCM receives an excessively low or high
voltage from the sensor.IHarness or connectors
(The solenoid circuit is open or shorted.)
IThrottle position sensor
IThrottle position switch
: P1705
SAT014K
SAT971J
SAT014K
SAT020K
DIAGNOSTIC TROUBLE CODE (DTC) CONFIRMATION
PROCEDURE
NBAT0066S01CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If ªDIAGNOSTIC TROUBLE CODE CONFIRMATION PROCE-
DUREº has been previously conducted, always turn ignition
switch ªOFFº and wait at least 5 seconds before conducting
the next test.
After the repair, perform the following procedure to confirm the
malfunction is eliminated.
With CONSULT-II
1) Turn ignition switch ªONº and select ªDATA MONITORº mode
for ªA/Tº with CONSULT-II.
2) Apply vacuum to the throttle opener, then check the following.
Refer to steps 1 and 2 of ªPreparationº, ªTCM SELF-DIAG-
NOSTIC PROCEDURE (No Tools)º, AT-46.
Accelerator pedal
conditionTHRTL POS SEN CLOSED THL/SW W/O THRL/P´SW
Fully released Less than 4.7V ON OFF
Partially
depressed0.1 - 4.6V OFF OFF
Fully depressedMore than
1.9 - 4.6VOFF ON
If the check result is NG, go to ªDIAGNOSTIC PROCEDUREº,
AT-180.
If the check result is OK, go to following step.
3) Turn ignition switch ªONº and select ªDATA MONITORº mode
for ªENGINEº with CONSULT-II.
4) Start engine and maintain the following conditions for at least
3 consecutive seconds. Then release accelerator pedal com-
pletely.
VHCL SPEED SE: 10 km/h (6 MPH) or more
THRTL POS SEN: Approximately 3V or less
Selector lever: D position (OD ªONº)
If the check result is NG, go to ªDIAGNOSTIC PROCEDUREº,
AT-180.
If the check result is OK, go to following step.
5) Maintain the following conditions for at least 3 consecutive
seconds. Then release accelerator pedal completely.
VHCL SPEED SE: 10 km/h (6 MPH) or more
Accelerator pedal: Wide open throttle
Selector lever: D position (OD ªONº)
GI
MA
EM
LC
EC
FE
TF
PD
AX
SU
BR
ST
RS
BT
HA
SC
EL
IDX
DTC P1705 THROTTLE POSITION SENSOR
Description (Cont'd)
AT-177
Page 190 of 2395

SAT341H
DescriptionNBAT0068The overrun clutch solenoid valve is activated by the TCM in
response to signals sent from the inhibitor switch, overdrive con-
trol switch, vehicle speed and throttle position sensors. The over-
run clutch operation will then be controlled.
TCM TERMINALS AND REFERENCE VALUENBAT0068S02Remarks: Specification data are reference values.
Terminal
No.Wire color Item ConditionJudgement
standard
(Approx.)
20 L/BOverrun clutch
solenoid valve
When overrun clutch solenoid valve operates.Battery volt-
age
When overrun clutch solenoid valve does not
operate.0V
ON BOARD DIAGNOSIS LOGICNBAT0068S03
Diagnostic trouble code Malfunction is detected when ... Check item (Possible cause)
: O/R CLTCH SOL/CIRCTCM detects an improper voltage drop
when it tries to operate the solenoid
valve.IHarness or connectors
(The solenoid circuit is open or shorted.)
IOverrun clutch solenoid valve
: P1760
SAT014K
SAT020K
DIAGNOSTIC TROUBLE CODE (DTC) CONFIRMATION
PROCEDURE
NBAT0068S01CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If ªDIAGNOSTIC TROUBLE CODE CONFIRMATION PROCE-
DUREº has been previously conducted, always turn ignition
switch ªOFFº and wait at least 5 seconds before conducting
the next test.
TESTING CONDITION:
Always drive vehicle on a level road to improve accuracy of
test.
After the repair, perform the following procedure to confirm the
malfunction is eliminated.
With CONSULT-II
1) Turn ignition switch ªONº and select ªDATA MONITORº mode
for ªENGINEº with CONSULT-II.
2) Start engine.
3) Accelerate vehicle to a speed of more than 10 km/h (6MPH)
in ªDº position (OD ªONº).
4) Release accelerator pedal completely in ªDº position (OD
ªOFFº).
GI
MA
EM
LC
EC
FE
TF
PD
AX
SU
BR
ST
RS
BT
HA
SC
EL
IDX
DTC P1760 OVERRUN CLUTCH SOLENOID VALVE
Description
AT-185
Page 196 of 2395

ON BOARD DIAGNOSIS LOGICNBAT0172S04
Diagnostic trouble code Malfunction is detected when ... Check item (Possible cause)
: BATT/FLUID TEMP SEN
TCM receives an excessively low or high
voltage from the sensor.IHarness or connectors
(The sensor circuit is open or shorted.)
IA/T fluid temperature sensor
: 8th judgement flicker
SAT014K
SAT971J
DIAGNOSTIC TROUBLE CODE (DTC) CONFIRMATION
PROCEDURE
NBAT0172S01After the repair, perform the following procedure to confirm the
malfunction is eliminated.
With CONSULT-II
1) Start engine.
2) Select ªDATA MONITORº mode for ªA/Tº with CONSULT-II.
3) Drive vehicle under the following conditions:
Selector lever in ªDº position, vehicle speed higher than 20
km/h (12 MPH).
SAT674I
No Tools
1) Start engine.
2) Drive vehicle under the following conditions:
Selector lever in ªDº position, vehicle speed higher than 20
km/h (12 MPH).
3) Perform self-diagnosis.
Refer to TCM SELF-DIAGNOSTIC PROCEDURE (No Tools),
AT-46.
GI
MA
EM
LC
EC
FE
TF
PD
AX
SU
BR
ST
RS
BT
HA
SC
EL
IDX
DTC BATT/FLUID TEMP SEN (A/T FLUID TEMP SENSOR CIRCUIT AND TCM
POWER SOURCE)
Description (Cont'd)
AT-191
Page 202 of 2395

DescriptionNBAT0071The vehicle speed sensor´MTR is built into the speedometer
assembly. The sensor functions as an auxiliary device to the revo-
lution sensor when it is malfunctioning. The TCM will then use a
signal sent from the vehicle speed sensor´MTR.
TCM TERMINALS AND REFERENCE VALUENBAT0071S02Remarks: Specification data are reference values.
Terminal
No.Wire color Item ConditionJudgement
standard
(Approx.)
40 W/LVehicle speed
sensor
When moving vehicle at 2 to 3 km/h (1 to 2
MPH) for1m(3ft)ormore.Voltage varies
between less
than 1V and
more than
4.5V
ON BOARD DIAGNOSIS LOGICNBAT0071S03
Diagnostic trouble code Malfunction is detected when ... Check item (Possible cause)
: VHCL SPEED SEN´MTR
TCM does not receive the proper voltage
signal from the sensor.IHarness or connectors
(The sensor circuit is open or shorted.)
IVehicle speed sensor
: 2nd judgement flicker
SAT014K
SAT971J
DIAGNOSTIC TROUBLE CODE (DTC) CONFIRMATION
PROCEDURE
NBAT0071S01CAUTION:
IAlways drive vehicle at a safe speed.
IIf conducting this ªDTC CONFIRMATION PROCEDUREº
again, always turn ignition switch ªOFFº and wait at least
5 seconds before continuing.
After the repair, perform the following procedure to confirm the
malfunction is eliminated.
With CONSULT-II
1) Turn ignition switch ªONº and select ªDATA MONITORº mode
for ªA/Tº with CONSULT-II.
2) Start engine and accelerate vehicle from 0 to 25 km/h (0 to 6
MPH).
GI
MA
EM
LC
EC
FE
TF
PD
AX
SU
BR
ST
RS
BT
HA
SC
EL
IDX
DTC VEHICLE SPEED SENSOR´MTR
Description
AT-197
Page 208 of 2395

SAT014K
SAT971J
SAT635I
DIAGNOSTIC TROUBLE CODE (DTC) CONFIRMATION
PROCEDURE
NBAT0224S03CAUTION:
IAlways drive vehicle at a safe speed.
IIf conducting this ªDTC CONFIRMATION PROCEDUREº
again, always turn ignition switch ªOFFº and wait at least
5 seconds before continuing.
After the repair, perform the following procedure to confirm the
malfunction is eliminated.
With CONSULT-II
1) Start engine.
2) Select ªDATA MONITORº mode for ªA/Tº with CONSULT-II.
3) Drive vehicle under the following conditions:
Selector lever in ªDº, vehicle speed higher than 40 km/h (25
MPH), engine speed higher than 1,500 rpm, throttle opening
greater than 1.0/8 of the full throttle position and driving for
more than 5 seconds.
No Tools
1) Start engine.
2) Drive vehicle under the following conditions:
Selector lever in ªDº, vehicle speed higher than 40 km/h (25
MPH), engine speed higher than 1,500 rpm, throttle opening
greater than 1/8 of the full throttle position and driving for more
than 5 seconds.
3) Perform self-diagnosis.
Refer to TCM SELF-DIAGNOSTIC PROCEDURE (No Tools),
AT-46.
GI
MA
EM
LC
EC
FE
TF
PD
AX
SU
BR
ST
RS
BT
HA
SC
EL
IDX
DTC TURBINE REVOLUTION SENSOR
Description (Cont'd)
AT-203
