ACC-4Revision: November 2009
ACCELERATOR CONTROL SYSTEM
2006 QX56
4. Disconnect the adjustable pedal electric motor electrical connec-tor.
5. Disconnect the adjustable pedal electric motor memory electri- cal connector, if equipped.
6. Disconnect the accelerator position sensor electrical connector.
7. Remove the two upper and one lower accelerator pedal nuts.
8. Remove the adjustable accelerator pedal assembly. CAUTION:
Do not disassemble the accelerator pedal assembly.
Do not remove the accelerator pedal position sensor
from the accelerator pedal bracket.
Do not disassemble the accelerator pedal adjusting mechanism.
Avoid damage from dropping the accelerator pedal assembly during handling.
Keep the accelerator pedal assembly away from water.
INSTALLATION
Installation is in the reverse order of removal.
INSPECTION AFTER INSTALLATION
Check that the accelerator pedal moves smoothly within the specified ranges.
Depress and release the accelerator pedal to check that it returns smoothly to the original released posi-
tion.
Perform an electrical inspection of the accelerator pedal position sensor. Refer to EC-567, "DTC P2138
APP SENSOR" .
CAUTION:
When the harness connector of the accelerator pedal position sensor is disconnected, perform
“Accelerator Pedal Released Position Learning”. Refer to EC-78, "
Accelerator Pedal Released
Position Learning" .
LBIA0380E
Adjustable accelerator pedal – total pedal applied stroke : 48.3 mm (1.90 in)
Adjustable accelerator pedal – total pedal adjustment travel : 73.2 mm (2.88 in)
Page 12 of 3383
SERVICE DATA AND SPECIFICATIONS (SDS)ACC-5
C
DE
F
G H
I
J
K L
M A
ACC
Revision: November 2009 2006 QX56
SERVICE DATA AND SPECIFICATIONS (SDS)PFP:00030
Accelerator ControlEBS00M40
ADJUSTABLE ACCELERATOR PEDAL
Total Pedal Travel and Stroke
Unit: mm (in)
Adjustable accelerator pedal - total pedal applied stroke 48.3 (1.90)
Adjustable accelerator pedal - total pedal adjustment travel 73.2 (2.88)
Page 13 of 3383
ACC-6Revision: November 2009
SERVICE DATA AND SPECIFICATIONS (SDS)
2006 QX56
Page 14 of 3383
ACS-1
AUTO CRUISE CONTROL SYSTEM
K ELECTRICAL
CONTENTS
C
DE
F
G H
I
J
L
M
SECTION
A
B
ACS
Revision: November 2009 2006 QX56
ASCD
AUTOMATIC SPEED CONTROL DEVICE (ASCD) ..... 3
Description .......................................................... ..... 3
ICC
PRECAUTIONS ..................................................... ..... 4
Precautions for Supplemental Restraint System
(SRS) “AIR BAG” and “SEAT BELT PRE-TEN-
SIONER” ............................................................. ..... 4
Precautions for ICC System Service ................... ..... 4
PREPARATION ...................................................... ..... 5
Special Service Tool ............................................ ..... 5
DESCRIPTION ....................................................... ..... 6
Outline ................................................................. ..... 6
VEHICLE-TO-VEHICLE DISTANCE CONTROL
MODE .............................................................. ..... 6
CONVENTIONAL (FIXED SPEED) CRUISE
CONTROL MODE ............................................ ..... 6
BRAKE ASSIST (WITH PREVIEW FUNCTION) ..... 6
System Diagram .................................................. ..... 6
Components Description ..................................... ..... 7
CAN Communication ........................................... ..... 7
SYSTEM DESCRIPTION ................................. ..... 7
Switch Operation ................................................. ..... 7
ICC System Display ............................................ ..... 8
ACTION TEST ....................................................... ..... 9
ICC System Running Test ................................... ..... 9
VEHICLE-TO-VEHICLE DISTANCE CONTROL
MODE .............................................................. ..... 9
CONVENTIONAL (FIXED SPEED) CRUISE
CONTROL MODE ............................................ ... 10
LASER BEAM AIMING ADJUSTMENT ................ ... 12
Outline of Laser Beam Aiming Adjustment Proce-
dure ..................................................................... ... 12
Preparation .......................................................... ... 12
Setting up the ICC Target Board ......................... ... 12
ADJUSTING HEIGHT OF THE TARGET ......... ... 12
ADJUSTING THE POSITION OF THE TARGET
BOARD STRING .............................................. ... 13POSITIONING THE TARGET ..........................
... 13
Sensor Adjustment .............................................. ... 14
CHECK AFTER THE ADJUSTMENT ............... ... 17
ELECTRICAL UNITS LOCATION ......................... ... 18
Component Parts and Harness Connector Location ... 18
WIRING DIAGRAM ................................................ ... 19
Schematic ............................................................ ... 19
Wiring Diagram — ICC — ................................... ... 20
TERMINALS AND REFERENCE VALUE .............. ... 24
Terminals and Reference Values for ICC Unit ..... ... 24
Terminals and Reference Values for ICC Sensor ... 24
TROUBLE DIAGNOSIS — GENERAL DESCRIP-
TION ....................................................................... ... 25
Work Flow ............................................................... 25
CONSULT-II Function (ICC) ................................ ... 26
CONSULT-II OPERATION ................................ ... 26
WORK SUPPORT ............................................ ... 27
SELF-DIAGNOSTIC RESULTS ........................ ... 28
DATA MONITOR .............................................. ... 28
ACTIVE TEST ..................................................... 30
Self-Diagnostic Function ...................................... ... 31
WITH CONSULT-II ........................................... ... 31
WITHOUT CONSULT-II .................................... ... 32
SELF-DIAGNOSIS BY ICC SYSTEM DISPLAY
WILL NOT RUN ................................................ ... 33
TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC
ITEMS ..................................................................... ... 36
Diagnostic Trouble Code (DTC) Chart ................ ... 36
DTC 11 CONTROL UNIT .................................... ... 37
DTC 12 VDC CONTROL UNIT ............................ ... 37
DTC 20 CAN COMM CIRCUIT ............................ ... 38
DTC 31 POWER SUPPLY CIR1, DTC 34 POWER
SUPPLY CIR2 ........................................................ 38
DTC 41 VHCL SPEED SE CIRC ......................... ... 39
DTC 43 VDC/TCS/ABS CIRC ............................. ... 39
DTC 45 BRAKE SW/STOP L SW ........................ ... 40
DTC 46 OPERATION SW CIRC .......................... ... 41
DTC 74 LASER BEAM OFF CNTR ..................... ... 42
DTC 90 STOP LAMP RLY FIX ............................... 43
DTC 92 ECM CIRCUIT ........................................ ... 47
Page 15 of 3383
ACS-2Revision: November 20092006 QX56
DTC 96 NP RANGE ............................................
... 48
DTC 97 AT CIRCUIT ........................................... ... 48
DTC 98 GEAR POSITION ................................... ... 49
DTC 102 LASER STAIN ...................................... ... 49
DTC 103 LASER SENSOR FAIL ......................... ... 50
DTC 104 LASER AIMING INCMP ....................... ... 50
DTC 107 LASER COMM FAIL ............................. ... 51
DTC 109 LASER HIGH TEMP ............................ ... 51
TROUBLE DIAGNOSIS FOR SYMPTOMS ........... ... 52
Symptom Chart ....................................................... 52
Symptom 1: ON/OFF Switch Does Not Switch ON*
1
, ON/OFF Switch Does Not Switch OFF*
2 ........... ... 53
Symptom 2: The ICC System Cannot Be Set (ON/
OFF Switch Turns On/Off) ................................... ... 53
Symptom 3: The ICC System Cannot Be Operated
by the CANCEL Switch, ACCEL/RES Switch, or
DISTANCE Switch ............................................... ... 54Symptom 4: The ICC System Is Not Cancelled
When the Gear Is in ‘N’ ........................................
... 55
Symptom 5: Chime Does Not Sound ................... ... 55
Symptom 6: Driving Force Is Hunting .................. ... 56
Symptom 7: The ICC System Frequently Cannot
Detect the Vehicle Ahead/The Detection Zone is
Short .................................................................... ... 56
Symptom 8: The System Does Not Detect the Vehi-
cle Ahead at All .................................................... ... 56
ELECTRICAL COMPONENT INSPECTION .......... ... 58
ICC Steering Switch ............................................. ... 58
ICC Brake Switch and Stop Lamp Switch ............ ... 58
Parking Brake Switch ........................................... ... 58
REMOVAL AND INSTALLATION ........................... ... 59
ICC Unit ............................................................... ... 59
ICC Sensor .......................................................... ... 59
ICC Steering Switch ............................................. ... 59
Page 16 of 3383
AUTOMATIC SPEED CONTROL DEVICE (ASCD)ACS-3
[ASCD]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
AUTOMATIC SPEED CONTROL DEVICE (ASCD)PFP:18930
DescriptionEKS00BLB
Regarding the information for ASCD system, refer to EC-29, "AUTOMATIC SPEED CONTROL DEVICE
(ASCD)" .
Page 17 of 3383
ACS-4
[ICC]
PRECAUTIONS
Revision: November 20092006 QX56
PRECAUTIONSPFP:00001
Precautions for Supplemental Restraint System (SRS) “AIR BAG” and “SEAT
BELT PRE-TENSIONER”
EKS00BLC
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER ”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for ICC System ServiceEKS00BLD
Do not look straight into the laser beam discharger when adjusting laser beam aiming.
Turn the ON/OFF switch OFF during chassis dynamometer testing.
Do not remove, disassemble, or reposition the ICC sensor unless told to do so.
Erase DTC when replacing parts of ICC system, then check the operation of ICC system after adjusting
laser beam aiming if necessary.
Page 18 of 3383
PREPARATIONACS-5
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
PREPARATIONPFP:00002
Special Service ToolEKS00BLF
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here.
Tool number
(Kent-Moore No.)
Tool nameDescription
KV99110100
(J-45718)
ICC target board Performing laser beam aiming ad-
justment
PKIA0358J
Page 19 of 3383
ACS-6
[ICC]
DESCRIPTION
Revision: November 20092006 QX56
DESCRIPTIONPFP:00000
OutlineEKS00BLG
The Intelligent Cruise Control (ICC) system automatically maintains a selected distance from the vehicle
ahead according to that vehicle's speed, or at the set speed, if the road ahead is clear.
The ICC function has two cruise control modes and brake assist (with preview function). The ICC system may
AUTO-CANCEL for various reasons, for example, when the windshield wipers are operating.
VEHICLE-TO-VEHICLE DISTANCE CONTROL MODE
Vehicle-to-vehicle distance control mode, the same speed as other vehicles, can be maintained without the
constant need to adjust the operating speed as with a conventional cruise control system.
The system is intended to enhance the operation of the vehicle when following another vehicle in the same
lane and direction.
If the distance sensor detects a slower moving vehicle ahead, the system will reduce speed so that the vehicle
ahead can be followed at the selected distance.
The system automatically controls the throttle and applies the brakes (up to 25% of vehicle braking power) if
necessary.
The detection range of the sensor is approximately 120 m (390 ft) ahead.
Refer to Owner's Manual for Intelligent Cruise Control System operating instructions.
CONVENTIONAL (FIXED SPEED) CRUISE CONTROL MODE
Conventional (fixed speed) cruise control mode is cruising at preset speeds.
Refer to Owner's Manual for Intelligent Cruise Control System operation instructions.
BRAKE ASSIST (WITH PREVIEW FUNCTION)
When the force applied to brake pedal exceeds a certain level, the brake assist is activated and generates a
greater braking force than that of a conventional brake booster, even with light pedal force.
When the preview function identifies the need to apply the sudden brake by sensing the vehicle ahead in the
same lane and the distance and relative speed from it, it applies the brake pre-pressure before driver
depresses the brake pedal and improves brake response by reducing its free play.
Refer to Owner's Manual for Intelligent Cruise Control System operating instructions.
System DiagramEKS00BLH
WKIA1976E
Page 20 of 3383
DESCRIPTIONACS-7
[ICC]
C
DE
F
G H
I
J
L
M A
B
ACS
Revision: November 2009 2006 QX56
Components DescriptionEKS00BLI
CAN CommunicationEKS00BLJ
SYSTEM DESCRIPTION
Refer to LAN-26, "CAN COMMUNICATION" .
Switch OperationEKS00BLK
The system is operated by a master ON/OFF switch and four control switches, all mounted on the steering
wheel.
Component Vehicle-to-vehicle
distance control mode Conventional
(fixed speed)
cruise control mode Brake assist
(with preview brake) Description
ICC unit ××× Controls vehicle speed through ECM via CAN
communication.
ICC sensor ×× Irradiate laser beam, and receives reflected
laser beam to measure distance from preceding
vehicle.
ECM ××× Transmits throttle position signal and ICC steer-
ing switch signal to ICC unit.
ABS actuator and electric
unit (control unit) ××× Transmits wheel speed signal to ICC unit.
Operates brake booster based on CAN commu-
nication.
Brake pressure sensor ×× Detects fluid pressure in master cylinder.
Brake booster ×× Adjusts brake fluid pressure based on command
from ABS actuator and electric unit (control
unit).
BCM × Transmit front wiper request signal to ICC unit.
TCM ×× Transmits gear position signal and output shaft
revolution signal to ICC unit.
No.
Switch name Description
1 ACCEL/RES switch Resumes set speed or increases speed incrementally.
2 COAST/SET switch Sets desired cruise speed, reduces speed incrementally.
3 ON/OFF switch Master switch to activate the system.
SKIA5973E
