When the BCM receives this signal or unlock signal from keyfob, the vehicle security system is deactivated.
(Disarmed phase)
PANIC ALARM OPERATION
Remote keyless entry system may or may not operate vehicle security system (horn and headlamps) as
required.
When the remote keyless entry system is triggered, ground is supplied intermittently
• from IPDM E/R terminal 45
• to headlamp high relay and
• to horn relay terminal 1.
The headlamp flashes and the horn sounds intermittently.
The alarm automatically turns off after 25 seconds or when BCM receives any signal from keyfob.
CAN Communication System DescriptionINFOID:0000000003532940
Refer to LAN-4.

BL-70
< SERVICE INFORMATION >
VEHICLE SECURITY (THEFT WARNING) SYSTEM
CONSULT-II Function (BCM)
INFOID:0000000003532945
CONSULT-II can display each diagnostic item using the diagnostic test modes shown following.
CONSULT-II START PROCEDURE
Refer to GI-36, "CONSULT-II Start Procedure".
CONSULT-II APPLICATION ITEM
Data Monitor
Active Test
Work Support
BCM
diagnostic test itemDiagnostic mode Description
Inspection by partWORK SUPPORTSupports inspections and adjustments. Commands are transmitted to the
BCM for setting the status suitable for required operation, input/output sig-
nals are received from the BCM and received date is displayed.
DATA MONITOR Displays BCM input/output data in real time.
ACTIVE TESTOperation of electrical loads can be checked by sending drive signal to
them.
SELF-DIAG RESULTS Displays BCM self-diagnosis results.
CAN DIAG SUPPORT MNTRThe result of transmit/receive diagnosis of CAN communication can be
read.
ECU PART NUMBER BCM part number can be read.
CONFIGURATION Performs BCM configuration read/write functions.
Monitored Item Description
DOOR SW-AS Indicates [ON/OFF] condition of front door switch RH.
DOOR SW-RR Indicates [ON/OFF] condition of rear door switch RH.
DOOR SW-RL Indicates [ON/OFF] condition of rear door switch LH.
DOOR SW-DR Indicates [ON/OFF] condition of front door switch LH.
BACK DOOR SW Indicates [ON/OFF] condition of back door latch.
TRNK OPN MNTR Indicates [ON/OFF] condition of glass hatch ajar switch.
ACC ON SW Indicates [ON/OFF] condition of ignition switch in ACC position.
IGN ON SW Indicates [ON/OFF] condition of ignition switch in ON position.
KEYLESS UNLOCK Indicates [ON/OFF] condition of unlock signal from keyfob.
KEYLESS LOCK Indicates [ON/OFF] condition of lock signal from keyfob.
KEY CYL LK-SW Indicates [ON/OFF] condition of lock signal from door key cylinder switch.
KEY CYL UN-SW Indicates [ON/OFF] condition of unlock signal from door key cylinder switch.
KEYLESS PBD Indicates [ON/OFF] condition of unlock signal from door key cylinder switch.
CDL UNLOCK SW Indicates [ON/OFF] condition of unlock signal from lock/unlock switch.
CDL LOCK SW Indicates [ON/OFF] condition of lock signal from lock/unlock switch.
HOOD SW Indicates [ON/OFF] condition of hood switch.
Test Item Description
THEFT INDThis test is able to check security indicator lamp operation. The lamp will be turned on when “ON”
on CONSULT-II screen is touched.
HEADLAMP (HI)This test is able to check vehicle security lamp operation. The high beam headlamps will be acti-
vated for 0.5 seconds after “ON” on CONSULT-II screen is touched.
VEHICLE SECURITY HORNThis test is able to check vehicle security horn operation. The horns will be activated for 0.5 sec-
onds after “ON” on CONSULT-II screen is touched.

VEHICLE SECURITY (THEFT WARNING) SYSTEM
BL-71
< SERVICE INFORMATION >
C
D
E
F
G
H
J
K
L
MA
B
BL
N
O
P
Trouble DiagnosisINFOID:0000000003532946
WORK FLOW
• “POWER DOOR LOCK SYSTEM” Diagnosis refer to BL-15 .
• “REMOTE KEYLESS ENTRY SYSTEM” Diagnosis refer to BL-37
.
Test Item Description
SECURITY ALARM SET This mode can confirm and change security alarm ON-OFF setting.
THEFT ALM TRGThe switch which triggered vehicle security alarm is recorded. This mode is able to confirm and
erase the record of vehicle security alarm. The trigger data can be erased by touching “CLEAR” on
CONSULT-II screen.
WIIA0599E

BL-72
< SERVICE INFORMATION >
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Preliminary Check
INFOID:0000000003532947
The system operation is canceled by turning ignition switch to ACC at any step between START and ARMED
in the following flow chart.
After performing preliminary check, go to symptom chart.
Symptom ChartINFOID:0000000003532948
WIIA0627E
SYMPTOM PROCEDURE Diagnostic procedure
1Vehicle security
system cannot be
set by ····Door switch Refer to BL-73, "
Door Switch Check".
Lock/unlock switch Refer to BL-79, "
Door Lock/Unlock Switch Check".
Door outside keyRefer to BL-77, "
Front Door Lock Assembly LH (Key Cylinder Switch)
Check".
BCM If the above systems are “OK”, replace BCM. Refer to BCS-24, "
BCM".
2Security indicator
does not turn
“ON”.Combination meter Refer to BL-76, "
Combination Meter (Security Indicator Lamp) Check".
BCM If the above systems are “OK”, replace BCM. Refer to BCS-24, "
BCM".

VEHICLE SECURITY (THEFT WARNING) SYSTEM
BL-73
< SERVICE INFORMATION >
C
D
E
F
G
H
J
K
L
MA
B
BL
N
O
P
*1: Make sure the system is in the armed phase.
Door Switch CheckINFOID:0000000003532949
1.CHECK DOOR SWITCHES INPUT SIGNAL
With CONSULT-II
Check door switches ("DOOR SW-DR", "DOOR SW-AS", "DOOR SW-RL", "DOOR SW-RR", "BACK DOOR
SW", "TRNK OPN MNTR") in DATA MONITOR mode with CONSULT–II.Refer to BL-70, "
CONSULT-II Func-
tion (BCM)".
• When doors are open:
• When doors are closed:
Without CONSULT-II
3*1 Vehicle security
system does not
alarm when ····Any door, hood or glass hatch is
opened.Refer to BL-73, "
Door Switch Check".
Refer to BL-75, "
Hood Switch Check".
If the above systems are “OK”, replace BCM. Refer to BCS-24, "
BCM".
4Vehicle security
alarm does not ac-
tivate.Horn alarmRefer to BL-79, "
Vehicle Security Horn Alarm Check" .
If the above systems are “OK”, check horn system.
Refer to WW-43
.
Headlamp alarmRefer to BL-79, "
Vehicle Security Headlamp Alarm Check".
If the above systems are “OK”, replace BCM. Refer to BCS-24, "
BCM".
5Vehicle security
system cannot be
canceled by ····Door outside keyRefer to BL-77, "
Front Door Lock Assembly LH (Key Cylinder Switch)
Check" .
If the above systems are “OK”, check main power window and door lock/
unlock switch.
KeyfobCheck remote keyless entry function. Refer to BL-52, "
Keyfob Battery and
Function Check".
If the above systems are “OK”, replace BCM. Refer to BCS-24, "
BCM" . SYMPTOM PROCEDURE Diagnostic procedure
DOOR SW-DR : ON
DOOR SW-AS : ON
DOOR SW-RL : ON
DOOR SW-RR : ON
BACK DOOR SW : ON
TRNK OPN MNTR : ON
DOOR SW-DR : OFF
DOOR SW-AS : OFF
DOOR SW-RL : OFF
DOOR SW-RR : OFF
BACK DOOR SW : OFF
TRNK OPN MNTR : OFF
WIIA0466E

VEHICLE SECURITY (THEFT WARNING) SYSTEM
BL-77
< SERVICE INFORMATION >
C
D
E
F
G
H
J
K
L
MA
B
BL
N
O
P
2. Check voltage between BCM harness connector M18 terminal
23 and ground.
OK or NG
OK >> Security indicator lamp is OK.
NG >> GO TO 2.
2.SECURITY INDICATOR LAMP CHECK
Check security indicator lamp condition.
Refer to DI-5
.
OK or NG
OK >> GO TO 3.
NG >> Replace combination meter (security indicator lamp). Refer to DI-5
.
3.CHECK HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect BCM and combination meter (security indicator lamp).
3. Check continuity between BCM connector (A) M18 terminal 23
and combination meter (security indicator lamp) harness con-
nector (B) M24 terminal 28.
4. Check continuity between BCM connector (A) M18 terminal 23
and ground.
OK or NG
OK >> Check the following:
• 10A fuse [No. 19, located in fuse block (J/B)]
• Harness for open or short between combination meter (security indicator lamp) and fuse
NG >> Repair or replace harness.
Front Door Lock Assembly LH (Key Cylinder Switch) CheckINFOID:0000000003532952
1.CHECK FRONT DOOR LOCK ASSEMBLY LH (KEY CYLINDER SWITCH)
With CONSULT-II
Check front door lock assembly LH (key cylinder switch) ("KEY CYL LK-SW") and ("KEY CYL UN-SW) in
DATA MONITOR mode in CONSULT–II.Refer to BL-70, "
CONSULT-II Function (BCM)".
• When key inserted in front key cylinder is turned to LOCK:
• When key inserted in front key cylinder is turned to UNLOCK:
Without CONSULT-II
ConnectorTe r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (-)
M18 23 GroundON 0
OFFBattery volt-
age
LIIA0523E
23 - 28 : Continuity should exist.
23 - ground : Continuity should not exist.
LIIA2253E
KEY CYL LK-SW : ON
KEY CYL UN-SW : ON
LIIA0188E

BL-78
< SERVICE INFORMATION >
VEHICLE SECURITY (THEFT WARNING) SYSTEM
Check voltage between main power window and door lock/unlock switch connector D7 terminals 4, 6 and
ground.
OK or NG
OK >> Front door lock assembly LH (key cylinder switch) signal is OK.
NG >> GO TO 2.
2.CHECK DOOR KEY CYLINDER SWITCH LH GROUND HARNESS
Check continuity between front door lock assembly LH (key cylinder
switch) connector (A) D14 terminal 5 and body ground.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace harness.
3.CHECK DOOR KEY CYLINDER SWITCH LH
Check continuity between front door lock assembly LH (key cylinder
switch) terminals.
OK or NG
OK >> GO TO 4.
NG >> Replace front door lock assembly LH (key cylinder switch). Refer to BL-110, "
Removal and Instal-
lation".
4.CHECK DOOR KEY CYLINDER HARNESS
ConnectorTe r m i n a l s
ConditionVoltage (V)
(Approx.)
(+) (–)
D74
GroundNeutral/Unlock 5
Lock 0
6Neutral/Lock 5
Unlock 0
LIIA0566E
Connector Terminals Continuity
D14 5 – Ground Yes
WIIA0755E
Terminals Condition Continuity
1 – 5 Key is turned to UNLOCK or neutral. No
Key is turned to LOCK. Yes
5 – 6Key is turned to LOCK or neutral. No
Key is turned to UNLOCK. Yes
LIIA1573E

VEHICLE SECURITY (THEFT WARNING) SYSTEM
BL-79
< SERVICE INFORMATION >
C
D
E
F
G
H
J
K
L
MA
B
BL
N
O
P
Check continuity between main power window and door lock/unlock
switch connector (A) D7 terminals 4, 6 and front door lock assembly
LH (key cylinder switch) connector (B) D14 terminals 1, 6 and body
ground.
OK or NG
OK >> Replace main power window and door lock/unlock switch.
NG >> Repair or replace harness.
Vehicle Security Horn Alarm CheckINFOID:0000000003532953
1.CHECK HORN OPERATION
Check if horn sounds with horn switch.
Does horn operate?
YES >> Check harness for open or short between IPDM E/R and horn relay.
NO >> Check horn circuit. Refer to WW-43
.
Vehicle Security Headlamp Alarm CheckINFOID:0000000003532954
1.CHECK VEHICLE SECURITY HEADLAMP ALARM OPERATION
Check if headlamps operate with lighting switch.
Do headlamps come on when turning switch ON?
YES >> Headlamp alarm is OK.
NO >> Check headlamp system. Refer to LT- 5
or LT- 2 4.
Door Lock/Unlock Switch CheckINFOID:0000000003532955
1.CHECK DOOR LOCK/UNLOCK SWITCH INPUT SIGNAL
Check if power door lock operates with door lock/unlock switch.
Do doors lock/unlock when using each door lock/unlock switch?
YES >> Door lock/unlock switch is OK.
NO >> Refer to "Door Lock/Unlock Switch Check ".
Connector Terminals Connector Terminals Continuity
A: Main
power win-
dow and
door lock/
unlock
switch4 B: Front
door lock
assembly
LH (key
cylinder
switch)1Yes
66Yes
4, 6 Ground No
WIIA0756E

AUTOMATIC BACK DOOR SYSTEM
BL-81
< SERVICE INFORMATION >
C
D
E
F
G
H
J
K
L
MA
B
BL
N
O
P
The automatic back door system must be initialized by fully closing the back door anytime the battery
power is lost to the back door control unit.
The automatic back door system consists of a one piece unit that combines the back door control unit along
with the back door motor, back door clutch and the back door encoder. The back door latch contains a lock
function that can control the two functions of automatic back door latch closure and electrical opener with a
single motor when you close the back door to the halfway-state.
• Back door auto closure
When the back door is closed to the halfway state (half-latch) position, the motor automatically drives to
rotate the latch lever and pull it in from half latched to full latched.
• Power back door
With the back door closed, press the power liftgate switch or press the keyfob button, or pull the back door
handle with the back door unlocked, the back door latch motor opens the locking plate and releases the
latch. The back door motor then raises the door to the full open position.
With the back door fully open, press the power liftgate switch, keyfob button or the back door close switch,
the back door motor closes the door to the half-latch state. The back door latch motor then drives the latch to
the full close position.
At the onset of each power open or power close application, the hazard lamps will flash 3 times and the
warning chime will sound 3 times lasting a total of 2 seconds.
OPERATION DESCRIPTION
Power Liftgate Switch Operation (Fully Closed → Fully Open Operation)
• When the power liftgate switch is pressed, back door control unit terminal 23 receives the signal.
• The back door control unit checks the A/T selector lever (P position) through terminal 18, vehicle speed
through terminal 21, ignition status through terminal 7, glass hatch is closed through terminal 17 and battery
voltage is present through terminal 3.
• When the back door control unit receives the signal, if the auto back door operating enable conditions are
met, it sends a 5 volt signal through terminal 6 and grounds terminal 9 to sound the warning chime, sends a
signal to the BCM through terminal 4 to flash the hazard lamps and unlocks the back door latch through ter-
minal 12.
• The back door control unit supplies power to the magnetic clutch and the back door motor and moves the
back door in the open direction. (At this time, it also executes speed control, input reverse, and anti-pinch
detection control.)
• When the back door is opened to the full-open position, the full-open position is detected by the encoder,
and the back door control unit switches the back door motor OFF and the magnetic clutch is pulsed and then
turned OFF.
• The back door is held in the fully open position by the gas stays.
Remote Keyless Entry Operation (Fully Closed → Fully Open Operation)
• When the keyfob button is pressed for at least 0.5 seconds, back door control unit terminal 21 receives the
signal.
• The back door control unit checks the A/T selector lever (P position) through terminal 18, vehicle speed
through terminal 21, ignition status through terminal 7, glass hatch is closed through terminal 17 and battery
voltage is present through terminal 3.
• When the back door control unit receives the signal, if the auto back door operating enable conditions are
met, it sends a 5 volt signal through terminal 6 and grounds terminal 9 to sound the warning chime, sends a
signal to the BCM through terminal 4 to flash the hazard lamps and unlocks the back door latch through ter-
minal 12.
• The back door control unit supplies power to the magnetic clutch and the back door motor and moves the
back door in the open direction. (At this time, it also executes speed control, input reverse, and anti-pinch
detection control.)
• When the back door is opened to the full-open position, the full-open position is detected by the encoder,
and the back door control unit switches the back door motor OFF and the magnetic clutch is pulsed and then
turned OFF.
• The back door is held in the fully open position by the gas stays.
Back Door Handle Switch Operation (Fully Closed → Fully Open Operation)
• When the back door handle is pulled, back door control unit terminal 26 receives the signal.
• The back door control unit checks that the back door is unlocked and checks the A/T selector lever (P posi-
tion) through terminal 18, vehicle speed through terminal 21, ignition status through terminal 7, glass hatch is
closed, battery voltage and back door close switch position through terminal 13.
• When the back door control unit receives the signal, if all auto back door operating enable conditions are
met, it sends a 5 volt signal through terminal 6 and grounds terminal 9 to sound the warning chime, sends a

BL-82
< SERVICE INFORMATION >
AUTOMATIC BACK DOOR SYSTEM
signal to the BCM through terminal 4 to flash the hazard lamps and unlocks the back door latch through ter-
minal 12.
• The back door control unit supplies power to the magnetic clutch and the back door motor and moves the
back door in the open direction. (At this time, it also executes speed control, input reverse, and anti-pinch
detection control.)
• When the back door is opened to the full-open position, the full-open position is detected by the encoder,
and the back door control unit switches the back door motor OFF and the magnetic clutch is pulsed and then
turned OFF.
• The back door is held in the fully open position by the gas stays.
Power Liftgate Switch Operation (Fully Open → Fully Closed Operation)
• When the power liftgate switch is pressed, the back door control unit terminal 23 receives the signal.
• The back door control units checks door position through the rotary encoder.
• When the back door control unit receives the signal, if the auto back door operating enable conditions are
met, it sends a signal through terminal 6 and grounds terminal 9 to sound the warning chime and sends a
signal to the BCM through terminal 4 to flash the hazard lamps.
• The back door control unit supplies power to the magnetic clutch and the back door motor and move the
back door in the close direction. (At this time, it also executes speed control, input reverse, and anti-pinch
detection control.)
• When the back door reaches the half-latch state, the half-latch switch detects this and the signal is sent to
the back door control unit terminal 22.
• When the back door control unit receives the half latch switch signal, it switches OFF the back door motor
and the magnetic clutch and operates the cinch latch motor.
• When the back door latch operates and full close is detected through terminal 14 of the back door control
unit, the cinch latch motor reverses to the neutral position and the back door auto closure operation ends
and the door is fully closed.
Remote Keyless Entry Operation (Fully Open → Fully Closed Operation)
• When the keyfob switch is pressed for at least 0.5 seconds, the back door control unit terminal 21 receives
the signal.
• The back door control units checks door position through the rotary encoder.
• When the back door control unit receives the signal, if the auto back door operating enable conditions are
met, it sends a signal through terminal 6 and grounds terminal 9 to sound the warning chime and sends a
signal to the BCM through terminal 4 to flash the hazard lamps.
• The back door control unit supplies power to the magnetic clutch and the back door motor and move the
back door in the close direction. (At this time, it also executes speed control, input reverse, and anti-pinch
detection control.)
• When the back door reaches the half-latch state, the half-latch switch detects this and the signal is sent to
the back door control unit terminal 22.
• When the back door control unit receives the half latch switch signal, it switches OFF the back door motor
and the magnetic clutch and operates the cinch latch motor.
• When the back door latch operates and full close is detected through terminal 14 of the back door control
unit, the cinch latch motor reverses to the neutral position and the back door auto closure operation ends
and the door is fully closed.
Back Door Close Switch Operation (Fully Open → Fully Closed Operation)
• When the back door close switch is pressed, the back door control unit terminal 8 receives the signal.
• The back door control units checks back door close switch terminal 13 status and door position (must be
fully opened), through rotary encoder and battery voltage.
• When the back door control unit receives the signal, if the auto back door operating enable conditions are
met, it sends a signal through terminal 6 and grounds terminal 9 to sound the warning chime and sends a
signal to the BCM through terminal 4 to flash the hazard lamps.
• The back door control unit supplies power to the magnetic clutch and the back door motor and move the
back door in the close direction. (At this time, it also executes speed control, input reverse, and anti-pinch
detection control.)
• When the back door reaches the half-latch state, the half-latch switch detects this and the signal is sent to
the back door control unit terminal 22.
• When the back door control unit receives the half latch switch signal, it switches OFF the back door motor
and the magnetic clutch and operates the cinch latch motor.
• When the back door latch operates and full close is detected through terminal 14 of the back door control
unit, the cinch latch motor reverses to the neutral position and the back door auto closure operation ends
and the door is fully closed.
