TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS
Are “DTC 11 CONTROL UNIT” or “DTC 20 CAN COMM CIRCUIT” item indicated in self-diagnosis display
item?
YES or NO
YES >> GO TO applicable item inspection. Refer to ACS-36, "DTC 11 CONTROL UNIT", and ACS-37,
"DTC 20 CAN COMM CIRCUIT".
NO >> • Replace ICC sensor and adjust laser beam aiming. Refer to ACS-55, "
ICC Sensor".
• Erase DTC and perform ICC system running test. Refer to ACS-9, "
ICC System Running Test".
Then perform self-diagnosis of ICC system again.
DTC 104 LASER AIMING INCMPINFOID:0000000003533811
1.DIAGNOSTIC CHECK
1. Adjust laser beam aiming. Refer to ACS-12
. Erase DTC and perform ICC system running test. Refer to
ACS-9, "
ICC System Running Test".
2. Perform self-diagnosis of ICC system. Is “DTC 104 LASER AIMING INCMP” indicated?
CAUTION:
Ensure that laser beam aiming apparatus is set up accurately.
YES or NO
YES >> • Replace ICC sensor and adjust laser beam aiming. Refer to ACS-55, "ICC Sensor".
• Erase DTC and perform ICC system running test. Refer to ACS-9, "
ICC System Running Test".
Then perform self-diagnosis of ICC system again.
NO >> Inspection end.
DTC 107 LASER COMM FAILINFOID:0000000003533812
1.DIAGNOSTIC CHECK
Is “DTC 11 CONTROL UNIT” or “DTC 20 CAN COMM CIRCUIT” indicated in the self-diagnosis display item?
YES or NO
YES >> GO TO applicable item inspection. Refer to ACS-36, "DTC 11 CONTROL UNIT" , or ACS-37,
"DTC 20 CAN COMM CIRCUIT".
NO >> • Replace ICC sensor and adjust laser beam aiming. Refer to ACS-55, "
ICC Sensor".
• Erase DTC and perform ICC system running test. Refer to ACS-9, "
ICC System Running Test".
Then perform self-diagnosis of ICC system again.
DTC 109 LASER HIGH TEMPINFOID:0000000003533813
1.CHECK SYMPTOM
Is cooling system malfunctioning?
YES or NO
YES >> • Repair cooling system.
• Erase DTC and perform ICC system running test. Refer to ACS-9, "
ICC System Running Test".
Then perform self-diagnosis of ICC system again.
NO >> • Replace ICC sensor and adjust laser beam aiming. Refer to ACS-55, "
ICC Sensor".
• Erase DTC, then perform ICC system running test. Refer to ACS-9, "
ICC System Running Test".
Then perform self-diagnosis of ICC system again.

TROUBLE DIAGNOSIS FOR SYMPTOMS
ACS-49
< SERVICE INFORMATION >[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
N
O
P
TROUBLE DIAGNOSIS FOR SYMPTOMS
Symptom ChartINFOID:0000000003533814
Symptom 1 ON/OFF Switch Does Not Switch ON*1, ON/OFF Switch Does Not Switch
OFF
*2INFOID:0000000003533815
NOTE:
• *1: The ICC system display in the combination meter does not illuminate.
• *2: The ICC system display in the combination meter remains powered.
1.CHECK ON/OFF SWITCH
With CONSULT-II
• With "DATA MONITOR" on the CONSULT-II, check that ON/OFF switch operates normally.
OK or NG
OK >> GO TO 2.
NG >> GO TO 3.
Symptoms Reference page
OperationON/OFF switch does not switch ON.Symptom 1
ACS-49
ON/OFF switch does not switch OFF.Symptom 1
ACS-49
Cruise does not function for setting (powering functions).Symptom 2
ACS-50
CANCEL switch does not function.Symptom 3
ACS-51
RESUME does not function.Symptom 3
ACS-51
The set speed does not increase.Symptom 3
ACS-51
The set distance to the vehicle ahead cannot be changed.Symptom 3
ACS-51
The ICC is not cancelled when the gear is in "N".Symptom 4
ACS-51
Display/ChimeThe ICC system display does not appear.Check combination meter. Refer to
DI-15, "
How to Proceed with Trou-
ble Diagnosis"
Chime does not function.Symptom 5
ACS-51
Control Driving force is hunting.Symptom 6
ACS-52
Function to detect the vehicle
aheadThe system frequently cannot detect the vehicle ahead.Symptom 7
ACS-52
The distance to detect the vehicle ahead is short.Symptom 7
ACS-52
The system misidentifies a vehicle even though there is no ve-
hicle ahead.• Refer toACS-12
• Refer to ACS-9, "
ICC System
Running Test"
The system misidentifies a vehicle in the next lane.• Refer to ACS-12• Refer to ACS-9, "ICC System
Running Test"
The system does not detect a vehicle at all.Symptom 8
ACS-53

ACS-50
< SERVICE INFORMATION >[ICC]
TROUBLE DIAGNOSIS FOR SYMPTOMS
2.CHECK ICC UNIT CONNECTOR
1. Turn ignition switch OFF.
2. Disconnect ICC unit harness connectors.
3. Check connector housing for disconnected, loose, bent, and collapsed terminals.
OK or NG
OK >> GO TO 3.
NG >> • Poor connector connection.
• Repair ICC unit connector. Erase DTC and perform ICC system running test. Refer to ACS-9,
"ICC System Running Test". Then perform self-diagnosis of ICC system again.
3.DIAGNOSIS CHECK
With CONSULT-II
• Perform self-diagnosis with CONSULT-II. Is “CAN COMM CIRCUIT” indicated?
YES or NO
YES >> Refer to ACS-37, "DTC 20 CAN COMM CIRCUIT".
NO >> Refer to ACS-40, "
DTC 46 OPERATION SW CIRC".
Symptom 2 the ICC System Cannot Be Set (ON/OFF Switch Turns On/Off)
INFOID:0000000003533816
The ICC cannot be set in the following cases.• When the vehicle speed is not in range of approx. 40 km/h (25 MPH) to 144 km/h (89 MPH).
• When the selector lever is in "N".
• While the brake is in operation.
• When the windshield wipers are operating.
1.CHECK CAUSE OF AUTOMATIC CANCELLATION
With CONSULT-II
1. With “CAUSE OF AUTO-CANCEL” in "WORK SUPPORT" on CONSULT-II, check if any cause of cancel-
lation exists.
OK or NG
OK >> • Cancel with appropriate cause.
• For causes A, B, or C, go to specified diagnosis.
A: “OPE SW VOLT CIRC” : Refer to ACS-40, "
DTC 46 OPERATION SW CIRC".
B: “VHCL SPD UNMATCH” : Refer to ACS-38, "
DTC 41 VHCL SPEED SE CIRC".
C: “IGN LOW VOLT” : Refer to ACS-37, "
DTC 31 POWER SUPPLY CIR1, DTC 34
POWER SUPPLY CIR2".
NG >> GO TO 2.
2.PERFORM SELF-DIAGNOSIS
With CONSULT-II
1. Perform CONSULT-II self-diagnosis to check for malfunctioning items.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace as necessary, erase DTC. Perform ICC system running test. Refer to ACS-9,
"ICC System Running Test". Then perform self-diagnosis of ICC system again.
3.CHECK SWITCHES AND VEHICLE SPEED SIGNAL
With CONSULT-II
1. With "DATA MONITOR" on the CONSULT-II, check that the following switches and vehicle speed signal
operate normally.
A: VHCL SPEED SE B: NP RANGE SW
C: BRAKE SW D: SET/COAST SW
OK or NG
OK >> Replace ICC unit and erase DTC. Refer to ACS-55, "ICC Unit". Perform ICC system running test.
Refer to ACS-9, "
ICC System Running Test". Then perform self-diagnosis of ICC system again.
NG >> • A: Refer to ACS-38, "
DTC 41 VHCL SPEED SE CIRC".

TROUBLE DIAGNOSIS FOR SYMPTOMS
ACS-51
< SERVICE INFORMATION >[ICC]
C
D
E
F
G
H
I
J
L
MA
B
ACS
N
O
P
• B: Refer to ACS-51, "Symptom 4 the ICC System Is Not Cancelled When the Gear Is in ‘N’".
• C: Refer to ACS-38, "
DTC 45 BRAKE SW/STOP L SW".
• D: Refer to ACS-40, "
DTC 46 OPERATION SW CIRC".
Symptom 3 the ICC System Cannot Be Operated by the CANCEL Switch, ACCEL/
RES Switch, or DISTANCE Switch
INFOID:0000000003533817
RESUME will not function in the following cases:
• When ON/OFF switch is pressed once after the ICC system was ON.
• When the vehicle speed is less than 32 km/h (20 MPH).
1.CHECK SWITCH
With CONSULT-II
1. With "DATA MONITOR" on the CONSULT-II, check that the following switches operate normally.
“RESUME/ACC SW”, “CANCEL SW”, “DISTANCE ADJ”.
OK or NG
OK >> Replace ICC unit and erase DTC. Refer to ACS-55, "ICC Unit". Perform ICC system running test.
Refer to ACS-9, "
ICC System Running Test". Then perform self-diagnosis of ICC system again.
NG >> GO TO 2.
2.CHECK DIAGNOSIS
With CONSULT-II
• Perform self-diagnosis with CONSULT-II. Is “CAN COMM CIRCUIT” indicated?
YES or NO
YES >> Refer to ACS-37, "DTC 20 CAN COMM CIRCUIT".
NO >> Refer to ACS-40, "
DTC 46 OPERATION SW CIRC".
Symptom 4 the ICC System Is Not Cancelled When the Gear Is in ‘N’INFOID:0000000003533818
1.CHECK D RANGE SWITCH
With CONSULT-II
1. With "DATA MONITOR" on the CONSULT-II, check that “NP RANGE SW” operates normally.
OK or NG
OK >> Replace ICC unit and erase DTC. Refer to ACS-55, "ICC Unit". Perform ICC system running test.
Refer to ACS-9, "
ICC System Running Test". Then perform self-diagnosis of ICC system again.
NG >> GO TO 2.
2.CHECK CAN COMMUNICATION
With CONSULT-II
1. With CONSULT-II self-diagnosis, check “CAN COMM CIRCUIT”.
OK or NG
OK >> GO TO 3.
NG >> Refer to ACS-37, "
DTC 20 CAN COMM CIRCUIT".
3.CHECK NP RANGE SWITCH
1. With "DATA MONITOR" on the CONSULT-II, check that “N” position switch operates normally.
OK or NG
OK >> Replace ICC unit. Refer to ACS-55, "ICC Unit". Perform ICC system running test. Refer to ACS-9,
"ICC System Running Test". Then perform self-diagnosis of ICC system again.
NG >> Repair or replace as necessary. Perform ICC system running test. Refer to ACS-9, "
ICC System
Running Test". Then perform self-diagnosis of ICC system again.
Symptom 5 Chime Does Not SoundINFOID:0000000003533819
