REMOTE KEYLESS ENTRY FUNCTION
REMOTE KEYLESS ENTRY F UNCTION : System DiagramINFOID:0000000006225845
REMOTE KEYLESS ENTRY FUNCT ION : System DescriptionINFOID:0000000006225846
The Intelligent Key has the same functions as the remote control entry system. Therefore, it can be used in the
same manner as the remote controller by operating the door lock/unlock button.
OPERATION
Remote keyless entry system controls operation of the following items.
 Door lock/unlock function
 Selective unlock function
 Auto door lock function
 Hazard and horn reminder function
 Automatic back door open/close function
OPERATION AREA
To check that the Intelligent Key works normally, use within 1 m (3 ft) range of each doors, however the opera-
ble range may differ according to surroundings.
DOOR LOCK/UNLOCK FUNCTION
 When door lock/unlock button of the Intelligent Key is pr essed, lock signal or unlock signal transmitted from
Intelligent Key to BCM via remote keyless entry receiver.
 When BCM receives the door lock/unlock signal, it operates all door lock actuators and fuel lid lock actuator,
blinks the hazard lamp (lock: 2 time, unlock: 1 times) and horn chirp signal to IPDM E/R at the same time as
a reminder.
 IPDM E/R honks horn (lock: 1 time) as a reminder.
Function
Intelligent Key
Remote keyless entry receiver Back door opener switch
Back door lock assembly Inside key antenna
Outside key antenna (back door) CAN communication system BCM
Automatic back door control module
Back door open function ×××××××××
JMKIA5435GB
Revision: 2010 May2011 QX56

DLK-24
< SYSTEM DESCRIPTION >
SYSTEM (INTELLIGENT KEY SYSTEM)
OPERATION CONDITION
If the following condition are satisfied, remote keyless entry operation is performed when the Intelligent Key is
operated.
SELECTIVE UNLOCK FUNCTION
 When an LOCK signal is transmitted from Intelligent Key, all doors and fuel filler lid are locked.
 When an UNLOCK signal is transmitted from Intelligent Key once, driver side door and fuel filler lid are
unlocked.
 Then, if an UNLOCK signal is transmitted from Inte lligent Key again within 60 seconds, all other doors
(except for back door) are unlocked.
How to change selective unlock operation mode.
Selective unlock operation mode can be changed using CONSULT-III.
Refer to DLK-39, "
DOOR LOCK : CONSULT-III Function (BCM - DOOR LOCK)".
AUTO DOOR LOCK FUNCTION
After door is unlocked by Intelligent Key button operati on and if 60 seconds or more passes without performing
the following operation, all doors are locked. Howe ver, operation check function does not activate.
How to change auto door lock operation mode.
Auto door lock mode can be changed using CONSULT-III.
Refer to DLK-41, "
INTELLIGENT KEY : CONSULT-III Function (BCM - INTELLIGENT KEY)".
HAZARD AND HORN REMINDER FUNCTION
When doors are locked or unlocked by Intelligent Key, BCM blinks hazard warning lamps as a reminder.
The hazard and horn reminder has a horn chirp mode (C mode) and a non-horn chirp mode (S mode).
Operating Function of Hazard and Horn Reminder
Hazard and horn reminder does not operate in the following conditions.
 Ignition switch position is ON.
 Door is open (only lock operation)
How to Change Hazard and Horn Reminder Mode
With CONSULT-III
Hazard and horn reminder operation mode can be changed using CONSULT-III.
Refer to DLK-41, "
INTELLIGENT KEY : CONSULT-III Function (BCM - INTELLIGENT KEY)".
Without CONSULT-III
Remote controller operation Operation condition
Lock  Panic alarm is not activated
 P position warning is not activated
Unlock Panic alarm is not activated
Operating condition  Door switch is ON
(door is open)
Door is locked
 Push switch is pressed
C mode S mode
Intelligent Key operation Lock Unlock Lock Unlock
Hazard warning lamp blinks Twice Once Twice —
Horn sound Once — — —
Revision: 2010 May2011 QX56

SYSTEM (INTELLIGENT KEY SYSTEM)
DLK-27
< SYSTEM DESCRIPTION >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
 When the BCM detects that the Intelligent Key is within the outside key antenna detection area. BCM trans-
mits the request signal to the Intelligent Key and check it is near the door.
 Intelligent Key receives the request signal and transmits the key ID signal to the BCM via remote keyless
entry receiver.
 BCM receives the key ID signal and compares it with the registered key ID.
 BCM illuminates lamps that are set, when key ID verification is OK.
TIMER FUNCTION
BCM can operate welcome light function, using the timer function, for 9 days, after key switch is turned OFF.
The timer function resets when the engine is started
*.Operating period of timer function may differ depending
on battery size.
*: Timer function does not stop if another Intelligent Key that has a different key ID is detected within the inte-
rior antenna detection area, when starting the engine.
OPERATION CONDITION
If the following condition are satisfi ed, welcome light function is operated.
OUTSIDE KEY ANTENNA DETECTION AREA
The outside key antenna detection area of door lock/unlock function
is in the range of approximately 80 cm (31.50 in) surrounding the
driver, passenger door handles (1) and back door handle (2). How-
ever, this operating range depends on the ambient conditions.
WELCOME LIGHT FUNCTION SETTING
Welcome light function operation mode can be changed using CONSULT-III
With CONSULT-III
Refer to DLK-41, "
INTELLIGENT KEY : CONSULT-III F unction (BCM - INTELLIGENT KEY)".
Without CONSULT-III
The welcome light function ON/OFF can be s witched by performing the following operation.
1. Turn ignition switch: OFF →ON
2. Press and hold the driver side door request switch for 5 seconds or more within 20 seconds after turning the ignition switch ON.
3. The switching is complete when combination meter buzzer sounds.
WARNING FUNCTION
WARNING FUNCTION : System DescriptionINFOID:0000000006225851
OPERATION DESCRIPTION
The warning function are as per the following items and are given to the user as warning information and
warnings using combinations of Intelligent Key warning buzzer, combination meter buzzer, KEY warning lamp
and information display in combination meter.
 Intelligent Key system malfunction
 OFF position warning
 P position warning
 ACC warning
Function Operation condition
Welcome light function  All door are closed
 All doors is locked
 Ignition switch: OFF position
 Shift position: P position
 Intelligent Key is outside the vehicle
 Timer function is activated
JMKIA5224ZZ
Revision: 2010 May2011 QX56

DLK-42
< SYSTEM DESCRIPTION >
DIAGNOSIS SYSTEM (BCM)
SELF-DIAG RESULT
Refer to BCS-57, "DTCIndex".
DATA MONITOR
AUTO LOCK SET Auto door lock operation time can be changed in this mode
 MODE 1: OFF
 MODE 2: 30 sec
 MODE 3: 1 minute
 MODE 4: 2 minutes
 MODE 5: 3 minutes
 MODE 6: 4 minutes
 MODE 7: 5 minutes
HORN WITH KEYLESS LOCK Horn reminder function mode by Intelligent Key button can be selected from the following with
this mode
 On: Operate
 Off: Non-operation
PW DOWN SET Unlock button pressing time on Intelligent Key button can be selected from the following with
this mode
 MODE 1: 3 sec
 MODE 2: Non-operation
 MODE 3: 5 sec
WELCOME LIGHT SELECT Welcome light function mode can be selected from the following with this mode
 Puddle/Outside Handle
 Room lamp
 Head & Tail Lamps (this item is displayed, but cannot be used)
 Heart Beat
WELCOME LIGHT OP SET Welcome light function mode can be changed to operation with this mode
 On: Operate
 Off: Non-operation
Monitor item Description
Monitor Item Condition
REQ SW -DR Indicates [On/Off] condition of door request switch (driver side)
REQ SW -AS Indicates [On/Off] condition of door request switch (passenger side)
REQ SW -BD/TR Indicates [On/Off] condition of back door request switch
PUSH SW Indicates [On/Off] condition of push-button ignition switch
CLUTCH SW NOTE:
This item is displayed, but cannot be monitored
BRAKE SW 1 Indicates [On/Off]* condition of stop lamp switch power supply
BRAKE SW 2 Indicates [On/Off] condition of stop lamp switch
DETE/CANCL SW Indicates [On/Off] condition of P position
SFT PN/N SW Indicates [On/Off] condition of P or N position
S/L -LOCK Indicates [On/Off] condition of steering lock unit (LOCK)
S/L -UNLOCK Indicates [On/Off] condition of steering lock unit (UNLOCK)
S/L RELAY -F/B Indicates [On/Off] condition of steering lock relay
UNLK SEN -DR Indicates [On/Off] condition of driver door UNLOCK status
PUSH SW -IPDM Indicates [On/Off] condition of push-button ignition switch
IGN RLY1 -F/B Indicates [On/Off] condition of ignition relay 1
DETE SW -IPDM Indicates [On/Off] condition of P position
SFT PN -IPDM Indicates [On/Off] condition of P or N position
SFT P -MET Indicates [On/Off] condition of P position
SFT N -MET Indicates [On/Off] condition of N position
ENGINE STATE Indicates [Stop/Stall/Crank/Run] condition of engine states
Revision: 2010 May2011 QX56

DIAGNOSIS SYSTEM (BCM)DLK-43
< SYSTEM DESCRIPTION >
C
DE
F
G H
I
J
L
M A
B
DLK
N
O P
*: OFF is displayed when brake pedal is depressed while brake switch power supply is OFF.
ACTIVE TEST
S/L LOCK-IPDM Indicates [On/Off] condition of steering lock unit (LOCK)
S/L UNLK-IPDM Indicates [On/Off] condition of steering lock unit (UNLOCK)
S/L RELAY-REQ Indicates [On/Off] condition of steering lock relay
VEH SPEED 1 Display the vehicle speed signal received from combination meter by numerical value [Km/h]
VEH SPEED 2 Display the vehicle spee d signal received from ABS or VDC or TCM by numerical value [Km/h]
DOOR STAT-DR Indicates [LOCK/READY/UNLK] condition of unlock sensor
DOOR STAT-AS Indicates [LOCK/READY/UNLK] condition of passenger side door status
ID OK FLAG Indicates [Set/Reset] condition of key ID
PRMT ENG STRT Indicates [Set/Reset] condition of engine start possibility
PRMT RKE STRT NOTE:
This item is displayed, but cannot be monitored
TRNK/HAT MNTR NOTE:
This item is displayed, but cannot be monitored
RKE-LOCK Indicates [On/Off] condition of LOCK signal from Intelligent Key
RKE-UNLOCK Indicates [On/Off] condition of UNLOCK signal from Intelligent Key
RKE-TR/BD NOTE:
This item is displayed, but cannot be monitored
RKE-PANIC Indicates [On/Off] condition of PANIC button of Intelligent Key
RKE-MODE CHG Indicates [On/Off] condition of MODE CHANGE signal from Intelligent Key
RKE OPE COUN1 When remote keyless entry receiver receives the signal transmitted while operating on Intelli-
gent Key, the numerical value start changing
RKE OPE COUN2 NOTE:
This item is displayed, but cannot be monitored
Monitor Item Condition
Test item Description
BATTERY SAVER This test is able to check interior room lamp operation
 On: Operate
 Off: Non-operation
OUTSIDE BUZZER This test is able to check Intelligent Key warning buzzer operation
 On: Operate
 Off: Non-operation
INSIDE BUZZER This test is able to check warning chime in combination meter operation
 Take Out: Take away warning chime sounds when CONSULT-III screen is touched
 Key: Key warning chime sounds when CONSULT-III screen is touched
 Knob: OFF position warning chime sounds when CONSULT-III screen is touched
 Off: Non-operation
INDICATOR This test is able to check warning lamp operation
 KEY ON: “KEY” Warning lamp illuminates when CONSULT-III screen is touched
 KEY IND: “KEY” Warning lamp blinks when CONSULT-III screen is touched
 Off: Non-operation
INT LAMP This test is able to check interior room lamp operation
 On: Operate
 Off: Non-operation
Revision: 2010 May2011 QX56

DIAGNOSIS SYSTEM (AUTOMATIC BACK DOOR CONTROL UNIT)
DLK-45
< SYSTEM DESCRIPTION >
C
D E
F
G H
I
J
L
M A
B
DLK
N
O P
DIAGNOSIS SYSTEM (AUTOMATIC BACK DOOR CONTROL UNIT)
CONSULT-III Function (AUTOMATIC BACK DOOR CONTROL UNIT)INFOID:0000000006225858
APPLICATION ITEM
CONSULT-III performs the following functions via CA N communication with automatic back door control unit.
DATA MONITOR
SELF-DIAG RESULT
Refer to DLK-50, "DTCIndex".
Diagnosis mode Function Description
Self Diagnostic Result Displays the diagnosis results judged by automatic back door control unit
CAN Diag Support Monitor Monitors the reception status of CAN communication viewed from automatic back door
control unit
Data Monitor The automatic back door control unit input/output signals are displayed
Ecu Identification The automatic back door control unit part number is displayed
Monitor Item Unit Description
VHCL SPEED MTR [km/h] Display the vehicle speed signal received from combination meter by nu-
merical value
VHCL SPEED ABS [km/h] Display the vehicle speed
signal received from ABS actuator and electrical
unit by numerical value
VHCL SPEED SIG [NORMAL/ER-
ROR] Indicates condition of vehicle speed from automatic back door control unit
MAIN SW [ON/OFF] Indicates condition of automatic back door main switch
AUTO BD SW [ON/OFF] Indicates condition of automatic back door switch
BK DOOR CL SW [ON/OFF] Indicates condition of automatic back door close switch
UNLOCK SEN DR [ON/OFF] Indicates condition of unlock sensor
OPEN SW [ON/OFF] Indicates condition of open switch
CLOSE SW [ON/OFF] Indicates condition of close switch
HALF LATCH SW [ON/OFF] Indicates condition of half latch switch
TOUCH SEN RH [ON/OFF/OPEN] Indicates condition of touch sensor RH
TOUCH SEN LH [ON/OFF/OPEN] Indicates condition of touch sensor LH
P RANGE IND [ON/OFF] Indicates condition of P range signal from combination meter
RKE REQ [OFF/MOVE/
REV] Indicates condition of remote keyless entry signal from BCM
IGN SW [ON/OFF] Indicates condition of IGN power supply
ENCODER A [LO/HI] Indicates condition of encoder signal from encoder A
ENCODER B [LO/HI] Indicates condition of encoder signal from encoder B
BD OPENER SW [ON/OFF] Indicates condition of back door opener switch
UNLOCK SEN BD [LOCK/
UNLOCK] NOTE:
This item is displayed, but cannot be monitored
DESTINATION [JPN/NAM] Indicates specification of destination of the automatic back door system
HAZARD [ON/OFF] Indica tes specification of hazard warning
Revision: 2010 May2011 QX56

DLK-134
< DTC/CIRCUIT DIAGNOSIS >
REMOTE KEYLESS ENTRY RECEIVER
REMOTE KEYLESS ENTRY RECEIVER
Component Function CheckINFOID:0000000006225947
1.CHECK FUNCTION
1. Select “INTELLIGE NT KEY” of “BCM” using CONSULT-III.
2. Select “RKE OPE COUN1” in “DATA MONITOR” mode.
3. Check that the function operates normall y according to the following conditions.
Is the inspection result normal?
YES >> Remote keyless entry receiver is OK.
NO >> Refer to DLK-134, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000006225948
1.CHECK REMOTE KEYLESS ENTRY RECEIVER OUTPUT SIGNAL
1. Turn ignition switch OFF.
2. Check signal between remote keyless entry receiver harness connector and ground using oscilloscope.
Is the inspection result normal?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK REMOTE K EYLESS ENTRY RECEIVER CIRCUIT 1
1. Disconnect BCM and remote keyless entry receiver connector
2. Check continuity between BCM harness connector and remote keyless entry receiver harness connector.
Is the inspection result normal?
YES >> GO TO 8.
NO >> Repair or replace harness.
Monitor item Condition
RKE OPE COUN1 Checks whether value changes when operating Intelligent Key
(+) (–) Condition Signal
(Reference value)
Remote keyless entry receiver
Connector Terminal
B21 2 Ground Waiting
Signal receiving
JMKIA3838GB
JMKIA3841GB
BCM Remote keyless entry receiver
Continuity
Connector Terminal Connector Terminal
M68 20 B21 2 Existed
Revision: 2010 May2011 QX56

REMOTE KEYLESS ENTRY RECEIVERDLK-135
< DTC/CIRCUIT DIAGNOSIS >
C
DE
F
G H
I
J
L
M A
B
DLK
N
O P
3.CHECK REMOTE KEYLESS EN TRY RECEIVER CIRCUIT 2
1. Disconnect BCM connector.
2. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
4.CHECK REMOTE KEYLESS ENTRY RECEIVER POWER SUPPLY
1. Disconnect remote keyless entry receiver.
2. Check signal between remote keyless entry rece iver harness connector and ground using oscilloscope.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 5.
5.CHECK REMOTE KEYLESS EN TRY RECEIVER CIRCUIT 3
1. Disconnect BCM connector.
2. Check continuity between BCM harness connector and remote keyless entry receiver harness connector.
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-81, "Removal and Installation".
NO >> Repair or replace harness.
6.CHECK REMOTE KEYLESS ENTR Y RECEIVER GROUND CIRCUIT 1
1. Disconnect BCM connector.
2. Check continuity between BCM harness connector and remote keyless entry receiver harness connector.
BCM
GroundContinuity
Connector Terminal
M68 20 Not existed
(+)
(–)Signal
(Reference value)
Remote keyless entry receiver
Connector Terminal
B21 4 Ground
JMKIA3838GB
BCM Remote keyless entry receiver Continuity
Connector Terminal Connector Terminal
M68 19 B21 4 Existed
BCM GroundContinuity
Connector Terminal
M68 19 Not existed
BCM Remote keyless entry receiver Continuity
Connector Terminal Connector Terminal
M68 18 B21 1 Existed
Revision: 2010 May2011 QX56

DLK-136
< DTC/CIRCUIT DIAGNOSIS >
REMOTE KEYLESS ENTRY RECEIVER
3. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace harness.
7.CHECK REMOTE KEYLESS ENTRY RECEIVER GROUND CIRCUIT 2
1. Connect BCM connector.
2. Check continuity between BCM harness connector and ground.
Is the inspection result normal?
YES >> Replace remote keyless entry receiver.
NO >> Replace BCM. Refer to BCS-81, "
Removal and Installation".
8.CHECK REMOTE KEYLESS ENTRY RE CEIVER RSSI OUTPUT SIGNAL
1. Connect BCM and remote keyless entry receiver connector.
2. Check signal between remote keyless entry receiver harness connector and ground using oscilloscope.
Is the inspection result normal?
YES >> GO TO 9.
NO >> Replace remote keyless entry receiver.
9.CHECK REMOTE KEYL ESS ENTRY RECEIVER RSSI CIRCUIT
1. Disconnect BCM and remote keyless entry receiver connector.
2. Check continuity between BCM harness connector and remote keyless entry receiver harness connector.
Is the inspection result normal?
YES >> Replace BCM. Refer to BCS-81, "Removal and Installation".
NO >> Repair or replace harness.
BCM
GroundContinuity
Connector Terminal
M68 18 Not existed
BCM GroundContinuity
Connector Terminal
M68 18 Existed
(+) (–) Condition Signal
(Reference value)
Remote keyless entry receiver
Connector Terminal
B21 3 Ground Waiting 0 V
Signal receiving
JMKIA3838GB
BCM Remote keyless entry receiver
Continuity
Connector Terminal Connector Terminal
M68 22 B21 3 Existed
Revision: 2010 May2011 QX56

DLK-172
< SYMPTOM DIAGNOSIS >
DOOR DOES NOT LOCK/UNLOCK WITH DOOR REQUEST SWITCH
DOOR DOES NOT LOCK/UNLOCK WITH DOOR REQUEST SWITCH
ALL DOOR REQUEST SWITCHES
ALL DOOR REQUEST SWITCHES : DescriptionINFOID:0000000006226005
All doors do not lock/unlock using all door request switches.
ALL DOOR REQUEST SWITCHES : Diagnosis ProcedureINFOID:0000000006226006
1.CHECK REMOTE KEYLESS ENTRY FUNCTION
Check remote keyless entry function.
Does door lock/unlock with Intelligent Key button?
YES >> GO TO 2.
NO >> Refer to DLK-134, "
ComponentFunctionCheck".
2.CHECK “LOCK/UNLOCK BY I-KEY” SETTING IN “WORK SUPPORT”
1. Select “INTELLIGE NT KEY” of “BCM” using CONSULT-III.
2. Select “LOCK/UNLOCK BY I-K EY” in “WORK SUPPORT” mode.
3. Check “LOCK/UNLOCK BY I-KEY” setting in “WORK SUPPORT”. Refer to DLK-41, "
INTELLIGENT KEY : CONSULT-III F unction (BCM - INTELLIGENT KEY)".
Is the inspection result normal?
YES >> GO TO 3.
NO >> Set “ON” in “LOCK/UNLOCK BY I-KEY”.
3.CHECK DOOR SWITCH
Check door switch.
Refer to DLK-117, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace the malfunctioning parts.
4.CHECK INSIDE KEY ANTENNA
Check inside key antenna.
 Instrument center: Refer to DLK-104, "
DTC Logic".
 Console: Refer to DLK-106, "
DTC Logic".
 Luggage room: Refer to DLK-108, "
DTC Logic".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace the malfunctioning parts.
5.CHECK OUTSIDE KEY ANTENNA
Check outside key antenna.
 Driver side: Refer to DLK-110, "
DTC Logic".
 Passenger side: Refer to DLK-112, "
DTC Logic".
 Back door: Refer to DLK-114, "
DTC Logic".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace the malfunctioning parts.
6.CHECK BACK DOOR SWITCH
Check back door switch.
Refer to DLK-120, "
ComponentFunctionCheck".
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair or replace the malfunctioning parts.
7.REPLACE BCM
Revision: 2010 May2011 QX56
