Page 2717 of 5598
![INFINITI QX56 2011 Factory Owners Guide
COMPONENT PARTSEXL-7
< SYSTEM DESCRIPTION > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
*1: With headlamp aiming control system (manual) models
*2: With AFS system models
EXTERIOR LIGHTING SYSTEM INFINITI QX56 2011 Factory Owners Guide
COMPONENT PARTSEXL-7
< SYSTEM DESCRIPTION > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
*1: With headlamp aiming control system (manual) models
*2: With AFS system models
EXTERIOR LIGHTING SYSTEM](/img/42/57033/w960_57033-2716.png)
COMPONENT PARTSEXL-7
< SYSTEM DESCRIPTION > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
*1: With headlamp aiming control system (manual) models
*2: With AFS system models
EXTERIOR LIGHTING SYSTEM : Component DescriptionINFOID:0000000006213888
1. Combination meter 2. BCM
Refer to BCS-4, "
BODY CONTROL
SYSTEM : Compon ent Parts Loca-
tion"
3. Optical sensor
4. IPDM E/R Refer to PCS-4, "
Component Parts
Location"
5. ECM
Refer to EC-16, "
Component Parts
Location"
6. Parking lamp
7. Front turn signal lamp 8. Front fog lamp 9. Headlamp
10. Front side marker lamp 11. Combination switch 12. Headlamp aiming switch*
1
13. Front door switch (driver side) 14.
Steering angle sensor*2
Refer to BRC-10, "Component Parts
Location"
15. License plate lamp
16. Tail lamp 17. Rear turn signal lamp 18. Rear side marker lamp
19. Hazard switch 20. Side turn signal lamp 21. Headlamp swivel actuator
22. Headlamp aiming motor 23. AFS switch*
224.Rear height sensor*2
25.AFS control unit*226.Front height sensor*2
A. Front combination lamp (back) B. View with instrument driver lower
panel (LH)C. Rear suspension member (RH)
D. View with instrument lower cover E. Front suspension arm (RH)
Part Description
BCM Controls the exterior lighting system.
ECM*
1Transmits engine speed signal to AFS control unit. (via CAN communication)
TCM*
1Transmits Shift position signal to AFS control unit. (via CAN communication)
IPDM E/R Controls the integrated relay, and supplies voltage to the load according to the request
from BCM (via CAN communication).
AFS control unit*
1AFS control unit judges the vehicle condition from each signal. AFS control unit con-
trols AFS function and the headlamp aiming.
Combination meter Outputs the vehicle speed signal (8-pulse) to AFS control unit.
Blinks the turn signal indicator lamp and outputs the turn signal operating sound with
integrated buzzer according to the request from BCM (via CAN communication).
Turns the tail lamp indicator lamp and high beam indicator lamp ON according to the
request from BCM (via CAN communication).
Turns the AFS OFF indicator lamp ON/OFF /blinking according to the request from
AFS control unit (via CAN communication).
Headlamp assembly Xenon bulb Refer to
EXL-8, "
FRONT COMBINATION LAMP : Xenon Headlamp".
HID control unit Refer to EXL-9, "
FRONT COMBINATION LAMP : HID control unit".
High beam solenoid Refer to EXL-9, "
FRONT COMBINATION LAMP : High Beam Solenoid".
Aiming motor Refer to EXL-9, "
FRONT COMBINATION LAMP : Aiming Motor".
Swivel actuator*
1Refer to EXL-9, "FRONT COMBINATION LAMP : Swivel Actuator".
Height sensor*
1
The height sensor is installed to the front suspension member and rear suspension member.
The height sensor detects the suspension arm displacement as the vehicle height change.
The height sensor transmits the height sensor signal to AFS control unit.
NOTE:
The sensor angle of the unloaded vehicle position is the reference value.
Optical sensor Optical sensor converts the outside brightness (lux) to voltage and transmits the opti-
cal sensor signal to BCM.
Revision: 2010 May2011 QX56
Page 2720 of 5598
![INFINITI QX56 2011 Factory Owners Guide
EXL-10
< SYSTEM DESCRIPTION >[XENON TYPE]
SYSTEM
SYSTEM
HEADLAMP SYSTEM
HEADLAMP SYSTEM : System DiagramINFOID:0000000006213894
HEADLAMP SYSTEM : System DescriptionINFOID:0000000006213895
OUTLINE
Hea INFINITI QX56 2011 Factory Owners Guide
EXL-10
< SYSTEM DESCRIPTION >[XENON TYPE]
SYSTEM
SYSTEM
HEADLAMP SYSTEM
HEADLAMP SYSTEM : System DiagramINFOID:0000000006213894
HEADLAMP SYSTEM : System DescriptionINFOID:0000000006213895
OUTLINE
Hea](/img/42/57033/w960_57033-2719.png)
EXL-10
< SYSTEM DESCRIPTION >[XENON TYPE]
SYSTEM
SYSTEM
HEADLAMP SYSTEM
HEADLAMP SYSTEM : System DiagramINFOID:0000000006213894
HEADLAMP SYSTEM : System DescriptionINFOID:0000000006213895
OUTLINE
Headlamp is controlled by combination switch r
eading function and headlamp control function of BCM, and
relay control function of IPDM E/R.
HEADLAMP (LO) OPERATION
BCM detects the combination switch conditi on with the combination switch reading function.
BCM transmits the low beam request signal to IPDM E/R via CAN communication according to the head-
lamp (LO) ON condition.
Headlamp (LO) ON condition- Lighting switch 2ND
- Lighting switch AUTO (auto light function ON judgment)
- Lighting switch AUTO, with the front fog la mp switch ON and the ignition switch ON
- Lighting switch PASS
IPDM E/R turns the integrated headlamp low relay ON , and turns the headlamp ON according to the low
beam request signal.
HEADLAMP (HI) OPERATION
BCM transmits the high beam request signal to IPDM E/R and the combination meter via CAN communica- tion according to the headlamp (HI) ON condition.
Headlamp (HI) ON condition
- Lighting switch HI with the lighting switch 2ND or AUTO (auto light function ON judgment)
- Lighting switch PASS
- Lighting switch AUTO, with the front fog lamp swit ch ON, the ignition switch ON and lighting switch HI
Combination meter turns the high beam indicator lamp ON according to the high beam request signal.
IPDM E/R turns the integrated headlamp high relay ON , and turns the headlamp ON according to the high
beam request signal.
HEADLAMP SYSTEM : Fail-safeINFOID:0000000006213896
CAN COMMUNICATION CONTROL
When CAN communication with BCM is impossible, IPDM E/R performs fail-safe control. After CAN communi-
cation recovers normally, it also returns to normal control.
If No CAN Communication Is Available With BCM
JMLIA1083GB
Revision: 2010 May2011 QX56
Page 2721 of 5598
![INFINITI QX56 2011 Factory Owners Guide
SYSTEMEXL-11
< SYSTEM DESCRIPTION > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
*: With daytime running light system
AUTO LIGHT SYSTEM
AUTO LIGHT SYSTEM : System DiagramINFOID:0000000006213897
AUT INFINITI QX56 2011 Factory Owners Guide
SYSTEMEXL-11
< SYSTEM DESCRIPTION > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
*: With daytime running light system
AUTO LIGHT SYSTEM
AUTO LIGHT SYSTEM : System DiagramINFOID:0000000006213897
AUT](/img/42/57033/w960_57033-2720.png)
SYSTEMEXL-11
< SYSTEM DESCRIPTION > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
*: With daytime running light system
AUTO LIGHT SYSTEM
AUTO LIGHT SYSTEM : System DiagramINFOID:0000000006213897
AUTO LIGHT SYSTEM : System Description (For CANADA)INFOID:0000000006218912
OUTLINE
Auto light system is controlled by each function of BCM and IPDM E/R.
Control by BCM- Combination switch reading function
- Headlamp control function
- Auto light function
- Delay timer function
- Wiper linked auto lighting function
- Auto light adjustment system
Control by IPDM E/R
- Relay control function
Auto light system has the auto light function, wiper linked auto lighting function and delay timer function.
- Auto light function automatically turns ON/OFF the exterior lamps* and each illumination automatically,
depending on the outside brightness.
- Wiper linked auto lighting function automatically tu rns ON/OFF the exterior lamps* and each illumination
when the light switch is in the AUTO posit ion, according to a front wiper operation.
- When auto light system turns the exterior lamps ON wit h the ignition switch OFF, delay timer function turns
the exterior lamps OFF, depending on the vehicle condition with the auto light function after a certain period
of time.
*: Headlamp (LO/HI), parking lamp, side marker lamp, tail lamp and front fog lamp (Headlamp HI and front fog
lamp depend on the combination switch condition.)
AUTO LIGHT FUNCTION
BCM detects the combination switch conditi on with the combination switch reading function.
BCM supplies voltage to optical sensor when the ignition switch is turned ON or ACC.
Optical sensor converts outside brightness (lux) to voltage and transmits the optical sensor signal to BCM.
BCM judges outside brightness from the optical sens or signal and judges ON/OFF condition of the exterior
lamp and each illumination according to the outside brightness.
Control part Fail-safe operation
Headlamp Turns ON the headlamp low relay when the ignition switch is turned ON
Turns OFF the headlamp low relay when the ignition switch is turned OFF
Headlamp high relay OFF
JMLIA1254GB
Revision: 2010 May2011 QX56
Page 2722 of 5598
![INFINITI QX56 2011 Factory Owners Guide
EXL-12
< SYSTEM DESCRIPTION >[XENON TYPE]
SYSTEM
BCM transmits each request signal to IPDM E/R wit
h CAN communication according to ON/OFF condition
by the auto light function.
NOTE:
ON/OFF timing INFINITI QX56 2011 Factory Owners Guide
EXL-12
< SYSTEM DESCRIPTION >[XENON TYPE]
SYSTEM
BCM transmits each request signal to IPDM E/R wit
h CAN communication according to ON/OFF condition
by the auto light function.
NOTE:
ON/OFF timing](/img/42/57033/w960_57033-2721.png)
EXL-12
< SYSTEM DESCRIPTION >[XENON TYPE]
SYSTEM
BCM transmits each request signal to IPDM E/R wit
h CAN communication according to ON/OFF condition
by the auto light function.
NOTE:
ON/OFF timing differs based on the sensit ivity from the setting. The setting can be set by CONSULT-III. Refer
to EXL-23, "
HEADLAMP : CONSULT-III Function (BCM - HEAD LAMP)".
AUTO LIGHT ADJUSTMENT SYSTEM
The auto light adjustment system automatically, dims/bri ghtens the display and combination meter, according
to brightness outside the vehicle, when lighting switch 1ST or lighting switch 2ND is operated. Refer to INL-11,
"AUTO LIGHT ADJUSTMENT SYSTEM : System Description".
DELAY TIMER FUNCTION
BCM turns the exterior lamp OFF depending on the vehicle condition with the auto light function when the igni-
tion switch is turned OFF.
Turns the exterior lamp OFF 5 minutes afte r detecting that any door opens. (Door switch ON).
Turns the exterior lamp OFF a certain period of time* after closing all doors. (Door switch ON →OFF).
Turns the exterior lamp OFF with the igni tion switch ACC or the light switch OFF.
*: The preset time is 45 seconds. The timer operat ing time can be set by CONSULT-III. Refer to EXL-23,
"HEADLAMP : CONSULT-III Function (BCM - HEAD LAMP)".
NOTE:
When any position other than the light switch AUTO is set, the auto light system function switches to the exte-
rior lamp battery saver function.
AUTO LIGHT SYSTEM : System De scription (Except for CANADA)INFOID:0000000006218908
OUTLINE
Auto light system is controlled by each function of BCM and IPDM E/R.
Control by BCM- Combination switch reading function
- Headlamp control function
- Auto light function
- Delay timer function
- Wiper linked auto lighting function
- Auto light adjustment system
Control by IPDM E/R- Relay control function
Auto light system has the auto light function (with twilight lighting function), wiper linked auto lighting function
and delay timer function.
- Auto light function automatically turns ON/OFF the exterior lamps* and each illumination automatically,
depending on the outside brightness.
- Wiper linked auto lighting function automatically turn s ON/OFF the exterior lamps* and each illumination
when the light switch is in the AUTO posit ion, according to a front wiper operation.
- When auto light system turns the exterior lamps ON with the ignition switch OFF, delay timer function turns the exterior lamps OFF, depending on the vehicle conditi on with the auto light function after a certain period
of time.
*: Headlamp (LO/HI), parking lamp, side marker lamp, tail lamp and front fog lamp (Headlamp HI and front fog
lamp depend on the combination switch condition.)
NOTE:
The settings of the twilight lighting function and the wiper linked auto lighting function can be changed with
CONSULT-III. Refer to EXL-23, "
HEADLAMP : CONSULT-III Function (BCM - HEAD LAMP)".
AUTO LIGHT FUNCTION (WITH TWILIGHT LIGHTING FUNCTION)
Description
BCM detects the combination switch conditi on with the combination switch reading function.
BCM supplies voltage to the optical sensor when the ignition switch is turned ON or ACC.
Optical sensor converts outside brightness (lux) to voltage and transmits the optical sensor signal to BCM.
When ignition switch is turned ON, BCM detects out side brightness from the optical sensor signal and
judges ON/OFF condition of the exterior lamp and each illumination, depending on the outside brightness
condition (standard or twilight).
Revision: 2010 May2011 QX56
Page 2724 of 5598
![INFINITI QX56 2011 Factory Owners Guide
EXL-14
< SYSTEM DESCRIPTION >[XENON TYPE]
SYSTEM
AUTO LIGHT ADJUSTMENT SYSTEM
The auto light adjustment system automatically, dims/bri
ghtens the display and combination meter, according
to brightnes INFINITI QX56 2011 Factory Owners Guide
EXL-14
< SYSTEM DESCRIPTION >[XENON TYPE]
SYSTEM
AUTO LIGHT ADJUSTMENT SYSTEM
The auto light adjustment system automatically, dims/bri
ghtens the display and combination meter, according
to brightnes](/img/42/57033/w960_57033-2723.png)
EXL-14
< SYSTEM DESCRIPTION >[XENON TYPE]
SYSTEM
AUTO LIGHT ADJUSTMENT SYSTEM
The auto light adjustment system automatically, dims/bri
ghtens the display and combination meter, according
to brightness outside the vehicle, when lighting switch 1ST or lighting switch 2ND is operated. Refer to INL-11,
"AUTO LIGHT ADJUSTMENT SYSTEM : System Description".
DELAY TIMER FUNCTION
BCM turns the exterior lamp OFF depending on the vehicle condition with the auto light function when the igni-
tion switch is turned OFF.
Turns the exterior lamp OFF 5 minutes afte r detecting that any door opens. (Door switch ON).
Turns the exterior lamp OFF a certain period of time* after closing all doors. (Door switch ON →OFF).
Turns the exterior lamp OFF with the igni tion switch ACC or the light switch OFF.
*: The preset time is 45 seconds. The timer operat ing time can be set by CONSULT-III. Refer to EXL-23,
"HEADLAMP : CONSULT-III Function (BCM - HEAD LAMP)".
NOTE:
When any position other than the light switch AUTO is set, the auto light system function switches to the exte-
rior lamp battery saver function.
DAYTIME RUNNING LIGHT SYSTEM
DAYTIME RUNNING LIGHT S YSTEM : System DiagramINFOID:0000000006214028
DAYTIME RUNNING LIGHT SYSTEM : System DescriptionINFOID:0000000006214029
OUTLINE
Turns the front fog lamp ON as the daytime running light.
Daytime running light is controlled by daytime runni ng light control function and combination switch reading
function of BCM, and relay c ontrol function of IPDM E/R.
DAYTIME RUNNING LIGHT OPERATION
BCM detects the combination switch conditi on by the combination switch reading function.
BCM detects the vehicle condition depending on the following signals.
- Parking brake switch signal (received from combination meter via CAN communication)
BCM transmits the front fog light request signal to IPDM E/R via CAN communication according to the day-
time running light ON condition.
Daytime running light ON condition- While the engine running with the parking brake released
- Lighting switch OFF
- Lighting switch AUTO (auto light function OFF judgment)
- Passing switch OFF
- Front fog lamp switch OFF
IPDM E/R turns the integrated front fog lamp relay ON and turns the front fog lamp ON according to the front
fog light request signal.
ACTIVE ADAPTIVE FRONT-LIGHTING SYSTEM
JMLIA1078GB
Revision: 2010 May2011 QX56
Page 2729 of 5598
![INFINITI QX56 2011 Factory Owners Guide
SYSTEMEXL-19
< SYSTEM DESCRIPTION > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
agramINFOID:0000000006213903
PARKING, LICENSE PLATE, SIDE MARKER AND TAIL LAMP SYSTEM : System De-
scription
INFOID INFINITI QX56 2011 Factory Owners Guide
SYSTEMEXL-19
< SYSTEM DESCRIPTION > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
agramINFOID:0000000006213903
PARKING, LICENSE PLATE, SIDE MARKER AND TAIL LAMP SYSTEM : System De-
scription
INFOID](/img/42/57033/w960_57033-2728.png)
SYSTEMEXL-19
< SYSTEM DESCRIPTION > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
agramINFOID:0000000006213903
PARKING, LICENSE PLATE, SIDE MARKER AND TAIL LAMP SYSTEM : System De-
scription
INFOID:0000000006213904
OUTLINE
Parking, license plate, side marker and tail lamps ar e controlled by combination switch reading function and
headlamp control function of BCM, and re lay control function of IPDM E/R.
PARKING, LICENSE PLATE, SIDE MARKER AND TAIL LAMPS OPERATION
BCM detects the combination switch conditi on by the combination switch reading function.
BCM transmits the position light request signal to IPDM E/R and the combination meter via CAN communi-
cation according to the ON/OFF condition of the pa rking, license plate, side marker and tail lamps.
Parking, license plate, side marker and tail lamps ON condition- Lighting switch 1ST
- Lighting switch 2ND
- Lighting switch AUTO, and the auto light function ON judgment
- Lighting switch AUTO, with the front fog lamp switch ON and the ignition switch ON
IPDM E/R turns the integrated tail lamp relay ON and tu rns the parking, license plate, side marker and tail
lamps ON according to the position light request signal.
Combination meter turns the tail lamp indicator lamp ON according to the position light request signal.
PARKING, LICENSE PLATE, SIDE MARKER AND TAIL LAMP SYSTEM : Fail-safe
INFOID:0000000006213905
CAN COMMUNICATION CONTROL
When CAN communication with BCM is impossible, IPDM E/R performs fail-safe control. After CAN communi-
cation recovers normally, it also returns to normal control.
If No CAN Communication Is Available With BCM
*: With daytime running light system
FRONT FOG LAMP SYSTEM
JMLIA0687GB
Control part Fail-safe operation
Parking lamps
License plate lamps
Illuminations
Tail lamps Turns ON the tail lamp relay and daytime running light relay
* when the ignition switch
is turned ON
Turns OFF the tail lamp relay and daytime running light relay
* when the ignition switch
is turned OFF
Revision: 2010 May2011 QX56
Page 2730 of 5598
![INFINITI QX56 2011 Factory Owners Guide
EXL-20
< SYSTEM DESCRIPTION >[XENON TYPE]
SYSTEM
FRONT FOG LAMP SYSTEM : System Diagram
INFOID:0000000006213906
FRONT FOG LAMP SYSTEM : System DescriptionINFOID:0000000006213907
OUTLINE
Front fog lam INFINITI QX56 2011 Factory Owners Guide
EXL-20
< SYSTEM DESCRIPTION >[XENON TYPE]
SYSTEM
FRONT FOG LAMP SYSTEM : System Diagram
INFOID:0000000006213906
FRONT FOG LAMP SYSTEM : System DescriptionINFOID:0000000006213907
OUTLINE
Front fog lam](/img/42/57033/w960_57033-2729.png)
EXL-20
< SYSTEM DESCRIPTION >[XENON TYPE]
SYSTEM
FRONT FOG LAMP SYSTEM : System Diagram
INFOID:0000000006213906
FRONT FOG LAMP SYSTEM : System DescriptionINFOID:0000000006213907
OUTLINE
Front fog lamp is controlled by combination switch r eading function and front fog lamp control function of BCM,
and relay control function of IPDM E/R.
FRONT FOG LAMP OPERATION
BCM detects the combination switch conditi on by the combination switch reading function.
BCM transmits the front fog lights request signal to IPDM E/R via CAN communication according to the front
fog lamp ON condition.
Front fog lamp ON condition- Front fog lamp switch ON and any of the followings. (except for the high beam ON)
Lighting switch 2ND
Lighting switch AUTO (auto light function ON judgment)
IPDM E/R turns the integrated front fog lamp relay ON, and turns the front fog lamp ON according to the front
fog lights request signal.
FRONT FOG LAMP SYSTEM : Fail-SafeINFOID:0000000006422123
CAN COMMUNICATION CONTROL
When CAN communication with ECM and BCM is impossible, IPDM E/R performs fail-safe control. After CAN
communication recovers normally, it also returns to normal control.
If No CAN Communication Is Available With BCM
EXTERIOR LAMP BATTERY SAVER SYSTEM
EXTERIOR LAMP BATTERY SAVE R SYSTEM : System DiagramINFOID:0000000006213908
JMLIA1154GB
Control part Fail-safe operation
Front fog lamp Front fog lamp relay OFF
JPLIA1037GB
Revision: 2010 May2011 QX56
Page 2731 of 5598
![INFINITI QX56 2011 Factory Owners Guide
SYSTEMEXL-21
< SYSTEM DESCRIPTION > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
EXTERIOR LAMP BATTERY SAVE R SYSTEM : System DescriptionINFOID:0000000006213909
OUTLINE
Exterior lamp battery save INFINITI QX56 2011 Factory Owners Guide
SYSTEMEXL-21
< SYSTEM DESCRIPTION > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
EXTERIOR LAMP BATTERY SAVE R SYSTEM : System DescriptionINFOID:0000000006213909
OUTLINE
Exterior lamp battery save](/img/42/57033/w960_57033-2730.png)
SYSTEMEXL-21
< SYSTEM DESCRIPTION > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
EXTERIOR LAMP BATTERY SAVE R SYSTEM : System DescriptionINFOID:0000000006213909
OUTLINE
Exterior lamp battery saver system is c ontrolled by each function of BCM and IPDM E/R.
Control by BCM
- Combination switch reading function
- Headlamp control function
- Exterior lamp battery saver function
Control by IPDM E/R
- Relay control function
BCM turns the exterior lamp* OFF after a period of ti me to prevent the battery from over-discharge when the
ignition switch is turned OFF with the exterior lamp ON.
*: Headlamp (LO/HI), parking lamp, tail lamp, side marker lamp, license plate lamp and front fog lamp
EXTERIOR LAMP BATTERY SAVER ACTIVATION
BCM activates the timer and turns the exterior lamp OFF 5 minutes after the ignition switch is turned from ON
→ OFF with the exterior lamps ON.
NOTE:
Headlamp control function turns the exterior lamps ON normally when the ignition switch is turned ACC or
the engine started (both before and after the exte rior lamp battery saver is turned OFF).
The timer starts at the time that the lighting switch is turned from OFF → 1ST or 2ND with the exterior lamp
OFF.
Revision: 2010 May2011 QX56
Page 2734 of 5598
![INFINITI QX56 2011 Factory Owners Guide
EXL-24
< SYSTEM DESCRIPTION >[XENON TYPE]
DIAGNOSIS SYSTEM (BCM)
*1: Factory setting
*
2: For models for Canada, this item is displayed but is not operated.
DATA MONITOR
BATTERY SAVER SET On*1With th INFINITI QX56 2011 Factory Owners Guide
EXL-24
< SYSTEM DESCRIPTION >[XENON TYPE]
DIAGNOSIS SYSTEM (BCM)
*1: Factory setting
*
2: For models for Canada, this item is displayed but is not operated.
DATA MONITOR
BATTERY SAVER SET On*1With th](/img/42/57033/w960_57033-2733.png)
EXL-24
< SYSTEM DESCRIPTION >[XENON TYPE]
DIAGNOSIS SYSTEM (BCM)
*1: Factory setting
*
2: For models for Canada, this item is displayed but is not operated.
DATA MONITOR
BATTERY SAVER SET On*1With the exterior lamp battery saver function
Off Without the exterior lamp battery saver function
ILL DELAY SET MODE 1*
145 sec.
Sets delay timer function timer operation time
(All doors closed)
MODE 2
Without the
function
MODE 3 30 sec.
MODE 4 60 sec.
MODE 5 90 sec.
MODE 6 120 sec.
MODE 7 150 sec.
MODE 8 180 sec.
AUTO LIGHT LOGIC SET*
2
MODE 1*1With twilight ON custom & with wiper INT, LO and HI
MODE 2 With twilight ON custom & with wiper LO and HI
MODE 3 With twilight ON custom & without
MODE 4 Without twilight ON custom & with wiper INT, LO and HI
MODE 5 Without twilight ON custom & with wiper LO and HI
MODE 6 Without twilight ON custom & without
Service item Setting item Setting
Monitor item
[Unit] Description
PUSH SW
[On/Off] The switch status input from push-button ignition switch
ENGINE STATE
[Stop/Stall/Crank/Run] The engine status received from ECM via CAN communication
VEH SPEED 1
[km/h] The value of the vehicle speed received from combination meter via CAN communi-
cation
TURN SIGNAL R
[On/Off]
Each switch status that BCM judges from the combination switch reading function
TURN SIGNAL L
[On/Off]
TA I L L A M P S W
[On/Off]
HI BEAM SW
[On/Off]
HEAD LAMP SW1
[On/Off]
HEAD LAMP SW2
[On/Off]
PASSING SW
[On/Off]
AUTO LIGHT SW
[On/Off]
FR FOG SW
[On/Off]
RR FOG SW
[On/Off]
NOTE:
This item is indicated, but can not monitored
Revision: 2010 May2011 QX56
Page 2735 of 5598
![INFINITI QX56 2011 Factory Owners Guide
DIAGNOSIS SYSTEM (BCM)EXL-25
< SYSTEM DESCRIPTION > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
ACTIVE TEST
*: Only models for Canada display this item.
FLASHER
FLASHER : CONSULT-III F unction (BC INFINITI QX56 2011 Factory Owners Guide
DIAGNOSIS SYSTEM (BCM)EXL-25
< SYSTEM DESCRIPTION > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
ACTIVE TEST
*: Only models for Canada display this item.
FLASHER
FLASHER : CONSULT-III F unction (BC](/img/42/57033/w960_57033-2734.png)
DIAGNOSIS SYSTEM (BCM)EXL-25
< SYSTEM DESCRIPTION > [XENON TYPE]
C
D
E
F
G H
I
J
K
M A
B
EXL
N
O P
ACTIVE TEST
*: Only models for Canada display this item.
FLASHER
FLASHER : CONSULT-III F unction (BCM - FLASHER)INFOID:0000000006213912
WORK SUPPORT
DOOR SW-DR
[On/Off] The switch status input from front door switch (driver side)
DOOR SW-AS
[On/Off] The switch status input from front door switch (passenger side)
DOOR SW-RR
[On/Off] The switch status input from rear door switch RH
DOOR SW- RL
[On/Off] The switch status input from rear door switch LH
DOOR SW-BK
[On/Off] The switch status input from back door switch
OPTICAL SENSOR
[On/Off] The sensor status input from optical sensor
OPTI SEN (DTCT)
[V] The value of outside brightness voltage input from the optical sensor
OPTI SEN (FILT)
[V] The value of outside brightness voltage filtered by BCM
Monitor item
[Unit] Description
Test item Operation Description
TAIL LAMP On
Transmits the position light request signal to IPDM E/R via CAN commu-
nication to turn the tail lamp ON
Off Stops the tail lamp request signal transmission
HEAD LAMP Hi
Transmits the high beam request signal via CAN communication to turn
the headlamp (HI)
Lo Transmits the low beam request signal via CAN communication to turn
the headlamp (LO)
Off Stops the high & low beam request signal transmission
FR FOG LAMP On
Transmits the front fog lights request signal to IPDM E/R via CAN com-
munication to turn the front fog lamp ON
Off Stops the front light request signal transmission
RR FOG LAMP On
NOTE:
This item is indicated, but can not tested
Off
DAYTIME RUNNING LIGHT* On
Transmits the front fog lights request signal to IPDM E/R via CAN com-
munication to turn the front fog lamp ON (daytime running light system)
Off Stops the front light request signal transmission (daytime running light
system)
ILL DIM SIGNAL On Transmits the dimmer signal to combination meter via CAN communi-
cation and dims combination meter
Transmits the dimmer signal to AV control unit and dims display
Off Stops the dimmer signal transmission
Revision: 2010 May2011 QX56
