INFINITI QX56 2011 Factory Service Manual

WCS
SYSTEMWCS-7
< SYSTEM DESCRIPTION >
C
DE
F
G H
I
J
K L
M B A
O P
WARNING CHIME SYSTEM : Fail-SafeINFOID:0000000006369726
FA I L - S A F E
The combination meter activates the fail-safe contro l if CAN communication with each unit is malfunctioning.
Seat belt warning chimeThe warning chime sounds when the driver
seat belt is unfastened with the ignition switch
in ON position. BCMWCS-11,
"SEAT BELT
WARNING
CHIME : Sys-
tem Descrip-
tion"
Parking brake release warning chime
The warning chime sounds when the ignition
switch is in ON position with the parking brake
in operation and the vehicle speed 7 km/h (4.3
MPH) or more. Combination meterWCS-12,
"PA R K I N G
BRAKE RE-
LEASE WARN-
ING CHIME :
System De-
scription"
Warning functions Out line Warning judgment unit Refer to
Function Specifications
Speedometer
Reset to zero by suspending communication.
Tachometer
Engine coolant temperature gauge
Engine oil pressure gauge
Illumination control When suspending communication, changes to nighttime mode.
Information display Odo/trip meter An indicated value is maintained at communications blackout.
Shift position indicator The display turns OFF by suspending communication.
Door open warning The display turns OFF by suspending communication.
Buzzer The buzzer turns OFF by suspending communication.
Revision: 2010 May2011 QX56

WCS-8
< SYSTEM DESCRIPTION >
SYSTEM
LIGHT REMINDER WARNING CHIME
LIGHT REMINDER WARNING CHIME : System DiagramINFOID:0000000006222543
LIGHT REMINDER WARNING CHIME : System DescriptionINFOID:0000000006222544
WARNING CHIME OPERATION CONDITIONS
If all of the following conditions are fulfilled.
WARNING CHIME CANCEL CONDITIONS
Warning lamp/indicator lampABS warning lamp
The lamp turns ON by suspending communication.
VDC warning lamp
Brake warning lamp
IBA OFF indicator lamp
4WD warning lamp
Malfunction indicator lamp
VDC OFF indicator lamp
CRUISE warning lamp
Low tire pressure warning lamp The lamp blinking caused by suspending communication.
High beam indicator lamp
The lamp turns OFF by suspending communication.
Turn signal indicator lamp
Tail lamp indicator lamp
A/T CHECK indicator lamp
Key warning lamp
ATP warning lamp
Lane departure warning lamp
LDP ON indicator lamp
CRUISE indicator lamp
Oil pressure warning lamp
SNOW mode indicator lamp
TOW mode indicator lamp
CK SUSP indicator lamp
BSW indicator lamp
Function Specifications
JSNIA2421GB
Operation conditions
Ignition switch OFF or ACC position
Combination switch (Lighting
switch) 1st or 2nd position
Driver door Open [front door switch (driver side) ON]
Revision: 2010 May2011 QX56

WCS
SYSTEMWCS-9
< SYSTEM DESCRIPTION >
C
DE
F
G H
I
J
K L
M B A
O P
Warning is canceled if any of t he following conditions is fulfilled.
SIGNAL PATH
1. BCM requires warning chime output to combination meter when it judges light reminder warning chime is
necessary from signals below.
2. Combination meter sounds integrated buzzer, followi ng the warning chime output requirement (below sig-
nal) from BCM.
TIMING CHART
FRONT FOG LIGHT REMINDER WARNING CHIME
Operation conditions
Ignition switch ON
Combination switch (Lighting
switch) OFF or AUTO position
Driver door Close [front door switch (driver side) OFF]
Signal name Signal path
Ignition switch signal —
Combination switch signal Combination switch (Lighting switch) BCM
Driver door switch signal Front door switch (driver side) BCM
Signal name Signal path
Buzzer output signal BCM Combination meter
JSNIA2426GB
Revision: 2010 May2011 QX56

WCS-10
< SYSTEM DESCRIPTION >
SYSTEM
FRONT FOG LIGHT REMINDER WARNING CHIME : System Diagram
INFOID:0000000006222545
FRONT FOG LIGHT REMINDER WARNING CHIME : System DescriptionINFOID:0000000006222546
WARNING CHIME OPERATION CONDITIONS
Warning chime sounds during 2 seconds when the ignition sw itch is in LOCK, OFF or ACC position, if all of
below operation conditions is met.
SIGNAL PATH
1. BCM requires warning chime output to combination meter when it judges front fog light reminder warning
chime is necessary from signals below.
2. Combination meter sounds integrated buzzer, following the warning chime output requirement (below sig- nal) from BCM.
TIMING CHART
SEAT BELT WARNING CHIME
JSNIA3117GB
Operation conditions
Ignition switch ON position
Combination switch (Lighting
switch) AUTO position and front fog lamp switch ON
position
Signal name Signal path
Ignition switch signal —
Combination switch signal Combination switch (Lighting switch) BCM
Signal name Signal path
Buzzer output signal BCM Combination meter
JSNIA3110GB
Revision: 2010 May2011 QX56

WCS
SYSTEMWCS-11
< SYSTEM DESCRIPTION >
C
DE
F
G H
I
J
K L
M B A
O P
SEAT BELT WARNING CHIME : System DiagramINFOID:0000000006222685
SEAT BELT WARNING CHIME : System DescriptionINFOID:0000000006222686
WARNING OPERATION CONDITIONS
If all of the following conditions are fulfilled.
WARNING CANCEL CONDITIONS
Warning is canceled if any of t he following conditions is fulfilled.
SIGNAL PATH
1. BCM requires warning chime output to combination meter when it judges seat belt warning chime is nec-
essary from signals below.
2. Combination meter sounds integrated buzzer, followi ng the warning chime output requirement (below sig-
nal) from BCM.
JSNIA3118GB
Operation conditions
Ignition switch ON
Driver seat belt Unfastened [seat belt buckle switch (driver side) ON]
Operation conditions
Ignition switch OFF
Seat belt (driver side) Fastened (driver side seat belt buckle switch OFF)
6 seconds after the start of warning sound
Signal name Signal path
Ignition switch signal —
Seat belt buckle switch signal
(driver side) Seat belt buckle switch (driver side) Combination meter
BCM
Signal name Signal path
Buzzer output signal BCM Combination meter
Revision: 2010 May2011 QX56

WCS-12
< SYSTEM DESCRIPTION >
SYSTEM
TIMING CHART
SOUND SPECIFICATION
PARKING BRAKE RELEASE WARNING CHIME
PARKING BRAKE RELEASE WARNING CHIME : System DiagramINFOID:0000000006222547
PARKING BRAKE RELEASE WARNING CHIME : System DescriptionINFOID:0000000006222548
WARNING OPERATION CONDITIONS
If all of the following conditions are fulfilled.
WARNING CANCEL CONDITIONS
Warning is canceled if any of the following conditions are fulfilled.
JSNIA3123GB
J S N I A 3 111 G B
JSNIA2422GB
Operation conditions
Ignition switch ON
Parking brake During the operation (parking brake switch ON)
Vehicle speed Approximately 7 km/h (4.3 MPH) or more
Revision: 2010 May2011 QX56

WCS
SYSTEMWCS-13
< SYSTEM DESCRIPTION >
C
DE
F
G H
I
J
K L
M B A
O PSIGNAL PATH
Combination meter sounds integrated buzzer when it judges that parking brake release warning chime is nec-
essary from signals below.
TIMING CHART
SOUND SPECIFICATION
Operation conditions
Ignition switch OFF
Parking brake Release condition (parking brake switch OFF)
Vehicle speed Approximately 3 km/h (1.9 MPH) or less
Signal name Signal path
Ignition switch signal —
Parking brake switch signal Parking brake switch Combination meter
Vehicle speed signal ABS actuator and electric unit (control unit) Combination meter
JSNIA2428GB
JSNIA3139GB
Revision: 2010 May2011 QX56

WCS-14
< SYSTEM DESCRIPTION >
DIAGNOSIS SYSTEM (COMBINATION METER)
DIAGNOSIS SYSTEM (COMBINATION METER)
CONSULT-III FunctionINFOID:0000000006222742
CONSULT-III APPLICATION ITEMS
CONSULT-III can perform the following diagnosis modes via CAN communication and the combination meter.
SELF DIAG RESULT
Refer to MWI-43, "DTC Index".
DATA MONITOR
Display Item List
X: Applicable
System Diagnosis mode Description
METER/M&A Self Diagnostic Result The combination meter checks the conditions and displays memorized errors.
Data Monitor Displays the combination meter input/output data in real time.
Special function Lighting history of the warning lamp and indicator lamp can be checked.
Display item [Unit]
MAIN
SIGNALS Description
SPEED METER
[km/h] XValue of vehicle speed
signal received from ABS actuator and el ectric unit (control
unit) via CAN communication.
NOTE:
655.35 is displayed when the malfunction signal is received.
SPEED OUTPUT
[km/h] XVehicle speed signal value transmitted to other units via CAN communication.
NOTE:
655.35 is displayed when the malfunction signal is received.
ODO OUTPUT
[km/h or mph] Odometer signal value transmitted to other units via CAN communication.
TACHO METER
[rpm] XValue of the engine speed signal received from ECM via CAN communication.
NOTE:
8191.875 is displayed when the malfunction signal is received.
FUEL METER
[L] X Fuel level indicated on combination meter.
W TEMP METER
[ ° C] XValue of engine coolant temperature signal is received from ECM via CAN com-
munication.
NOTE:
215 is displayed when the malfunction signal is input.
ABS W/L
[On/Off] Status of ABS warning lamp
detected from ABS warning lamp signal is received
from ABS actuator and electric unit (control unit) via CAN communication.
VDC/TCS IND
[On/Off] Status of VDC OFF indicator lamp detected from VDC OFF indicator lamp signal
is received from ABS actuator and electric
unit (control unit) via CAN communica-
tion.
SLIP IND
[On/Off] Status of VDC warning lamp detected from VDC warning lamp signal received
from ABS actuator and electric unit (control unit) via CAN communication.
BRAKE W/L
[On/Off] Status of brake warning lamp detected from brake warning lamp signal is received
from ABS actuator and electric unit (control unit) via CAN communication.
NOTE:
Displays “Off” if the brake warning lamp is illuminated when the valve check starts,
the parking brake switch is turned ON or the brake fluid level switch is turned ON.
DOOR W/L
[On/Off] Status of door open warning detected from door switch signal received from BCM
via CAN communication.
HI-BEAM IND
[On/Off] Status of high beam indicator lamp detected from high beam request signal is re-
ceived from BCM via CAN communication.
TURN IND
[On/Off] Status of turn indicator lamp detected from turn indicator signal is received from
BCM via CAN communication.
Revision: 2010 May2011 QX56

WCS
DIAGNOSIS SYSTEM (COMBINATION METER)
WCS-15
< SYSTEM DESCRIPTION >
C
D E
F
G H
I
J
K L
M B A
O P
FR FOG IND
[Off] This item is displayed, but cannot be monitored.
RR FOG IND
[Off] This item is displayed, but cannot be monitored.
LIGHT IND
[On/Off] Status of light indicator lamp detected from position light request signal is received
from BCM via CAN communication.
OIL W/L
[On/Off] Status of oil pressure warning lamp detected from oil pressure switch signal is re-
ceived from BCM via CAN communication.
MIL
[On/Off] Status of malfunction indicator lamp detected from malfunctioning indicator lamp
signal is received from ECM via CAN communication.
GLOW IND
[Off] This item is displayed, but cannot be monitored.
CRUISE IND
[On/Off]  Status of CRUISE indicator detected from ASCD status signal is received from
ECM via CAN communicat ion. (ASCD models)
 Status of CRUISE indicator de tected from meter display signal is received from
ADAS control unit via CAN communication. (ICC models)
SET IND
[On/Off] Status of SET indicator detected from meter display signal is received from ADAS
control unit via CAN communication.
CRUISE W/L
[On/Off] Status of CRUISE warning lamp
judged from ICC warning lamp signal received
from ADAS control unit with CAN communication line.
BA W/L
[On/Off] Status of IBA OFF indicator lamp judged from IBA OFF indicator lamp signal re-
ceived from ADAS control unit with CAN communication line.
ATC/T-AMT W/L
[On/Off] Status of A/T CHECK warning lamp judged
from A/T CHECK indicator lamp signal
received from TCM with CAN communication line.
ATF TEMP W/L
[Off] This item is displayed, but cannot be monitored.
4WD W/L
[On/Off] Status of 4WD warning lamp judged from 4WD warning lamp signal received from
4WD control unit with
CAN communication line.
FUEL W/L
[On/Off] Low-fuel warning lamp status detected by the identified fuel level.
WASHER W/L
[On/Off] Status of low washer fluid warning judged from washer level switch input to com-
bination meter.
AIR PRES W/L
[On/Off] Status of low tire pressure warning lamp judged from low tire pressure warning
lamp signal received from BCM with CAN communication line.
KEY G/Y W/L
[On/Off] Status of KEY warning lamp
(Green/Yellow) detected from KEY warning lamp sig-
nal is received from BCM via CAN communication.
KEY KNOB W/L
[Off] This item is displayed, but cannot be monitored.
AFS OFF IND
[On/Off] Status of AFS OFF indicator lamp judged from AFS OFF indicator lamp signal re-
ceived from AFS control unit with CAN communication line.
DDS
* W/L
[Off] This item is displayed, but cannot be monitored.
LANE W/L
[On/Off] Status of lane departure warning lamp judged from lane departure warning lamp
signal received from ADAS control unit with CAN communication line.
LDP IND
[On/Off] Status of LDP ON indicator lamp judged from LDP ON indicator lamp signal re-
ceived from ADAS control unit with CAN communication line.
AT P W / L
[On/Off] Status of ATP warning lamp judged from ATP warning lamp signal received from
4WD control unit with
CAN communication line.
DCA IND
[Off] This item is displayed, but cannot be monitored.
CHECK SUS IND
[On/Off] Status of CK SUSP indicator lamp judged from CK SUSP indicator lamp signal re-
ceived from E-SUS control unit with CAN communication line.
Display item [Unit]
MAIN
SIGNALS Description
Revision: 2010 May2011 QX56

WCS-16
< SYSTEM DESCRIPTION >
DIAGNOSIS SYSTEM (COMBINATION METER)
LCD
[B&P N, B&P I, ID NG, ROTAT, SFT
P, INSRT, BATT, NO KY, OUTKY, LK
WN]Displays status of Intelligent Key system warning judged from meter display signal
received from BCM with CAN communication line.
ACC TARGET
[On/Off] Status of vehicle ahead detection indicator judged from meter display signal re-
ceived from ADAS control unit with CAN communication line.
ACC DISTANCE
[Off, Short, Middle, Long] Status of set distance indicator judged from meter display signal received from
ADAS control unit with
CAN communication line.
ACC OWN VHL
[On/Off] Status of own vehicle indicator judged from meter display signal received from
ADAS control unit with
CAN communication line.
ACC SET SPEED
[Off, km/h] Status of set vehicle speed indicator judged from meter display signal received
from ADAS control unit with CAN communication line.
ACC UNIT
[On/Off] Status of display unit judged from meter display signal received from ADAS con-
trol unit with CAN communication line.
SHIFT IND
[P, R, N, D, M1, M2, M3, M4, M5, M6,
M7] Status of shift position indicator judged from shift position signal and manual mode
indicator signal received from TCM with CAN communication line.
4WD IND
[AUTO, LOCK, 2W, 4Lo, HL1, HL2,
MALF] Status of 4WD indicator judged from 4WD indicator signal received from 4WD
control unit with CAN communication line.
BSW IND
[Off] This item is displayed, but cannot be monitored.
BSW W/L
[On/Off] Status of BSW warning lamp (orange) judged from BSW warning lamp signal re-
ceived from ADAS control unit with CAN communication line.
AT S MODE SW
[On/Off] Status of snow mode switch.
M RANGE SW
[On/Off] Status of manual mode switch.
NM RANGE SW
[On/Off] Status of non-manual mode switch.
AT SFT UP SW
[On/Off] Status of manual mode shift up switch.
AT SFT DWN SW
[On/Off] Status of manual mode shift down switch.
PKB SW
[On/Off] Status of parking brake switch.
BUCKLE SW
[On/Off] Status of seat belt buckle switch (driver side).
BRAKE OIL SW
[On/Off] Status of brake fluid level switch.
A/C AMP CONN
[Off] This item is displayed, but cannot be monitored.
ENTER SW
[On/Off] Status of (ENTER) switch.
SELECT SW
[On/Off] Status of (SELECT) switch.
DISTANCE
[km] Value of distance to empty calculated by combination meter.
OUTSIDE TEMP
[ ° C or °F] Ambient temperature value converted from ambient sensor signal received from
ambient sensor.
NOTE:
This may not match with the temperature value indicated on the information dis-
play. (Because the information display value is a corrected value from the ambient
sensor input value.)
Display item [Unit]
MAIN
SIGNALS Description
Revision: 2010 May2011 QX56
