sensor INFINITI QX56 2011 Factory Service Manual

SYSTEMHAC-29
< SYSTEM DESCRIPTION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
 Sensitivity of exhaust gas / out side odor detecting sensor can be changed by “GAS SENSOR ADJUST-
MENT” in “WORK SUPPORT” mode of CONSULT-III. Refer to HAC-70, "
ACCS (ADVANCED CLIMATE
CONTROL SYSTEM) : Exhaust Gas / Outside Odor Detecting Sensor Sensitivity Adjustment Function".
 Automatic intake control (exhaust gas / outside odor detecting mechanism) does not operate when ambient
temperature is −2 °C (28 °F) or less. In this case, control is only for control of automatic air inlet of automatic
air conditioning system.
ACCS (ADVANCED CLIMATE CONTROL SYSTEM) : Plasmacluster Control
INFOID:0000000006275878
DESCRIPTION
Plasmacluster™ control eliminates microbes and reduces odor on interior surface by including high density
Plasmacluster
™ ion in air conditioning outlet air flow.
OPERATION DESCRIPTION
 Plasmacluster™ control operates by interlocking to blower motor. Plasmacluster™ control operates when
blower motor operates.
 Control status is displayed on front air conditioning system display screen. Refer to HAC-37, "
ACCS
(ADVANCED CLIMATE CONTROL SYSTEM) : Switch Name and Function".
NOTE:
 Plasmacluster
™ ion technology developed by Sharp Corporation is installed in this item.
 Plasmacluster
™ is a trademark of Sharp Corporation.
Revision: 2010 May2011 QX56

DIAGNOSIS SYSTEM (HVAC)HAC-39
< SYSTEM DESCRIPTION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
DIAGNOSIS SYSTEM (HVAC)
DescriptionINFOID:0000000006275884
Air conditioning system performs self-diagnosis, operat ion check, function diagnosis, and various settings
using diagnosis function of each control unit.
CONSULT-III FunctionINFOID:0000000006275885
CONSULT-III performs the following functions via CAN communication with A/C auto amp.
NOTE:
Diagnosis should be performed with engine running. D oor motor operation speeds become slower and NO
results may be returned even for normal operation if battery voltage drops below 12 V during self-diagnosis.
SELF-DIAGNOSIS RESULTS
Refer to HAC-45, "DTC Index".
DATA MONITOR
Display item list
ECU Diagnostic item
(CONSULT-III)
A/C auto amp. HVACSelf Diagnostic Result
Data Monitor
Active Test
Work support
AV c o n t r o l u n i t MULTI AV
Self Diagnostic Result
Multi AV system on board diagnosis function
ECM ENGINESelf Diagnostic Result
Data Monitor
IPDM E/R IPDM E/RSelf Diagnostic Result
Data Monitor
Auto active test
Diagnostic mode Description
Self diagnostic result Displays the diagnosis results judged by A/C auto amp.
Data monitor Displays the input/output signal of A/C auto amp.
Active test The signals used to activate each device are forcibly supplied from A/C auto amp.
Work support Changes the setting for each setting function.
ECU identification Displays the part number of A/C auto amp.
Monitor item [Unit] Description
AMB TEMP SEN [ °C ( °F)] Ambient sensor value converted from ambient sensor signal received from ambient sen-
sor
IN-VEH TEMP [ °C ( °F)] Front in-vehicle sensor value converted from front in-vehicle sensor signal received from
front in-vehicle sensor
INT TEMP SEN [ °C ( °F)] Intake sensor value converted from intake sensor signal received from intake sensor
SUNLOAD SEN [w/m
2]Sunload sensor value converted from sunload sensor signal (driver side) received from
sunload sensor
AMB SEN CAL [ °C ( °F)] Ambient temperature value calculated by A/C auto amp.
IN-VEH CAL [ °C ( °F)] In-vehicle temperature (front side) value calculated by A/C auto amp.
INT TEMP CAL [ °C ( °F)] Front evaporator fin temperature value calculated by A/C auto amp.
SUNL SEN CAL [w/m
2]Sunload value (driver side) calculated by A/C auto amp.
Revision: 2010 May2011 QX56

HAC-40
< SYSTEM DESCRIPTION >[AUTOMATIC AIR CONDITIONING]
DIAGNOSIS SYSTEM (HVAC)
ACTIVE TEST
Check each output device
COMP REQ SIG [On/Off] Displays A/C switch ON/OFF status transmitted to other units via CAN communication
FAN REQ SIG [On/Off]Displays front blower motor ON/OFF status transmitted to other units via CAN commu-
nication
FAN DUTY Duty ratio of front blower motor judged by A/C auto amp.
XM Target discharge front air temperature (driver side) judged by A/C auto amp. depending
on the temperature setting and the value from each sensor
PASS SUNL CAL [w/m
2]Sunload value (passenger side) calculated by A/C auto amp.
PASS SUNLOAD SEN [w/m
2]Sunload sensor value converted from sunload sensor signal (passenger side) received
from sunload sensor
PA TARGET A/TEMP Target discharge front air temperature (passenger side) judged by A/C auto amp. de-
pending on the temperature setting and the value from each sensor
RRIN TEMP SEN [ °C ( °F)] Rear in-vehicle sensor value converted from rear in-vehicle sensor signal received from
rear in-vehicle sensor.
RRIN TEMP CAL [ °C ( °F)] In-vehicle temperature (rear side) value calculated by A/C auto amp.
RR INT TMP CL [ °C ( °F)] Rear evaporator fin temperature value calculated by A/C auto amp.
RRFAN REQ SIG [On/Off] Displays rear blower motor ON/OFF status transmitted to other units via CAN communi-
cation
RR FAN DUTY Duty ratio of rear blower motor judged by A/C auto amp.
RR XM Target discharge rear air temperature (driver side) judged by A/C auto amp. depending
on the temperature setting and the value from each sensor
ENG COOL TEMP [ °C ( °F)] Engine coolant temperature signal value received from ECM via CAN communication
VEHICLE SPEED [km/h
(mph)] Vehicle speed signal value received from combination meter via CAN communication
Monitor item [Unit] Description
Te s t i t e m D e s c r i p t i o n
HVAC TEST The operation check of air conditioning system can be performed by selecting the mode.
Refer to the following table for the conditions of each mode.
Te s t i t e m
MODE 1 MODE 2 MODE 3 MODE 4 MODE 5 MODE 6 MODE 7
Front mode door motor posi-
tion VENT VENT B/L B/L FOOT D/F DEF
Intake door motor position REC REC 20% FRE 20% FRE FRE FRE FRE
Front air mix door motor (driver
side) position FULL COLD FULL COLD FULL COLD FULL HOT FULL HOT FULL HOT FULL HOT
Front air mix door motor (pas-
senger side) position FULL COLD FULL COLD FULL COLD FULL HOT FULL HOT FULL HOT FULL HOT
Front blower motor control sig-
nal duty ratio 35% 35% 59% 59% 89% 89% 35%
Magnet clutch ON ON ON ON OFF OFF ON
Upper ventilator door motor
position OPEN CLOSE OPEN CLOSE CLOSE CLOSE CLOSE
Rear mode door motor posi-
tion VENT VENT B/L B/L FOOT FOOT FOOT
Rear air mix door motor posi-
tion FULL COLD FULL COLD FULL COLD FULL HOT FULL HOT FULL HOT FULL HOT
Rear blower motor control sig-
nal duty ratio 35% 35% 59% 59% 89% 89% 35%
Revision: 2010 May2011 QX56

DIAGNOSIS SYSTEM (HVAC)HAC-41
< SYSTEM DESCRIPTION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
*: With ACCS (advanced climate control system)
NOTE:
Perform the inspection of each output device after starting the engine because the compressor is operated.
WORK SUPPORT
*: With ACCS (advanced climate control system)
NOTE:
When the battery cable is disconnected from the negative terminal or when the battery voltage becomes 10 V
or less, the setting of WORK SUPPORT may be cancelled.
Rear A/C relay ON ON ON ON OFF OFF ON
Ionizer
*ON ON ON ON ON ON OFF
Front display (Ion mode)
*CLEAN CLEAN QUICK
CLEAN QUICK
CLEAN QUICK
CLEAN QUICK
CLEAN OFF
Te s t i t e m
MODE 1 MODE 2 MODE 3 MODE 4 MODE 5 MODE 6 MODE 7
Work item Description Refer to
TEMP SET CORRECT Setting change of temperature setting trimmer (front) can be per-
formed. HAC-68, "
FRONT AUTO-
MATIC AIR CONDITION-
ING SYSTEM :
Temperature Setting Trim-
mer (Front)"
BLOWER SET Setting change of foot position setting trimmer can be performed.
HAC-68, "
FRONT AUTO-
MATIC AIR CONDITION-
ING SYSTEM : Foot
Position Setting Trimmer"
REC MEMORY SET
Setting change of inlet port memory function (REC) can be per-
formed. HAC-69, "
FRONT AUTO-
MATIC AIR CONDITION-
ING SYSTEM : Inlet Port
Memory Function (REC)"
FRE MEMORY SET
Setting change of inlet port memory function (FRE) can be per-
formed. HAC-69, "
FRONT AUTO-
MATIC AIR CONDITION-
ING SYSTEM : Inlet Port
Memory Function (FRE)"
GAS SENSOR ADJUSTMENT*Setting change of exhaust gas / outside odor detecting sensor sensi-
tivity adjustment function can be performed. HAC-70, "
ACCS (AD-
VANCED CLIMATE CON-
TROL SYSTEM) :
Exhaust Gas / Outside
Odor Detecting Sensor
Sensitivity Adjustment
Function"
CLEAN SW SET*Setting change of auto intake switch interlocking movement change
function can be performed.
HAC-70, "
ACCS (AD-
VANCED CLIMATE CON-
TROL SYSTEM) : Auto
Intake Switch Interlocking
Movement Change Func-
tion"
REAR TEMP SET CORRECT
Setting change of temperature setting trimmer (rear) can be per-
formed. HAC-68, "
FRONT AUTO-
MATIC AIR CONDITION-
ING SYSTEM :
Temperature Setting Trim-
mer (Front)"
Revision: 2010 May2011 QX56

A/C AUTO AMP.HAC-43
< ECU DIAGNOSIS INFORMATION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
TERMINAL LAYOUT
PHYSICAL VALUES
RR XM Ignition switch ON — Value according to target air
flow temperature (rear side)
ENG COOL TEMP Ignition switch ON — Equivalent to engine coolant
temperature
VEHICLE SPEED Driving — Equivalent to speedometer
reading
Monitor item Condition Value/Status
JMIIA0787ZZ
Te r m i n a l N o .
(Wire color) Description
ConditionVa l u e
(Approx.)
+ − Signal name Input/
Output
1
(L) —CAN-H Input/
Output ——
2
(B) —Ground — — —
3
(Y/G) Ground Battery power supply Input Ignition switch OFF Battery voltage
4
(V) Ground ACC power supply Input Ignition switch ACC Battery voltage
5
*1
(W) Ground
Ionizer (ON/OFF) control
signal
OutputIgnition
switch
ON Front blower
motor: ON
0 V
Front blower
motor: OFF 12 V
6
(V/W) GroundA/C auto amp. connection
recognition signal Output Ignition switch ON 12 V
7
(W/R) Ground Ambient sensor signal Input Ignition switch ON 0 – 4.8 V
Output voltage varies with ambient temperature
8
(GR/L) Ground
Rear in-vehicle sensor sig-
nal Input Ignition switch ON 0 – 4.8 V
Output voltage varies with in-vehi-
cle temperature (rear side)
9
(BR) GroundSunload sensor (driver side)
signal
Input Ignition switch ON 0 – 4.8 V
Output voltage varies with sunload (driver side) amount
10
*1
(V/W) Ground
Exhaust gas / outside odor
detecting sensor signal InputIgnition switch ON
NOTE:
The signal is depending
on measurement environ-
ment of the vehicle
ZJIA1163J
Revision: 2010 May2011 QX56

HAC-44
< ECU DIAGNOSIS INFORMATION >[AUTOMATIC AIR CONDITIONING]
A/C AUTO AMP.
11
(W) GroundCommunication signal
(A/C auto amp.
→Rear A/C
control) Output Ignition switch ON
14
(O/L) GroundFront blower motor control
signal
Output Ignition switch ON
 Front fan speed: 1st
speed (manual)
16
(R/G) Ground Each door motor LIN signal Input/
Output Ignition switch ON
17
(L/Y) GroundEach door motor power sup-
ply
Output Ignition switch ON 12 V
21
(P) —CAN-L
Input/
Output ——
22
(B) —Ground — — —
23
(GR/L) Ground Ignition power supply Input Ignition switch ON Battery voltage
25
*1, *
(R) ———— —
26
(B) — Sensor ground — — —
27
(GR) GroundFront in-vehicle sensor sig-
nal
Input Ignition switch ON 0 – 4.8 V
Output voltage varies with in-vehi- cle temperature (front side)
28
(R) Ground Intake sensor signal Input Ignition switch ON 0 – 4.8 V
Output voltage varies with front evaporator fin temperature
29
(O) Ground
Sunload sensor (passenger
side) signal Input Ignition switch ON 0 – 4.8 V
Output voltage varies with sunload
(passenger side) amount
31
(O/L) GroundCommunication signal
(Rear A/C control
→A/C auto
amp.) Input Ignition switch ON
Te r m i n a l N o .
(Wire color) Description
ConditionVa l u e
(Approx.)
+ − Signal name Input/
Output
SJIA1521J
JSIIA0096ZZ
SJIA1453J
SJIA1522J
Revision: 2010 May2011 QX56

A/C AUTO AMP.HAC-45
< ECU DIAGNOSIS INFORMATION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
*1: With ACCS (advanced climate control system)
*2: A/C auto amp. is not used for control.
Fail-safeINFOID:0000000006275887
FAIL-SAFE FUNCTION
If a communication error exists between the A/C auto am p., and the AV control unit and preset switch for 30
seconds or longer, air conditioning is controlled under the following conditions:
When ambient temperature is less than 3 °C (37 °F) and engine coolant temperature is less than 56 °C (133 °F)
When ambient temperature is 3 °C (37 °F) or more, or engine coolant temperature is 56 °C (133 °F) or more
DTC IndexINFOID:0000000006275888
34
(L/O) GroundRear blower motor control
signal Output Ignition switch ON
 Rear fan speed: 1st
speed (manual)
37
(B) —Ground — — —
38
(G/W) Ground Rear A/C relay control signal Output Ignition
switch
ONRear blower
motor: ON
0 V
Rear blower
motor: OFF 12 V
Te r m i n a l N o .
(Wire color) Description
ConditionVa l u e
(Approx.)
+ − Signal name Input/
Output
JSIIA0096ZZ
Compressor : ON
Air outlet : DEF
Air inlet : FRE (Fresh air intake)
Blower fan speed : AUTO
Set temperature : Setting before communication error occurs
Compressor : ON
Air outlet : AUTO
Air inlet : 20% FRE (20% fresh air intake)
Blower fan speed : AUTO
Set temperature : Setting before communication error occurs
DTC Items
(CONSULT-III screen terms) Reference
U1000 CAN COMM CIRCUIT HAC-72, "
DTC Logic"
U1010 CONTROL UNIT (CAN)HAC-73, "DTC Logic"
B2578 IN-VEHICLE SENSORHAC-74, "DTC Logic"
B2579 IN-VEHICLE SENSORHAC-74, "DTC Logic"
B257B AMBIENT SENOR HAC-77, "DTC Logic"
B257C AMBIENT SENOR HAC-77, "DTC Logic"
B2581 INTAKE SENSORHAC-80, "DTC Logic"
B2582 INTAKE SENSORHAC-80, "DTC Logic"
Revision: 2010 May2011 QX56

HAC-46
< ECU DIAGNOSIS INFORMATION >[AUTOMATIC AIR CONDITIONING]
A/C AUTO AMP.
*1: With ACCS (advanced climate control system)
*2: Perform self-diagnosis under sunshine. When performi
ng indoors, aim a light (more than 60 W) at sunload
sensor, otherwise self-diagnosis indicates even though the sunload sensor is functioning normally.
NOTE:
If all of door motor DTCs (B2632, B2633, B2634, B2635, B2636, B2637, B2638, B2639, B263D, B263E,
B263F, B2654, B2655, B2661, B2662, B2663, B2664, B 2665, B2666, B2669, and B266A) are detected, check
door motor communication circuit. Refer to HAC-120, "
Diagnosis Procedure".
B262A*1GAS SENSOR HAC-83, "DTC Logic"
B262B*1GAS SENSORHAC-83, "DTC Logic"
B2630*2SUNLOAD SENSORHAC-86, "DTC Logic"
B2631*2SUNLOAD SENSORHAC-86, "DTC Logic"
B2632 DR AIRMIX DOOR MOT HAC-89, "DTC Logic"
B2633 DR AIRMIX DOOR MOTHAC-89, "DTC Logic"
B2634 PASS AIR MIX DOOR MOTHAC-91, "DTC Logic"
B2635 PASS AIR MIX DOOR MOTHAC-91, "DTC Logic"
B2636 DR VENT DOOR FAILHAC-93, "DTC Logic"
B2637 DR B/L DOOR FAILHAC-93, "DTC Logic"
B2638 DR D/F1 DOOR FAILHAC-93, "DTC Logic"
B2639 DR DEF DOOR FAILHAC-93, "DTC Logic"
B263D FRE DOOR FAIL HAC-95, "DTC Logic"
B263E 20P FRE DOOR FAILHAC-95, "DTC Logic"
B263F REC DOOR FAILHAC-95, "DTC Logic"
B2654 D/F2 DOOR FAILHAC-93, "DTC Logic"
B2655 B/L2 DOOR FAILHAC-93, "DTC Logic"
B2657*1GAS SENSOR CIRCUITHAC-83, "DTC Logic"
B2658*1GAS SENSOR CIRCUITHAC-83, "DTC Logic"
B2661 UPPER VENT DOOR MOT HAC-97, "DTC Logic"
B2662 UPPER VENT DOOR MOTHAC-97, "DTC Logic"
B2663 UPPER VENT DOOR MOTHAC-97, "DTC Logic"
B2664 REAR AIR MIX DOOR MOTHAC-99, "DTC Logic"
B2665 REAR AIR MIX DOOR MOTHAC-99, "DTC Logic"
B2666 REAR MODE DOOR MOTHAC-101, "DTC Logic"
B2667*2PASS SUNLOAD SENSORHAC-103, "DTC Logic"
B2668*2PASS SUNLOAD SENSORHAC-103, "DTC Logic"
B2669 REAR MODE DOOR MOT HAC-101, "DTC Logic"
B266A REAR MODE DOOR MOT HAC-101, "DTC Logic"
B266B REAR IN-VEHICLE SENHAC-106, "DTC Logic"
B266C REAR IN-VEHICLE SEN HAC-106, "DTC Logic"
B27B0 A/C AUTO AMP.HAC-109, "DTC Logic"
DTCItems
(CONSULT-III screen terms) Reference
Revision: 2010 May2011 QX56

OPERATION INSPECTIONHAC-67
< BASIC INSPECTION > [AUTOMATIC AIR CONDITIONING]
C
D
E
F
G H
J
K L
M A
B
HAC
N
O P
Operate fan switch. Visually check that status indica tor in front display changes in accordance with the follow-
ing table.
NOTE:
 Plasmacluster
™ ion technology developed by Sharp Corporation is installed in this item.
 Plasmacluster
™ is a trademark of Sharp Corporation.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 4.
3.CHECK AUTOMATIC INTAKE CONTROL (EXHAUST GAS / OUTSIDE ODOR DETECTING MECHANISM)
1. Operate fan switch to set the fan speed to maximum speed.
2. Press auto intake switch to set the air inlet to recirculation. The auto intake switch indicator and intake switch indicator turn ON.
3. Listen to intake sound and confirm air inlets change.
4. Wait approximately for 5 minutes until ai r inlet switches to fresh air intake.
5. Apply cigarette smoke or similar substance to exhaust gas / outside odor detecting sensor portion.
6. Listen to intake sound and confirm air inlets change to recirculation.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 4.
4.CHECK SELF-DIAGNOSIS WITH CONSULT-III
1. Perform self-diagnosis with CONSULT-III.
2. Check that any DTC is detected.
Is any DTC detected?
YES >> Refer to HAC-45, "DTC Index" and perform the appropriate diagnosis.
NO >> Refer to HAC-135, "
Diagnosis Chart By Symptom" and perform the appropriate diagnosis.
Fan speed Front display (ion indicator)
2nd CLEAN
5th QUICK CLEAN
Revision: 2010 May2011 QX56

HAC-70
< BASIC INSPECTION >[AUTOMATIC AIR CONDITIONING]
SYSTEM SETTING
If the temperature felt by the customer is different from
the rear air flow temperature controlled by the temper-
ature setting, the A/C auto amp. control temperature can be adjusted to compensate for the temperature set-
ting.
HOW TO SET
With CONSULT-III
Perform “REAR TEMP SET CORRECT” of HVAC work support item.
NOTE:
 When −3.0 °C ( −6 °F) is corrected on the temperature setting set as 25.0 °C (77 °F) the temperature controlled
by A/C auto amp. is 25.0 °C (77 °F) −3.0 °C ( −6 °F) = 22.0 °C (72 °F) and the temperature becomes lower than
the temperature setting.
 When the battery cable is disconnected from the negativ e terminal or when the battery voltage becomes 10
V or less, the setting of the difference between t he set temperature and control temperature may be can-
celled.
ACCS (ADVANCED CLIM ATE CONTROL SYSTEM)
ACCS (ADVANCED CLIMATE CONTROL SYSTE M) : Exhaust Gas / Outside Odor
Detecting Sensor Sensitiv ity Adjustment Function
INFOID:0000000006275901
DESCRIPTION
According to customer’s sense of smell, exhaust gas / outside odor detecting sensor sensitivity can be
changed.
HOW TO SET
With CONSULT-III
Perform the “GAS SENSOR ADJUSTME NT” of HVAC work support item.
NOTE:
When the battery cable is disconnected from the negativ e terminal or when the battery voltage becomes 10 V
or less, the setting of WORK SUPPORT may be cancelled.
ACCS (ADVANCED CLIMATE CONTROL SYSTEM) : Auto Intake Switch Interlocking
Work support items Display ( °C) Display ( °F)
REAR TEMP SET CORRECT 3.0 6
2.5 5
2.0 4
1.5 3
1.0 2
0.5 1
0 (initial status) 0 (initial status) −0.5 −1
− 1.0 −2
− 1.5 −3
− 2.0 −4
− 2.5 −5
− 3.0 −6
Work support items Display Setting
GAS SENSOR ADJUSTMENT 2 Less sensitive setting than display 1 (REC later than display 1.)
1 Less sensitive setting than normal setting (REC later than normal operation.)
0 (initial status) Normal −1 More sensitive setting than normal setting (REC earlier than normal operation.)
− 2 More sensitive setting than display −1 (REC earlier than display −1.)
Revision: 2010 May2011 QX56
