ISUZU TF SERIES 2004 Workshop Manual

WHEELS AND TIRES 3E-9


Important Operations
1. Tire Assembly
Align the match mark (approx. 10mm diameter paint mark) of
wheel with match mark (approx. 8mm diameter red paint mark)
of tire to assemble. If the match mark at wheel has
disappeared, align with air valve to assemble.


2. Wheel and Tire Assembly







3. Wheel Nut
Tighten wheel nuts in numerical order.
Wheel Nut Torque kgf
m (lb
ft/N
m)
12.0  1.0 (86.8  7.2 / 117.7  9.8)

3E-10 WHEELS AND TIRES

TROUBLESHOOTING
Typical examples of abnormal tire tread wear and major causes :

CAUTION:
Similar wear patterns can be caused by worn suspension parts, misalignment of wheels and tires, and
other suspension related problems.


Spotty wear - wear localized
on shoulder section. In
extreme cases, the tire
becomes polygonal in shape.
Tire or wheel out of
round or distorted.Hub or knuckle out
of round or distorted.Play in hub bearings
or ball joints.Rotating parts out of
balance.
Tread wear one-sided.
Rotating parts out of
balance.Tire or wheel out of
round.Hub or knuckle out
of round or distorted.
Localized tread wear.
Once spotty wear develops in
tread due to hard braking or
abrupt starting, localized wear
tends to be accelerated.

WHEELS AND TIRES 3E-11

Shoulder wear (generally
wear develops on outer
shoulder).
Camber or toe-in
incorrect.Shoulder wear
caused by repeated
hard-cornering.
Wear on shoulders at points
opposed to each other.
Tire or wheel out of
round or distorted.Play in bearings or
ball joint.
Premature wear on
shoulders.
Flexing of tire excessive due
to under-inflation.
One-sided feather edging.
Wear caused by
repeated hard-
cornering.Camber or toe-in
incorrect.

3E-12 WHEELS AND TIRES
MEMO

No. TFSTG-WE-0431

WORKSHOP MANUAL
TF SERIES
TRANSFER

SECTION 7D

TRANSFER CASE 7D-1

SECTION 7D
TRANSFER CASE
TABLE OF CONTENTS
PAGE
Service Precaution .......................................................................................................... 7D – 2
General Description ........................................................................................................ 7D – 3
Transfer Rear Oil Seal .................................................................................................... 7D – 4
Transfer Rear Oil Seal and Associated Parts ............................................................ 7D – 4
Removal ........................................................................................................................ 7D – 4
Installation .................................................................................................................... 7D – 4
Transfer Case Assembly ................................................................................................ 7D – 6
Transfer Case Assembly and Associated Parts ........................................................ 7D – 6
Removal ........................................................................................................................ 7D – 7
Installation .................................................................................................................... 7D – 7
Transfer Control Unit ...................................................................................................... 7D – 10
Removal ........................................................................................................................ 7D – 10
Installation .................................................................................................................... 7D – 10
Transfer Disassembly ..................................................................................................... 7D – 11
Removal ........................................................................................................................ 7D – 11
Inspection and Repair .................................................................................................. 7D – 20
Inspection and Repair (Transfer Case Assembly) ..................................................... 7D – 20
Reassembly .................................................................................................................. 7D – 24
Main Data and Specifications ........................................................................................ 7D – 33
Special Tools ................................................................................................................ 7D – 36

7D-2 TRANSFER CASE

Service Precaution
WARNING: THIS VEHICLE HAS A SUPPLEMENTAL
RESTRAINT SYSTEM (SRS). REFER TO THE SRS
COMPONENT AND WIRING LOCATION VIEW IN
ORDER TO DETERMINE WHETHER YOU ARE
PERFORMING SERVICE ON OR NEAR THE SRS
COMPONENTS OR THE SRS WIRING. WHEN YOU
ARE PERFORMING SERVICE ON OR NEAR THE
SRS COMPONENTS OR THE SRS WIRING, REFER
TO THE SRS SERVICE INFORMATION. FAILURE TO
FOLLOW WARNINGS COULD RESULT IN
POSSIBLE AIR BAG DEPLOYMENT, PERSONAL
INJURY, OR OTHERWISE UNNEEDED SRS SYSTEM
REPAIRS.
CAUTION: Always use the correct fastener in the
proper location. When you replace a fastener, use
ONLY the exact part number for that application.
ISUZU will call out those fasteners that require a
replacement after removal. ISUZU will also call out
the fasteners that require thread lockers or thread
sealant. UNLESS OTHERWISE SPECIFIED, do not
use supplemental coatings (Paints, greases, or
other corrosion inhibitors) on threaded fasteners or
fastener joint interfaces. Generally, such coatings
adversely affect the fastener torque and the joint
clamping force, and may damage the fastener.
When you install fasteners, use the correct
tightening sequence and specifications. Following
these instructions can help you avoid damage to
parts and systems.
