warning JAGUAR XFR 2010 1.G Owners Manual

Left-hand drive vehicles


11.
WARNING: Braking efficiency may be seriously
impaired if an incorrect bleed sequence is used.

Repeat the brake bleeding procedure for each brake
caliper, following the above sequence.










Right-hand drive vehicles




All vehicles

12.

WARNING: Braking efficiency may be seriously
impaired if an incorrect bleed sequence is used.

Repeat the brake bleeding procedure for each brake
caliper, following the above sequence.

13. Fill the brake fluid reservoir to the MAX mark.

14. Apply the brakes and check for leaks.

15. Install the brake fluid reservoir cap.

16. Install the brake master cylinder cover.
Carefully secure the clip.

Published: 17-Feb-2012
Brake System - General Information - Front Brake Disc Runout Check - With
Wheel On Vehicles With: High Performance Brakes
General Procedures

1. NOTES:


Some variation in the illustrations may occur, but the essential
information is always correct.


RH illustration shown, LH similar


All measurements must taken with the wheel installed.


2. WARNING: Make sure to support the vehicle with axle stands.

Raise the front of the vehicle.

3. Mount the DTI Dial Test Indicator (DTI) gauge to the bolt as shown with tool 100-053.

4. Make sure the DTI is securely mounted.

Published: 27-Feb-2012
Brake System - General Information - Rear Brake Disc Runout Check - With
Wheel On
General Procedures

1. NOTES:


Some variation in the illustrations may occur, but the essential
information is always correct.


RH illustration shown, LH similar.


All measurements must be taken with the wheel installed.


2. WARNING: Make sure to support the vehicle with axle stands.

Raise the rear of the vehicle.

3. Modify tool 100-053 with an M8 bolt and nut as shown.
4. Mount the DTI Dial Test Indicator (DTI) gauge on the tool as shown. www.JagDocs.com

BRAKE CALIPERS System Operation

When hydraulic pressure is supplied to the caliper, the pistons extend to force the inner pad against the brake disc. The caliper
reacts and slides along two guide pins to bring the outer pad into contact with the brake disc.

BRAKE PAD WEAR SENSORS

When a brake pad incorporating a brake pad wear sensor is approximately 75% worn, the sensor wire within the pad material
is worn through and the brake pad wear sensor goes open circuit. When the instrument cluster detects the open circuit, it
illuminates the amber LED (light emitting diode) in the brake warning indicator, displays an appropriate warning in the
message center and sounds a warning chime.
Refer to: Instrument Cluster (413-01 Instrument Cluster, Description and Operation).

NOTE: A new pad wear sensor lead must be fitted whenever the brake pads are changed, irrespective of the brake pad
warning sensor being triggered.



BRAKE CALIPERS Component Description

Each caliper is mounted within a fixed carrier that is secured to the front wheel knuckle with two bolts. The inboard brake pad
of the LH (left-hand) brake incorporates a wear sensor.

Each outboard brake pad is installed with a pressed steel anti-rattle spring. On SC (supercharger) vehicles, a badge with the
'R' symbol is formed on the anti-rattle spring.

BRAKE PAD WEAR SENSORS

The brake pad wear sensor is wired in series with a wear sensor on the RH (right-hand) rear brake and the instrument cluster.
If the thickness of one of the brake pads connected to a wear sensor decreases to a predetermined limit, the instrument
cluster illuminates the brake warning indicator.

Published: 02-May-2013
Front Disc Brake - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol - Brake Caliper Vehicles With: High Performance Brakes
Removal and Installation

Removal


CAUTION: Brake fluid will damage paint finished surfaces. If spilled, immediately remove the fluid and clean the area
with water.


NOTE: Removal steps in this procedure may contain installation details.


1. WARNING: Do not work on or under a vehicle supported only by a jack.
Always support the vehicle on safety stands.
Raise and support the vehicle.

2. Remove the left-hand front wheel and tire.

Refer to: Wheel and Tire (204-04 Wheels and Tires, Removal and Installation).

3. www.JagDocs.com

7. CAUTION: Removal of the clips is a delicate
procedure, damage will occur if any force is used.


NOTE: Left-hand shown, right-hand similar.

Lever the anti-rattle spring in the center of the
spring until either side is released.

















8. WARNING: If the brake caliper piston seal is damaged
a new brake caliper must be installed.


CAUTION: Do not allow the brake caliper to hang on
the brake hose.


NOTE: Left-hand shown, right-hand similar.
















9. NOTE: Left-hand shown, right-hand similar.
Release the clip.

Installation
10.
NOTE: Left-hand shown, right-hand similar.


1. WARNING: Do not use compressed air to clean brake components.
Dust from friction materials can be harmful if inhaled.


CAUTION: As the piston is pushed back into the caliper housing,
the brake fluid level in the reservoir will rise. Do not allow the reservoir
to overflow.
Press the piston into the caliper housing.

2.
Apply grease C2C-39930 to the areas indicated.

Published: 11-May-2011
Front Disc Brake - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol - Brake Disc Vehicles With: High Performance Brakes
Removal and Installation

Removal


CAUTION: Brake discs must be renewed in pairs.


NOTE: Removal steps in this procedure may contain installation details.


1. WARNING: Do not work on or under a vehicle supported only by a jack.
Always support the vehicle on safety stands.
Raise and support the vehicle.

2. Refer to: Brake Pads - Vehicles With: High Performance Brakes (206-03B Front Disc Brake - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol,
Removal and Installation).

3. Torque: 115 Nm 4.
Remove the 2 clips.
Clean the components mating faces.













Installation 5. Repeat the above procedure on the opposite side.

1. To install, reverse the removal procedure.

Published: 11-May-2011
Front Disc Brake - TDV6 3.0L Diesel /V8 5.0L Petrol/V8 S/C 5.0L Petrol - Brake Pads Vehicles With: High Performance Brakes
Removal and Installation

Removal


CAUTION: Brake fluid will damage paint finished surfaces. If spilled, immediately remove the fluid and clean the area
with water.


NOTE: Removal steps in this procedure may contain installation details.


1. WARNING: Do not work on or under a vehicle supported only by a jack.
Always support the vehicle on safety stands.
Raise and support the vehicle.

2. Refer to: Wheel and Tire (204-04 Wheels and Tires, Removal and Installation).

3.

7. WARNING: If the brake caliper piston seal is damaged
a new brake caliper must be installed.


CAUTION: Do not allow the brake caliper to hang on
the brake hose.


NOTE: Left-hand shown, right-hand similar.
















8. NOTE: Left-hand shown, right-hand similar.
Release the clip.














9. NOTE: Left-hand shown, right-hand similar.
