JAGUAR XFR 2010 1.G Workshop Manual

Exterior Lighting - Headlamp Assembly
Removal and Installation

Removal


NOTE: RH illustration shown, LH is similar.



1.
2. Published: 11-May-2011











NOTE: Turn the steering wheel to full LH lock.

4. Torque: 5 Nm

Exterior Lighting - Headlamp Leveling Front Sensor
Removal and Installation

Removal Published: 11-May-2011

1. WARNING: Do not work on or under a vehicle supported only by a
jack. Always support the vehicle on safety stands.

Raise and support the vehicle.

2. Remove the headlamp leveling sensor.
Disconnect the height sensor link.
Disconnect the electrical connector.
Remove the 2 bolts.












3. NOTE: Do not disassemble further if the component is removed for
access only.
Remove the height sensor link.


4. NOTE: Note the fitted position.

Remove the bracket.
Remove the 2 Allen bolts. www.JagDocs.com

Installation

1. NOTE: Align to the position noted on removal.
Install the bracket.
Tighten to 5 Nm.










2. Install the height sensor link.

3. Install the headlamp leveling sensor.
Tighten to 25 Nm.
Connect the electrical connector.
Connect the height sensor link.

Exterior Lighting - Headlamp Leveling Rear Sensor
Removal and Installation

Removal Published: 11-May-2011

1. WARNING: Do not work on or under a vehicle supported only by a
jack. Always support the vehicle on safety stands.

Raise and support the vehicle.

2. Remove the headlamp leveling sensor.
Disconnect the height sensor link.
Release and disconnect the electrical connector.
Remove the 2 bolts.














3. NOTES:


Do not disassemble further if the component is
removed for access only.


Note the fitted position.

Remove the bracket.
Remove the 2 Allen bolts.






Installation


1. NOTE: Align to the position noted on removal.

Install the bracket.
Tighten to 5 Nm.

2. Install the headlamp leveling sensor.
Tighten to 25 Nm
Connect the electrical connector.
Install the height sensor link.

Exterior Lighting - High Mounted Stoplamp
Removal and Installation

Removal


NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011

1. Refer to: Parcel Shelf (501-05 Interior Trim and Ornamentation, Removal and Installation).
2.
Installation

1. To install, reverse the removal procedure.

Exterior Lighting - Rear Fog Lamp
Removal and Installation

General Equipment Published: 11-May-2011

Removal


NOTE: Removal steps in this procedure may contain installation details.

1. Refer to: Luggage Compartment Lid Moulding (501-08 Exterior Trim and Ornamentation, Removal and Installation).




Installation

2. CAUTIONS:


Protect the surrounding paintwork to avoid damage.


Take extra care not to damage the edges of the
component.
General Equipment: Spatula
1. To install, reverse the removal procedure. Spatula
www.JagDocs.com
