JAGUAR XFR 2010 1.G Workshop Manual

Installation 6. CAUTIONS:


Protect the surrounding components.


Protect the surrounding paintwork to avoid damage.











7. WARNING: This step requires the aid of another
technician.

1. CAUTIONS:


Make sure that the mating faces are clean and free of
foreign material.


Correct preparation of body apertures “post painting”
to ensure satisfactory glass adhesion, must be carried out
in line with industry practise.

Prepare the window glass, window glass flange and
trimmed PU adhesive in accordance with the
instructions included with the PU adhesive kit.

2. CAUTION: Touching the adhesive surface will impair
rebonding.















3. WARNING: This step requires the aid of another
technician.

CAUTIONS:


Make sure that the component is correctly located on
the locating dowels.


Make sure that equal pressure is applied to the full
length of the component.

If the ambient temperature falls below 10 degrees
C, apply warm air (25 degrees C) continuously for 15
minutes.


4. CAUTION: Make sure that no excess sealant residue is
evident.

If water is used as a means for the leak check, then
allow sealant to dry before testing.
Spray water around the windshield glass, mark any
area that leaks. Dry the windshield glass and
sealant before applying additional sealant.










5.

Installation).

7. Refer to: A-Pillar Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).

8. Refer to: Cowl Vent Screen (501-02 Front End Body Panels, Removal and Installation).

Glass, Frames and Mechanisms - Door Window Regulator Motor
Removal and Installation

Removal Published: 11-May-2011

1. Refer to: Front Door Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).


2. NOTE: Right-hand shown, left-hand similar.
















3. NOTE: Components removed for clarity. www.JagDocs.com

4. NOTES:


Make sure the door window glass is in the fully closed
position.


Components removed for clarity.

Apply suitable adhesive tape to the door window
glass and over the door frame, to prevent the door
window glass from damage.

























5. CAUTION: Make sure the drum remains in position.
Use a suitable flat blade screwdriver to secure the drum
while seperating the motor.

2. CAUTIONS:


Install all the bolts finger tight before final tightening.


Care must be taken not to damage the outer door
panel.

Install the retaining bolt 1 to the witness mark on
the body.
Torque:
1 1.9 Nm 2 5 Nm






















3. NOTE: Components removed for clarity.
4. NOTE: Right-hand shown, left-hand similar.
Torque: 1.5 Nm









5. Refer to: Front Door Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).

Instrument panel retaining bolts 20 15 - Floor console retaining nuts 5 - 44 Instrument panel support brackets retaining bolts 9 - 80 Instrument panel support brackets retaining nuts 9 - 80

Published: 11-May-2011
Instrument Panel and Console - Instrument Panel - Component Location
Description and Operation
COMPONENT LOCATION










































Item Description 1 Cross car beam 2 Glovebox switch 3 Energy absorbing brackets (2 off) www.JagDocs.com

Safety Belt System (501-20A Safety Belt System, Description and Operation), Air Bag and Safety Belt Pretensioner Supplemental Restraint System (SRS) (501-20B Supplemental Restraint System, Description and Operation),
Pedestrian Protection System (501-20C Pedestrian Protection System, Description and Operation).
