JAGUAR XFR 2010 1.G Manual Online
Page 1907 of 3039
Installation
1. CAUTION: Make sure that the battery negative cable
to the body retaining bolt is not loose and fully tightened.
Torque: 9 Nm
2. NOTE: Make sure that both the positive and negative battery
terminals are correctly located.
To install, reverse the removal procedure.
3. NOTE: This step is only necessary when installing a new
component.
Using the Jaguar approved diagnostic equipment, reset the battery
monitoring system.
4. Refer to: Door Window Motor Initialization (501-11 Glass, Frames and Mechanisms, General Procedures).
5. Enter the audio unit preset radio frequencies.
6. Reset the clock to the correct time.
7. Start the engine and allow to idle until the engine reaches normal
operating temperature.
8. Switch the engine off. www.JagDocs.com
Page 2447 of 3039
2. CAUTIONS:
Install all the bolts finger tight before final tightening.
Care must be taken not to damage the outer door
panel.
Install the retaining bolt 1 to the witness mark on
the body.
Torque:
1 1.9 Nm 2 5 Nm
3. NOTE: Components removed for clarity.
4. NOTE: Right-hand shown, left-hand similar.
Torque: 1.5 Nm
5. Refer to: Front Door Trim Panel (501-05 Interior Trim and Ornamentation, Removal and Installation).
Page 2466 of 3039
Instrument Panel and Console - Glove Compartment
Removal and Installation
Removal
NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011
1. Refer to: Passenger Side Register (412-01 Climate Control, Removal and Installation).
2.
3. CAUTION: Fixings must be started by hand to avoid
damaging threads.
Upper 3 bolts.
Torque: 2.5 Nm Lower 3 bolts.
Torque: 9 Nm
Page 2479 of 3039
Lower 3 bolts.
Torque: 9 Nm www.JagDocs.com
Page 2553 of 3039
Wipers and Washers - Windshield Wiper Motor
Removal and Installation
Removal
NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011
1. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).
2. Refer to: Cowl Vent Screen (501-02 Front End Body Panels, Removal and Installation).
3. CAUTION: Tighten the bolts in the sequence shown.
NOTE: LHD illustration shown, RHD is similar.
Torque: 12 Nm
4. NOTE: LHD illustration shown, RHD is similar.
5. NOTE: LHD illustration shown, RHD is similar.
Page 2582 of 3039
Bumpers - Front Bumper Cover
Removal and Installation
Removal
NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011
1. WARNING: Make sure to support the vehicle with axle stands.
Raise and support the vehicle.
2. Torque: 3 Nm 3. Torque:
Retaining screws 2 Nm Retaining bolts 7 Nm
Page 2600 of 3039
Safety Belt System - Front Safety Belt Buckle
Removal and Installation
Removal
NOTE: Removal steps in this procedure may contain installation details. Published: 11-May-2011
1. Refer to: Standard Workshop Practices (100-00 General Information, Description and Operation).
2. Refer to: Front Seat (501-10 Seating, Removal and Installation).
Installation
3. CAUTION: Discard the bolt.
Torque: 35 Nm
1. CAUTION: Make sure that a new bolt is installed. To
install, reverse the removal procedure.
Page 3022 of 3039
1. CAUTION: Only tighten the bolts finger-tight at this stage.
2. CAUTION: Tighten the bolts in the sequence shown.
Torque:
Bolt 1 63 Nm Bolt 2 63 Nm Bolt 1 63 Nm
3. Torque: 12 Nm www.JagDocs.com
Page 3025 of 3039
10. Remove the special tool.
Special Tool(s): 502-005
11.
Torque:
Stage 1: 100 Nm Stage 2: 270°
12. CAUTION:
Make sure each bolt aligns with the removal markings.
Torque: 175 Nm
Page 3026 of 3039
13. CAUTION:
Make sure each bolt aligns with the removal markings.
Torque: 175 Nm
14.
15.
NOTE: Repeat the step for the other side.
Torque: 175 Nm
Torque: 43 Nm
