15. WARNING: Install the M12 subframe bolts prior to
removing axle support.
























NOTE: LH illustration shown, RH is similar.

Torque: 133 Nm

Installation
16.























17.
CAUTION: Make sure that new bolts are installed.

General Equipment: Powertrain Jack Torque:
Stage 1:80 Nm Stage 2:240°
1. To install, reverse the removal procedure.

2. Refer to: Brake System Bleeding (206-00 Brake System - General Information, General Procedures).

3. Refer to: Camber and Caster Adjustment (204-00 Suspension System - General Information, General Procedures). www.JagDocs.com
