Torque bolt JAGUAR XFR 2010 1.G Repair Manual

3. NOTE: Tighten the bolts in the indicated sequence.
Torque: 13 Nm

3. NOTE: Tighten the bolts in the indicated sequence.

Torque: 13 Nm

3. NOTE: Tighten the bolts in the indicated sequence.

Torque:
M6 12 Nm M8 20 Nm











4. Torque: 12 Nm













5. Refer to: Brake Vacuum Pump - V8 5.0L Petrol/V8 S/C 5.0L Petrol (206-07 Power Brake Actuation, Removal and Installation).

6. Torque: 25 Nm

7. NOTE: Install the bolt finger tight before final
tightening.
Torque: 40 Nm












8. Torque: 40 Nm













9. Refer to: Crankshaft Pulley (303-01D Engine - V8 S/C 5.0L Petrol, Removal and Installation).

10. Refer to: Battery Disconnect and Connect (414-01 Battery, Mounting and Cables, General Procedures).


11. CAUTION: Make sure that the vehicle is left for 5 minutes from
filling with oil and that the engine oil level is reading at least minimum
(by following Steps 14-18), before starting the engine.

Fill the engine with oil - for filling values on vehicles without
supercharger:

Refer to: Specifications (303-01C Engine - V8 5.0L Petrol, Specifications).
Fill the engine with oil - for filling values on vehicles with
supercharger:

Refer to: Specifications (303-01D Engine - V8 S/C 5.0L Petrol, Specifications).
Clean any residual engine oil from the oil filler cap area.


12. CAUTION: Make sure that the vehicle has been left for 5 minutes
from filling with oil.
Follow the Steps 14-18 before starting the engine.

13.
Start the engine and allow to run for 10 minutes, stop the
engine.

Engine - V8 S/C 5.0L Petrol - Engine
Installation

NOTES:


Some variation in the illustrations may occur, but the essential information is always correct. Published: 19-Nov-2013

If a new engine is to be installed, remove the intake manifold to access the top transmission retaining bolts.


1. NOTE: This step requires the aid of another technician.
Install the engine assembly.





















2. Torque: 45 Nm

6. CAUTIONS:


Make sure that the area around the open fuel injector ports are clean
and free of foreign material and lubricant prior to installing the fuel injector.


When Installing the fuel injector(s), make sure that the Teflon seal is
clean and free of foreign material and lubricant.










7. CAUTIONS:


If new fuel injectors are installed, a new injector clamp must be
installed


Make sure that the fuel injector is aligned and installed into the fuel
rail correctly, as noted in the removal step.


Tighten the fuel rail retaining bolts a turn at a time until the correct
torque is achieved.


NOTE: Lubricate the fuel injector O-ring seals with clean engine oil.

Torque: 20 Nm







8. Special Tool(s): 310-200-01, 310-200-02 9. Torque: 20 Nm

10.
















11.
12.
13. NOTE: Tighten in the sequence indicated.

Torque:
Bolt 2 30 Nm Bolt 3 30 Nm Bolt 1 30 Nm Bolt 4 30 Nm











NOTE: RH shown LH similar.

Special Tool(s): 303-1450 Torque: 20 Nm




















Torque: 7 Nm

14.
15. NOTES:


Lubricate
the union
threads with
clean engine
oil.


Do not
tighten at
this stage.


Remove and
discard the
blanking
caps.





Torque:
union 21 Nm bolts 8 Nm














16.
Torque: 21 Nm











17.
Refer to: Air Cleaner Outlet Pipe RH (303-12C Intake Air Distribution and Filtering - V8 5.0L Petrol, Removal and Installation).

5. CAUTION: If a new cylinder head has been installed then the special tool
310-200-02 without the thread must be used to install the fuel rail.

Special Tool(s): 310-200-01, 310-200-02












6. CAUTIONS:


Make sure that the area around the open fuel injector ports are clean
and free of foreign material and lubricant prior to installing the fuel injector.


When Installing the fuel injector(s), make sure that the Teflon seal is
clean and free of foreign material and lubricant.









7. CAUTIONS:


If new fuel injectors are installed, a new injector clamp must be
installed


Make sure that the fuel injector is aligned and installed into the fuel
rail correctly, as noted in the removal step.


Tighten the fuel rail retaining bolts a turn at a time until the correct
torque is achieved.


NOTE: Lubricate the fuel injector O-ring seals with clean engine oil.

Torque: 20 Nm







8. NOTE: LH shown RH similar.
Special Tool(s): 310-200-01, 310-200-02

9.
















10.
11.
12. NOTE: LH shown RH similar.

Torque: 20 Nm













NOTES:


LH shown RH similar.


Tighten in the sequence indicated.

Torque:
Bolt 2 30 Nm Bolt 3 30 Nm Bolt 1 30 Nm Bolt 4 30 Nm























Special Tool(s): 303-1450 Torque: 20 Nm
