Torque bolt JAGUAR XFR 2010 1.G Repair Manual

13.
















14.
15. NOTE: LH shown RH similar.

Torque: 7 Nm















NOTE: LH shown RH similar.

















CAUTION: Lubricate only the union threads with clean engine oil.

NOTES:


Engine shown removed for clarity.


Install the bolt and unions finger tight before final tightening.


Remove and discard the blanking caps.
















16. Lower the vehicle. www.JagDocs.com

24.


















25.


















NOTES:


Lubricate the
union threads
with clean
engine oil.


Do not
tighten at
this stage.


Remove
and discard
the blanking
caps.





26. Torque:
Unions 21 Nm Bolts 8 Nm

5. CAUTION: Install new high-pressure fuel supply lines.
NOTES:
Engine shown removed for clarity.

Remove and discard the blanking caps.

Install the bolt and unions fully finger tight before final
tightening.























6. CAUTION: Care must be taken when positioning the fuel rail
high-pressure fuel pump cover to one side.

NOTE: Fuel rail high-pressure fuel pump cover shown removed for
clarity.
Torque: 12 Nm





7. Lower the vehicle.
8. NOTES:

Do not tighten at this stage.

Remove and discard the blanking caps.








9. WARNING: Do not work on or under a vehicle supported only by a jack. Always

12.
13.
14. NOTES:

Install the bolt and unions finger tight before final tightening.

Remove and discard the blanking caps.
Torque: Unions 21 Nm M6 11 Nm














Torque: 21 Nm


















NOTE: Engine shown removed for clarity.
Torque: M10 29 Nm M6 11 Nm

21. NOTES:

Lubricate
the
union
threads
with
clean
engine
oil.

Do
not tighten
at this
stage.

Remove
and
discard
the
blanking
caps.

22. Torque: Unions 21 Nm Bolts 8 Nm










23. Refer to: Air Cleaner Outlet Pipe RH (303-12D Intake Air Distribution and Filtering - V8 S/C 5.0L Petrol, Removal and Installation).
24. www.JagDocs.com

5. CAUTION: Install new high-pressure fuel supply lines.
NOTES:
Engine shown removed for clarity.

Remove and discard the blanking caps.

Install the bolt and unions fully finger tight before final
tightening.






















6. CAUTION: Care must be taken when positioning the fuel rail
high-pressure fuel pump cover to one side.

NOTE: Fuel rail high-pressure fuel pump cover shown removed for
clarity.
Torque: 12 Nm





7. Lower the vehicle.
8. NOTES:

Do not tighten at this stage.

Remove and discard the blanking caps.








9. WARNING: Do not work on or under a vehicle supported only by a jack. Always
support the vehicle on safety stands.

12.
13.
14. NOTES:

Install the bolt and unions finger tight before final tightening.

Remove and discard the blanking caps.
Torque: Unions 21 Nm M6 11 Nm














Torque: 21 Nm


















NOTE: Engine shown removed for clarity.
Torque: M10 29 Nm M6 11 Nm

21. NOTES:

Install and lightly tighten bolts in sequence illustrated.
Complete the tightening sequence.
Remove and discard the gasket.
Torque: 25 Nm www.JagDocs.com

Installation 13.

















14.


1. CAUTION: If a new cylinder head has been installed, then new
taptite bolts must be used to install the supercharger.


NOTE: New taptite bolts when used cut their own threads on the
first application.
To install, reverse the removal procedure.

2. Torque: 25 Nm

3. Torque: 25 Nm 4. Torque: 10 Nm 5.
6.
CAUTIONS:


If a new cylinder head has been installed then
the special tool 303-1449-02 without the thread
must be used to install the supercharger.


If a new cylinder head has been installed, then
new taptite bolts must be used to install the
supercharger.


NOTE: New taptite bolts when used cut their
own threads on the first application.
