GETTING TO KNOW YOUR INSTRUMENT PANEL
68
If filling the tank is done with a remaining
range of AdBlue® (UREA) in the tank equal
to zero, you may need to wait two minutes
before starting the vehicle.
Refer to “Refueling The Vehicle” in “Starting
And Operating” for further information.
Rear Fog Indicator — If Equipped
This indicator light will illuminate
when the rear fog lights are on.
Water In Fuel Indicator Light — If Equipped
The “Water In Fuel Indicator Light”
will illuminate when there is water
detected in the fuel filter. If this
light remains on, DO NOT start the vehicle
before you drain the water from the fuel filter
to prevent engine damage, and please see an
authorized dealer.Wait To Start Light — If Equipped
This indicator light will illuminate
for approximately two seconds when
the ignition is turned to the RUN
position. Its duration may be longer based on
colder operating conditions. Vehicle will not
initiate start until telltale is no longer
displayed.
Refer to “Starting The Engine” in “Starting
And Operating” for further information. NOTE:
The “Wait To Start” telltale may not illumi
-
nate if the intake manifold temperature is
warm enough.
Green Indicator Lights
Active Speed Limiter SET Indicator Light — If
Equipped With A Premium Instrument Cluster
This indicator light will illuminate
when the Active Speed Limiter is on
and set to a specific speed.
Refer to “Active Speed Limiter — If
Equipped” in “Starting And Operating” for
further information.
Adaptive Cruise Control (ACC) Set With No
Target Detected Indicator Light — If
Equipped
This light will turn on when the
Adaptive Cruise Control is set and
there is no target vehicle detected.
Refer to "Adaptive Cruise Control (ACC) — If
Equipped" in "Starting And Operating" for
further information.
CAUTION!
The presence of water in the fuel system
circuit may cause severe damage to the
injection system and irregular engine
operation. If the indicator light is
illuminated, contact an authorized dealer
as soon as possible to bleed the system. If
the above indications come on
immediately after refuelling, water has
probably been poured into the tank: switch
the engine off immediately and contact an
authorized dealer.
