zone”. The side mirrors LED’s will be lit up and
stay lit until the vehicle exits the zone.
Uconnect™ Phone — IF EQUIPPED
NOTE:
For Uconnect™ Phone with Navigation or
Multimedia radio, refer to the Navigation or
Multimedia radio’s User’s Manual (separate
booklet) Uconnect™ Phone section.
Uconnect™ Phone is a voice-activated, hands-
free, in-vehicle communications system.
Uconnect™ Phone allows you to dial a phone
number with your mobile phone* using simple
voice commands (e.g., “Call”“Jim”“Work” or
“Dial”“151-1234 -5555”). Your mobile phone’s
audio is transmitted through your vehicle’s au-
dio system; the system will automatically mute
your radio when using the Uconnect™ Phone.
Uconnect™ Phone allows you to transfer calls
between the Uconnect™ Phone and your mo-
bile phone as you enter or exit your vehicle and
enables you to mute the Uconnect™ Phone’s
microphone for private conversation. The Uconnect™ Phone is driven through your
Bluetooth
“Hands-Free profile” mobile phone.
Uconnect™ Phone features Bluetooth tech-
nology - the global standard that enables dif-
ferent electronic devices to connect to each
other without wires or a docking station, so
Uconnect™ Phone works no matter where you
stow your mobile phone (be it your purse,
pocket, or briefcase), as long as your phone is
turned on and has been paired to the vehicle’s
Uconnect™ Phone. The Uconnect™ Phone al-
lows up to seven mobile phones to be linked to
the system. Only one linked (or paired) mobile
phone can be used with the Uconnect™ Phone
at a time. The Uconnect™ Phone is available in
English, Dutch, French, German, Italian or
Spanish languages (as equipped).
WARNING!
Any voice commanded system should be
used only in safe driving conditions following
local laws and phone use. All attention should
be kept on the roadway ahead. Failure to do
so may result in a collision causing serious
injury or death. Uconnect™ Phone Button
The radio or steering wheel con-
trols (if equipped) will contain the
two control buttons (Uconnect™
Phone
button and Voice Com-
mandbutton) that will en-
able you to access the system.
When you press the button you will hear the
word Uconnect™ followed by a BEEP. The
beep is your signal to give a command.
Voice Command Button Actual button location may vary
with radio. The individual buttons
are described in the “Operation”
section.
The Uconnect™ Phone can be used with
Hands-Free Profile certified Bluetooth mobile
phones. Some phones may not support all the
Uconnect™ Phone features. Refer to your mo-
bile service provider or the phone manufacturer
for details.
The Uconnect™ Phone is fully integrated with
the vehicle’s audio system. The volume of the
Uconnect™ Phone can be adjusted either from
74

the radio volume control knob or from the
steering wheel radio control, if so equipped.
The radio display will be used for visual
prompts from the Uconnect™ Phone such as
CELL or caller ID on certain radios.
Compatible Phones* The Uconnect™ Phone requires a mobile
phone equipped with the Bluetooth
“Hands-Free Profile”, version 1.0 or higher.
See Uconnect™ website for supported
phones.
• www.chrysler.com/uconnect
• www.dodge.com/uconnect
• www.jeep.com/uconnect
To find the list of compatible phones navigate
through the following menus:
• Select model year for the vehicle
• Select type of the vehicle
• In the getting started tab, select compatible
phones
OperationVoice commands can be used to operate the
Uconnect™ Phone and to navigate through the
Uconnect™ Phone menu structure. Voice com-
mands are required after most Uconnect™
Phone prompts. You will be prompted for a
specific command and then guided through
the available options.
•Prior to giving a voice command, one must
wait for the beep, which follows the “Ready”
prompt or another prompt.
• For certain operations, compound com-
mands can be used. For example, instead of
saying “Setup” and then “Phone Pairing”, the
following compound command can be said:
“Setup Phone Pairing”.
• For each feature explanation in this section,
only the compound form of the voice com-
mand is given. You can also break the com-
mands into parts and say each part of the
command when you are asked for it. For
example, you can use the compound form
voice command “Phonebook New Entry”, or
you can break the compound form com-
mand into two voice commands: “Phone- book” and “New Entry”. Please remember,
the Uconnect™ Phone works best when you
talk in a normal conversational tone, as if
speaking to someone sitting a few feet/
meters away from you.
Voice Command Tree
Refer to “Voice Tree.”
Help Command
If you need assistance at any prompt, or if you
want to know your options at any prompt, say
“Help” following the beep. The Uconnect™
Phone will play all the options at any prompt if
you ask for help.
To activate the Uconnect™ Phone from idle,
simply press the
button and follow the
audible prompts for directions. All Uconnect™
Phone sessions begin with a press of the
button on the radio control head.
Cancel Command
At any prompt, after the beep, you can say
“Cancel” and you will be returned to the main
menu. However, in a few instances the system
will take you back to the previous menu.
75

1. Power – Turns the screen and wireless
headphone transmitter for the selected Chan-
nel on or off. To hear audio while the screen is
closed, press the Power button to turn the
headphone transmitter on.
2. Channel Selector Indicators – When a but-
ton is pressed, the currently affected channel
or channel button is illuminated momentarily.
3. Light – Turns the remote control backlighting
on or off. The remote backlighting turns off
automatically after five seconds.4. Channel/Screen Selector Switch - Indicates
which channel is being controlled by the re-
mote control. When the selector switch is in the
Channel 1 position, the remote controls the
functionality of headphone Channel 1 (right
side of the screen). When the selector switch is
in the Channel 2, position the remote controls
the functionality of headphone Channel 2 (left
side of the screen).
5.
 – In radio modes, press to seek the next
tunable station. In disc modes, press and hold
to fast forward through the current audio track
or video chapter. In menu modes use to navi-
gate in the menu.
6. / Prev – In radio modes, press to select to
the previous station. In disc modes, press to
advance to the start of the current or previous
audio track or video chapter. In menu modes,
use to navigate in the menu.
7. MENU – Press to return to the main menu of
a DVD disc, to select a satellite audio channel
from the Station list, or select playback modes
(RANDOM for a CD). 8.
/ (Play/Pause) – Begin/resume or pause
disc play.
9. (Stop) – Stops disc play
10. PROG Up/Down – When listening to a radio
mode, pressing PROG Up selects the next
preset and pressing PROG Down selects the
previous preset stored in the radio. When lis-
tening to compressed audio on a data disc,
PROG Up selects the next directory and PROG
Down selects the previous directory. When
listening to a disc in a radio with a multiple-disc
changer, PROG Up selects the next disc and
PROG Down selects the previous disc.
11. MUTE – Press to mute the headphone
audio output for the selected channel.
12. SLOW – Press to slow playback of a DVD
disc. Press play () to resume normal play.
13. STATUS – Press to display the current
status.
Figure 1: Remote Control
194

Shared ModesThe VES™ and radio are capable of communi-
cating with each other. This allows the VES™ to
output radio audio to the headphones and the
radio to output VES™ audio to the vehicle
speakers. When the radio and VES™ are in the
same (shared) mode, a VES™ icon will be
visible on the radio’s display and the shared
icon will be visible on the VES™ screen. When
in shared mode, the same audio source is
heard in the headphones and vehicle speakers
simultaneously.
If the radio functions (FM, AM, or SAT) are in the
shared mode with the VES™, only the radio is
able to control the radio functions. In this case,
VES™ can share the radio mode, but not
change stations until the radio mode is
changed to a mode that is different from the
VES™ selected radio mode. When shared, the
radio has priority over the VES™ or all radio
modes (FM, AM, and SAT). The VES™ has the
ability to switch tuner (AM/FM/MW/LW), SEEK,
TUNE, and recall presets in radio modes as
long as it is not in shared mode.When in shared disc or satellite video mode
both the radio and the VES™ have control of
the video functions. The VES™ has the ability to
control the following video modes:
1. CD: Ability to Fast Forward, Rewind, and
Track Up/Down.
2. CD Changer (in radio): Ability to Disk Up/
Down and program all listed CD controls (Fast
Forward, Rewind, and Track Up/Down).
The VES™ can even control radio modes or
video modes while the radio is turned off. The
VES™ can access the radio modes or disc
modes by navigating to those modes on the
VES™ and activating a radio mode or disc
mode.Information Mode Display
When information mode is active, the current
mode setting for both audio channels is dis-
played. In addition to the items called out by
number, the remaining information displays the
current status of the source (such as station
frequency, name, preset or track number, song
title, artist name, album name, etc.).
1. Channel 1 Mode – Displays the current
source for Channel 1.
Figure 5: Information Mode
Video Screen Display
199

2. Channel 1 Shared Status – When the icon is
displayed, the audio for Channel 1 is also
shared with the radio and playing through the
cabin speakers.
3. Channel 1 Audio Only/Mute - Audio: The
audio only icon is not used on Channel 1, in a
single screen system. Mute: when the Mute
icon is displayed, the audio for Channel 1 has
been muted using the remote control’s MUTE
button.
4. Channel 2 Mode – Displays the current
source for Channel 2.
5. Channel 2 Shared Status – When the icon is
displayed, the audio for Channel 2 is also
shared with the radio and playing through the
cabin speakers.
6. Channel 2 Audio Only/Mute – Audio: Only in
a single screen system: The audio only icon is
displayed on Channel 2 when Channel 1 is in a
video mode. Mute: when the Mute icon is
displayed, the audio for Channel 2 has been
muted using the remote control’s MUTE button.
7. Channel 1 ENTER Button Action – When the
ENTER button on the remote control is pressedwith the
INPUT FILE # button visible on the
screen, the screen shows a numeric entry
keypad which allows you to enter a specific
track number on data discs and HDD (see
Numeric Keypad Menu section of this manual).
Also, Enter Button Action – “INPUT TRK #” to
enter a specific track number on audio discs.
8. Channel 2 ENTER Button Action – When the
ENTER button on the remote control is pressed
with the DIRECT TUNE button visible on the
screen, the screen shows a numeric entry
keypad which allows you to enter a specific
tuner frequency, or tuner channel for AM/FM/
MW/LW/SAT (see Numeric Keypad Menu sec-
tion).
9. Clock – Displays the time.
10. Video Lock – When the icon is displayed,
the remote control functions are disabled.
11. Not Available / Error – Operational or status
errors are displayed here.
12. Disc Changer Status – When the source for
either Channel 1 or Channel 2 is a multi-disc
changer, the disc loaded / selected status is
displayed.Mode Selection Menu
The first press of the MODE button causes the
Mode Selection menu to appear on screen
(Figure 6). The current mode is always the
default selection. The mode can be changed
for either Channel/Screen 1 or Channel/Screen
2 using the remote control.
Use the remote control’s navigation buttons ( ,
, ,) to navigate through the available
modes, and then press the remote control’s
ENTER button to select the mode. An alternate
method of changing modes is repeated press-
ing of the MODE button until the desired mode
Figure 6: Mode Selection Menu
200

is highlighted then press the ENTER button on
the remote control to select the mode.
In a single screen system, when a video mode
(such as DVD-video, Aux video, etc.) is active
and Channel/Screen 1 is selected using the
remote control selector switch, the first press of
the remote control’s MODE button causes the
Mode Selection menu to appear.
Numeric Keypad Menu
When the display for either Channel 1 or Chan-
nel 2 shows a direct action button, pressing the
remote control’s ENTER button activates a nu-
meric keypad menu (as seen in Figure 7 Chan-
nel 1). This screen makes it easy to enter a
specific tuner frequency, satellite channel, or
track number. To enter the desired digit:
1. Press the remote control’s navigation but-
tons (,,,) to navigate to the desired
digit.
2. When the digit is highlighted, press the
remote control’s ENTER button to select the
digit. Repeat these steps until all digits are
entered.
3. To delete the last digit, navigate to the Del
button and press the remote control’s ENTER
button.
4. After all of the digits are entered, navigate to
the Go button and press the remote control’s
ENTER button.Disc Menu
When listening to a CD Audio or CD Data disc,
pressing the remote control’s MENU button
displays a list of all commands which control
playback of the disc. Using the options you can
activate or cancel play and Random play.
Figure 7: Numeric Keypad Menu
Figure 9: Disc Menu For CDs
201
