JEEP GRAND CHEROKEE 2013 Owner handbook (in English)

Remote ControlButton Standard Screens
Menu Screens
AM/FM/
MW/LW HDD–Hard
Disc Drive DISC/DVD
AUX/AUX1/AUX2 Mode
Select Menu Screen
Setup
Status Not Available Slow Mode
and Content Info Not
Available Audio:Not Available
Audio:
Not
Available Not
Available Not
Available
Video Play: Show Mode Info Video:
Show Mode Info
Mode Advance
to Next Mode Show
Mode
Select Item
Prog Up Next Preset* Not
Available Not
Available Next Disc
(if player is changer) Not
Available Not
Available Not
Available
Prog Down Previous
Preset* Not
Available Not
Available Previous Disc
(if player is changer) Not
Available Not
Available Not
Available
Ensure remote control selector switch is set to
Screen or Channel to be controlled: 1 OR 2.
Ensure headphone selector switch is set to
Screen or Channel to be listened to: 1 OR 2.
*No action when mode is shared with cabin
speakers.
197

1. Power – Turns the screen and wireless
headphone transmitter for the selected Channel
on or off. To hear audio while the screen is
closed, press the Power button to turn the
headphone transmitter on.
2. Channel Selector Indicators – When a but-
ton is pressed, the currently affected channel or
channel button is illuminated momentarily.
3. Light – Turns the remote control backlighting
on or off. The remote backlighting turns off
automatically after five seconds.4. Channel/Screen Selector Switch - Indicates
which channel is being controlled by the remote
control. When the selector switch is in the
Channel 1 position, the remote controls the
functionality of headphone Channel 1 (right side
of the screen). When the selector switch is in
the Channel 2, position the remote controls the
functionality of headphone Channel 2 (left side
of the screen).
5.
 – In radio modes, press to seek the next
tunable station. In disc modes, press and hold
to fast forward through the current audio track
or video chapter. In menu modes use to navi-
gate in the menu.
6. / Prev – In radio modes, press to select to
the previous station. In disc modes, press to
advance to the start of the current or previous
audio track or video chapter. In menu modes,
use to navigate in the menu.
7. MENU – Press to return to the main menu of
a DVD disc, to select a satellite audio channel
from the Station list, or select playback modes
(RANDOM for a CD).
8. / (Play/Pause) – Begin/resume or pause
disc play. 9.
■(Stop) – Stops disc play
10. PROG Up/Down – When listening to a
radio mode, pressing PROG Up selects the
next preset and pressing PROG Down selects
the previous preset stored in the radio. When
listening to compressed audio on a data disc,
PROG Up selects the next directory and PROG
Down selects the previous directory. When lis-
tening to a disc in a radio with a multiple-disc
changer, PROG Up selects the next disc and
PROG Down selects the previous disc.
11. MUTE – Press to mute the headphone
audio output for the selected channel.
12. SLOW – Press to slow playback of a DVD
disc. Press play () to resume normal play.
13. STATUS – Press to display the current
status.
14. MODE – Press to change the mode of the
selected channel. See the Mode Selection sec-
tion of this manual for details on changing
modes.
Remote Control
198

15. SETUP – When in a video mode, press the
SETUP button to access the display settings
(see the display settings section) to access the
DVD setup menu, select the menu button on the
radio. When a disc is loaded in the DVD player
(if equipped) and the VES™ mode is selected
and the disc is stopped, press the SETUP
button to access the DVD Setup menu. (see the
DVD Setup Menu of this manual.)
16. BACK – When navigating in menu mode,
press to return to the previous screen. When
navigating a DVDs disc menu, the operation
depends on the disc’s contents.
17. – In radio modes, press to seek to the
previous tunable station. In disc modes, press
and hold to fast rewind through the current
audio track or video chapter. In menu modes
use to navigate in the menu.
18. ENTER – Press to select the highlighted
option in a menu.
19. / NEXT – In radio modes, press to select
to the next station. In disc modes, press to
advance to the next audio track or video chap-
ter. In menu modes, use to navigate in the
menu.Remote Control StorageThe video screen(s) come with a built in storage
compartment for the remote control which is
accessible when the screen is opened. To re-
move the remote, use your index finger to pull
and rotate the remote towards you. Do not try to
pull the remote straight down as it will be very
difficult to remove. To return the remote back
into its storage area, insert one long edge of the
remote into the two retaining clips first, and then
rotate the remote back up into the other two
retaining clips until it snaps back into position.Locking The Remote ControlAll remote control functionality can be disabled
as a parental control feature.
•
To disable the Remote Control from making any
changes, press the Video Lock button and follow
the radio’s instructions (select menu, rear ves,
lock). If the vehicle is not equipped with a DVD
player, follow the radio’s instructions to turn
Video Lock on. The radio and the video
screen(s) indicate when Video Lock is active.
•Pressing the Video Lock again or turning the
ignition OFF turns Video Lock OFF and allows
remote control operation of the VES™.
Replacing The Remote Control
Batteries
The remote control requires two AAA batteries
for operation. To replace the batteries:
• Locate the battery compartment on the back
of the remote, then slide the battery cover
downward.
•
Replace the batteries, making sure to orient
them according to the polarity diagram shown.
• Replace the battery compartment cover.
The Remote Control Storage
199

Headphones OperationThe headphones receive two separate chan-
nels of audio using an infrared transmitter from
the video screen.
Front seat occupants receive some headphone
audio coverage to allow them to adjust the
headphone volume for the young rear seat
occupants that may not be able to do so for
themselves.
If no audio is heard after increasing the volume
control, verify that the screen is turned on and in
the down position and that the channel is not
muted and the headphone channel selector
switch is on the desired channel. If audio is still
not heard, check that fully charged batteries are
installed in the headphones.
ControlsThe headphone power indicator and controls
are located on the right ear cup.
NOTE:
The rear video system must be turned on
before sound can be heard from the head-
phones. To conserve battery life, the head-
phones will automatically turn off approxi-
mately three minutes after the rear video
system is turned off.Changing the Audio Mode for Headphones
1. Ensure the Remote Control channel/screen
selector switch is in the same position as the
headphone selector switch.
NOTE:
•
When both switches are on Channel 1, the
Remote is controlling Channel 1 and the
headphones are tuned to the audio of the
VES™ Channel 1.
• When both switches are on Channel 2, the
Remote is controlling Channel 2 and the
headphones are tuned to the audio of the
VES™ Channel 2.
2.
Press the MODE button on the remote control.
3. If the video screen is displaying a video
source (such as a DVD Video), pressing STA-
TUS shows the status on a popup banner at the
bottom of the screen. Pressing the MODE but-
ton will advance to the next mode. When the
mode is in an audio only source (such as FM),
the Mode Selection menu appears on screen.
1. Volume Control
2. Power Button
3. Channel Selection Switch
4. Power Indicator
200

4. When the Mode Selection menu appears on
screen, use the cursor buttons on the remote
control to navigate to the available modes and
press the ENTER button to select the new
mode.
5. To cancel out of the Mode Selection menu,
press the BACK button on the remote control.
Replacing The Headphone BatteriesEach set of headphones requires two AAA
batteries for operation. To replace the batteries:
•Locate the battery compartment on the left
ear cup of the headphones, and then slide
the battery cover downward.
• Replace the batteries, making sure to orient
them according to the polarity diagram
shown.
• Replace the battery compartment cover.
Unwired® Stereo Headphone
Lifetime Limited Warranty
Who Does This Warranty Cover? This war-
ranty covers the initial user or purchaser ( "you"
or "your") of this particular Unwired Technology
LLC ("Unwired") wireless headphone ("Prod-
uct"). The warranty is not transferable.
How Long Does The Coverage Last? This
warranty lasts as long as you own the Product.
What Does This Warranty Cover? Except as
specified below, this warranty covers any Prod-
uct that in normal use is defective in workman-
ship or materials.
What Does This Warranty Not Cover? This
warranty does not cover any damage or defect
that results from misuse, abuse or modification
of the Product other than by Unwired. Foam
earpieces, which will wear over time through
normal use, are specifically not covered (re-
placement foam is available for a nominal
charge). UNWIRED TECHNOLOGY IS NOT
LIABLE FOR ANY INJURIES OR DAMAGES
TO PERSONS OR PROPERTY RESULTING
FROM THE USE OF, OR ANY FAILURE OR
DEFECT IN, THE PRODUCT, NOR IS UN- WIRED LIABLE FOR ANY GENERAL, SPE-
CIAL, DIRECT, INDIRECT, INCIDENTAL, CON-
SEQUENTIAL, EXEMPLARY, PUNITIVE OR
OTHER DAMAGES OF ANY KIND OR NA-
TURE WHATSOEVER. Some states and juris-
dictions may not allow the exclusion or limitation
of incidental or consequential damages, so the
above limitation may not apply to you. This
warranty gives you specific legal rights. You
may also have other rights, which vary from
jurisdiction to jurisdiction.
What Will Unwired® Do?
Unwired®, at its
option, will repair or replace any defective Prod-
uct. Unwired® reserves the right to replace any
discontinued Product with a comparable model.
THIS WARRANTY IS THE SOLE WARRANTY
FOR THIS PRODUCT, SETS FORTH YOUR
EXCLUSIVE REMEDY REGARDING DEFEC-
TIVE PRODUCTS, AND IS IN LIEU OF ALL
OTHER WARRANTIES (EXPRESS OR IM-
PLIED), INCLUDING ANY WARRANTY OR
MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE.
You may register your Unwired® wireless head-
phones online at www.unwiredtechnology.com
or by phone at 1-888-293-3332.
201

Video Screen Operation
Displaying VideoThe video screen has two different operating
modes, a video mode (when displaying video
such as DVD video, Aux video, etc.) and an
information mode as shown in Figure 5. Because
the VES™ is a dual channel system, Information
Mode is displayed in a split screen format. When
in Information Mode, the left side of the screen is
referred to as Channel 1 and the right side of the
screen is referred to as Channel 2.
Only Channel 1 displays video images. When in
video mode the image is displayed on the full
screen, however Channel 2’s functionality is still
available. A popup banner at the bottom of the
screen is displayed momentarily over the video
image. While in video mode and Channel 2 is
selected on the remote control selector switch,
the first remote control key press will activate
the popup banner indicating Channel 2’s status.
While the banner is still visible, any subsequent
remote control key press for Channel 2 shall
initiate the requested remote control command.In a two-screen system, the video for Channel 1
is displayed on the first rear seat screen and the
video for Channel 2 is displayed on the second
rear seat screen. Information Mode is displayed
in split screen, the left side of the screen
(Channel 1) shows the status/mode of the first
rear seat screen and the right side of the screen
(Channel 2) shows the status/mode of the sec-
ond rear seat screen.
When Channel 1 is in a video mode, the image
is displayed on the first rear seat screen as a full
screen image. A popup banner at the bottom of
the screen is displayed momentarily over the
video image showing any change in status of
Channel 2.When Channel 2 is in video mode, the image is
displayed on the second rear seat screen as a
full screen image. A popup banner at the bottom
of the screen is displayed momentarily over the
video image showing any change in status of
Channel 1.
Playing A Disc On The VES™The following actions occur automatically when
a disc is inserted into the radio on a single
screen system and into the remote DVD player
on a two screen system:
•
If the video screen is in the open position (the
LCD screen is visible), then the screen turns on
and the wireless headphone transmitter turns
on. If the video screen is closed, the wireless
headphone transmitter must be turned on by
using the power button on the remote control
(headphones only receive audio signals if the
headphones are powered on).
•
After the disc is inserted, the disc begins
playing to cabin speakers, wireless head-
phones, and rear video screens.
Popup Banner
202

Shared ModesThe VES™ and radio are capable of communi-
cating with each other. This allows the VES™ to
output radio audio to the headphones and the
radio to output VES™ audio to the vehicle
speakers. When the radio and VES™ are in the
same (shared) mode, a VES™ icon will be
visible on the radio’s display and the shared
icon will be visible on the VES™ screen. When
in shared mode, the same audio source is
heard in the headphones and vehicle speakers
simultaneously.
If the radio functions (FM, AM, or SAT) are in the
shared mode with the VES™, only the radio is
able to control the radio functions. In this case,
VES™ can share the radio mode, but not
change stations until the radio mode is changed
to a mode that is different from the VES™
selected radio mode. When shared, the radio
has priority over the VES™ or all radio modes(FM, AM, and SAT). The VES™ has the ability
to switch tuner (AM/FM/MW/LW), SEEK, TUNE,
and recall presets in radio modes as long as it is
not in shared mode.
When in shared disc or satellite video mode
both the radio and the VES™ have control of
the video functions. The VES™ has the ability to
control the following video modes:
1. CD: Ability to Fast Forward, Rewind, and
Track Up/Down.
2. CD Changer (in radio): Ability to Disk Up/
Down and program all listed CD controls (Fast
Forward, Rewind, and Track Up/Down).
The VES™ can even control radio modes or video
modes while the radio is turned off. The VES™
can access the radio modes or disc modes by
navigating to those modes on the VES™ and
activating a radio mode or disc mode.
Information Mode Display
When information mode is active, the current
mode setting for both audio channels is dis-
played. In addition to the items called out by
number, the remaining information displays the
current status of the source (such as station
frequency, name, preset or track number, song
title, artist name, album name, etc.).
1. Channel 1 Mode – Displays the current
source for Channel 1.
Information Mode Video Screen Display
203

2. Channel 1 Shared Status – When the icon is
displayed, the audio for Channel 1 is also
shared with the radio and playing through the
cabin speakers.
3. Channel 1 Audio Only/Mute - Audio: The
audio only icon is not used on Channel 1, in a
single screen system. Mute: when the Mute
icon is displayed, the audio for Channel 1 has
been muted using the remote control’s MUTE
button.
4. Channel 2 Mode – Displays the current
source for Channel 2.
5. Channel 2 Shared Status – When the icon is
displayed, the audio for Channel 2 is also
shared with the radio and playing through the
cabin speakers.
6. Channel 2 Audio Only/Mute – Audio: Only in
a single screen system: The audio only icon is
displayed on Channel 2 when Channel 1 is in a
video mode. Mute: when the Mute icon is dis-
played, the audio for Channel 2 has been muted
using the remote control’s MUTE button.7. Channel 1 ENTER Button Action – When the
ENTER button on the remote control is pressed
with the
"INPUT FILE #" button visible on the
screen, the screen shows a numeric entry key-
pad which allows you to enter a specific track
number on data discs and HDD (see Numeric
Keypad Menu section of this manual). Also,
Enter Button Action – “INPUT TRK #” to enter a
specific track number on audio discs.
8. Channel 2 ENTER Button Action – When the
ENTER button on the remote control is pressed
with the "DIRECT TUNE" button visible on the
screen, the screen shows a numeric entry key-
pad which allows you to enter a specific tuner
frequency, or tuner channel for AM/FM/MW/LW
(see Numeric Keypad Menu section).
9. Clock – Displays the time.
10. Video Lock – When the icon is displayed,
the remote control functions are disabled.
11. Not Available / Error – Operational or status
errors are displayed here.
12.
Disc Changer Status – When the source for
either Channel 1 or Channel 2 is a multi-disc
changer, the disc loaded / selected status is dis-
played.
Mode Selection Menu
The first press of the MODE button causes the
Mode Selection menu to appear on screen. The
current mode is always the default selection.
The mode can be changed for either Channel/
Screen 1 or Channel/Screen 2 using the remote
control.
Use the remote control’s navigation buttons ( ,
, ,) to navigate through the available
modes, and then press the remote control’s
ENTER button to select the mode. An alternate
method of changing modes is repeated press-
Mode Selection Menu
204

ing of the MODE button until the desired mode
is highlighted then press the ENTER button on
the remote control to select the mode.
In a single screen system, when a video mode
(such as DVD-video, Aux video, etc.) is active
and Channel/Screen 1 is selected using the
remote control selector switch, the first press of
the remote control’s MODE button causes the
Mode Selection menu to appear.
Numeric Keypad Menu
When the display for either Channel 1 or Chan-
nel 2 shows a direct action button, pressing the
remote control’s ENTER button activates a nu-
meric keypad menu. This screen makes it easy
to enter a specific tuner frequency, satellite
channel, or track number. To enter the desired
digit:
1. Press the remote control’s navigation but-
tons (,,,) to navigate to the desired
digit.
2. When the digit is highlighted, press the re-
mote control’s ENTER button to select the digit.
Repeat these steps until all digits are entered.
3. To delete the last digit, navigate to the Del
button and press the remote control’s ENTER
button.
4. After all of the digits are entered, navigate to
the Go button and press the remote control’s
ENTER button.Disc Menu
When listening to a CD Audio or CD Data disc,
pressing the remote control’s MENU button
displays a list of all commands which control
playback of the disc. Using the options you can
activate or cancel play and Random play.
Numeric Keypad Menu
Disc Menu For CDs
205

Display Settings
When watching a video source (DVD Video with
the disc in Play mode, Aux Video, etc.), pressing
the remote control’s SETUP button activates
the Display Settings menu. These settings con-
trol the appearance of the video on the screen.
The factory default settings are already set for
optimum viewing, so there is no need to change
these settings under normal circumstances.
To change the settings, press the remote con-
trol’s navigation buttons (,) to select an
item, then press the remote control’s navigation
buttons (, ) to change the value for the currently selected item. To reset all values back
to the original settings, select the Default Set-
tings menu option and press the remote con-
trol’s ENTER button.
Disc Features control the remote DVD player’s
(if equipped) settings of DVD being watched in
the remote player.
Listening To Audio With The Screen
Closed
To listen to only audio portion of the channel
with the screen closed:
•
Set the audio to the desired source and
channel.
• Close the video screen.
• To change the current audio mode, press the
remote control’s SOURCE button. This will
automatically select the next available audio
mode without using the MODE/SOURCE Se-
lect menu.
• When the screen is reopened, the video
screen will automatically turn back on and
show the appropriate display menu or media. If the screen is closed and there is no audio
heard, verify that the headphones are turned on
(the ON indicator is illuminated) and the head-
phone selector switch is on the desired channel.
If the headphones are turned on, press the
remote control’s power button to turn audio on.
If audio is still not heard, check that fully
charged batteries are installed in the head-
phones.Why Does The Screen Mode Change
Automatically?
In order to make the operation of the VES™
simple and with the least amount of driver distrac-
tion, specific events will cause the screen(s) to
automatically switch to DVD mode. These events
are:
•
Loading a disc in the DVD player (if so
equipped),
• Pressing the PLAY button on the DVD player
faceplate when the disc is stopped or
paused, or
• AM/FM band selection via Radio.
Video Screen Display Settings
206
