display KIA OPTIMA PLUG-IN HYBRID 2017 Owners Manual

Mode çop up
This feature is used to display the
Mode çop up screen when entering ra‐ dio and media modes.
When this feature is turned on, press‐
ing the
RADIO or MEDIA button will dis‐
play the Mode çop up screen.
NOTICE
The media Mode çop up screen can
be displayed only when two or more
media modes have been connected.
Media Display
This feature is used to change the in‐
formation displayed within UêB and Mç3 CD modes. • Folder File: Displays file name and folder name. • Album Artist êong: Displays album
name/artist name/song.
With the Sound Button
çress the SETUP button êelect
[êound]
You can select and control options rela‐ ted to [êound êetting], [èuantum Logic
êound], [êpeed Dependent Vol.] and
[Touch êcreen Beep].
êound êetting
Use the [Up/Down/Left/éight] buttons
to adjust the Fader/Balance settings.
Use the [Left/éight] buttons to adjust the Bass/Middle/Treble settings.
çress the [Default] button to reset.
èLê (èuantum Logic êurround)
èLê can be set by selecting from On/
Off.
Audio system
6-116

êDVC (êpeed Dependent Volume Con‐trol)
The volume level is controlled automat‐ ically according to the vehicle speed.
êDVC can be set by selecting from On/
Off.
Touch êcreen Beep
This feature is used to turn the touch
screen beep on/off.
With the Clock/Calendar Button
çress the SETUP button êelect [Clock/
Calendar]
You can select and control options rela‐
ted to [Clock êettings], [Calendar êet‐ tings] and [Time Format].
Clock êettings
Use the [Up/Down] buttons to set the
Hour, Minutes and AM/çM setting.
çress and hold the
button
(over 0.8 seconds) to display the Clock/ Calendar screen.
Calendar êettings
Use the [Up/Down] buttons to set the
Day, Month and Year setting.
Time Format
This feature is used to change the clock
format between 12hr or 24hr.
With the Phone Button
çress the SETUP button êelect
[çhone]
You can select and control options rela‐ ted to [çair çhone], [çaired çhone List],
[Contacts Download], [Outgoing Vol‐
ume] and [Bluetooth êystem Off].

6-117
6
Audio system

CAUTION
•The Rear View Camera has beenequipped with an optical lens toprovide a wider range of vision andmay appear different from the ac‐tual distance. For safety, directlycheck the rear and left/right sides.
•The color of the parking guidelinesdisplayed in the picture may differfrom the actual screen.
•When booted up, blinking may oc‐cur when you switch to a UIscreen.
Audio system
6-120

Before driving............................................................................ 7-04Before entering vehicle........................................................ 7-04
Necessary inspections..........................................................7-04
Before starting...................................................................... 7-04
Engine start/stop button......................................................... 7-06 Illuminated engine start/stop button................................ 7-06
Engine start/stop button position..................................... 7-06
Starting the hybrid system................................................. 7-08
Automatic transaxle................................................................. 7-11 Automatic transaxle operation...........................................7-11
Good driving practices.......................................................... 7-15
Brake system.............................................................................7-17 Power brakes ........................................................................ 7-17
Foot parking brake................................................................ 7-18
Electronic parking brake (EPB) .......................................... 7-19
AUTO HOLD ........................................................................... 7-24
Warning messages................................................................7-26
Anti-lock brake system (ABS).............................................7-28
Electronic stability control (ESC) ....................................... 7-30
Vehicle stability management (VSM) ............................... 7-33
Hill-start assist control (HAC) ............................................ 7-34
Emergency Stop Signal (ESS) ............................................. 7-35
Good braking practices.........................................................7-35
Autonomous emergency braking (AEB) ............................... 7-37 System setting and activation............................................7-37
AEB warning message and system control......................7-39
Brake operation..................................................................... 7-40
Sensor to detect the distance from the vehicle
in front (front radar)............................................................ 7-41
System malfunction............................................................. 7-42 Limitation of the system..................................................... 7-43
Recognizing pedestrians...................................................... 7-45
Cruise control system ............................................................. 7-47 Cruise control switch............................................................ 7-48
To set cruise control speed................................................. 7-48
To increase cruise control set speed................................. 7-49
To decrease the cruising speed.......................................... 7-50
To temporarily accelerate with the cruise control on.... 7-50
To cancel cruise control........................................................7-50
To resume cruising speed at more than approxi‐
mately 30 km/h..................................................................... 7-51
To turn cruise control off.................................................... 7-51
Speed Limit Control System ................................................... 7-52 To set speed limit.................................................................. 7-52
To turn off the speed limit control.................................... 7-53
Speed Limit Information Function (SLIF) ............................. 7-55 SLIF activation/deactivation................................................ 7-55
Operation................................................................................ 7-56
Display.....................................................................................7-56
Driver's attention.................................................................. 7-58
Advanced Smart Cruise Control system .............................. 7-59 Speed setting......................................................................... 7-60
Vehicle to vehicle distance setting..................................... 7-64
To adjust the sensitivity of advanced smart
cruise control......................................................................... 7-69
To convert to cruise control mode..................................... 7-69
Limitations of the system................................................... 7-70
Drive mode integrated control system ................................ 7-75 Hybrid vehicle.........................................................................7-75
Drive mode integrated control system ................................ 7-77
Driving your vehicle

7

(Continued)
•Always check the surroundingareas near your vehicle for people,especially children, before shiftinga vehicle into D (Drive) or R (Re‐verse).
•Before leaving the driver’s seat, al‐ways make sure the shift lever isin the P (Park) position; then setthe parking brake fully and shutthe engine off. Unexpected andsudden vehicle movement can oc‐cur if these precautions are notfollowed in the order identified.
•Do not use the engine brake (shift‐ing from a high gear to lower gear)rapidly on slippery roads.The vehicle may slip causing an ac‐cident.
CAUTION
•To avoid damage to your trans‐axle, do not accelerate the enginein R (Reverse) or any forward gearposition with the brakes on.
(Continued)
(Continued)
•When stopped on an uphill grades,do not hold the vehicle stationarywith engine power. Use the brakepedal or the parking brake.
•Do not shift from N (Neutral) or P(Park) into D (Drive), or R (Reverse)when the engine is above idlespeed.
Transaxle ranges
The indicator lights in the instrument
cluster displays the shift lever position when the engine start/stop button
switch is in the ON position.
P (Park)
Always come to a complete stop before
shifting into P (Park). This position locks the transaxle and prevents the
front wheels from rotating.
To shift from P (Park), you must de‐
press firmly on the brake pedal and make sure your foot is off the acceler‐
ator pedal.
If you have done all of the above andstill cannot shift the lever out of P(Park), see L

AUTO HOLD deactivating. Pressbrake pedal
5ZQF
"
0+'-
5ZQF
#
0+'-
When the conversion from Auto Hold to
EPB is not working properly a warning will sound and a message will appear.
NOTICE
When this message is displayed, the
Auto Hold and EPB may not operate.
For your safety, depress the brake
pedal.
Press brake pedal to deactivateAUTO HOLD
5ZQF
"
0+'-
5ZQF
#
0+'-
If you did not apply the brake pedal
when you release the Auto Hold by pressing the [AUTO HOLD] switch, a
warning will sound and a message will
appear.
AUTO HOLD conditions not met.Close door, hood, and fastenseatbelt
0+'-
When you press the [AUTO HOLD]
switch, if the driver’s door, engine hood are not closed or the driver’s seat belt
is unfastened, a warning will sound and
a message will appear on the LCD dis‐ play. At this moment, press the [AUTO
HOLD] button after closing the driver’s
door, engine hood and fastening the seat belt.

7-27
7
Driving your vehicle

The driver can activate the AEB by
placing the engine start/stop button switch to the ON position and by se‐
lecting 'User Settings', 'Driving Assist',
and 'Autonomous Braking System'. The AEB deactivates, when the driver can‐
cels the system setting.
The warning light illuminates on the LCD display, when youcancel the AEB system.
The driver can monitor the AEBON/OFF status on the LCD display.
When the warning light remains ON
with the AEB activated, we recom‐
mend you to have the system checked
by an authorized Kia dealer.
5ZQF
"
0+'-#
5ZQF
#
0+'-#
The driver can select the initial warning
activation time in the User Settings in the instrument cluster LCD display. The
options for the initial Forward Collision
Warning include the following:
Driving your vehicle
7-38

EARLY - When this condition is se‐lected, the initial Forward
Collision Warning is activa‐ted earlier than normal.This setting maximizesthe amount of distance
between the vehicle or
pedestrian ahead beforethe initial warning occurs.
NORMAL - When this condition is se‐
lected, the initial Forward
Collision Warning is activa‐ted normally. This settingallows for a nominalamount of distance be‐
tween the vehicle or pe‐
destrian ahead before theinitial warning occurs.
LATE - When this condition is se‐ lected, the initial Forward
Collision Warning is activa‐ted later than normal.
This setting reduces theamount of distance be‐
tween the vehicle or pe‐
destrian ahead before theinitial warning occurs.Prerequisite for activation
The AEB gets ready to be activated,when the AEB is selected on the LCD
display, and when the following prereq‐
uisites are satisfied.
- The ESC is activated.
- The driving speed is over 10 km/h.
(However, AEB is activated within
certain driving speed.)
- When recognizing the vehicle or the
pedestrian in front. (However, AEB
does not activate according to condi‐
tions in front and vehicle systems, but it notices only certain warnings.)
WARNING
•The AEB automatically activatesupon placing the ignition switch tothe ON position. The driver can de‐activate the AEB by canceling thesystem setting on the LCD display.
•The AEB automatically deactivatesupon canceling the ESC. When theESC is canceled, the AEB cannot beactivated on the LCD display.
(Continued)
(Continued)
•Set or cancel AEB with controllingswitches on steering wheel afterstopping the vehicle in a safe placefor your safety.
AEB warning message and
system control
The AEB produces warning messages
and warning alarms in accordance with the collision risk levels of followings like
vehicle’s sudden braking in front or lack
of vehicle to vehicle distance or collision to pedestrians. Also, it controls the
brakes in accordance with the collision
risk levels.

7-39
7
Driving your vehicle

Forward warning (1st warning)
0+'-
The warning message appears on the
LCD display with the warning alarms.
Collision warning (2nd warning)
0+'-
• The warning message appears on the LCD display with the warning alarms.
• The AEB controls the brakes within certain limit to release shock fromthe collision.
Emergency braking (3rd warning)
0+'-
• The warning message appears on the LCD display with the warning alarms.
• The AEB controls the brakes within certain limit to release shock fromthe collision.
The AEB controls the maximum
brakes just before the collision.
Brake operation
• In an urgent situation, the braking system enters into the ready status
for prompt reaction against the driv‐ er’s depressing the brake pedal.
Driving your vehicle
7-40

-There is a group of pedestrians.
WARNING
•Cancel the AEB in the User Set‐tings on the LCD display, beforetowing another vehicle. While tow‐ing, the brake application may ad‐versely affect your vehicle safety.
•Pay great caution to the vehicle infront, when it has heavy loadingextended rearward, or when it hashigher ground clearance.
•The sensor only detects pedes‐trians, not carts, bicycles, motor‐cycles, luggage bags, or strollers.
•The AEB does not operate in a cer‐tain situation. Thus, never test-operate the AEB against a personor an object. It may cause a severeinjury or even death.
NOTICE
The system may temporarily cancel
due to the strong electric waves.
Driving your vehicle

7-46
