HILL HOLDER SYSTEM (where provided)
It is an integral part of the ESP system and
facilitates starting on an uphill slope.
It is automatically activated in the following
conditions:
Uphill: vehicle stationary on a road with gradient
above 2%, engine running, clutch and brake pedals
pressed and gearbox in neutral position or gear
engaged (reverse excluded).
Downhill: stationary on a road with gradient above
2%, engine running, clutch and brake pedals
pressed and reverse engaged.
During pickup the ESP system control unit
maintains the wheel braking pressure until the
engine torque required for start up is reached, or
anyway for a maximum of 2 seconds, so that the
right foot can be moved easily from the brake pedal
to the accelerator pedal.After 2 seconds and without starting the car, the
system automatically deactivates gradually releasing
the braking pressure. During this phase it is possible
to hear the typical brake mechanical disengaging
noise which indicates the car is about to move off.
Failure warnings
In the event of failure, the instrument cluster
warning light
*will come on together with the
message on the multifunction display.
IMPORTANT The Hill Holder system is not a
parking brake therefore, never leave the car without
engaging the parking brake, the first gear and
turning the engine off.
141
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND
CONTROLS
WARNING
During the use of the spare wheel, the ESP system carries on working.
However, you must remind that the spare wheel presents dimensions smaller
than the standard tyre and therefore the grip is reduced as to the other car
tyres.
WARNING
For correct operation of the ESP system, the tyres must absolutely be of the same
brand and type on all wheels, in perfect conditions and, above all, of the type,
brand and size specified.

SNOW TYRES
Use snow tyres of the same size as the normal tyres
provided with the car.
Lancia Dealership will be happy to provide advice
concerning the most suitable type of tyre for the
customer’s requirements.
For the type of tyre to be used, inflation pressures
and the specifications of snow tyres, follow the
instructions given in paragraph “Wheels” in section
“Technical specifications”.
The winter features of these tyres are reduced
considerably when the tread depth is below 4 mm.
In this case, they should be replaced.Due to the snow tyre features, under normal
conditions of use or on long motorway journeys, the
performance of these tyres is lower than that of
normal tyres. It is therefore necessary to limit their
use to the purposes for which they are certified.
IMPORTANT When snow tyres are used with a max
speed index below the one that can be reached by
the car (increased by 5%), place a notice in the
passenger compartment, plainly in the driver’s view
which states the max permissible speed of the snow
tyres (as per EC Directive).
All four tyres should be the same (brand and track)
to ensure greater safety when driving and braking
and better driveability.
Remember that it is inappropriate to change the
direction of rotation of tyres.
206
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
WARNINGThe max speed for snow tyres with “T” marking is 190 km/h.
The Road Traffic Code speed limits must however be always strictly observed.

207
WARNING
LIGHTS AND
MESSAGES
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
INDEX
DASHBOARD
AND CONTROLS
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
SNOW CHAINS
Use of snow chains should be in compliance with
local regulations.
Snow chains should only be applied to the driving
wheels (front wheels). We recommend using
Lineaccessori Lancia snow chains.
Check the tension of the chains after driving some
ten metres.IMPORTANT Snow chains cannot be fitted to the
space-saver spare wheel. So, if a front (drive) wheel
is punctured and chains are needed, a rear wheel
should be fitted to the front of the vehicle and the
spare wheel should be fitted to the rear. This way
with two normal drive wheels, snow chains can be
fitted to them to solve an emergency.
IMPORTANT Tyres 205/50 R16 87V cannot be
fitted with snow chains.
Tyres on which chains can be fitted
185/65 R14 86T
195/60 R15 88TType of snow chains to be used
Snow chains with standard size
with max protrusion beyond the tyre profile of 12 mm.
Keep your speed down when snow chains are fitted. Do not exceed 50 km/h. Avoid potholes,
steps and pavements and avoid also to drive for long distances on roads not covered with snow
to prevent damaging the car and the roadbed.
Refer to the above mentioned table for information on the wheels where snow chains can be fitted.
Follow the prescriptions.

WHEELS
RIMS AND TYRES
Pressed steel or alloy rims. Tubeless tyres with radial carcass. The
homologated tyres are listed in the Log book.
IMPORTANT In the event of discrepancies between the information
provided on this “Owner handbook” and the “Log book”, consider
the specifications shown in the log book only.
Attaining to the prescribed size, to ensure safety of the car in
movement, it must be fitted with tyres of the same make and type on
all wheels.
IMPORTANT Do not use inner tubes with Tubeless tyres.
SPACE-SAVER SPARE WHEEL
Pressed steel rim. Tubeless tyre.
WHEEL GEOMETRY
Front wheel toe-in measured from rim to rim: 0 ±1 mm.
The values refer to the car in running order.
UNDERSTANDING TYRE MARKING
Example: 185/65 R 14 86 T
185 = Nominal width (S, distance between sidewalls in mm).
65 = Percentage height/width ratio (H/ S).
R = Radial tyre.
14 = Rim diameter in inches (Ø).
86 = Load rating.
T = Maximum speed rating.
325
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARDAND CONTROLS
SAFETY
DEVICES
ACORRECT
USE OF
THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
L0D0229m

COLD TYRE INFLATION PRESSURE (bar)
328
WARNING
LIGHTS AND
MESSAGES
INDEX
DASHBOARDAND CONTROLS
SAFETY
DEVICES
CORRECT
USE OF
THE CAR
IN AN
EMERGENCY
CAR
MAINTENANCE
TECHNICALSPECIFICATIONS
STANDARD TYRES
Size Medium load Full load
Front Rear Front Rear
185/65 R14 86T 2,2 2,1 2,3 2,3
195/60 R15 88T 2,2 2,1 2,3 2,3
205/50 R16 87V 2,2 2,1 2,3 2,3
135/80 B14 84M 2,8SPARE WHEEL
125/80 R15 95M 4,2
Add +0.3 bar to the prescribed inflation pressure when the tyres are warm. Recheck pressure value with cold tyres.
With snow tyres, add +0.2 bar to the inflation pressure value prescribed for standard tyres.

ENGINE OIL CHANGE COLD TYRE INFLATION PRESSURE (bar)
STANDARD TYRES
Size Medium load Full load
Front Rear Front Rear
FUEL CAPACITIES (litres)
1.48V - 1.416V1.3 Multijet 1.9 Multijet
Tank capacity 47 47 47
Reserve 5 - 7 5 - 7 5 - 7
Refuel petrol engines with unleaded petrol with an octane rating (RON) no lower than 95 only.
Refuel diesel engines with diesel fuel for motor vehicles (EN590 specifications) only.
Fiat Auto S.p.A.
Quality - Assistenza Tecnica - Ingegneria Assistenziale
Largo Senatore G. Agnelli, 5 - 10040 Volvera - Torino (Italia)
Print no. 603.81.169 - 01/2007 - 1
stedition
1.418V1.416V1.3 Multijet 1.9 Multijet
litres kg litres kg litres kg litres kg
Engine sump 2.4 2.1 2.5 2.2 2.85 2.5 4.2 3.75
Engine sump and filter 2.62.25 2.7 2.35 3.0 2.6 4.4 3.9
185/65 R14 86T 2,2 2,1 2,3 2,3
195/60 R15 88T 2,2 2,1 2,3 2,3
205/50 R16 87V 2,2 2,1 2,3 2,3
135/80 B14 84M 2,8SPARE WHEEL
125/80 R15 95M 4,2
Add +0.3 bar to the prescribed inflation pressure when the tyres are warm. Recheck pressure value with cold tyres.
With snow tyres, add +0.2 bar to the inflation pressure value prescribed for standard tyres.
