LAND ROVER DISCOVERY 2002 Owners Manual

TORQUE WRENCH SETTINGS
06-6
Engine management system - V8
Cooling system
Manifolds and exhaust systems - Td5
TORQUE DESCRIPTION METRIC IMPERIAL
Spark plugs20 Nm (15 lbf.ft)
Fuel tank cradle45 Nm (33 lbf.ft)
ECT sensor10 Nm (7 lbf.ft)
CKP sensor6 Nm (4.4 lbf.ft)
CMP sensor8 Nm (6 lbf.ft)
KS sensor22 Nm (16 lbf.ft)
Throttle body10 Nm (7 lbf.ft)
Plenum chamber22 Nm (16 lbf.ft)
Breather adaptor6 Nm (4.4 lbf.ft)
Throttle cable abutment bracket 10 Nm (7 lbf.ft)
TP sensor 2.2 Nm (1.6 lbf.ft)
IACV sensor8 Nm (6 lbf.ft)
HO
2S sensor45 Nm (33 lbf.ft)
Ignition coils8 Nm (6 lbf.ft)
Fuel rail9 Nm (7 lbf.ft)
TORQUE DESCRIPTION METRIC IMPERIAL
Cylinder block drain plug 30 Nm (22 lbf.ft)
Coolant pump24 Nm (18 lbf.ft)
Coolant pump pulley 22 Nm (16 lbf.ft)
Coolant pump cover - Td5 10 Nm (7 lbf.ft)
TORQUE DESCRIPTION METRIC IMPERIAL
Front pipe to turbocharger 27 Nm (20 lbf.ft)
Inlet manifold25 Nm (18 lbf.ft)
Tail pipe25 Nm (18 lbf.ft)
Fuel cooler25 Nm (18 lbf.ft)
EGR valve10 Nm (7 lbf.ft)
Exhaust manifold25 Nm (18 lbf.ft)
Exhaust manifold heatshield (M6) bolts 10 Nm (7 lbf.ft)
Exhaust manifold heatshield (M8) bolts 25 Nm (18 lbf.ft)
EGR pipe Allen screws 10 Nm (7 lbf.ft)

TORQUE WRENCH SETTINGS
06-7
Manifolds and exhaust systems - V8
Clutch
TORQUE DESCRIPTION METRIC IMPERIAL
Intermediate pipe/silencer nuts 25 Nm (18 lbf.ft)
Inlet manifold bolts - initial tighten 10 Nm (7 lbf.ft)
Inlet manifold gasket clamp bolts 18 Nm (13 lbf.ft)
Inlet manifold bolts - final tighten 51 Nm (38 lbf ft)
Tail pipe25 Nm (18 lbf.ft)
Coolant outlet pipe 22 Nm (16 lbf.ft)
Front pipe flange nuts 30 Nm (22 lbf.ft)
Exhaust manifold55 Nm (40 lbf.ft)
TORQUE DESCRIPTION METRIC IMPERIAL
Clutch bleed screw 9 Nm (7 lbf.ft)
Clutch cover nuts Td5 25 Nm (18 lbf.ft)
Clutch cover bolts V8 40 Nm (30 lbf.ft)
Clutch master cylinder to pedal box 25 Nm (18 lbf.ft)
Hydraulic pipe union 18 Nm (13 lbf.ft)
Clutch release bearing pivot point bolt 8 Nm (6 lbf.ft)
Slave cylinder25 Nm (18 lbf.ft)

TORQUE WRENCH SETTINGS
06-8
Manual gearbox - R380
Transfer box - LT230SE
Note: † New Patchlok nut must be fitted.
TORQUE DESCRIPTION METRIC IMPERIAL
Bias plate bolts25 Nm (18 lbf.ft)
Gearbox to engine bolts 45 Nm (33 lbf.ft)
Coolant pipe housing bolts 25 Nm (18 lbf.ft)
Breather pipe banjo bolt 15 Nm (11 lbf.ft)
Gear lever extension clamp bolt 25 Nm (18 lbf.ft)
Gearbox mounting bolts 85 Nm (63 lbf.ft)
Gearbox mounting nuts 48 Nm (37 lbf.ft)
Seal housing bolts 18 Nm (13 lbf.ft)
Bearing sleeve bolts 25 Nm (18 lbf.ft)
Fork bolt7 Nm (5.2 lbf.ft)
Reverse light switch 24 Nm (18 lbf.ft)
Extension housing bolts 25 Nm (18 lbf.ft)
Gear selector housing bolts 25 Nm (18 lbf.ft)
Oil pump to housing Torx screws 6 Nm (4.4 lbf.ft)
Gear change lever yoke Allen screw 25 Nm (18 lbf.ft)
5th gear stake nut 350 Nm (258 lbf.ft)
Spool retainer bolts 8 Nm (6 lbf.ft)
Centre plate detent spring and ball Torx screw 25 Nm (18 lbf.ft)
Selector lever to housing bolts 25 Nm (18 lbf.ft)
Clutch Bell housing bolts 73 Nm (54 lbf.ft)
TORQUE DESCRIPTION METRIC IMPERIAL
High/low selector cable 30 Nm (22 lbf.ft)
Bottom plate bolts 25 Nm (18 lbf.ft)
Transfer box to gearbox 45 Nm (33 lbf.ft)
Rear cover plate25 Nm (18 lbf.ft)
Differential lock warning lamp switch locknut - Up to 03 MY
11 Nm(8 lbf.ft)
Differential lock warning lamp switches - 03 MY onwards
25 Nm (18 lbf.ft)
Drive flange nut148 Nm (109 lbf.ft)
Output shaft housing 45 Nm (33 lbf.ft)
Oil temperature sensor 42 Nm (31 lbf.ft)
Inhibitor switch to transfer box 26 Nm (19 lbf.ft)
Intermediate shaft nut †88 Nm (65 lbf.ft)
Side cover bolts25 Nm (18 lbf.ft)
Bearing retaining nut 72 Nm (53 lbf.ft)
Output flange nut 162 Nm (119 lbf.ft)
Selector housing bolts 25 Nm (18 lbf.ft)
Bearing housing/cover bolts 25 Nm (18 lbf.ft)

TORQUE WRENCH SETTINGS
06-9
Automatic gearbox - ZF4HP22/24
Propeller shafts
Axles
TORQUE DESCRIPTION METRIC IMPERIAL
Selector lever to selector shaft nut 26 Nm (19 lbf.ft)
Starter inhibitor switch bolts 10 Nm (7 lbf.ft)
Engine to torque converter bolts - Td5 & V8 50 Nm (37 lbf.ft)
Closing plate to gearbox housing bolt - V8 7 Nm (5.2 lbf.ft)
Fluid pump to intermediate plate bolts 10 Nm (7 lbf.ft)
Intermediate plate Allen plugs (M14) 40 Nm (30 lbf.ft)
Intermediate plate Allen plugs (M20) 50 Nm (37 lbf.ft)
Oil cooler adaptors 42 Nm (31 lbf.ft)
Extension housing bolts 25 Nm (18 lbf.ft)
Oil sump to gearbox housing bolts 8 Nm (6 lbf.ft)
Oil filter Torx screws 8 Nm (6 lbf.ft)
Oil pick-up tube Torx screw 8 Nm (6 lbf.ft)
Parking pawl guide Torx screw 10 Nm (7 lbf.ft)
Pressure regulator to valve body assembly 8 Nm (6 lbf.ft)
Lock-up solenoid valve, retaining fork Torx screw 8 Nm (6 lbf.ft)
Lock-up solenoid valve assembly to valve body Torx screws 8 Nm (6 lbf.ft)
Gearbox bell housing (intermediate plate and converter housing to gearbox casing)
bolts46 Nm (34 lbf.ft)
Speed sensor bracket screws 8 Nm (6 lbf.ft)
TORQUE DESCRIPTION METRIC IMPERIAL
Propeller shaft to transfer gearbox 47 Nm (35 lbf.ft)
Propeller shaft to differential 47 Nm (35 lbf.ft)
Propeller shaft to flexible coupling 76 Nm (56 lbf.ft)
Flexible coupling to differential 76 Nm (56 lbf.ft)
TORQUE DESCRIPTION METRIC IMPERIAL
Differential to axle bolts 55 Nm (40 lbf.ft)
Hub to axle bolts 100 Nm (74 lbf.ft)
Pinion flange bolt 100 Nm (74 lbf.ft)
Drive shaft nut490 Nm (360 lbf.ft)

TORQUE WRENCH SETTINGS
06-10
Steering
TORQUE DESCRIPTION METRIC IMPERIAL
Drag link to drop arm 80 Nm (59 lbf.ft)
Track rod to steering knuckle 125 Nm (92 lbf.ft)
Tension collet to steering knuckle 5 Nm (3.7 lbf.ft)
Steering damper125 Nm (92 lbf.ft)
Steering knuckle to axle yoke upper ball joint 110 Nm (81 lbf.ft)
High pressure pipe union 20 Nm (15 lbf.ft)
Drag link/track rod M8 bolts 22 Nm (16 lbf.ft)
Drag link/track rod M10 bolts 33 Nm (24 lbf.ft)
Steering box90 Nm (66 lbf.ft)
Universal joint to intermediate shaft 25 Nm (18 lbf.ft)
Panhard rod230 Nm (170 lbf.ft)
Steering box output shaft 88 Nm (65 lbf.ft)
Drop arm240 Nm (177 lbf.ft)
Auxiliary housing bolts 40 Nm (30 lbf.ft)
Auxiliary housing nut 10 Nm (7 lbf.ft)
PAS pump - V822 Nm (16 lbf.ft)
PAS pump pipe bracket bolt 22 Nm (16 lbf.ft)
Jockey pulley bolt 50 Nm (37 lbf.ft)
PAS pump adaptor pipe 10 Nm (7 lbf.ft)
PAS pump to coolant pump bolts - Td5 25 Nm (18 lbf.ft)
Steering column to fascia 25 Nm (18 lbf.ft)
Universal joint to steering box 25 Nm (18 lbf.ft)
Ball joint to swivel hub 77 Nm (57 lbf.ft)
PAS pump pulley22 Nm (16 lbf.ft)
Steering wheel nut 43 Nm (32 lbf.ft)

TORQUE WRENCH SETTINGS
06-11
Front suspension
TORQUE DESCRIPTION METRIC IMPERIAL
Wheel nuts140 Nm (103 lbf.ft)
Panhard rod230 Nm (170 lbf.ft)
Lower ball joint nut 135 Nm (100 lbf.ft)
Track rod and drag link 80 Nm (59 lbf.ft)
Damper to front axle 55 Nm (40 lbf.ft)
Anti-roll bar link - upper 100 Nm (74 lbf.ft)
Anti-roll bar link - lower 100 Nm (74 lbf.ft)
Turret to chassis23 Nm (17 lbf.ft)
Radius arm230 Nm (170 lbf.ft)
ACE pump pulley 25 Nm (18 lbf.ft)
ACE pump banjo bolt 28 Nm (21 lbf.ft)
Valve block to chassis 18 Nm (13 lbf.ft)
Valve block clamping plate 21 Nm (15 lbf.ft)
ACE valve block pipe clip 6 Nm (4.4 lbf.ft)
ACE valve block filter cap 35 Nm (26 lbf.ft)
Pressure transducer 20 Nm (15 lbf.ft)
Fluid pipes to actuator cap 29 Nm (21 lbf.ft)
Banjo to pump bolt 28 Nm (21 lbf.ft)
Actuator to long arm 48 Nm (35 lbf.ft)
Actuator to short arm 180 Nm (133 lbf.ft)
Torsion bar clamp plate bolts 45 Nm (33 lbf.ft)
Long arm to torsion bar bolt 185 Nm (136 lbf.ft)

TORQUE WRENCH SETTINGS
06-12
Rear suspension
Brakes
TORQUE DESCRIPTION METRIC IMPERIAL
Wheel nuts140 Nm (103 lbf.ft)
Wheel hub to axle 100 Nm (74 lbf.ft)
Damper to axle125 Nm (92 lbf.ft)
SLS height sensor link to radius arm 25 Nm (18 lbf.ft)
Radius arm230 Nm (170 lbf.ft)
Transverse links to pivot housing 155 Nm (114 lbf.ft)
Pivot housing to axle bolts 230 Nm (170 lbf.ft)
Transverse link to chassis 140 Nm (103 lbf.ft)
SLS height sensor 6 Nm (4.4 lbf.ft)
SLS compressor25 Nm (18 lbf.ft)
ACE actuator to short arm 185 Nm (136 lbf.ft)
ACE actuator to long arm 48 Nm (35 lbf.ft)
ACE actuator pipe cap nuts 29 Nm (21 lbf.ft)
Anti-roll bar link - upper 50 Nm (37 lbf.ft)
Anti-roll bar link - lower 100 Nm (74 lbf.ft)
ACE long arm to torsion bar 180 Nm (133 lbf.ft)
TORQUE DESCRIPTION METRIC IMPERIAL
Brake caliper bleed screw 10 Nm (7 lbf.ft)
Brake disc to drive flange 13 Nm (10 lbf.ft)
Caliper bolts - Front 175 Nm (129 lbf.ft)
Caliper bolts - Rear 95 Nm (70 lbf.ft)
Master cylinder to servo 25 Nm (18 lbf.ft)
Master cylinder brake pipe, unions 25 Nm (18 lbf.ft)
Brake caliper pivot bolt 30 Nm (22 lbf.ft)
Vacuum pump8 Nm (6 lbf.ft)
Vacuum pump lubrication pipe union 10 Nm (7 lbf.ft)
Brake caliper guide pin bolts 30 Nm (22 lbf.ft)
Brake caliper banjo bolt 32 Nm (24 lbf.ft)
ABS modulator to mounting bracket nuts 9 Nm (7 lbf.ft)
ABS modulator - 13 mm unions 22 Nm (16 lbf.ft)
ABS modulator - 11 mm union 14 Nm (10 lbf.ft)
Handbrake lever to floor bolts 22 Nm (16 lbf.ft)

TORQUE WRENCH SETTINGS
06-13
Restraint systems
TORQUE DESCRIPTION METRIC IMPERIAL
Front seat belt upper anchorage 32 Nm (24 lbf.ft)
Front seat belt reel 50 Nm (37 lbf.ft)
Front seat belt lower anchorage to seat 32 Nm (24 lbf.ft)
Second row upper anchorage 50 Nm (37 lbf.ft)
Second row seat belt reel 32 Nm (24 lbf.ft)
Second row lower anchorage 32 Nm (24 lbf.ft)
Third row upper anchorage 50 Nm (37 lbf.ft)
Third row seat belt reel 50 Nm (37 lbf.ft)
Third row lower anchorage 32 Nm (24 lbf.ft)
'B' post adjustable seat belt mounting 22 Nm (16 lbf.ft)
Seat belt pre-tensioners 32 Nm (24 lbf.ft)
Driver's side air bag 9 Nm (7 lbf.ft)
Passenger side air bag 8 Nm (6 lbf.ft)
SRS DCU10 Nm (7 lbf.ft)

TORQUE WRENCH SETTINGS
06-14
Body
TORQUE DESCRIPTION METRIC IMPERIAL
Front and rear door hinges 30 Nm (22 lbf.ft)
Tail door hinge bolts 34 Nm (25 lbf.ft)
Door frames10 Nm (7 lbf.ft)
Regulator to glass 6 Nm (4.4 lbf.ft)
Chassis cross member 25 Nm (18 lbf.ft)
Bulkhead to chassis bolts 45 Nm (33 lbf.ft)
Body to chassis bolts 45 Nm (33 lbf.ft)
Quarter light glass to frame 10 Nm (7 lbf.ft)
Glass lift motor to regulator 5 Nm (3.7 lbf.ft)
Tail door hand rail 10 Nm (7 lbf.ft)
Latch and motor assembly 7 Nm (5.2 lbf.ft)
Door handle7 Nm (5.2 lbf.ft)
Damper to step17 Nm (13 lbf.ft)
Throttle pedal assembly 13 Nm (10 lbf.ft)
Step assembly to chassis 45 Nm (33 lbf.ft)
Wing to sill finisher bracket 17 Nm (13 lbf.ft)
Front wing to body 17 Nm (13 lbf.ft)
Door mirror4 Nm (3 lbf.ft)
Roof bars32 Nm (24 lbf.ft)
Bonnet release lever 10 Nm (7 lbf.ft)
Front bumper to crash cans 13 Nm (10 lbf.ft)
Front bumper to side mountings 13 Nm (10 lbf.ft)
Mudshield10 Nm (7 lbf.ft)
Rear bumper45 Nm (33 lbf.ft)
Grab handle to body 3 Nm (2.2 lbf.ft)
Fascia26 Nm (19 lbf.ft)
Fascia to steering column bracket 11 Nm (8 lbf.ft)
Front seat to floor 45 Nm (33 lbf.ft)
Second row seats to floor 45 Nm (33 lbf.ft)
Third row seats to lower rear quarter 22 Nm (16 lbf.ft)
Sunroof tray to frame 2 Nm (1.5 lbf.ft)
Solenoid securing cap 11 Nm (8 lbf.ft)
Support stay to alternator 25 Nm (18 lbf.ft)
Sunroof glass3 Nm (2.2 lbf.ft)
Motor to sunroof tray 2 Nm (1.5 lbf.ft)
Drive cable assembly to frame 2.5 Nm (1.8 lbf.ft)
Front and rear door striker bolts 26 Nm (19 lbf.ft)
Tail door striker bolts 26 Nm (19 lbf.ft)

TORQUE WRENCH SETTINGS
06-15
Heating and air conditioning
Wipers and washers
Electrical
TORQUE DESCRIPTION METRIC IMPERIAL
Heater assembly16 Nm (12 lbf.ft)
Compressor bolts 22 Nm (16 lbf.ft)
Blower motor19 Nm (14 lbf.ft)
Compressor to mounting bracket bolts 25 Nm (18 lbf.ft)
A/C pipes to compressor bolts 10 Nm (7 lbf.ft)
Condenser pipe bolt 5 Nm (3.7 lbf.ft)
Receiver drier to bracket bolts 5 Nm (3.7 lbf.ft)
Adaptor block to receiver drier bolt 5 Nm (3.7 lbf.ft)
Evaporator pipe bolts 5 Nm (3.7 lbf.ft)
Dual pressure switch to receiver drier 10 Nm (7 lbf.ft)
Air conditioning pipes to receiver drier bolts 5 Nm (3.7 lbf.ft)
TX valve pressure pipe union 22 Nm (16 lbf.ft)
Evaporator pipe to TXV valve 32 Nm (24 lbf.ft)
Evaporator assembly to body bolts 16 Nm (12 lbf.ft)
High and low pressure pipe, bolts 10 Nm (7 lbf.ft)
Fuel burning heater Torx bolts 25 Nm (18 lbf.ft)
TORQUE DESCRIPTION METRIC IMPERIAL
Link to motor spindle 7 Nm (5.2 lbf.ft)
Front motor assembly 2.5 Nm (1.8 lbf.ft)
Spindle nut 3 Nm (2.2 lbf.ft)
Wiper arm nut13 Nm (10 lbf.ft)
TORQUE DESCRIPTION METRIC IMPERIAL
Alternator support stay 25 Nm (18 lbf.ft)
Alternator lead - Td5 6 Nm (4.4 lbf.ft)
Auxiliary drive belt tensioner bolt 50 Nm (37 lbf.ft)
Alternator pulley80 Nm (59 lbf.ft)
Alternator B+ nut - V8 18 Nm (13 lbf.ft)
Alternator B+ nut - V8 5 Nm (3.7 lbf.ft)
Starter motor - Td5 27 Nm (20 lbf.ft)
Starter motor solenoid 10 Nm (7 lbf.ft)
Starter motor - V8 44 Nm (32 lbf.ft)
Alternator45 Nm (33 lbf.ft)
Starter motor heat shield - V8 10 Nm (7 lbf.ft)
Horn13 Nm (10 lbf.ft)
Battery carrier bolts 28 Nm (21 lbf.ft)
