ECU LAND ROVER DISCOVERY 2002 Workshop Manual

MANUAL GEARBOX - R380
REPAIRS 37-23
5.Release oil cooler from location on radiator,
and remove the oil cooler.
CAUTION: Always fit plugs to open
connections to prevent contamination.
Refit
1.Fit oil cooler to radiator and secure with screw.
2.Ensure connections are clean and secure
hoses to cooler.
3.Fit intercooler.

+ ENGINE MANAGEMENT SYSTEM -
Td5, REPAIRS, Intercooler.
4.Top up gearbox oil level.

+ MAINTENANCE, PROCEDURES,
Manual gearbox.
Cooler - oil - gearbox - V8
$% 37.24.02
Remove
1. If fitted: Remove engine oil cooler.

+ ENGINE - V8, REPAIRS, Cooler -
engine oil.
2.Position absorbent cloth under each gearbox
oil cooler hose connection to collect spillage.
3.Push against coupling release rings and
disconnect both hoses from oil cooler.
CAUTION: Always fit plugs to open
connections to prevent contamination.
4.Remove screw securing oil cooler to radiator.
5.Release oil cooler from its location on radiator.

MANUAL GEARBOX - R380
37-24 REPAIRS
6.Move radiator towards engine sufficiently only
to release gearbox oil cooler from radiator.
7.Remove gearbox oil cooler.
CAUTION: Always fit plugs to open
connections to prevent contamination.
Refit
1.Fit gearbox oil cooler to radiator, engage in
location and secure with screw.
2.Ensure connections are clean and secure
hoses to cooler.
3. If fitted: Fit engine oil cooler.

+ ENGINE - V8, REPAIRS, Cooler -
engine oil.
4.Top up gearbox oil.

+ MAINTENANCE, PROCEDURES,
Manual gearbox.
Switch - Reverse light
$% 37.27.01
Remove
1.Raise vehicle on ramp.
2.Disconnect reverse lamp switch multiplug.
3.Remove switch and collect sealing washer.
Refit
1.Clean switch and mating face on gearbox.
2.Using a new sealing washer, fit the reverse light
switch and tighten to 24 Nm (17 lbf.ft).
3.Connect switch multiplug.
4.Lower vehicle.

MANUAL GEARBOX - R380
OVERHAUL 37-29
20.Check end float of 3rd gear between gear and
flange on output shaft:
lNew = 0.11 - 0.21 mm (0.004 - 0.0083 in)
lService limit = 0.337 mm (0.013 in)
21.Check output shaft and layshaft end float as
follows.
22.The end float setting for both shafts is:
lNew = 0.00 to 0.05 mm (0.0 to - 0.002 in)
lService limit = 0.05 mm (0.002 in)
23.Fit front cover to gearbox case without the oil
seal and tighten bolts by diagonal selection to
25 Nm (18 lbf.ft).
24.Position in vice with front cover facing
downwards.
25.Fit input shaft to gearbox case less 4th gear
baulk ring.
26.Fit output shaft assembly to input shaft.
27.Fit output shaft bearing track and shim to centre
plate.
28.Fit centre plate to gearbox case and secure
using 8 slave bolts.
29.Rotate output shaft to settle bearings.
30.Fit a suitably large ball bearing into end of
output shaft.
31.Position a suitable DTI and zero probe on ball
bearing.
32.Lift output shaft and note DTI reading.
33.If reading is incorrect, dismantle and fit shim to
give correct end float.
34.Repeat above procedure.
35.Repeat procedure for layshaft end float.
36.Remove and discard 6 bolts and remove
gearbox front cover.
37.Fit gearbox selector fork - set.

+ MANUAL GEARBOX - R380,
OVERHAUL, Fork - set - selector shaft.
38.Fit gearbox front cover.

+ MANUAL GEARBOX - R380,
OVERHAUL, Cover - front.
Synchroniser - gearbox - set
$% 37.20.07
Disassembly
1.Remove gearbox selector fork set.

+ MANUAL GEARBOX - R380,
OVERHAUL, Fork - set - selector shaft.
2.Using tool LRT-99-002 and support bars
under 1st gear, press output shaft bearing from
output shaft.
3.Remove 1st gear, bearing collar, needle roller
bearing and synchromesh rings.
4.Noting its fitted position, remove 1st / 2nd gear
synchroniser hub, 2nd gear synchromesh
rings, 2nd gear and needle roller bearing.

MANUAL GEARBOX - R380
OVERHAUL 37-35
Extension - gearbox rear
$% 37.12.01
Disassembly
1.Remove 4 bolts and remove gear selector
housing.
2.Using tools LRT-37-009, LRT-37-001/2 and
LRT-37-010 , remove output shaft oil seal
collar.3.Remove bolt securing interlock spool retainer
and discard 'O' ring.
4.Noting fitted position of 2 longest bolts, remove
10 bolts securing extension housing to
gearbox.
5.Remove extension housing from gearbox
centre plate.

MANUAL GEARBOX - R380
37-36 OVERHAUL
6.Fit 2 off 8x35 mm slave bolts to secure centre
plate to gearbox casing.
7.Remove 3 Torx screws, remove oil pump and
discard 'O' ring.
8.Drift out layshaft support bearing.
9.Remove and discard output shaft rear oil seal.
10.Remove oil pick-up pipe.
11.Drift out output shaft support bearing and oil
pick-up ring.
12.Remove reverse inhibitor shaft, cam and
spring. 13.Remove 2 bolts and remove gate plate.
14.Remove reverse light switch and discard
sealing washer.
15.Remove 2 bolts, remove oil cooler by-pass and
discard 'O' rings.
Reassembly
1.Clean extension housing and mating faces.
2.Clean oil cooler by-pass.
3.Using new 'O' rings, fit oil cooler by-pass and
tighten bolts to 15 Nm (11 lbf.ft).
4.Using new sealing washer, fit reverse light
switch and tighten to 24 Nm (17 lbf.ft).
5.Fit reverse inhibitor spring and cam.
6.Clean threads of reverse inhibitor shaft and
gate plate bolts.
7.Apply Loctite 290 to threads of reverse inhibitor
shaft, fit and tighten shaft.
8.Apply Loctite 290 to threads of gate plate bolts.
9.Position gate plate and tighten bolts to 15 Nm
(11 lbf.ft).
10.Fit output shaft support bearing and oil pick-up
ring. Align tag with centre of drain slot.
11.Fit layshaft support bearing.
12.Fit new output shaft oil seal using tool LRT-37-
014.

MANUAL GEARBOX - R380
OVERHAUL 37-37
13.Fit oil pick-up pipe with the off-set uppermost.
14.Lubricate oil pump recess with gearbox oil.
15.Lubricate a new 'O' ring with gearbox oil and fit
to oil pump.
16.Locate oil pump in extension housing with word
'TOP' towards top of housing.
17.Align oil pump fixing screw holes and tap pump
lightly around edges until it is fully in recess.
Do not attempt to pull pump into recess
using fixing screws.
18.Fit Torx screws and tighten to 6 Nm (4.5 lbf.ft).
19.Remove 2 slave bolts securing centre plate to
gearbox casing.
20.Apply sealant, Part No. STC 3254 to gearbox
casing face.
21.Position extension housing, align oil pump drive
with layshaft.
22.Clean extension housing bolt threads.
23.Apply Loctite 290 to threads of extension
housing bolts, fit bolts ensuring 2 longest bolts
are in their original positions and tighten by
diagonal selection to 25 Nm (18 lbf.ft).
24.Using new 'O' ring, fit interlock spool retainer
and tighten bolt to 8 Nm (6 lbf.ft).
25.Using tool LRT-37-015 and LRT-37-021, fit oil
seal collar.
26.Clean gear selector selector housing and
mating face.
27.Apply sealant, Part No. STC 3254 to gear
selector housing face.
28.Position gear selector housing and tighten
bolts to 25 Nm (18 lbf.ft).
Pump - gearbox oil
$% 37.12.47
Disassembly
1.Remove gearbox extension.

+ MANUAL GEARBOX - R380,
OVERHAUL, Extension - gearbox rear.
2.Remove 3 Torx screws, remove oil pump and
discard 'O' ring.
Reassembly
1.Clean oil pump recess in extension housing,
ensure screw holes are clean and dry.
2.Lubricate oil pump recess in housing with
gearbox oil.
3.Lubricate a new 'O' ring with gearbox oil and fit
to oil pump.
4.Locate oil pump in extension housing with word
'TOP' towards top of housing.
5.Align fixing screw holes and tap pump lightly
around edges until pump is fully in housing. Do
not pull pump into housing by tightening
screws.
6.Fit Torx screws and tighten to 6 Nm (4.5 lbf.ft).
7.Fit gearbox extension.

+ MANUAL GEARBOX - R380,
OVERHAUL, Extension - gearbox rear.

MANUAL GEARBOX - R380
OVERHAUL 37-39
Reassembly
1.Clean gears and shafts.
2.Position 5th gear and baulk ring to output shaft.
3.Using tool LRT-37-015 and LRT-37-021, fit
support bearing track to output shaft.
4.Fit 5th gear - layshaft.

+ MANUAL GEARBOX - R380,
OVERHAUL, 5th gear - layshaft.
Synchronizer assembly - 5th/reverse
$% 37.20.38
Disassembly
1.Remove gearbox rear extension.

+ MANUAL GEARBOX - R380,
OVERHAUL, Extension - gearbox rear.
2.Remove 5th gear set.

+ MANUAL GEARBOX - R380,
OVERHAUL, Gear - 5th gear set.
3.Remove split needle roller bearing from output
shaft.
4.Remove and discard Allen screw and remove
gear change yoke.
5.Remove and discard circlip securing 5th/
reverse synchronizer hub to output shaft.
6.Remove synchronizer hub and selector fork
assembly.

MANUAL GEARBOX - R380
OVERHAUL 37-41
5.Remove retaining ring and split collars
securing 5th gear to output shaft.
6.Remove split collar and 5th gear from layshaft. Reassembly
1.Clean gear and layshaft.
2.Position 5th gear and split collar to layshaft
ensuring that bevelled side of collar is towards
5th gear.
3.Position split collars and retaining ring securing
5th gear to output shaft.
4.Position tool LRT-37-023 to hold 5th gear and
tighten new stake nut to 220 Nm (162 lbf.ft) and
stake nut.
5.Apply a small amount of heat and fit support
bearing track to layshaft.
6.Fit gearbox extension.

+ MANUAL GEARBOX - R380,
OVERHAUL, Extension - gearbox rear.

MANUAL GEARBOX - R380
OVERHAUL 37-45
5.Remove 2 bolts securing spool retainer to
gearbox case. Remove retainer, remove and
discard 'O' ring - if fitted.
6.Remove interlock spool from selector shaft.
7.Remove filter from gearbox case.
8.Align selector shaft pin with slot in centre plate
and using wooden blocks and hide mallet,
release centre plate and collect lower detent
ball and spring. 9.Press out reverse idler shaft using a suitable
press.
10.Remove idler gear, needle roller bearing and
spacer.
Reassembly
1.Clean centre plate and reverse gear
components.
2.Lubricate gearbox components with clean gear
oil.
3.Position idler gear, bearing and spacer to idler
shaft.
4.Using a suitable press fit idler shaft to centre
plate.
5.Using feeler gauges, check clearance between
reverse idler and shaft flange; fit a thicker or
thinner spacer if necessary in order to achieve
correct clearance:
lNew clearance = 0.04 - 0.38 mm (0.002 -
0.015 in)
lService limit = 0.38 mm (0.015 in)
6.Apply sealant, Part No. STC 3254 to gearbox
casing.
7.Fit lower spring and detent ball into centre
plate, retain using a dummy shaft.
8.Align selector shaft pin with slot in centre plate.
9.Fit centre plate and fit 2 off 8x35 mm slave bolts
to retain centre plate in position on gearbox
case; recover dummy shaft.

MANUAL GEARBOX - R380
OVERHAUL 37-47
Lever - gear change
$% 37.16.04
Disassembly
1.Remove gear selector housing.

+ MANUAL GEARBOX - R380,
OVERHAUL, Housing - gear selector
mechanism.
2.Restrain right hand bias spring using a suitable
pair of grips.
3.Remove 2 bolts securing right hand side of bias
spring adjustment plate.
4.Repeat operations for left hand bias spring.
5.Remove bias springs and adjustment plate.6.Remove lower gear lever.
7.Remove and discard Railko bush.
8.Remove and discard oil seal from housing.
Reassembly
1.Clean components.
2.Apply multi-purpose grease to ball and cross
pins.
3.Apply multi-purpose to new Railko bush and fit
to housing ensuring that slots are correctly
aligned.
4.Lubricate a new seal with gearbox oil and fit, lip
side towards housing using a suitable mandrel.
5.Position lower gear lever to selector housing
ensuring cross pins are located in Railko bush.
6.Position bias spring adjustment plate to
selector housing.
7.Clean threads of bias spring adjustment plate
bolts and apply Loctite 290 to threads.
8.Fit 2 short bolts to secure front of adjustment
plate and tighten to 25 Nm (18 lbf.ft).
9.Position right hand bias spring to pillar ensuring
longest end of spring is against gear lever.
10.Restrain bias spring using a suitable pair of
grips, ensure shortest end of spring is on
outside edge of bolt hole.
