Technical specificationsENGINE SPECIFICATIONS
Data Petrol
Number of cylinders 6 Displacement cc's 3192
Firing order 1-5-3-6-2-4
Compression ratio 10.8:1
Power output kW (PS) 171 (233) at 6300 rpm
Maximum torque Nm 317 at 3200 rpm
Data Diesel Diesel with DPF
Number of cylinders 4 4 Displacement cc's 2179 2179 Firing order 1-3-4-2 1-3-4-2
Compression ratio 16.5:1 16.5:1
Power output kW (PS) 118 (160) at 4000 rpm Belgium 110 (150) at 4000
rpm 112 (152) at 4000 rpm
Belgium 110 (150) at 4000 rpm
Maximum torque Nm 400 at 2000 rpm 400 at 2000 rpm

Technical specifications
212
L
WEIGHTS
¹ This figure includes the tool kit, all fluids to
the correct levels, and spare wheel, but
excludes the driver and passengers.
² The maximum permissi ble weight of the
vehicle including passengers and load. ³ The maximum permissi
ble weight of the
vehicle and braked trailer including their
respective loads.
Note: ¹ The front and rear axle maximum loads
can not be reached simult aneously as this will
exceed the GVW limit.
² This figure includes the weight of the roof
rack. Variant Approximate unladen
weight¹ Gross Vehicle Weight
(GVW)² Gross Train Weight³
Petrol 1825 kg 4020 lbs 2505 kg
5520 lbs 4505 kg
9930 lbs
Diesel 1820 kg 4010 lbs 2505 kg
5520 lbs 4505 kg
9935 lbs
Variant Maximum front axle load¹ Maximum rear
axle load¹ Maximum roof
rack load² Maximum
payload
Petrol and Diesel 1310 kg 2885 lbs 1360 kg
2995 lbs 75 kg
165 lbs 500 kg
1100 lbs

213
Technical specifications
R
DIMENSIONS
2
E8238416
5
438
7
Item Description mm/inches Degrees 1 Width 2180/85.7 -
1 Width with mirrors folded 2005/78.8 -
2 Maximum height (inc roof rails) 1820/71.6 -
3 Approach angle - 31°
4 Breakover angle - 157°
5 Wheelbase 2660/104.7 -
6 Length excluding number plate plinth 4500/177.1 -
7 Track - front 1601/63 -
7 Track - rear 1614/63.5 -
8 Departure angle without tow hitch - 34°
8 Departure angle with detachable tow ball - 18°
- Turning circle (kerb to kerb) 11.3m/37.1ft -
- Maximum wading depth 500/19.7 -

Technical specifications
214
L
Wheel alignment data (China only)
Clutch and brake pedal travel (China
only)
The clutch and brake pedal travel are set at the
factory and non-adjustable. Wheel alignment -
front Wheel alignment -
rear Camber - front Camber - rear Castor - front and
rear
+0.30° +0.46° -0.5° -1.95° Non-adjustable

215
Type approval
R
Type approvalDeclarations of conformity
E84189

Type approval
216
L
E84190

217
Type approval
R
E84303

Audio introduction
218
L
Audio introductionRADIO RECEPTION
Some interference is to be expected from time
to time during a journey. Occasionally it may be
necessary to retune the audio unit to offset the
effects of moving from one transmitter area to
another.
While Radio Data System (RDS) automatic
retuning helps to reduce the effects of signal
changes, some manual retuning may still be
required (especially for lo cal stations) in areas
of weak reception.
FM Signals travel in a straight line so large
obstacles, such as tall buildings, can shield the
vehicle from the signal, causing distortion or
loss of reception (known as dead spots).
Distortion can also occur if FM signals received
directly from the transmitter, mix with signals
deflected by obstructions such as mountains,
hills and tall buildin gs. This is known as
multi-path distortion.
Note: Although distortion, interference and
lack of signal clarity are sometimes attributed
to a fault in the radio, this is rarely the case.
E81779

219
Audio unit overview
R
Audio unit overviewAUDIO UNIT OVERVIEW
Premium audio overview
1. On or off and volume control
• Press to switch on or off
• Rotate to adjust volume
2. Information display screen
3. Rearward search or previous track button
• Radio station automatic rearward search
• Compact disc previous track or
beginning of track
4. Manual tuning or review button
• Radio station manual rearward search
• Compact disc rearward search (review)
5. Compact disc eject button
6. Manual tuning or cue button
• Radio station manual forward search
• Compact disc forward search (cue)
7. Forward search or next track button
• Radio station automatic forward search
• Compact disc next track
8. Compact disc slot 9.
Compact disc player or AUX mode button
10. Telephone mode button
11. Audio MENU button:
• FM settings
• Clock
• CD settings
• Random
• AUX settings
12. EXIT button
13. Audio MENU control
• Rotate to scroll through options
• Press to enable or disable the function
14. SCAN button
• Press during CD play to listen to the first
10 seconds of each track
15. Input keypad
16. AUTO button
• Press to automatically store radio
stations
TA
NEWSPTY100.7
FM1
14 : 54
HEART FM
1234 6
2
E83108
34567
9
21
11
12
10
13141516
17
18
19
20
8

Audio unit overview
220
L
17. INFO button
• Press and release for traffic
announcements
• Press and hold for news
announcements
18. Tone and volume settings button
• Press and release for tone settings menu
• Press and hold for volume settings
menu
19. AM waveband button
20. FM waveband button
