411-1. For safe use
1
CT200h_OM_OM76102E_(EE)
For safety and security
Push the seat belt shoulder
anchor down while pressing the
release button.
Push the seat belt shoulder
anchor up.
Move the height adjuster up and
down as needed until you hear a
click.
The pretensioners help the seat belts
to quickly restrain the occupants by
retracting the seat belts when the
vehicle is subjected to certain types
of severe frontal or side collision.
The pretensioners do not activate in
the event of a minor frontal impact, a
minor side impact, a rear impact or a
vehicle rollover.
If the system determines that a collision is unavoidable, the front seat
belts will retract before the collision. (P. 273)
Adjusting the seat belt shoulder anchor height (front seats)
Release but-
1
2
Seat belt pretensioners (front seats)
Pre-crash seat belts (front seats of vehicles with pre-crash safety
system)

421-1. For safe use
CT200h_OM_OM76102E_(EE)
Store the buckle into the storage
location in the seat cushion.
Emergency locking retractor (ELR)
The retractor will lock the belt during a sudden stop or on impact. It may also
lock if you lean forward too quickly. A slow, easy motion will allow the belt to
extend so that you can move around fully.
Child seat belt usage
The seat belts of your vehicle were principally designed for persons of adult size.
Use a child restraint system appropriate for the child, until the child becomes
large enough to properly wear the vehicle’s seat belt. (P. 5 9 )
When the child becomes large enough to properly wear the vehicle’s seat belt,
follow the instructions regarding seat belt usage. (P. 40)
Replacing the belt after the pretensioner has been activated
If the vehicle is involved in multiple collisions, the pretensioner will activate for
the first collision, but will not activate for the second or subsequent collisions.
Seat belt regulations
If seat belt regulations exist in the country where you reside, please contact any
authorized Lexus dealer or repairer, or another duly qualified and equipped pro-
fessional for seat belt replacement or installation.
After using the rear center seat belt

431-1. For safe use
1
CT200h_OM_OM76102E_(EE)
For safety and security
WA R N I N G
Observe the following precautions to reduce the risk of injury in the event of sud-
den braking, sudden swerving or an accident.
Failing to do so may cause death or serious injury.
Wearing a seat belt
Ensure that all passengers wear a seat belt.
Always wear a seat belt properly.
Each seat belt should be used by one person only. Do not use a seat belt for
more than one person at once, including children.
Lexus recommends that children be seated in the rear seat and always use a
seat belt and/or an appropriate child restraint system.
To achieve a proper seating position, do not recline the seat more than neces-
sary. The seat belt is most effective when the occupants are sitting up straight
and well back in the seats.
Do not wear the shoulder belt under your arm.
Always wear your seat belt low and snug across your hips.
Pregnant women
People suffering illness
Obtain medical advice and wear the seat belt in the proper way. (P. 40)
Obtain medical advice and wear the seat
belt in the proper way. (P. 40)
Women who are pregnant should position
the lap belt as low as possible over the hips
in the same manner as other occupants,
extending the shoulder belt completely
over the shoulder and avoiding belt contact
with the rounding of the abdominal area.
If the seat belt is not worn properly, not
only the pregnant woman, but also the
fetus could suffer death or serious injury as
a result of sudden braking or a collision.

441-1. For safe use
CT200h_OM_OM76102E_(EE)
WA R N I N G
When children are in the vehicle
Do not allow children to play with the seat belt. If the seat belt becomes twisted
around a child’s neck, it may lead to choking or other serious injuries that could
result in death.
If this occurs and the buckle cannot be unfastened, scissors should be used to
cut the belt.
Seat belt pretensioners
If the pretensioner has activated, the SRS warning light will come on. In that
case, the seat belt cannot be used again and must be replaced at any authorized
Lexus dealer or repairer, or another duly qualified and equipped professional.
Adjustable shoulder anchor
Always make sure the shoulder belt is positioned across the center of your
shoulder. The belt should be kept away from your neck, but not falling off your
shoulder. Failure to do so could reduce the amount of protection in an accident
and cause death or serious injuries in the event of a sudden stop, sudden swerve
or accident. (P. 4 1 )
Seat belt damage and wear
Do not damage the seat belts by allowing the belt, plate, or buckle to be
jammed in the door.
Inspect the seat belt system periodically. Check for cuts, fraying, and loose
parts. Do not use a damaged seat belt until it is replaced. Damaged seat belts
cannot protect an occupant from death or serious injury.
Ensure that the belt and plate are locked and the belt is not twisted.
If the seat belt does not function correctly, immediately contact any autho-
rized Lexus dealer or repairer, or another duly qualified and equipped profes-
sional.
Replace the seat assembly, including the belts, if your vehicle has been
involved in a serious accident, even if there’s no obvious damage.
Do not attempt to install, remove, modify, disassemble or dispose of the seat
belts. Have any necessary repairs carried out by any authorized Lexus dealer
or repairer, or another duly qualified and equipped professional. Inappropriate
handling may lead to incorrect operation.

451-1. For safe use
1
For safety and security
CT200h_OM_OM76102E_(EE)
SRS airbags
SRS front airbags
SRS driver airbag/front passenger airbag
Can help protect the head and chest of the driver and front passenger
from impact with interior components
SRS knee airbags
Can help provide driver and front passenger protection
SRS side and curtain shield airbags
SRS side airbags
Can help protect the torso of the front seat occupants
SRS curtain shield airbags
Can help protect primarily the head of occupants in the outer seats
The SRS airbags inflate when the vehicle is subjected to certain types of
severe impacts that may cause significant injury to the occupants. They
work together with the seat belts to help reduce the risk of death or seri-
ous injury.
1
2
3
4

461-1. For safe use
CT200h_OM_OM76102E_(EE)
The main SRS airbag system components are shown above. The SRS air-
bag system is controlled by the airbag sensor assembly. As the airbags
deploy, a chemical reaction in the inflators quickly fills the airbags with
non-toxic gas to help restrain the motion of the occupants.
SRS airbag system components
Front passenger airbag
“PASSENGER AIR BAG” indi-
cator
Side airbags
Curtain shield airbags
Side impact sensors (rear)
SRS warning light
Driver airbag
Side impact sensors (front)Seat belt pretensioners
Driver’s seat belt buckle switch
Driver’s seat position sensor
Knee airbags
Front impact sensors
Airbag sensor assembly
Airbag manual on-off switch1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

471-1. For safe use
1
CT200h_OM_OM76102E_(EE)
For safety and security
WA R N I N G
SRS airbag precautions
Observe the following precautions regarding the SRS airbags.
Failure to do so may cause death or serious injury.
The driver and all passengers in the vehicle must wear their seat belts prop-
erly.
The SRS airbags are supplemental devices to be used with the seat belts.
The SRS driver airbag deploys with considerable force, and can cause death
or serious injury especially if the driver is very close to the airbag.
Since the risk zone for the driver’s airbag is the first 50 - 75 mm (2 - 3 in.) of
inflation, placing yourself 250 mm (10 in.) from your driver airbag provides
you with a clear margin of safety. This distance is measured from the center
of the steering wheel to your breastbone. If you sit less than 250 mm (10 in.)
away now, you can change your driving position in several ways:
• Move your seat to the rear as far as you can while still reaching the pedals
comfortably.
• Slightly recline the back of the seat. Although vehicle designs vary, many
drivers can achieve the 250 mm (10 in.) distance, even with the driver seat
all the way forward, simply by reclining the back of the seat somewhat. If
reclining the back of your seat makes it hard to see the road, raise yourself
by using a firm, non-slippery cushion, or raise the seat if your vehicle has
that feature.
• If your steering wheel is adjustable, tilt it downward. This points the airbag
toward your chest instead of your head and neck.
The seat should be adjusted as recommended above, while still maintaining
control of the foot pedals, steering wheel, and your view of the instrument
panel controls.
The SRS front passenger airbag also deploys with considerable force, and can
cause death or serious injury especially if the front passenger is very close to
the airbag. The front passenger seat should be as far from the airbag as possi-
ble with the seatback adjusted, so the front passenger sits upright.
Improperly seated and/or restrained infants and children can be killed or seri-
ously injured by a deploying airbag. An infant or child who is too small to use
a seat belt should be properly secured using a child restraint system. Lexus
strongly recommends that all infants and children be placed in the rear seats
of the vehicle and properly restrained. The rear seats are safer for infants and
children than the front passenger seat. (P. 59)

481-1. For safe use
CT200h_OM_OM76102E_(EE)
WA R N I N G
SRS airbag precautions
Do not sit on the edge of the seat or lean
against the dashboard.
Do not allow a child to stand in front of
the SRS front passenger airbag unit or sit
on the knees of a front passenger.
Do not allow the front seat occupants to
hold items on their knees.
Do not lean against the door, the roof side
rail or the front, side and rear pillars.
Do not allow anyone to kneel on the pas-
senger seat toward the door or put their
head or hands outside the vehicle.

491-1. For safe use
1
CT200h_OM_OM76102E_(EE)
For safety and security
WA R N I N G
SRS airbag precautions
Do not hang coat hangers or other hard objects on the coat hooks. All of these
items could become projectiles and may cause death or serious injury, should
the SRS curtain shield airbags deploy.
If a vinyl cover is put on the area where the SRS knee airbag will deploy, be
sure to remove it.
Do not use seat accessories which cover the parts where the SRS side airbags
inflate as they may interfere with inflation of the airbags. Such accessories
may prevent the side airbags from activating correctly, disable the system or
cause the side airbags to inflate accidentally, resulting in death or serious
injury.
Do not strike or apply significant levels of force to the area of the SRS airbag
components.
Doing so can cause the SRS airbags to malfunction.
Do not touch any of the component parts immediately after the SRS airbags
have deployed (inflated) as they may be hot.
Do not attach anything to or lean any-
thing against areas such as the dashboard,
steering wheel pad and lower portion of
the instrument panel.
These items can become projectiles when
the SRS driver, front passenger and knee
airbags deploy.
Do not attach anything to areas such as a
door, windshield glass, side door glass,
front or rear pillar, roof side rail, and
assist grip. (Except for the speed limit
sticker P. 614)

501-1. For safe use
CT200h_OM_OM76102E_(EE)
WA R N I N G
SRS airbag precautions
If breathing becomes difficult after the SRS airbags have deployed, open a
door or window to allow fresh air in, or leave the vehicle if it is safe to do so.
Wash off any residue as soon as possible to prevent skin irritation.
If the areas where the SRS airbags are stored, such as the steering wheel pad
and front and rear pillar garnishes, are damaged or cracked, have them
replaced by any authorized Lexus dealer or repairer, or another duly qualified
and equipped professional.
Modification and disposal of SRS airbag system components
Do not dispose of your vehicle or perform any of the following modifications
without consulting any authorized Lexus dealer or repairer, or another duly
qualified and equipped professional. The SRS airbags may malfunction or
deploy (inflate) accidentally, causing death or serious injury.
Installation, removal, disassembly and repair of the SRS airbags
Repairs, modifications, removal or replacement of the steering wheel, instru-
ment panel, dashboard, seats or seat upholstery, front, side and rear pillars or
roof side rails
Repairs or modifications of the front fender, front bumper, or side of the occu-
pant compartment
Installation of a grille guard (bull bars, kangaroo bar, etc.), snow plows or
winches
Modifications to the vehicle’s suspension system
Installation of electronic devices such as mobile two-way radios (RF-trans-
mitter) and CD players
Modifications to your vehicle for a person with a physical disability
