Lexus IS F 2011 Owner's Manual

458
5-2. Steps to take in an emergency
IS F_EE
If the electronic key does not operate properly
Locking and unlocking the doors, unlocking the trunk and key linked func-
tions
Use the mechanical key built in to the electronic keys to operate
the doors. (P. 33)
An alarm will sound if the alarm is set. ( P. 9 7 )
Doors
Remove the cover on the
driver’s door handle.
Locks all doors
Closes the windows/moon
roof (turn and hold)
Unlocks all doors
Opens the windows/moon
roof (turn and hold)
If communication between the electronic key and vehicle is inter-
rupted (P. 41) or the electronic key cannot be used because the bat-
tery is depleted, the smart entry & start system and wireless remote
control cannot be used. In such cases, the doors and trunk can be
opened or the engine can be started by following the procedure below.
STEP1
STEP2

5
459
5-2. Steps to take in an emergency
When trouble arises
IS F_EEAfter the operation is com-
pleted, reinstall the cover.
Hook the upper claw of the
cover onto the upper catch on
the vehicle side, and then push
on the lower side of the cover.
Make sure that the lower claw
of the cover is securely fastened
to the lower catch on the vehicle
side. If the cover is not securely
attached, it may fall off while
driving.
Trunk
Turn the mechanical key clock-
wise to open.
STEP3

460
5-2. Steps to take in an emergency
IS F_EE
Changing “ENGINE START STOP” switch modes and starting the
engine
Shift the shift lever to P and apply the brakes.
Touch the Lexus emblem side
of the electronic key to the
“ENGINE START STOP”
switch.
An alarm will sound to indicate
that the start function cannot
detect the electronic key that is
touched to the “ENGINE
START STOP” switch if any of
the doors is opened and closed
while the key is touched to the
switch.
STEP1
STEP2

5
461
5-2. Steps to take in an emergency
When trouble arises
IS F_EETo change “ENGINE START STOP” switch modes: Within
10 seconds of the buzzer sounding, release the brake pedal
and press the “ENGINE START STOP” switch. Modes can
be changed each time the switch is pressed. (P. 147)
To start the engine: Press the “ENGINE START STOP”
switch within 10 seconds after the buzzer sounds, keeping
the brake pedal depressed.
In the event that the engine still cannot be started, contact any
authorized Lexus dealer or repairer, or another duly qualified and
equipped professional.
Stopping the engine
Shift the shift lever to P and press the “ENGINE START STOP” switch as
you normally do when stopping the engine.
Replacing the key battery
As the above procedure is a temporary measure, it is recommended that the
electronic key battery be replaced immediately when the battery depletes.
(P. 390)
Alarm
Using the mechanical key to lock the doors will not set the alarm system.
If a door is unlocked using the mechanical key when the alarm system is set,
the alarm may be triggered.
STEP3

462
5-2. Steps to take in an emergency
IS F_EE
If the vehicle battery is discharged
The following procedures may be used to start the engine if the vehi-
cle's battery is discharged.
You can call any authorized Lexus dealer or repairer, or another duly
qualified and equipped professional.
If you have a set of jumper (or booster) cables and a second
vehicle with a 12-volt battery, you can jump start your Lexus
following the steps below.
Connecting the jumper cables.
Remove the engine cover.
Positive (+) battery terminal on your vehicle
Positive (+) battery terminal on the second vehicle
Negative (-) battery terminal on the second vehicle
Connect the jumper cable to ground on your vehicle as shown
in the illustration. (The illustration depicts a left-hand drive
vehicle. For right-hand drive vehicles, connect the jumper
cable to the metal base fitting of the engine cover pin by the
side of the engine oil filler cap.)
STEP1

5
463
5-2. Steps to take in an emergency
When trouble arises
IS F_EE
Starting the engine when the battery is discharged
The engine cannot be started by push-starting.
To prevent battery discharge
Turn off the headlights and the audio system while the engine is off.
Turn off any unnecessary electrical components when the vehicle is run-
ning at a low speed for an extended period, such as in heavy traffic, etc.
Charging the battery
The electricity stored in the battery will discharge gradually even when
the vehicle is not in use, due to natural discharge and the draining effects
of certain electrical appliances. If the vehicle is left for a long time, the
battery may discharge, and the engine may be unable to start. (The bat-
tery recharges automatically during driving.)
Start the engine of the second vehicle. Increase the
engine speed slightly and maintain at that level for
approximately 5 minutes to recharge the battery of your
vehicle.
Open and close any of the doors with the “ENGINE
START STOP” switch OFF.
Maintain the engine speed of the second vehicle and turn
the “ENGINE START STOP” switch to IGNITION ON
mode, then start the vehicle's engine.
Once the vehicle’s engine has started, remove the jumper
cables in the exact reverse order in which they were con-
nected.
Once the engine starts, have the vehicle checked at any autho-
rized Lexus dealer or repairer, or another duly qualified and
id fil iblSTEP2
STEP3
STEP4
STEP5

464
5-2. Steps to take in an emergency
IS F_EE
CAUTION
Avoiding battery fires or explosions
Observe the following precautions to prevent accidentally igniting the flam-
mable gas that may be emitted from the battery.
Make sure the jumper cable is connected to the correct terminal and that it
is not unintentionally in contact with any part other than the intended ter-
minal.
Do not allow the jumper cables to come into contact with the “+” and “-”
terminals.
Do not allow open flame or use matches, cigarette lighters or smoke near
the battery.
Battery precautions
The battery contains poisonous and corrosive acidic electrolyte, while
related parts contain lead and lead compounds. Observe the following pre-
cautions when handling the battery.
When working with the battery, always wear safety glasses and take care
not to allow any battery fluids (acid) to come into contact with skin, cloth-
ing or the vehicle body.
Do not lean over the battery.
In the event that battery fluid comes into contact with the skin or eyes,
immediately wash the affected area with water and seek medical attention.
Place a wet sponge or cloth over the affected area until medical attention
can be received.
Always wash your hands after handling the battery support, terminals, and
other battery-related parts.
Do not allow children near the battery.
NOTICE
When handling jumper cables
Be careful that the jumper cables do not become tangled in the cooling fan
or any of the belts when connecting or disconnecting them.

5
465
5-2. Steps to take in an emergency
When trouble arises
IS F_EE
If your vehicle overheats
If your engine overheats:
Stop the vehicle in a safe place and turn off the automatic
air conditioning system.
Check to see if steam is coming out from under the hood.
If you see steam:
Stop the engine. Carefully lift the hood after the steam
subsides and then restart the engine.
If you do not see steam:
Leave the engine running and carefully lift the hood.
Check to see if the cooling fans are operating.
If the fans are operating:
Wait until the temperature of the engine (shown on the
instrument cluster) begins to fall and then stop the
engine.
If the fans are not operating:
Stop the engine immediately and call any authorized
Lexus dealer or repairer, or another duly qualified and
equipped professional.
After the engine has cooled
down sufficiently, check the
engine coolant level and
inspect the radiator core
(radiator) for any leaks.
If the engine compartment
cover needs to be removed:
STEP1
STEP2
STEP3
STEP4

466
5-2. Steps to take in an emergency
IS F_EE
Overheating
If you observe the following, your vehicle may be overheating.
The display on the engine coolant temperature gauge flashes or a loss of
power is experienced.
Steam is coming from under the hood.
CAUTION
To prevent an accident or injury when inspecting under the hood of your
vehicle
If steam is seen coming from under the hood, do not open the hood until
the steam has subsided. The engine compartment may be very hot, caus-
ing serious injury such as burns.
Keep hands and clothing away from the fans and belt while the engine is
running.
Do not loosen the coolant reservoir cap while the engine and radiator are
hot.
Serious injury, such as burns, may result from hot coolant and steam
released under pressure.
Add engine coolant if neces-
sary.
Water can be used in an
emergency if engine coolant
is unavailable.
(P. 4 7 7)
Have the vehicle checked at the nearest authorized Lexus dealer
or repairer, or another duly qualified and equipped professional,
as soon as possible.
STEP5

5
467
5-2. Steps to take in an emergency
When trouble arises
IS F_EE
NOTICE
When adding engine coolant
Wait until the engine has cooled down before adding engine coolant.
When adding coolant, do so slowly. Adding cool coolant to a hot engine too
quickly can cause damage to the engine.
