lexus LC500h 2018 / LEXUS 2018 LC500, LC500H QUICK GUIDE (OM11444U) Owner's Guide
Manufacturer: LEXUS, Model Year: 2018, Model line: LC500h, Model: Lexus LC500h 2018Pages: 110, PDF Size: 2.04 MB
Page 31 of 110
31
LC500_LC500h_QG_OM11444U_(U)
1Right turn
2Lane change to the right (move the
lever partway and release it)
The right hand signal s will flash 3 times.
3Lane change to the left (move the lever
partway and release it)
The left hand signals will flash 3 times.
4Left turn
If the turn signals do not stop flashing after
turning left or right, or if you want to stop
them flashing, operate the lever in the
opposite direction to either position
2 or 3.
If you move the lever to either position
1 or
4, the selected turn signals will flash.
Turn Signal Lever
The lever will return to its original position immediately after operation.
Page 32 of 110
32
LC500_LC500h_QG_OM11444U_(U)
The parking brake can be set and released manually.U.S.A.
Canada
1Push the switch to set the parking
brake
The parking brake indicator light will
turn on.
Press and hold the parking brake
switch if an emerge ncy occurs and it is
necessary to operate the parking
brake while driving.
2Pull the switch to release the parking
brake
• Operate the parking brake switch while depressing the brake pedal.
• Using the parking brake automatic release function, the parking brake
can be released by depressing the
accelerator pedal. When using this
function, slowly depress the acceler-
ator pedal.
Make sure that the parking brake indi-
cator light turn off.
Parking Brake
The parking brake can be set or released automatically or manually.
Using the manual mode
A
B
Page 33 of 110
33
LC500_LC500h_QG_OM11444U_(U)
In automatic mode, the parking brake can be set or released automatically according to shift
lever operation. Also, even in automatic mode, the parking brake can be set or released
manually.
While the vehicle is stopped, press and hold
the parking brake switch until a message is
shown on the multi-information display
When the automatic mode is turned on, the
parking brake operates as follows.
●When the shift position is shifted from P,
the parking brake will be released, and
the parking brake indicator light turn off.
● When the shift position is shifted to P, the
parking brake will be set, and the park-
ing brake indicator light turn on.
Operate the shift lever and P position switch with the vehicle stopped and the brake pedal
depressed.
While the vehicle is stopped, pull and hold
the parking brake switch until a message is
shown on the multi-information display
Turns automatic mode on
Turns automatic mode off
Page 34 of 110
34
LC500_LC500h_QG_OM11444U_(U)
Press the brake hold switch to turn the sys-
tem on
The brake hold standby indicator comes
on. While the system is holding the brake,
the brake hold operated indicator
comes on.
Brake Hold
The brake hold system keeps the brake applied when the shift position is in D, M or N with
the system on and the brake pedal has been depressed to stop the vehicle. The system
releases the brake when the accelerator pedal is depressed with the shift position in D or
M to allow smooth start off.
A
B
Page 35 of 110
35
LC500_LC500h_QG_OM11444U_(U)
When the main meter is in the center position
Displays various drive information on the main meter.
Some of the contents which are displayed when th e main meter is in the side position cannot
be displayed.
When the main meter is in the side position
Selecting a menu icon displays a variety of
vehicle data or allows vehicle settings to be
customized.
/: Switch menu
/ : Change displayed content,
scroll up/down the screen and move
the cursor up/down
Press: Enter/Set
Press and hold: Reset
Return to the previous screen and
move the main meter
Multi-information Display
The multi-information display presents the driver with a variety of vehicle data.
Display
Changing the meter display
A
B
C
Page 36 of 110
36
LC500_LC500h_QG_OM11444U_(U)
Menu icons
Drive information
Select to display various drive data.
Navigation system-linked display
Select to display the following na vigation system-linked information.
•Route guidance
• Compass display (north-up display/heading-up display)
Audio system-linked display
Select to enable selection of an audio source or track on the meter using the
meter control switches.
Driving assist system information
Select to display the dynamic radar crui se control with full-speed range/LKA
(Lane-Keeping Assist) information, when the system is used. ( →P.45, 46)
Warning message display
Select to display warning messages and measures to be taken if a malfunction is
detected.
Settings display
Select to change the meter display settings
If a problem is detected in any of the vehicle’s systems, a warning message is shown on the
multi-information display.
Page 37 of 110
37
LC500_LC500h_QG_OM11444U_(U)
Navigation system-linked display area
Driving assist system status display
area
Vehicle speed display
Information display area
HUD (Head-up display) switch
(→ P.37)
■Enabling/Disabling the head-up display
Pressing the switch turns the head-up dis-
play on/off.
Head-up Display (if equipped)
The head-up display is linked to the meters an d navigation system and projects a variety of
information in front of the dr iver, such as the current vehicle speed and route guidance to
a set destination.
System components
A
B
C
D
E
Using the head-up display
Page 38 of 110
38
LC500_LC500h_QG_OM11444U_(U)
■Changing settings of the head-up display
Select on the multi-information display to change the following settings:
●Display brightness/position
Select to adjust the brightness and position of the head-up display.
● Eco Driving Indicator/tachometer (LC500)
Select to display Eco Driving Indi cator, tachometer or no content.
● Hybrid System Indicator/motor po wer display/tachometer (LC500h)
Select to display Hybrid System In dicator, tachometer or no content.
Motor power display can be displayed when Hybrid System Indicator is selected while
the driving mode ( →P.52) is other than the eco drive mode.
● Display content
Select to enable/disab le the following items:
• Route guidance to destination
• Driving assist system status
•Compass
• Audio system operation status
● Display angle
Select to adjust the angle of the head-up display.
■Eco Driving Indicator
Eco Driving Indicator Zone Display
Eco driving ratio based on accelera-
tion
Zone of Eco driving
Displayed content is the same as that
displayed on the multi-information dis-
play (Eco Driving Indicator).
■Tachometer
Displays the engine speed in revolutions per minute.
Eco Driving Indicator/tachometer (LC500)
A
B
C
Page 39 of 110
39
LC500_LC500h_QG_OM11444U_(U)
■Hybrid System Indicator
Charge area
Hybrid Eco area
Eco area
Power area
Displayed content is the same as that
displayed on the meter (Hybrid System
Indicator). For deta ils, refer to P.14.
■Motor power display
Charge area
Power area
Displayed content is the same as that
displayed on the meter (Motor power
display). For details , refer to P.15.
■Tachometer
Displays the engine speed in revolutions per minute.
Hybrid System Indicator/motor po wer display/tachometer (LC500h)
A
B
C
D
A
B
The head-up display may seem dark and hard to see when viewed through sunglasses,
especially polar ized sunglasses.
Adjust the brightness of the head-up display or remove your sunglasses.
Page 40 of 110
40
LC500_LC500h_QG_OM11444U_(U)
U.S.A.
Canada
1 The side marker, parking, tail,
license plate and instrument panel
lights, and daytime running lights turn
on.
2 The headlights an d all the lights
listed above (except daytime running
lights) turn on.
3 The headlights, daytime running
lights and all the lig hts listed above turn
on and off automatically.
4 (U.S.A.) Off
(Canada) The daytime running
lights turn on.
1With the headlights on, push the lever
away from you to turn on the high
beams.
Pull the lever toward you to the center
position to turn the high beams off.
2Pull the lever toward you and release it
to flash the high beams once.
You can flash the high beams with the
headlights on or off.
Headlights
A
B
Turning on the high beam headlights
