LEXUS LS430 2003 Factory Repair Manual

ENGINE ROOM JUNCTION & RELAY BLOCK
Fig. 1: Locating Engine Room Fusible Link, Junction & Relay Blocks

Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

Fig. 2: Identifying Engine Room No. 1 Junction & Relay Block Components
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
Engine Room No. 1 Junction & Relay Block Fuses
FuseSystem
7.5AA/C IGAutomatic Air Conditioning (Front)
7.5AEFI NO.2Engine Control
7.5AFR IGABS
Automatic Air Conditioning (Front)
Back-Up Light
Charging
Clock (w/ LEXUS Navigation System)
Cruise Control
Door Closer (w/ Smart Key System)
Door Closer (w/o Smart Key System)
Door Lock Control (w/ Smart Key System)
Door Lock Control (w/o Smart Key System)

Dynamic Radar/Laser Cruise Control System
Electronically Controlled Transmission and A/T Indicator
Headlight Cleaner
Key Reminder (w/ Smart Key System)
LEXUS Navigation System
LEXUS Parking Assist (Clearance Sonar)
LEXUS Parking Assist (Rear View Monitor)
Power Seat (Rear Passenger's Seat)
Pre-Collision Safety System
Radiator Fan
Rear Window Defogger
Remote Control Mirror
Smart Key System
Theft Deterrent (w/ Smart Key System)
VSC and Tire Pressure Warning System
Wiper and Washer
Wireless Door Lock Control (w/ Smart Key System)
7.5AIGNCruise Control
Dynamic Radar/Laser Cruise Control System
Electronically Controlled Transmission and A/T Indicator
Engine Control
7.5ASTAElectronically Controlled Transmission and A/T Indicator
Engine Control
Starting and Ignition
7.5ATAILAutomatic Light Control
Door Closer (w/ Smart Key System)
Door Lock Control (w/ Smart Key System)
Key Reminder (w/ Smart Key System)
Light Auto Turn Off System
Multiplex Communication System (BEAN - Steering Column Bus)
Smart Key System
Taillight
Theft Deterrent (w/ Smart Key System)
Theft Deterrent (w/o Smart Key System)
Wireless Door Lock Control (w/ Smart Key System)
10AETCSCruise Control
Dynamic Radar/Laser Cruise Control System
Electronically Controlled Transmission and A/T Indicator
Engine Control
10AHORNDoor Closer (w/ Smart Key System)
Door Lock Control (w/ Smart Key System)
Horn
Key Reminder (w/ Smart Key System)
Multiplex Communication System (BEAN - Steering Column Bus)
Smart Key System
Theft Deterrent (w/ Smart Key System)
Theft Deterrent (w/o Smart Key System)

FUSIBLE LINK BLOCK
Wireless Door Lock Control (w/ Smart Key System)
10AINJEngine Control
Starting and Ignition
15AFR FOGFront Fog Light
Multiplex Communication System (BEAN - Steering Column Bus)
15AH-LP L LWRHeadlight
Multiplex Communication System (BEAN - Steering Column Bus)
15AH-LP R LWRHeadlight
Multiplex Communication System (BEAN - Steering Column Bus)
20AH-LP HIHeadlight
Multiplex Communication System (BEAN - Steering Column Bus)
20AWASHERMultiplex Communication System (BEAN - Steering Column Bus)
Wiper and Washer
25AEFI NO.1Cruise Control
Dynamic Radar/Laser Cruise Control System
Electronically Controlled Transmission and A/T Indicator
Engine Control
30AH-LP CLNHeadlight Cleaner
30AWIPMultiplex Communication System (BEAN - Steering Column Bus)
Wiper and Washer

Fig. 3: Identifying Fusible Link Block Components
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
Fusible Link Block Fuses
FuseSystem
5AALT-SCharging
30AABS 1Dynamic Radar/Laser Cruise Control System
Tire Pressure Warning System
TRAC
VSC
30ABATTEngine Control
Engine Immobilizer System (w/o Smart Key System)
SRS
Starting and Ignition
30ASTElectronically Controlled Transmission and A/T Indicator
Engine Control
Starting and Ignition
40AAIRBUSElectronic Modulated Air Suspension
40ADEFOGRear Window Defogger
50AABS 2ABS
Dynamic Radar/Laser Cruise Control System
Tire Pressure Warning System
TRAC
VSC
50AFANRadiator Fan
50AHEATERAutomatic Air Conditioning (Front)
60ALUG J/BAudio System
Automatic Light Control
Back-Up Light
Climate Control Seat (Rear)
Clock (w/ LEXUS Navigation System)
Door Closer (w/ Smart Key System)
Door Lock Control (w/ Smart Key System)
Dynamic Radar/Laser Cruise Control System
Interior Light
Key Reminder (w/ Smart Key System)
LEXUS Navigation System
LEXUS Parking Assist (Clearance Sonar)
LEXUS Parking Assist (Clearance Sonar)
Light Auto Turn Off System
Multiplex Communication System (BEAN - Steering Column Bus)
Pre-Collision Safety System
Rear Air Conditioning
Smart Key System
Stop Light
Taillight

DRIVER SIDE JUNCTION BLOCK
Fig. 4: Locating Instrument Panel Junction & Relay Blocks

Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
Theft Deterrent (w/ Smart Key System)
Wireless Door Lock Control (w/ Smart Key System)
140AALTABS
Charging
Multiplex Communication System (BEAN - Steering Column Bus)
Tire Pressure Warning System
TRAC
VSC

Fig. 5: Identifying Driver Side Junction Block Components (Fuses)
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.

Fig. 6: Identifying Driver Side Junction Block Components (Relays)
Courtesy of TOYOTA MOTOR SALES, U.S.A., INC.
Driver Side Junction Block Fuses
FuseSystem

5AD B/ANCMultiplex Communication System (BEAN - Steering Column Bus)
Power Shoulder Belt Anchorage
5ASTOPABS
Cruise Control
Dynamic Radar/Laser Cruise Control System
Electronic Modulated Air Suspension
Electronically Controlled Transmission and A/T Indicator
Engine Control
Multiplex Communication System (BEAN - Steering Column Bus)
Power Seat (Rear Passenger's Seat)
Shift Lock
Stop Light
Tire Pressure Warning System
TRAC
VSC
Wiper and Washer
7.5AABS-IGABS
Adaptive Front-Lighting System
Dynamic Radar/Laser Cruise Control System
Electronic Modulated Air Suspension
PPS
Pre-Collision Safety System
Tire Pressure Warning System
TRAC
VSC
7.5AA/CAutomatic Air Conditioning (Front)
Rear Air Conditioning
7.5AAM1Multiplex Communication System (BEAN - Instrument Panel Bus)
Multiplex Communication System (BEAN - Steering Column Bus)
7.5AD-ACCDoor Lock Control and Door Closer (w/ Smart Key System)
Door Lock Control and Door Closer (w/o Smart Key System)
Key Reminder (w/ Smart Key System)
Multiplex Communication System (BEAN - Door Bus)
Multiplex Communication System (BEAN Bus)
Power Window
Remote Control Mirror
Shift Lock
Smart Key System
Theft Deterrent (w/ Smart Key System)
Theft Deterrent (w/o Smart Key System)
Wireless Door Lock Control (w/ Smart Key System)
Wireless Door Lock Control (w/o Smart Key System)
7.5AGAUGEABS
Adaptive Front-Lighting System
Audio System
Automatic Air Conditioning (Front)
Charging
